Senix PDDX2-M2 User manual

EnglishWWW.SENIXTOOLS.COM
CORDLESS 1/2" DRILL/DRIVER
• SAFETY
• ASSEMBLY
• OPERATION
• MAINTENANCE
• WARRANTY
CAUTION: Before using this tool, please read this manual completely,
and follow all operating safety measures.
Instruction Manual
YAT USA INC. 10506 Bryton Corporate Center Dr, #500 Huntersville, NC 28078
For customer support, please call 1-800-261-3981 or email us at [e-mail]
Model: PDDX2-M2

EN - 2 WWW.SENIXTOOLS.COM
TABLE OF CONTENTS
SAFETY & INTERNATIONAL SYMBOLS..............2
SAFETY INSTRUCTIONS.........................................3
KNOW YOUR UNIT.....................................................7
SPECIFICATIONS*.....................................................8
ASSEMBLY...................................................................8
OPERATION................................................................10
MAINTENANCE.........................................................13
TROUBLESHOOTING..............................................15
WARRANTY................................................................16
SAFETY &
INTERNATIONAL
SYMBOLS
Explanation of Safety & international symbols
describes safety and international symbols
and pictographs that may appear on this
product. Read the operator’s manual for
complete safety, assembly, operating and
maintenance and repair information.
Caution / Warning.
To reduce the risk of injury, user
must read instruction manual.
Wear eye protection.
Wear a dust mask.
Wear safety footwear.
Wear protective gloves.
Do not dispose of battery packs in
rivers or immerse in water.
Do not dispose of battery packs in
fire. They will explode and cause
injury.
Use the battery in a maximum tem-
perature of 122°F (50°C).
Max 122°F
Do not disassemble, crush, heat
above 212°F (100°C); Never expose
the battery to microwaves or high
pressures.
Keep bystanders a safe distance
away from the work area.
Indoor use only. Only use battery
charger indoors.

3 - EN
WWW.SENIXTOOLS.COM
SAFETY INSTRUCTIONS
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING!
Read all safety warnings, instructions,
illustrations and specifications, provided with
this power tool. Failure to follow all instructions
listed below may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers
to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1. Work Area Safety
a. Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
b. Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the
dust or fumes.
c. Keep children and bystanders away while
operating a power tool. Distractions can
cause you to lose control.
2. Electrical Safety
a. Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
3. Personal Safety
d. Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication. A moment of inattention while
operating power tools may result in serious
personal injury.
e. Use personal protective equipment. Always
wear eye protection. Protective equipment
such as a dust mask, non-skid safety shoes,
hard hat or hearing protection used for
appropriate conditions will reduce personal
injuries.
f. Prevent unintentional starting. Ensure
the switch is in the off position before
connecting to power source and/or battery
pack, picking up or carrying the tool. Carrying
power tools with your finger on the switch or
energising power tools that have the switch
on invites accidents.
g. Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key
left attached to a rotating part of the power
tool may result in personal injury.
h. Do not overreach. Keep proper footing and
balance at all times. This enables better
control of the power tool in unexpected
situations.
i. Dress properly. Do not wear loose clothing
or jewelry. Keep your hair and clothing away
from moving parts. Loose clothes, jewelry or
long hair can be caught in moving parts.
j. If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce
dust-related hazards.
k. Do not let familiarity gained from frequent
use of tools allow you to become complacent
and ignore tool safety principles. A careless
action can cause severe injury within a
fraction of a second.
4. Power Tool Use And Care
a. Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at
the rate for which it was designed.
b. Do not use the power tool if the switch
does not turn it on and off. Any power tool
that cannot be controlled with the switch is
dangerous and must be repaired.
c. Disconnect the plug from the power
source and/or remove the battery pack,
if detachable, from the power tool before
making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk
of starting the power tool accidentally.
d. Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions
to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e. Maintain power tools and accessories.
Check for misalignment or binding of moving
parts, breakage of parts and any other
condition that may affect the power tool’s
operation. If damaged, have the power tool
repaired before use. Many accidents are
caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier
to control.
g. Use the power tool, accessories and tool bits

