SENSORO Yunzi User manual

Yunzi Beacon User Manual
Outlook
Yunzi’s exterior is smooth and aesthetically appealing, designed with
an attention to detail. The location of internal chips is precise and
designed to optimize performance. Yunzi has multiple sensors and
operates with energy efficiency.
Features
1. Ultra-Low Power Consumption
Uses a Bluetooth® 4.0 (Bluetooth® low energy) Nordic NFR51822
chip with ultra-low power consumption.
Bluetooth low energy with intelligent energy-saving programs allows
Yunzi to work for at least two years on its button cell battery.

2. Instant Availability
Yunzi is turn on when you take it out of the package, as light sensors
tell it when to go in or out of sleep mode.
3. Compatibility
Software and firmware are fully compatible with Apple’s iBeacon and
Google’s Eddystone (include EID) technical requirements, and can
be applied to systems including:
iOS 7.0 or above:
iPhone 4S, iPhone 5, iPhone 5S, iPad 3, iPad mini, iPad air.
Android 4.3 or above:
Samsung Galaxy S III, Galaxy S IV, Galaxy Note II, Galaxy Note III
and Motorola RAZR, HTC ONE, etc.
4. Demo App and Configuration App
The Yunzi (demo) app allows you to experience our beacons, while
the Sensoro app (configuration tools) puts you in control of all of
their features.

Scan the QR code to download:
!
Signal Stability and Data Transmission
1. Transmission Stability and Distance
To achieve signal stability and long-distance data transmission
requirements, the SmartBeacon Yunzi underwent extensive testing
and modification. Its signal remains stable even in complex
deployment locations. Radius frequency (RF) power demand
configuration can be adjusted to a maximum radius of 80 meters.
The RF power demand configuration can reduce its radius to a
minimum of 0.15 meters, which covers an area of 0.225 square
meters. However, it is possible that no signal will be obtained if the
RF power is adjusted to a minimum.
2. Enterprise Class Device Management Support
Mass management of device status is an essential component of
our enterprise class cloud software solutions. Our patented beacon
devices can be deployed to collect bulk data, and using the
Sensoro cloud, your organization has the essential tools needed to
seamlessly manage large-scale deployments. Centralized
management on your phone or computer is made easy by
enterprise class software solutions.

Specifications
Property
Specifications
Chip
Nordic
External Dimensions
Diameter 50mm, Thickness 19mm
Weight
39g
Exterior Materials
Polished anodized aluminum alloy
ring, White ABS+ transparent PC
shell
Resistances
Water resistant / dust proof / anti-
vibration
Protocol Standards
Bluetooth® 4.0 low energy, supports
iBeacon and Eddystone
End User Compatibility
iOS 7.0 or above / Android 4.3 or
above
Software Upgrades
Support for over-the-air firmware
upgrades
Security
Hardware-level password access
Sensors
Temperature, light, accelerometer
LED
3 LED light bulbs
Radius Power
-30dBm to +4dBm (can be adjusted
to optimize signal strength)
Transmission Range
0.15 ~ 80m
Radio Frequency
(Transmission Broadcast
Interval)
Adjustable (100 milliseconds ~ 1.285
seconds)

Property
Specifications
Power Consumption per
Broadcast
7.58 * 10-6mAh (-8dBm transmitting
power)
Sleep Mode Power
Consumption
15uW
Sleep Mode Current
5uA
Supply Voltage
3.0V
Battery
Panasonic CR2477 Battery，
≥1000mAh
Operational Life
2-5 years
Operation Mode
Broadcasts at specific intervals;
equipped with intelligent adaptor
Sensoro App’s Configuration Tools
The Sensoro app is available for developers to check on and configure
the parameters of all nearby Sensoro beacons. The Sensoro app is
compatible with iOS 7.0 or above (iPhone 4S, iPhone 5, iPhone 5S,
iPad 3, iPad mini, iPad air) and Android 4.3 or above (Samsung Galaxy
S III, Galaxy S IV, Galaxy Note II, Galaxy Note III and Motorola RAZR,
HTC ONE, etc.). Using the Sensoro app, you can deploy beacons one
at a time, and then view all nearby beacons if you want to make
changes. If you would like to deploy and configure beacons in bulk,
please use the Deploy app.
Open the Sensoro app, and the Device List of all nearby beacons will
appear. The information for each beacon includes Major, Minor, as well
as other basic information including an animated display of the RSSI
strength.

All nearby Sensoro beacons will be listed by order of when the app
detected their presence. By changing the Major, Minor values, we can
differentiate beacons. Since Major, Minor consists of two values, we
recommend grouping associated beacons using the Major value, and
labeling individual beacons using the Minor value. For example,
beacons at a museum might all have the 00FF code for Major, and
each individual beacon placed at different locations throughout the
museum would have a unique Minor code. If you would like to view the
tags of all devices in range, please log into the Sensoro Cloud on the
Inspection app.
The Device Detail page displays the real-time details of each of the
beacon’s sensors, battery life, and RSSI signal. Touch the device box
on the Device List to enter the Device Detail page.

You can also locate an individual beacon on the Device List by
scanning the device’s QR code. Touch the scanning icon on the top
right of the device list. Once the device is scanned, it will take you to
the Device Detail page.

Swipe left on the top of the Device Detail page to bring up the real-time
RSSI line display graph. This more detailed RSSI graph allows
developers to accurately understand the signal changes in the device,
as show below.

Swipe left again to view whether the device being viewed is using
iBeacon or Eddystone protocol.
The Sensoro app supports setup of beacon’s basic information
(including UUID, Major and Minor) as well as the modification of device
transmitting power, radio frequency, and other parameters.
For Google Eddystone, UID, URL, TLM and EID are fully supported by
Sensoro app now. Moreover, you can also use this app to ONE-way-
switch the beacon mode into the standard Eddystone Configuration
GATT service.

*Notice:
1. Currently setting up the EID is only available on Android (download
link: http://www.sensoro.com/en/download/), which needs a full installation of
Google-Play-Service and Google Service Framework, and Nexus 5/6
are recommended.
2. We also have another "Full Eddystone GATT" special version
firmware available, which was built to work with Google’s Beacon Tool
App. Please contact our sales team ([email protected]) if you’d like to order
this special version.
Google’s Beacon Tool App download links:
iOS:
https://itunes.apple.com/us/app/beacon-tools/id1094371356?mt=8
Android:
https://play.google.com/store/apps/details?id=com.google.android.apps.location.beacon.beacontools&hl=en
3. Currently switching to the standard Eddystone Configuration GATT
service is a ONE way feature, and a third-party tool is needed when
switching back to Sensoro Configuration service. Manual for Mode
Switch download link:
http://www.sensoro.com/static/Manual_for_Mode_Switch.pdf

Security
The device is made secure by a hardware level password, used also by
the US military, which prevents unauthorized modification of
SmartBeacon Yunzi parameters. Yunzi allows you to enjoy rich
functionality and stability without security concerns.
!
Quality Assurance
Having passed FCC (FCC certification number: 2ADYO-C0), CE, and
MIC certification, each device has rigorously undergone factory defect,
spectrum, power, and stability testing.
