SetPower X50 User manual
X50
User Manual
V1.0
CONTENT
1.SAFETY INSTRUCTIONS
2.SPECIFICATIONS
3.GETTING STARTED
4.OPERATION
5.ERROR CODES
6.WARRANTY
01
04
05
06
11
12
01
1.SAFETY INSTRUCTIONS
Please read the user manual and safety instructions
carefully before using the appliance.
The manufacturer cannot be held responsible for the damage
resulting from improper usage or incorrect operation.
The use of accessories that are not recommended by manufacturer
can cause injuries and will invalidate any warranty that you may
have.
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge. Unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
1 Disclaimer
Place the unit on a dry, secure surface, with adequate ventilation.
Please make sure the lid is closed and secure, and only open the
fridge when you need to.
Please cool down hot/warm food before put it into the unit.
Please defrost the unit when ice forms on the internal walls or lid.
Select proper target temperature according to corresponding need.
2 Energy Saving Tips
Please power off and unplug the unit before cleaning or Maintenance.
3 Cleaning & Maintenance
02
Please use non-abrasive detergent to cleaning the interior/exterior of
the fridge.
Please don't scrap the interior of the fridge to defrost/de-ice the
fridge.
Please don't pressure-wash/spray the fridge with a running water
hose.
Do not expose the unit to moderate/heavy rain.
Do not use this appliance near direct heat sources, such as flame or
radiator.
Do not place open containers of liquid inside the fridge.
Place/arrange the content of your fridge securely before using the
refrigerator inside a moving vehicle.
Do not use electrical devices inside the food storage compartments
of the appliance, unless approved/recommended by the
manufacturer.
Do not store explosive items, such as aerosol cans with a flammable
propellant in this appliance.
Do not touch the compressor or the condenser when the fridge is
operating.
Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
Please ensure the supply cord is not trapped or damaged before
setting up the appliance.
4 Dos and Don’ts
Failure to obey the following warnings could result in
death or serious injury:
Do not immerse the product in water, or use it in an excessively
muddy area.
Do not use the cooler for any purpose other than as a portable
cooling device.
DANGER
FALL HAZARD
Do not stand on the cooler, which may damage the unit or injure
yourself.
RISK OF CHILD ENTRAPMENT
Before you throw the unit away:
Take off the doors.
Leave the shelves in place so that children can not easily climb into it.
This appliance is intended to be used in household and similar
applications such as:
5 INTENDED TO USE
Staff kitchen areas in shops, offices and other working environments;
Farm houses and hotels, motels and other residential type
environments;
Bed and meal environments;
Catering and similar non-retail applications.
03
ELECTRICAL SHOCK HAZARD
52.8Qt (50L) FRIDGE
2.SPECIFICATIONS
04
MODEL X50
External dimensions(LxWxH)
Net weight
Supply voltage
Rated current
USB
16.0 kg (35.3 lbs)
DC 12V/24V
5V/2A(Output)
616×351×560 mm
(24.3x13.8x22.0 inch)
7.8A/3.9A
Storage volume 50 liters (52.8 quarts)
Temperature setting 20°C to + 20°C (-4°F to 68°F)-
468mm(18.4 inch)
616mm(24.3 inch)
560mm(22.0 inch)
250.4mm
(9.9 inch)
351mm(13.8 inch)
453.2mm(17.8 inch)
3.GETTING STARTE
Some Reminders
1. If the device was not placed in the upright position
after transit and delivery, please keep it upright for 24
hours to make sure that the compressor can work
properly.
2. If the device can’t turn on or you encounter other
problems for first time use, please contact us for help.
3. the empty unit before using it to enhance Pre-cool
system efficiency.
05
2. Temperature Adjustment
Press corresponding “+” or “–” to adjust the target
temperature, the target value will flash on the gauge.
The temperature will change one degree on every press.
Tips: Holding the button can accelerate the changing
process.
1 Switched-on/off.
With the unit plugged in, long press the Power Button “ ” to
switch on/off the unit.
4.OPERATION
06
888
°C
°F
MA X ECO H M L
88.8 V
The Power Button
Temperature
Adjustment Buttons
The Setting Button
USB
3 Settings Menu.
With the unit turned on, press and hold the setting Button “ ”
for 3 seconds to enter into the Settings Menu, which contains
three functions, Battery Protection Settings(H/M/L), °C / °F
Settings and MAX/ECO Settings. The target setting will
flash on the gauge when press and hold the setting Button
“ ” for 3 seconds, which means that the unit enter into the
setting menu. Then short press the setting button “ ” to
choose the 3 of functions when enter into the
Settings Menu.
a) MAX / ECO Settings: Short press “+” or “-” button to
toggle between MAX and ECO when MAX / ECO flashes
on the gauge.
b) °C / °F Settings: Short press “+” or “-” button to toggle
between °C and °F when °C / °F flashes on the gauge.
c) Battery Protection Settings: Short press “+” or “-” button
to switch H / M / L when H / M / L flashes on the gauge.
Battery protection Level
Power
Source
Mid Level is the Default Setting
HIGH MID LOW
Start-up Cut-off Start-up Cut-off Start-up Cut-off
12V
24V
12.4V
25.7V
11.1V
24.3V
11.7V
24.2V
10.4V
22.8V
10.9V
22.7V
8.5V
21.3V
Protection
Level
07
4. Built-in Battery Operation
There are two ways to charge the battery:
1) Use the specific cord from us to charge the battery.
