SERV-WARE SGR-6B-C User manual

FOR QUESTIONS, CONTACT THE
SERVICE DEPARTMENT AT:
[e-mail] or
800•768•5953
Gas Range with Convection Oven
Service, Installation and Care Manual
Please read this manual completely before attempting to install or operate this equipment.
Notify carrier of damage! Inspect all components immediately.
SGR-6B-C
www.servware.com
800•768•5953
Save These Instructions!
Parts & Service Manuals Available at:
IMPORTANT INFORMATION
ABOUT YOUR UNIT ENCLOSED.
PLEASE READ BEFORE USE!

DANGER
WARNING
CAUTION
www.servware.com
800•768•5953
Service, Installation & Care Manual
1
COMMERCIAL RANGE SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always
read and obey all safety messages.
This is the Safety Alert Symbol. This symbol alerts you to potential
hazards that can kill or injure you and others. All safety messages
will follow the Safety Alert Symbol and either the words ”DANGER”,
“WARNING” or “CAUTION”.
DANGER means that failure to heed this safety
statement may result in severe personal injury or death.
WARNING means that failure to heed this safety
statement may result in extensive product
damage, serious personal injury, or death.
CAUTION means that failure to heed this safety
statement may result in minor or moderate
personal injury, or property or equipment damage.
All safety messages will alert you to what the potential hazard is, tell you how to reduce the chance
of injury, and let you know what can happen if the instructions are not followed.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualied persons in order to avoid a hazard. This appliance is not intended for use by
persons with lack of experience and knowledge regarding this type of equipment, unless they have
been given supervision or instruction concerning use of the appliance by a person responsible for
their safety. Cleaning and user maintenance shall not be made by inexperienced persons without
supervision.
Do not store explosive substances such as aerosol cans with a ammable propellant in this
appliance. The appliance uses ammable insulation blowing gas C5H10, disposal of the appliance
shall be in accordance with the regulations of federal, state and local authorities.

www.servware.com
800•768•5953
Service, Installation & Care Manual
2
COMMERCIAL RANGE SAFETY
• Do not touch any hot surfaces.
• Do not use this unit for any other than intended use.
• Do not use outdoors.
• Always use on a rm, dry and level surface.
• Keep the appliance area free and clear from combustibles
• The manual shall be retained for future reference
• Do not store or use gasoline or other ammable vapors or liquids in the vicinity of this or any
other equipment.
• Improper installation, adjustment, alteration, service or maintenance can cause property
damage, injury or death.
• Read the installation and maintenance instructions thoroughly before installing or servicing this
equipment.
• Have the equipment installed by a qualied installer in accordance with all federal, state and
local codes.
• Do not install or use without all 4 legs.
• This equipment is for use in non-combustible locations only.
• Do not obstruct the ow of combustion and ventilation air.
• Do not spray controls or the outside of the equipment with liquids or cleaning agents
• Allow for hot parts to cool before cleaning or moving.
• This equipment should only be used in a at, level position.
• Do not operate unattended.
• Any loose dirt or metal particles that are allowed to enter the gas lines on this equipment will
damage the valve and affect its operation.
• If you smell gas, follow the instructions provided by the gas supplier. Do not touch any electrical
switch; do not try to light the burner; do not use a telephone within close proximity.
• Never attempt to move grates while cooking.

