SERAX B7221604 User guide

Mounting Instruction
Seppe Van Heusden - Seam
Floor Lamp
B7221604
Luminary specs
TYPE Floor Lamp
MATERIAL Steel - Porcelain
COLOUR White
DIMENSIONS
L20 x W71 H196 cm
L7 7/8 x W28 H77 1/8 inch
DIMMING FUNCTION Yes
CABLE LENGTH 5 m
Bulb type
E27
Bulb included
Max. 5W
Max. 240V
Class II
196 cm
71 cm
STEP 2
STEP 3
STEP 1
STEP 4
STEP 5
Adjust the height of the
lampshade by pulling the
cable.
! Do not let the lampshade
touch the frame.
pulling the cable
insert the frame
into the foot
220-240V
50-60HZ
Max
5W
E27
WWW.SERAX.COM
Veldkant 21, 2550 Kontich, Belgium - Tel. [phone]

Safety Precautions
Please study the instruction manual and below information carefully before installing or using this product.
Please keep this user manual for further reference.
 1. Theluminairesmayonlybeinstalledbyauthorizedandqualiedtechniciansaccordingthevalidregulationsforelectricalinstallation.
 2. Maintenanceoftheluminairesislimitedtotheirsurfaces.Duringmaintenancenomoisturecancomeintocontactwithanyareasoftheterminalconnectionsorvolta
control parts.
3. The electrical supply must be switched off at the outset, preferably by means of a switch in the distribution box, before any installation, maintenance or repair work is
undertaken.
4. Exterior light must not be installed during rain.
 5. Takeaccountoftheminimalseparationdistancefromotherobjectsandtheroomrequiredaroundthetting.
6. If in any doubt, consult a professional, taking local installation requirements into account. Some countries stipulate that lighting may be installed only by registered
installers.
 7. Clampingscrewsinelectricalconnectionsmustbeadequatelytightened.Thisisparticularlythecasewith12Vlowvoltageconductors.
8. When replacing a halogen lamp, wait for it to cool, for a minimum of 5 minutes.
 9. Cleanwithaclean,dryclothorbrush,usenosolventsorabrasives.Avoiddampnessonallelectricalcomponents.
 10. Takeaccountofallavailabletechnicalinformation.
11. Take note of the symbols when connecting wires:
N = Neutral
  L= Live
= Earth
 12. Iftheexternalexiblecableorcordofthisluminaireisdamaged,itshallbeexclusivelyreplacedbythemanufacturerorhisserviceagentorasimilarqualiedpersonin
ordertoavoidahazard.
13. Meaning of symbols:
Protectionclass1:thettingmustbeearthed
Protectionclass2:thettingisdoubleinsulatedanddoesnotrequireearthing
Protectionclass3:thettingislowvoltage
Observetheindicatedminimumdistancebetweenthelampandtheilluminatedmaterials/objects
Only the self-screening halogen illuminants should be used with the luminaire
Strip the wire to the indicated length
Connectusingthespeciedcable
The maximum wattage indicated in each lighting unit, for example, must not be exceeded
Thisluminairewasdesignedtoworkonlywiththeindicatedvoltage
This luminaire cannot be disposed together with normal domestic waste in standard rubbish bin,
butyouhavetobringittoastagingareaforelectricalwaste
Thexturecanbeusedincombinationwithadimmer.Consultthesalesoutletforthecorrecttype
ofdimmer(importantinthecaseof12Vttings)
For indoor use only, where direct contact with water is impossible
0,5m
Max
5W
E27
220-240V
50-60HZ