When the battery is in the charging state, the light will
flash.
2) When the battery is running out, the light of the battery
will not be light up even though you long press the
button. At this point, plz put the battery into the fridge to
charge the battery for a few hours with the fridge
plugged in. After the battery is automatically charged,
it can be used again.
3) Put the battery into the fridge to charge the battery.
Then press and hold the button showing in Figure 1
for 3 seconds to switch the battery on. The light will
turn green and the capacity will be displayed on the
screen. When the battery is in the
charging state, the capacity will
show the dynamic effect. When it
is full, all 4 bars are illuminated,
as Figure2 shows.
How to charge the battery
888
°C
°F
MA X ECO H M L
88.8 V
N
E
P
O
Figure 1 Figure 2
08
Operating Mode and Battery Protection in
different power supply (Battery or External
Power Supply)
Current Power Supply
Current Power
Supply
No Power
Supply
Performed
Operation
Operating
Mode
Battery
Protection
Mode
Only Powered
by External
Power Supply
Only Powered
by Built-in
Battery
Powered by
both External
Power Supply
and Built-in
Battery
Plugged into
External Power
Supply(AC/DC)
Restore to the state before
the power is disconnected.
Plugged into
Built-in Battery
Switch to
ECO Mode
Switch to
L Level
No Changes
Plugged into
Built-in Battery
Switch to
ECO Mode
Disconnected
from Built-in
Battery
No Changes Switch to
M Level
Disconnected
from External
Power Supply
(AC/DC)
No Changes
Switch to
L Level
Switch to
M Level
09
Plugged into
External Power
Supply(AC/DC)
5. Wireless Charging
1. Make sure that the device you used could support wireless
charging and be placed in the charging area.
Note: We suggest you can move up a bit if your phone
could not be charging that was placed in the charging
area, showing in Figure 3.
2. Rated Charging Power induction coil: 15W
3. Only support charging one device at the same time.
888
°C
°F
MAX EC O H M L
88.8 V
Figure 3
10
11
5.ERROR CODES
Error Codes
E1 Low Input-Voltage Error
The Input DC voltage is below the protection setting and the battery protection
is activated.
E2 Fan Error
The cooling fan overloads with more than 1A Current.
E3 Motor Start Error
The motor of compressor is blocked or the pressure difference in the
refrigeration system is too high.
E4 Minimum Motor Speed Error
The compressor overloads and the motor can not maintain its minimum speed.
E5 Ambient Temperature Error
The refrigeration system overloads, or the ambient temperature is too high,
the control is overheated.
E6 Thermal Sensor Fault
Thermal Sensor is open-circuited or short-circuited.
E9 Connection Fault Between display screen and Controller
Board
When the battery failed, the battery icon displayed on the
screen will flash in particular frequency, as the below chart
shows.
Flashing
Frequency Error
1
OFF
Low Battery
Battery run out or battery insertion
not detected
The fridge will get error codes when the fridge does not work
properly.
6.WARRANTY & RETURN
1 Warranty
3-year Warranty for The Compressor
1-year General Warranty
For Warranty Registration, please contact us for more
information.
2 Customer Service
If the product is received damaged or defective, you can
contact us via these ways:
Customer Support Email: [email protected]
Order ID
Unit Model
Phone number
Description of the Defect
Delivery Address
Videos or Photos Related to The Defect
Note:
If calling the customer service number out of working time, you can
leave a voice/text message. We will respond to you after getting back
to work.
Videos or photos is preferred, because they can help us find out the
reason causing the issue and improve the efficiency of solving
problems.
Amazon Message Service
If you email us, these information needs to be included:
12
3 Return Policy
Amazon-Fulfilled Order
The postage is afforded by Amazon in Amazon return window.
If the return window is expired but still in warranty, the return policy will be same
as seller-fulfilled order.
Seller-Fulfilled Order
If the warranty is not expired, the postage is afforded when the return is
confirmed to be caused by QUALITY ISSUE of our products.
4 Refund & Replacement
For returns or exchanges, all accessories must be
returned in the original condition and packaging.
After the unit is shipped, please provide us with the
tracking number and carrier, so we can track it and
process the refund in time.
After the package is delivered back to our warehouse,
a full refund will be initiated.
If you file a return request on Amazon, we will process
it in 48 hours and contact you via Amazon Message
Service, please pay attention to your Amazon
Message Box or Email in order to avoid missing
important notifications.
13
OUR GUARANTEE
SetPower product comes with a 3-year warranty on the compressor
and 1 year warranty on all other parts for your peace of mind. In the
unlikely event this product fails when used according to our user
guide, we will either repair or replace it. For full warranty terms and
conditions on this product, please see the user guide.
We'd welcome you contact us [email protected] if you
have any question about the product.
This product is warranted for 3 years on the compressor and 1 year
for all other parts from the date of purchase. Our goods come with
guarantees that cannot be excluded under the Local Consumer
Law. You are entitled to a replacement or refund for a major failure
and compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure. Warranty does not cover
products that have not been used in accordance with user guide
or are outside the warranty terms and conditions.
Quality Service Guarantee
3-YEAR WARRANTY
Table of contents
Other SetPower Refrigerator manuals