www.servware.com
800•768•5953
Service, Installation & Care Manual
3
BEFORE INSTALLATION
BEFORE INSTALLATION............................................................................... 3
INSTALLATION............................................................................................... 4-5
OPERATION ................................................................................................... 5-6
GAS CONVERSION........................................................................................ 7
CLEANING...................................................................................................... 7
TROUBLESHOOTING CHART....................................................................... 8
SPECIFICATION LIST .................................................................................... 9
© Copyright 2022 Serv-Ware Products Incorporated. All rights reserved.
Reproduction without written permission is prohibited.
• Installation of this device should be performed by professional technicians.
• Installation of this unit should conform to provisions of gas safety, installation and usage.
• Check that electrical (if needed) and gas supply agree with the specications on the rating plate
located inside the kick panel of the unit. If the supply and equipment requirements do not agree,
do not proceed with the installation. Contact your dealer immediately.
• Unit must be installed so that the ow of combustion and ventilation air will not be obstructed,
ensure that there is an adequate supply of air in the room to allow proper combustion of gas at
the burners.
• This device should be kept a minimum clearance of 12" from combustible construction at the
sides and 10" at the rear. Clearance from non-combustible construction is 0" sides and 6" at the
back. Do not install on a ammable oor or around other combustible objects.
• This item is intended to sit on a solid and level oor.
INSTALLATION:
The installation of this equipment must conform with local codes, or with the National Gas Code,
ANSIZ223.1/NFPA 54, or the Natural Gas and Propane Installation Code, CSA B149.1, as applicable.
• The equipment and its individual shutoff valve must be disconnected from the gas supply piping
system during any pressure testing of that system at test pressures in excess of ½ psi (3.5 kPa).
• The equipment must be isolated from the gas supply piping system by closing its individual
manual shutoff valve during any pressure testing of the gas supply piping system at test pressures
equal to or less then ½ psi (3.5 kPa).
CONTENTS

www.servware.com
800•768•5953
Service, Installation & Care Manual
4
BEFORE INSTALLATION
INSTALLATION
Clearance and positioning:
• This equipment must be installed adjacent to non-combustible surfaces only with a minimum
spacing of 6" from all sides. This equipment must be a distance of 6" from other equipment. The
equipment must have the 4" legs installed and be placed on a non-combustible surface.
• For an oven equipped with casters, the installation shall be made with a connector that complies
with the Standard for Connectors for Movable Gas Appliances, ANSI Z21.69/CSA 6.16 and a
quick-disconnect device that complies with the Standard for Quick-Disconnect Devices for Use
with Gas Fuel, ANSI Z21.4/CSA 6.9. When installing the oven with casters and quick-disconnect
hose, adequate means must be provided to limit the movement of the oven without depending
on the connector and the quick disconnect device or its associated piping to limit the oven
movement. Restraining means may be attached to the vertical portion of the base frame in the
rear of the oven.
1. Level the device with a level gauge. The height can be adjusted by the adjustable feet. Unit should
not sway or tilt during operation. Units that are not level will experience operational problems.
2. The mounting position should be well-ventilated with proper hood exhaust system.
3. Codes require that a gas shut off valve should be installed upstream the device where it is easily
reached during operation.
4. Make sure you are using the correct gas supply that is specied for this model. If the gas supply is
not intended for this model, do not proceed with installation.
5. This unit is applicable to low pressure regulating valves only. High pressure regulating valves and
medium pressure regulating valves are not to be used.
6. Check to make sure the connection pipe to the unit has no leaks and that all connections and pipe
joint compound used are resistant to the action of propane gases.
Air Supply and ventilation:
• The area in front and around the equipment must be kept clear to avoid any obstruction of the
ow of combustion and ventilation air.
• Adequate clearance must be maintained at all times in front of and at the sides of the equipment
for servicing and proper ventilation.

www.servware.com
800•768•5953
Service, Installation & Care Manual
5
INSTALLATION
7. A pressure regulator must be installed with this unit. Ensure that the regulator type is in agreement
with the rating plate gas supply. Regulator must be upright after installation. If regulator is not level
during operation, performance problems may result.
8. After connecting the appliance to the gas system, check for leaks at joints and pipe ttings; to do
so, use soapy water or a specic leak detector (spray).
9. Check the gas supply pressure after installation.
10. Gas supply pressure can be measured with a liquid-lled pressure gauge (e.g. a U-shaped
pressure gauge, minimum scale division 0.1mbar) or a digital gauge. Procedure as follows:
• Ensure gas is turned off
• Remove the panel and unscrew the screw on the pressure port
• Place the pressure gauge
• Start up the appliance by following the instructions in this owner’s manual
• Check supply pressure. Pressure must agree with rating plate requirement when the unit is in
full operation
• After the check, turn off gas and remove the pressure gauge
• Replace the sealing screw
OPERATION
When turning on for the rst time please be advised that it might take a little longer to ignite due to
the air existing in the pipe.
BURNERS:
• Turn on the gas supply and ignite the pilot ame with a lighter. If the unit hasn’t been used in a
while or if this is the rst lighting, ignition might take a little longer (about two or three minutes).
• Press the corresponding valve knob of burner and turn 90 degrees counterclockwise.
The burner will be ignited and the ame will be at Max. To set the ame to Min, rotate
counterclockwise another 90 degrees.
• When nished turnoff main burner by rotating the knob clockwise to off position. Pilot should
remain lit.
• For complete shutdown, ensure that all burner knobs are turned to the off position, and then
turn main gas supply off.