EN - 4 WWW.SENIXTOOLS.COM
b. Never service damaged battery packs.
Service of battery packs should only
be performed by the manufacturer or
authorized service providers.
SAFETY WARNINGS FOR
DRILL
1. Safety Instructions For All Operations
a. Hold the power tool by insulated gripping
surfaces, when performing an operation
where the cutting accessory or fasteners
may contact hidden wiring. Cutting
accessory or fasteners contacting a "live"
wire may make exposed metal parts of
the power tool "live" and could give the
operator an electric shock.
2. Safety Instructions When Using Long Drill
Bits
a. Never operate at higher speed than the
maximum speed rating of the drill bit. At
higher speeds, the bit is likely to bend if
allowed to rotate freely without contacting
the workpiece, resulting in personal injury.
b. Always start drilling at low speed and with
the bit tip in contact with the workpiece.
At higher speeds, the bit is likely to bend if
allowed to rotate freely without contacting
the workpiece, resulting in personal injury.
c. Apply pressure only in direct line with the
bit and do not apply excessive pressure.
Bits can bend causing breakage or loss of
control, resulting in personal injury.
3. Dust/Chip Extraction
Dust from materials such as lead-containing
coatings, some wood types, minerals
and metal can be harmful to one’s health.
Touching or breathing-in the dust can cause
allergic reactions and/ or lead to respiratory
infections of the user or bystanders.Certain
dust, such as oak or beech dust, is considered
carcinogenic,especially in connection with
wood-treatment additives (chromate, wood
preservative). Materials containing asbestos
may only be worked by specialists.
a. Provide for good ventilation of the working
place.
b. It is recommended to wear a P2 filter-class
respirator.
c. Observe the relevant regulations in your
country for the materials to be worked.
d. Avoid dust accumulation at the workplace.
Dust can easily ignite.
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the
power tool for operations different from
those intended could result in a hazardous
situation.
h. Keep handles and grasping surfaces dry,
clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow
for safe handling and control of the tool in
unexpected situations.
5. Battery Tool Use And Care
a. Recharge only with the charger specified by
the manufacturer. A charger that is suitable
for one type of battery pack may create a risk
of fire when used with another battery pack.
b. Use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury and
fire.
c. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small
metal objects, that can make a connection
from one terminal to another. Shorting the
battery terminals together may cause burns
or a fire.
d. Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water.
If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery
may cause irritation or burns.
e. Do not use a battery pack or tool that
is damaged or modified. Damaged or
modified batteries may exhibit unpredictable
behaviour resulting in fire, explosion or risk
of injury.
f. Do not expose a battery pack or tool to fire
or excessive temperature. Exposure to fire
or temperature above 266°F(130 °C) may
cause explosion.
g. Follow all charging instructions and do not
charge the battery pack or tool outside
the temperature range specified in the
instructions. Charging improperly or at
temperatures outside the specified range
may damage the battery and increase the
risk of fire.
6. Service
a. Have your power tool serviced by a
qualified repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.

5 - EN
WWW.SENIXTOOLS.COM
ADDITIONAL SAFETY
INFORMATION FOR DRILL
a. Secure the workpiece. A workpiece
clamped with clamping devices or in a vice
is held more securely than by hand.
b. Always wait until the power tool has come
to a complete stop before placing it down.
The application tool can jam and cause you
to lose control of the power tool.
c. Switch the power tool off immediately if
the application tool becomes blocked.
Be prepared for high torque reactions
which cause kickback. The application
tool becomes blocked when it becomes
jammed in the workpiece or when the
power tool becomes overloaded.
d. Use suitable detectors to determine if
there are hidden supply lines or contact
the local utility company for assistance.
Contact with electric cables can cause fire
and electric shock. Damaging gas lines can
lead to explosion. Breaking water pipes
causes property damage.
e. Hold the power tool securely. When
tightening and loosening screws be
prepared for temporarily high torque
reactions.
f. In case of damage and improper use of
the battery, vapours may be emitted. The
battery can set alight or explode. Ensure
the area is well ventilated and seek medical
attention should you experience any
adverse effects. The vapours may irritate
the respiratory system.
g. Do not open the battery. There is a risk of
short-circuiting.
h. The battery can be damaged by pointed
objects such as nails or screwdrivers or by
force applied externally. An internal short
circuit may occur, causing the battery to
burn, smoke, explode or overheat.
i. Only use the battery with products from
the manufacturer. This is the only way in
which you can protect the battery against
dangerous overload.
SAFETY WARNING FOR
BATTERY PACK AND
BATTERY CHARGER
• Recharge only with the charger specified
by the manufacturer. A charger that is
suitable for one type of battery pack may
create a risk of fire when used with another
battery pack.
• Use appliances only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury
and fire.
WARNING!
Use only with SENIX X2 batteries: B20X2 /
B25X2 / B40X2 / B50X2.
• When battery pack is not in use, keep it
away from other metal objects, like paper
clips, coins, keys, nails, screws or other
small metal objects, that can make a
connection from one terminal to another.
Shorting the battery terminals together
may cause burns or a fire.
• Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from
the battery may cause irritation or burns.
(This advice is considered correct for
conventional NiMh, NiCd, lead acid and
lithium-ion cell types. If this advice is
incorrect for a cell design that differs from
these, then the correct advice may be
substituted.)
• Do not use a battery pack or appliance
that is damaged or modified. Damaged
or modified batteries may exhibit
unpredictable behavior resulting in fire,
explosion or risk of injury.
• Do not expose a battery pack or appliance
to fire or excessive temperature. Exposure
to fire or temperature above 266°F(130°C)
may cause explosion.
• Follow all charging instructions and do
not charge the battery pack or appliance
outside of the temperature range specified
in the instructions. Charging improperly or
at temperatures outside of the specified
range may damage the battery and
increase the risk of fire.
• Do not modify or attempt to repair
the appliance or the battery pack (as
applicable) except as indicated in the
instructions for use and care.
VIBRATION + NOISE
REDUCTION

EN - 6 WWW.SENIXTOOLS.COM
To reduce the impact of noise and vibration
emission, limit the time of operation, use low-
vibration and low-noise operating modes as
well as wear personal protective equipment.
Take the following points into account to
minimise the vibration and noise exposure
risks.
• Only use the product as intended by its
design and these instructions.
• Ensure that the product is in good condition
and well maintained.
• Use correct attachments for the product
and ensure they are in good condition.
• Keep tight grip on the handles/grip surface.
• Maintain this product in accordance
with these instructions and keep it well
lubricated (where appropriate).
• Plan your work schedule to spread any high
vibration tool use across a longer period of
time.
EMERGENCY
Familiarize yourself with the use of this
product by means of this instruction manual.
Memorize the safety directions and follow
them to the letter. This will help to prevent
risks and hazards.
• Always be alert when using this product,
so that you can recognize and handle risks
early. Fast intervention can prevent serious
injury and damage to property.
• Switch off the product and remove the
battery pack if there are malfunctions.
Have the product checked by a qualified
professional and repaired, if necessary,
before you operate it again.
INTENDED USE
This 18V cordless drilll is intended for drilling
in wood and metal materials with drill bits
and driving screws into wood and drywall
with scewdriver bits. Do not use it for other
purposes.

7 - EN
WWW.SENIXTOOLS.COM
KNOW YOUR UNIT
1
2
3
4
6
7
8
9
10
11
APPLICATIONS
Model: PDDX2-M2
As a cordless drill driver:
Drilling in all types of wood, metal products
with drill bits;
Driving screws into wood,metal with
screwdriver bits.
1 Speed Selector
2 Torque Ring
3 Chuck
4 Jaw
5 Variable Speed Trigger
6 Work Light
7 Release Button
8 Battery Pack
9 Belt Clip
10 Handle
11 Direction Selector

EN - 8 WWW.SENIXTOOLS.COM
SPECIFICATIONS*
Model PDDX2-M2
Input Voltage 9Š90D[
Max Torque 540 in-lbs
No load speed (RPM) 0-600 / 0-2000
RPM
Chuck Size 1/2 "
Chuck Type 1/2 " Keyless,
Ratcheting Chuck
Drilling Capacity
Steel: 1/2"
Wood: 1-1/2"
Metal: 1/2"
Weight 2.65 lbs
Battery model B20X2
Rated voltage 9Š90D[
Rated capacity 2.0 Ah
Weight 0.89 lbs
Charger model CHX2
Rated input 100 V - 240 V
~ 50 Hz / 60 Hz
Rated output 21 V, 2 A
Charging time
(with 2.0 Ah battery) 65 min
Protection class
(for charger) / II
Weight 0.75 lbs
*20V Max battery, maximum initial battery
voltage (measured without a workload) is 20V.
The nominal voltage is 18V.
ASSEMBLY
1. Unpack all parts and lay them on a flat,
stable surface:
2. Remove all packing materials and shipping
devices, if applicable.
3. The scope of delivery varies depending on
the country and purchased variant:
Model of PDDX2-M2
• Drill/Driver x1
• Battery Pack x1
• Charger x1
• Storage bag x1
• Belt clip x1
• Instruction manual x1
4. If you find that parts are missing or show
damage do not use the product but contact
your dealer. Using an incomplete or
damaged product represents a hazard to
people and property.
5. Ensure that you have all the accessories
and tools needed for assembly and
operation. This also includes suitable
personal protective equipment.
WARNING:
Wear protective gloves for this as-
sembly work and always lay the
product on a flat and stable surface
while assembling. Follow the as-
sembly instructions step-by-step
and use the pictures provided as a
visual guide to easily assemble the
product! Do not insert the battery
pack before the power tool is com-
pletely assembled or adjusted!