HL1 ...................... Power indicator
HL2...................... Motor indicator
HL3...................... Ignition indicator
S1 ........................ Power on/off switch
S2 ........................ COOK/COOL switch
S3 ........................ Micro switch
S4 ........................ Gas ignition switch
IC1 ....................... Digital thermostat
IC2....................... Ignition module
YV........................ Solenoid valve
M1/M2.................. Motor
www.servware.com
800•768•5953
Service, Installation & Care Manual
6
OPERATION
CONVECTION OVEN:
WIRING DIAGRAM:

www.servware.com
800•768•5953
Service, Installation & Care Manual
7
GAS CONVERSION
CLEANING
Conversion from Natural Gas to Liquid Propane (LP) or vice versa may only be performed by the
factory or its authorized service agent.
NOTE: It is important to check the machine daily. Checking the machine regularly can avoid serious
accidents. Stop using if user feels that there are some problems with the unit. Check the condition of
the machine before and after using every day.
1. Before cleaning, turn off all gas valves.
2. Please clean the burners and drip tray of all debris and spillage daily. A complete cleaning every
day will ensure a good service and extend the service life of the unit.
3. Clean the stainless steel surface with warm soapy water every day and rinse it completely. Do not
saturate range with water, excessive water will cause operational issues. During cleaning, do not
clean the stainless steel surface with abrasive detergent, brush or scraper etc. The residual iron
scale may cause rusting.
4. Do not clean the surface with chlorine cleanser (bleach, dish detergent, hydrochloric acid etc.).
Do not clean the oor where the device locates with corrosive substance.
5. Do not change the burner shutter settings.
6. Accumulation of substances containing salt or acidic ingredients, e.g. vinegar, lemon juice,
spices, salt etc. can cause corrosion. Thus, please do not allow these substances to have long
contact with the unit.
7. After cleaning, ensure that the ports of the burners are open and clear of any residue.
8. Clean cast iron top grates with a mild soap and water solution. Rinse thoroughly and dry with a
clean, water-absorbent towel. Immediately after drying, season grates lightly with liquid vegetable
oil. After seasoning, replace grates on range and turn burners on LOW, allow grates to heat for 15
minutes before using pots or pans on the range top. Failure to season grates after cleaning will
result in rust.
9. If unit will sit idle for a signicant period of time, please turn off the gas valve upstream the device.

www.servware.com
800•768•5953
Service, Installation & Care Manual
8
TROUBLESHOOTING CHART
PROBLEM CAUSES SOLUTIONS
The pilot ame can’t
be ignited
The gas pressure is too low Adjust the relieve valve to
increase pressure
The nozzle is clogged Unclog the nozzle
Connection of the thermocouple
is loose Tighten the thermocouple
The thermocouple is defective Replace the thermocouple
The gas control valve is
malfunctioning Replace the gas control valve
The pilot ame is on,
but the main burner
can’t be ignited
The gas pressure is too low Adjust the relieve valve to
increase pressure
The main burner nozzle
is clogged Unclog the nozzle
The gas control valve is defective Replace the gas control valve
It has a light back
sound when the gas
supply is turned off
Wrong orice size for the
gas supply Install proper orice
The air shutter is too open Adjust the damper
Gas pressure too low Increase the gas pressure
Gas pressure too low Increase the gas pressure
It has a yellow ame
and black smoke
Wrong orice size for the
gas supply Install proper orice
The air shutter is closed too far Adjust the air shutter
Running out of gas/propane Replace tank/increase gas
High elevation Install proper orices
for elevation
Bad air/gas mixture Increase air ow/gas to the unit