9 - EN
WWW.SENIXTOOLS.COM
BELT CLIP
Fix the belt clip to either side of tool by screw.
Make sure the belt clip is firmly installed so
that it can support the weight of the tool.
BIT
WARNING:
Observe the technical requirements of this
product (see section “SPECIFICATIONS”) when
purchasing and using bit. Always use special
bits according to the work to be performed.
The chuck and the bit can be very hot after
working, do not assemble/disassemble them
before cooling down.
To install:
Turn the chuck clockwise to open the jaw.
Align and insert the bit as far as into the jaw.
Then turn the chuck counterclockwise so that
the jaw bites the bit fixedly.
To remove:
Turn the chuck counterclockwise to open the
jaw and pull the bit out of the jaw.
NOTE:
Make sure the bit is fixed firmly and will never
comes out before use.
BATTERY PACK
NOTE:
Prior to installation, lock the switch trigger by
trigger lock to avoid unintentional start.
To install:
Align and slide the battery pack to the docking
port until it is locked in place.
To remove:
Press the unlock button on battery pack and
slide the battery pack out.
OPERATION

EN - 10 WWW.SENIXTOOLS.COM
OPERATION
WARNING:
Always wear eye, hearing, hand protection to
reduce the risk of injury when operating the
tool. Keep all parts of your body away from the
rotating bit.
RUNNING DIRECTION
The motor runs forward or backward for
driving the bit in or out. It is controlled by the
reversing lever.
WARNING:
Do not change direction of rotation while
chuck is rotating.
Forward Backward
Mode Application
Forward Driving screws or drill bits
Backward Loosening jammed screws or drill
bits
Center
Lock Locking the trigger
NOTE:
When changing bits or when the tool is not in
use, the reversing lever shall be kept in “center
lock" position to avoid unintended start.
TORQUE
1. 17 torque values are designed for screw
driving.Rotating the torque ring until the
arrow points at the desired value. The
screw will be automatically stopped once
the pre-set torque reached.
NOTE:
The torque required depends on the type and
size of the fastener being driven, as well as the
material of workpiece.
2. "" on the torque ring is designed for
drilling into wood or metal materials. The
motor will continue to output until it pene-
trates workpiece.

11 - EN
WWW.SENIXTOOLS.COM
SPEED
Mode SettingeMax Speed
Low 1 0-600 RPM
High 2 0-2,000 RPM
The tool reaches its highest speed when the
selector is set to the "2" setting.
WARNING:
Only press the speed selector when the power
tool is completely stop.
SWITCHING ON/OFF
1. Press the switch trigger to start power tool.
The tool stops when the trigger is released.
2. Apply more pressure to the trigger leads
to a faster spindle running under current
speed setting.
3. The work light which helps for the visibility
near the bit automatically turns on when
the trigger is pulled and turns off a few
seconds after the tool stops.
HOW TO CHARGE THE
BATTERY PACK
WARNING:
This Lithium-Ion battery pack is shipped
partially charged. Fully charge the battery
pack before using it for the first time.
NOTE:
Charge the battery at an ambient temperature
range of 32°F - 104°F (0°C - 40°C).
1. Charge the Lithium-Ion battery pack only
with the correct charger.
2. Connect the charger to a power supply, the
light indicator of the charger turns red.
3. Align the raised ribs of the battery pack
with the slot in the charger.
4. Insert the battery pack into the charger, the
light indicator of the charger turns green
and it flashes.
5. The charger will communicate with the
battery pack to evaluate the condition of
the battery pack.
6. It is fully charged that the four lights of
the battery turn on. Disconnect the power
supply from the charger. Remove battery
pack from the charger.

EN - 12 WWW.SENIXTOOLS.COM
CHARGING INDICATOR
Press the light button on the battery pack to
check whether it needs to charge.
Light Button Indicator
Lights
Status
Fully Lit 2ŕ Blinking
75% - 100%
50% - 75%
25% - 50%
5% - 25%
< 5%
(needs to be
charged)
WARNING:
Malfunctions may occur when the four lights
blinking in turns.
OVERHEAT PROTECTION
When the tool/battery is overheated, the tool
stops automatically. In this situation, let the
power tool/battery cool before turning the tool
on again.
OVERDISCHARGE
PROTECTION
When the battery capacity is not enough, the
tool stops automatically. In this case, remove
the battery from the tool and charge the
battery.
WORK AREA SET UP
1. Designate a work area that is clean and well
lit. The work area must not allow access by
children or pets to prevent distraction and
injury.
2. Secure loose workpieces using a vise
or clamps (not included) to prevent
movement while working.
3. There must not be objects, such as utility
lines,nearby that will present a hazard while
working.
PRACTICAL ADVICE
1. General
a. Ensure the tool is fitted with a suitable bit
for current work and the direction selector
is at center lock position before start.
b. Always keep the product perpendicular to
the work area. Otherwise, bit is more likely
to slip or be jammed and cause damage to
the tool.
c. Place the power tool in a start position first
and then switch the product on.
d. The feeding force and running speed
depends on tool characteristics and the
work material. Excessive feeding force
will overload the power tool and increase
the risk of losing control. Ask a power tool
specialist for advice if necessary.
e. If the tool gets stuck in work area, switch
off and try to perpendicularly draw it
out with slight force to avoid damage. If
this does not work, switch to backward
mode, run the tool at a slow speed and
perpendicularly draw out with slight force.
f. Check the power tool and its clamping
status regularly during work. Refit or
replace it if necessary.

13 - EN
WWW.SENIXTOOLS.COM
2. Drilling
a. Attach a bit specially for drilling and set the
torque ring to “ “.
b. Pre-drill larger holes with a small diameter
drill bit in advance for a easier operation
and better result.
c. In order to prevent the bit from slipping,
punch a point beforehand especially when
drilling metals.
d. Start with a low speed. Gradually increase
speed as drill bit bites into wood.
e. When drilling through holes, place a block
or wood behind the workpiece to prevent
ragged edges on the back side of the hole.
f. If necessary, use a cooling lubricant when
drilling metal.
3. Screw Driving
a. Attach a driver bit and select a proper
torque according to the type and size of
screw and material of workpiece.
b. Pre-drill a hole of proper diameter and
depth before driving big screws into
workpiece.
c. Hold the tool perpendicular to the screw
head and keep the bit tip well fitted into the
screw recess, then switch ton the tool.
d. Start at a low speed. Gradually increase
speed as the screw driven in.
e. Remove a jammed screw in the backward
mode.
WARNING:
Do not use the power tool like a hand screw
driver or wrench, this could damage the
automatic spindle lock in the power tool.
MAINTENANCE
WARNING:
Only perform cleaning and maintenance work
according to these instructions!
All further works must be performed by a
qualified specialist!
WARNING:
TO PREVENT SERIOUS INJURY FROM
ACCIDENTAL OPERATION: Make sure the
trigger is locked and battery pack is removed
before performing any procedure in this
section.
TO PREVENT SERIOUS INJURY FROM TOOL
FAILURE: Do not use damaged equipments. If
abnormal noise or vibration occurs, have the
problem corrected before further use.
There are no user-serviceable parts in your
power tool.
If any of following condition are found, stop
using it and send it to the authorized service
center for repair.
• leaking, swollen, or cracked battery pack
• loose hardware
• misalignment or binding of accessories.
• cracked or broken parts.
• any other condition that may affect its safe
operation.
CLEANING
1. Clean dust and debris from air vents.
2. Keep handle clean, dry and free of oil or
grease.
3. Make sure the chuck is not clogged with
debris.
4. Remove stubborn dirt from housing with
high pressure air (max. 3 bar).
NOTE:
Do not use chemical, alkaline, abrasive or
other aggressive detergents or disinfectants
to clean this product as they might be harmful
to its surfaces.
TRANSPORTATION
1. Only carry by its handle.
2. Protect from any heavy impact or strong
vibrations which may occur during
transportation in vehicles.
3. Secure to prevent it from slipping or falling
over.
STORAGE
1. Clean thoroughly as described above.
2. Store in a dark, dry, frost-free and well-
ventilated area that is inaccessible
to children. Store the battery within a
temperature range of 32°F - 77°F (0°C -
25°C).
3. Use original package for storage or cover
with a suitable cloth to protect it against
dust.

EN - 14 WWW.SENIXTOOLS.COM
NOTE:
To prolong battery life, store the battery
pack separately from the tool in a 30%-50%
charged condition. It's recommended to have
your battery pack charged at least every 6
months.
DISPOSAL
Waste product should not be disposed of with
household waste. Please recycle where
facilities exist.
Check with your local authority or retailer for
recycling advice.
Debris or dust may produced by the tool
during operation, users should clean these
objects to protect environment.
Electrical products should not be
discarded with household products.
Used electrical products must be
collected separately and disposed
of at collection points provided for
this purpose. Talk with your local
authorities or dealer for advice on
recycling.
*20V Max battery, maximum initial battery
voltage (measured without a workload) is 20
volts. The nominal voltage is 18.

15 - EN
WWW.SENIXTOOLS.COM
TROUBLESHOOTING
6XVSHFWHGPDOIXQFWLRQVDUHRIWHQGXHWRFDXVHVWKDWWKHXVHUVFDQŖ[WKHPVHOYHV7KHUHIRUH
check the product using this section. In most cases the problem can be solved quickly.
PROBLEM POSSIBLE CAUSE SOLUTION
Product does not
start
Reversing lever at center locking
position
Switch the reversing lever to
proper side
Battery pack not properly attached Attach properly
Battery pack discharged Charge the battery pack
Product does not
reach full power
Battery pack capacity too low Charge the battery pack
Battery pack reaches its life cycle Replace with new battery pack
Incorrect torque setting Adjust to a proper torque setting
Unsatisfactory
result
Drill/screwdriver bit is dull/damaged Replace with new one
Drill/screwdriver bit is not suitable for
intended operation Use proper drill/screwdriver bit.