www.servware.com
800•768•5953
Service, Installation & Care Manual
9
SPECIFICATION LIST
MODEL STYLE ELECTRIC
RATING OPEN BURNER OVEN GRIDDLE/ BROILER
SGR-6B-C 6 burners with 24"
griddle + oven 120VAC, 60HZ 30,000BTU/pc*6 31,000BTU/pc*2 20,000BTU/pc*2

www.servware.com
800•768•5953
Service, Installation & Care Manual
SERV-WARE PRODUCTS
LIMITED LABOR AND PARTS WARRANTY
GAS RANGES
10
Serv-Ware Products warrants to the original owner/user that any Gas Range manufactured by Serv-Ware Products (“the
products”) shall be free of defects in material or workmanship under normal and proper use and maintenance service as
specied by Serv-Ware Products and upon proper installation and start-up as well as for a period of one (1) year from
the original installation date or a maximum of eighteen (18) months after the shipment date from Serv-Ware Products.
The obligation of Serv-Ware Products and the rights and remedies of the owner/ user under this warranty are
exclusively limited to (1) the repair or replacement, including labor charges, of parts or assemblies that in Serv-
Ware Products opinion are defective within one year after the original date of installation; The labor warranty
shall include standard straight time labor charges at the product location only and shall exclude charges for travel time,
mileage or other premium charges. Any labor service required to fulll the warranty obligation must be performed by a
service company qualied and accepted by Serv-Ware Products.
(See Specication sheets for warranty period details.)
All claims for labor or parts must be made through Serv-Ware Products. The defective part for which labor
reimbursement is claimed, together with the service invoice, must be returned to the Serv-Ware Products within fteen
days from the date of service to be eligible for labor and parts warranty coverage. All replacement parts must be
approved Serv-Ware Products parts. Incidents of failure that do not require replacement of a part shall be explained in
sufcient detail on the service invoice to identify the failure. All claims shall include the product model number, serial
number, original date of installation and customer identication.
The foregoing warranty shall not apply to (1) any part or assembly (a) that has been altered, modied, or changed, (b)
that has been subjected to misuse, abuse, neglect or accidents, or (c) any Product on which the serial or model number
has been removed or altered, or (2) any Product that has been installed and /or maintained inconsistent with Serv-Ware
Product’s technical publications, or (3) any Product that has been installed or is located outside the standard warranty
coverage area. Warranty valid in United States only. Contact factory for warranty in other countries.
Serv-Ware Products assumes no liability for misuse or inadequate maintenance of the Product. In no event shall the
user by entitled to recover incidental or consequential damages, including but not limited to, damages for
inconvenience, food loss, rental or replacement equipment, loss of prots, or other commercial loss. Warranties
stated above are the only warranties made in connection with the sale and distribution of the Products. ANY AND ALL
OTHER EXPRESSED,STATUTORY AND IMPLIED WARRANTIES APPLICABLE TO THE PRODUCT INCLUDING,
WITHOUT LIMITATION, ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE ARE
EXPRESSLY DISCLAIMED. The warranty information set forth above shall be governed by and construed in accordance
with the lawsof the State of North Carolina and, if applicable, the laws of the United States of America. The warranty, as
stated, is extended only to the original owner/user and is not assignable.
This warranty does not include parts or labor coverage for component failure or other damage resulting from:
• External electrical power failure or miswiring to Product for any reason.
• Adverse operating conditions as set forth in the owner/user manual for the Product.
• Failure to clean and/or maintain Product as set forth in the owner/ user manual for the Product.
• Equipment use in a non-commercial setting.
“LIMITATION OF LIABILITY AND OTHER WARRANTIES”

www.servware.com
800•768•5953
Service, Installation & Care Manual
11
NOTES

www.servware.com
800•768•5953
Service, Installation & Care Manual
12
NOTES

www.servware.com
800•768•5953
Parts & Service Manuals Available at:
Products LLC.
222 Hwy 58 South
Kinston, NC 28504