EnglishWWW.SENIXTOOLS.COM
WARRANTY
SENIX TOOLS LIMITED WARRANTY
FOR FIVE YEARS from the date of original purchase this product is warranted against defects in material or
workmanship. WITH PROOF OF ORIGINAL PURCHASE a defective product will receive free repair. If the product
cannot be repaired it will be replaced free of charge.
For details to obtain warranty coverage, visit www.senixtools.com, email [e-mail],
or call 1-800-261-3981.
• This warranty does not cover repairs necessary due to product accident or abuse, or failure to operate or
maintain the product according to all supplied instructions.
• This warranty does not cover an included battery pack or charger, which offer three-year, replacement-only
coverage. See battery pack or charger instruction manuals for complete warranty details.
• This warranty does not cover expendable items that can wear out from normal use within the warranty
period, including but not limited to drill bits, cutting blades and trimmer spool or line.
• This warranty does not apply to damage resulting from repairs to the product made or attempted by other
than SENIX authorized agents.
• This warranty does not cover the cost of mailing or transporting the power tool to receive warranty
coverage.
• The warranty is void if the product has been used for commercial, professional, or rental service purposes.
• The warranty applies to the original retail purchaser and is not transferable.
• Proof of purchase is required to obtain warranty coverage.
THIS WARRANTY IS GIVEN IN LIEU OF ALL OTHERS, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, AND EXCLUDES ALL INCIDENTAL OR CONSEQUENTIAL DAMAGE.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental
RUFRQVHTXHQWLDOGDPDJHVVRWKHVHOLPLWDWLRQVPD\QRWDSSO\WR\RX7KLVZDUUDQW\JLYHV\RXVSHFLŖFOHJDOULJKWV
and you may have other rights which vary in certain states or provinces.
NOTE: Battery pack warranty voided if the battery pack is tampered with in any way. SENIX is not responsible for
any injury caused by tampering and may prosecute warranty fraud to the fullest extent permitted by law.
90-DAY MONEY-BACK GUARANTEE
,I IRU DQ\ UHDVRQ ZLWKLQ  GD\V IURP WKH GDWH RI RULJLQDO SXUFKDVH \RX DUH QRW FRPSOHWHO\ VDWLVŖHG ZLWK WKH
performance of this SENIX product, you can return it with the original sales receipt for a full refund.
Latin America: This warranty does not apply to products sold in Latin America. For products sold in Latin America,
VHH WKH FRXQWU\VSHFLŖF ZDUUDQW\ LQIRUPDWLRQ FRQWDLQHG LQ WKH SDFNDJLQJ FDOO WKH UHWDLOHU IURP ZKLFK LW ZDV
purchased, or visit the website for warranty information.
Free warning label replacement: If your warning labels become illegible or are missing, call 1-800-261-3981 for a
free replacement.
REGISTER ONLINE - www.senixtools.com/pages/product-registration
Thank you for your purchase! Register your product now for:
Warranty Service:5HJLVWHULQJ\RXUSURGXFWZLOOKHOS\RXREWDLQPRUHHŘFLHQWZDUUDQW\VHUYLFHLQFDVHRIDSUREOHP
with your product.
&RQŖUPDWLRQRI2ZQHUVKLS,QFDVHRIDQLQVXUDQFHORVVVXFKDVŖUHŗRRGRUWKHIW\RXURZQHUVKLSUHJLVWUDWLRQ
will serve as proof of purchase.
For your safety:5HJLVWHULQJ\RXUSURGXFWZLOODOORZXVWRFRQWDFW\RXLQWKHXQOLNHO\HYHQWDVDIHW\QRWLŖFDWLRQLV
required under the Federal Consumer Safety Act.
YAT USA INC. 10506 Bryton Corporate Center Dr, #500 Huntersville, NC 28078
For customer support, please call 1-800-261-3981 or email us at [email protected]

EspañolWWW.SENIXTOOLS.COM
• SEGURIDAD
• ENSAMBLAJE
• OPERACIÓN
• MANTENIMIENTO
• GARANTÍA
PRECAUCIÓN: Antes de usar esta herramienta, lea
completamente este manual y siga todas las medidas de
seguridad de operación.
Manual de instrucciones
YAT USA INC. 10506 Bryton Corporate Center Dr, #500 Huntersville, NC 28078
Para servicio al cliente en EE.UU., por favor llame al 1-800-261-3981 o envíenos un correo
electrónico a [e-mail]
TALADRO DESTORNILLADOR DE 1/2" (13 mm)
INALÁMBRICO
Modelo: PDDX2-M2

ES - 18 WWW.SENIXTOOLS.COM
ÍNDICE
SÍMBOLOS INTERNACIONALES Y DE SEGURI-
DAD...............................................................................18
INSTRUCCIONES DE SEGURIDAD.....................19
CONOZCA SU UNIDAD..........................................24
ESPECIFICACIONES*............................................25
ENSAMBLAJE..........................................................25
OPERACIÓN.............................................................. 27
MANTENIMIENTO...................................................30
SOLUCIÓN DE PROBLEMAS...............................32
GARANTÍA .................................................................33
SEGURIDAD Y SÍMBOLOS
INTERNACIONALES
Este manual del operador describe la seguri-
dad y los símbolos y pictogramas internacio-
nales que pueden aparecer en este producto.
Lea el manual del operador para obtener infor-
mación completa sobre seguridad, montaje,
operación y mantenimiento y reparación.
Precaución / Advertencia.
Para reducir el riesgo de lesiones,
el usuario debe leer y entender el
manual de instrucciones.
Use protección para los ojos.
Use una mascarilla antipolvo.
Use calzado de seguridad.
Use guantes de protección.
No deseche los paquetes de bat-
erías en los ríos ni los sumerja en
agua.
No arroje los paquetes de baterías
al fuego. Explotarán y causarán
lesiones.
Utilice la batería en una temperatura
máxima de 50°C (122°F).
Max 50°C
No desensamble, aplaste o caliente
por encima de los 100°C (212°F).
Nunca exponga la batería a mi-
croondas o altas presiones.
Mantenga a los transeúntes a una
distancia segura de la zona de tra-
bajo.
Para uso solo en interiores. Utilice
el cargador de batería únicamente
en interiores.

19 - ESWWW.SENIXTOOLS.COM
INSTRUCCIONES DE
SEGURIDAD
ADVERTENCIAS DE
SEGURIDAD GENERALES
PARA HERRAMIENTAS
ELÉCTRICAS
¡ADVERTENCIA!
Lea todas las advertencias de seguridad, ins-
WUXFFLRQHVLOXVWUDFLRQHV\HVSHFLŖFDFLRQHV
que se ofrecen con esta herramienta eléctrica.
Si no se cumple con todas las instrucciones
mencionadas a continuación, se pueden
producir descargas eléctricas, incendios y/o
lesiones graves.
Guarde todas las advertencias e instrucciones
para su consulta futura.
El término "herramienta eléctrica" que
aparece en las advertencias se refiere a her-
ramientas alimentadas por la red eléctrica
(con cable) o a herramientas alimentadas por
batería (sin cable).
1. Seguridad en el área de trabajo
a. Conserve el área de trabajo limpia y bien
iluminada. Las áreas desordenas invitan a
los accidentes.
b. No opere herramientas eléctricas en
ambientes explosivos, como ante la
presencia de líquidos, gases o polvos
inflamables. Las herramientas eléctricas
generan chispas que pueden hacer arder el
polvo o los vapores.
c. Mantenga a los niños y espectadores
alejados mientras esté operando una
herramienta eléctrica. Las distracciones
pueden hacerle que pierda el control.
2. Seguridad eléctrica
a. No exponga las herramientas eléctricas a
la lluvia o a condiciones húmedas. El agua
que ingresa a una herramienta eléctrica
aumentará el riesgo de descarga eléctrica.
3. Seguridad personal
a. Manténgase alerta, preste atención a lo
que está haciendo y use el sentido común
cuando opere una herramienta eléctrica.
No utilice una herramienta eléctrica cuando
esté cansado o bajo la influencia de drogas,
alcohol o medicamentos. Un momento
de descuido durante la operación de
herramientas eléctricas puede provocar una
lesión personal seria.
b. Use los equipos de protección personal.
Use siempre protección para los ojos.
Los equipos de protección que utilice
para las condiciones adecuadas, como
mascarillas antipolvo, zapatos de seguridad
antideslizantes o protección auditiva,
reducirán las lesiones personales.
c. Evite arranques accidentales. Asegúrese
que el interruptor esté en la posición de OFF
(apagado) antes de conectar la fuente de
energía y/o el bloque de baterías, recoger
la herramienta o transportarla. Transportar
herramientas eléctricas con el dedo en
el interruptor o energizar herramientas
eléctricas con el interruptor encendido,
invita a accidentes.
d. Retire cualquier llave de ajuste antes de
encender la herramienta eléctrica. Una
llave que se haya dejado fijada a una parte
giratoria de la herramienta eléctrica puede
dar como resultado una lesión personal.
e. No extienda el cuerpo en exceso. Mantenga
su posición de pie y su equilibrio en todo
momento. Esto permite un mejor control
de la herramienta eléctrica en situaciones
inesperadas.
f. Vístase correctamente. No use ropa suelta
ni joyas. Mantenga su cabello y ropa alejados
de las piezas móviles. La ropa suelta, las
joyas o el cabello largo pueden atascarse en
las piezas móviles.
g. Si se suministran dispositivos para la
conexión de instalaciones de extracción y
colección de polvo, asegúrese que estén
conectadas y que se usen correctamente. El
uso del colector de polvo puede reducir los
peligros relacionados con el polvo.
h. Cuide que por la familiaridad obtenida
con el uso frecuente de herramientas no
le haga volverse complaciente y termine
ignorando los principios de seguridad de la
herramienta. Una acción descuidada puede
llegar a causar lesiones severas en una
fracción de segundo.
4. Uso y cuidado de la herramienta
eléctrica
a. No fuerce la herramienta eléctrica. Use la
herramienta eléctrica para su aplicación. La
herramienta eléctrica correcta hará mejor y
más seguro el trabajo a la velocidad para la
que ha sido diseñada.
b. No use la herramienta eléctrica si el
interruptor no lo enciende y apaga. Cualquier

ES - 20 WWW.SENIXTOOLS.COM
paquetes de batería específicamente
designados. El uso de cualquier otro paquete
de batería puede generar riesgo de lesiones
e incendio.
c. Cuando el paquete de batería no esté en
uso, manténgalo alejado de otros objetos
metálicos como clips, monedas, llaves,
clavos, tornillos u otros objetos pequeños
de metal, que puedan hacer una conexión
entre una terminal y otra. Un cortocircuito
en las terminales de la batería podría causar
quemaduras o incendios.
d. En condiciones extremas, el líquido podría
ser eyectado de la batería; en ese caso, evite
el contacto. Si hay contacto accidental,
enjuague con agua. Si el líquido entrara en
los ojos, busque ayuda médica. El líquido
eyectado de la batería puede causar
irritación o quemaduras.
e. No use el paquete de batería o la
herramienta si esté dañada o modificada.
Las baterías dañadas o modificadas pueden
tener un comportamiento impredecible que
puede resultar en incendios, explosiones o
riesgo de lesiones.
f. No exponga el paquete de batería o la
herramienta al fuego o a temperaturas
excesivas. La exposición al fuego o a
temperaturas superiores a 130°C (266°F)
puede causar explosiones.
g. Siga todas las instrucciones de carga
y no cargue el paquete de batería o la
herramienta fuera del rango de temperatura
especificado en las instrucciones. La carga
inadecuada o a temperaturas que excedan el
rango especificado puede dañar la batería e
incrementar el riesgo de incendio.
6. Servicio
a. Haga reparar su herramienta eléctrica con
un reparador calificado, utilizando solamente
piezas de repuesto idénticas. Esto asegurará
que se mantenga la seguridad de la
herramienta eléctrica.
b. Nunca mande paquetes de batería dañados
a mantenimiento. El mantenimiento o
reparación de los paquetes de baterías lo
deben realizar únicamente el fabricante o los
proveedores autorizados de servicio.
ADVERTENCIAS DE
SEGURIDAD PARA EL
TALADRO
herramienta eléctrica que no pueda ser
controlada con el interruptor es peligrosa y
debe repararse.
c. Desconecte el enchufe de la fuente de
energía y/o retire el bloque de baterías,
si es desmontable, de la herramienta
eléctrica antes de hacer cualquier
ajuste, cambiar accesorios o guardar la
herramienta eléctrica. Tales medidas de
seguridad preventivas reducen el riesgo de
que la herramienta eléctrica se encienda
accidentalmente.
d. Guarde las herramientas eléctricas inactivas
fuera del alcance de los niños y no permita
el uso de la herramienta eléctrica por parte
de personas que no estén familiarizadas
con esta o con sus instrucciones. Las
herramientas eléctricas son peligrosas en
manos de usuarios sin capacitación.
e. Mantenga las herramientas eléctricas y los
accesorios. Compruebe que no hayan piezas
móviles desalineadas, atoradas o rotas ni
ninguna otra condición que pueda afectar el
funcionamiento de la herramienta eléctrica.
Si se daña, repare la herramienta eléctrica
antes de usarla. Muchos accidentes son
causados por herramientas eléctricas con
mal mantenimiento.
f. Conserve limpias y afiladas las herramientas
de corte. Las herramientas de corte con
un mantenimiento adecuado son menos
propensas a trabarse y son más fáciles de
controlar.
g. Use la herramienta eléctrica, los accesorios
y las brocas de la herramienta, etc. en
conformidad con estas instrucciones,
tomando en cuenta las condiciones del
trabajo y la tarea a realizar. El uso de la
herramienta eléctrica para operaciones
distintas de las previstas, podría dar como
resultado una situación peligrosa.
h. Mantenga las asas y las superficies de
agarre secas, limpias y sin aceite o grasa.
Con asas y superficies de agarre resbalosas,
no es posible tener un manejo seguro y un
control de la herramienta en situaciones
inesperadas.
5. Uso y cuidado de la herramienta de
batería
a. Recargar solo con el cargador especificado
por el fabricante. Un cargador adecuado
para un tipo de paquete de batería podría
crear un riesgo de incendio si se usa con
otro paquete de batería distinto.
b. Use herramientas eléctricas solo con los
