Thank you for selecting a Séura Television Mirror.
This product has been inspected and packaged carefully before shipment.
Please read this guide before beginning installation.
Please keep this manual for future reference.
Information in this manual is subject to change without prior notice.
FCC Information
This equipment has been tested and found to comply with limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and radiates radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
There is no guarantee that interference will not occur in a particular installation. If this equipment causes unacceptable interference to
radio and television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures.
 •Reorientorrelocatethereceivingantenna.
 •Increasetheseparationbetweentheequipmentandreceiver.
 •Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.
Consult the dealer or an experienced Radio/TV technician for additional help.
WARNINGS
To reduce the risk of re, electrical shock and other injuries, keep these safety
precautions in mind when installing, using, and maintaining your TV. The socket-
outlet should be installed near the equipment and be easily accessible. The TV
should be connected to a grounded main socket outlet.
WARNING: If you manipulate against the recommended usage, serious injury or
death to user may result.
To protect against electric shock, do not immerse the power cord, power
plug, or product in water or other liquid.
Do not overload AC outlets or extension cords. Overloading can cause
re or electric shock.
Close adult supervision is necessary when any product is used by or near
children.
Do not operate any product with a damaged cord or plug or operate it
after the appliance malfunctions or has been damaged in any manner.
Do not use the product close to any heat sources such as radiators, heat
registers, stoves, or other products that produce heat.
Do not let the power cord come in contact with hot surfaces.
If you notice any smoke or scorched smell near the product, unplug
power cord and refer to qualied personnel for service and/or repair.
Do not use or place any combustible or ammable substances near the
product.
To electrically disconnect the product, turn OFF the product, then remove
the electrical power plug from the outlet.
Do not place heavy articles or step on the product.
Do not place the product on an unstable cart, stand, tripod or table.
Do not use this product for other than intended use.
This Séura product is only intended for use indoors.
This product is not waterproof. Do not immerse this product in water and/
or expose to dripping or splashing water.
For added safety during a lighting storm, or when this product is left
unattended and unused for long periods of time, unplug it from the wall
outlet and disconnect the antenna.

3
CHAPTER 1
Before Use
1-1 In The Box.................................................5
1-2 Parts.......................................................... 5
1-3 Connections..............................................6
1-4 Remote Control......................................... 8
1-5 Insert Remote Control Batteries................9
1-6 Menu Controls on Remote........................ 9
1-7 Menu Conguration.................................10
1-8 Basic Operation .....................................10
CHAPTER 2
Installation
2-1 Recommended Location.........................12
2-2 Basic Installation Instructions .................12
CHAPTER 3
Connection
3-1 Preparation.............................................. 14
3-2 Connecting Power...................................14
3-3 Connecting TV Antenna .......................... 14
3-4 Connecting VIDEO / S-VIDEO................. 15
3-5 Connecting HDMI.................................... 15
3-6 Connecting Component Video................ 15
3-7 Connecting PC........................................16
3-8 Connecting Speaker Output ................... 16
3-9 Connecting RS-232C PC Control ........... 17
3-10 Connecting IR Output...........................18
3-11 Connecting IR Input.............................. 18
CHAPTER 4
Menu
4-1 The Menu System .................................... 21
4-2 Video Menu .............................................. 21
4-3 Audio Menu.............................................. 25
4-4 TV Menu................................................... 26
4-5 Setup Menu.............................................. 29
4-6 Parental Menu.......................................... 34
CHAPTER 5
Specifications
5-1 Specications........................................... 39
CHAPTER 6
Maintenance
6-1 Mirror Care ............................................... 41
6-2 Troubleshooting........................................ 41
Contents

4
1-1 In The Box
1-2 Parts
1-3 Connections
1-4 Remote Control
1-5 Insert Remote Control Batteries
1-6 Menu Controls on Remote
1-7 Menu Conguration
1-8 Basic Operation
1
Before Use

5
Please make sure the following items are included.
Television Mirror Product
Waterproof Remote Control
Power Cord & Power Adapter
User Manual
1-1 In The Box
1-2 Parts
Mirror Surface
FRONT
BOTTOM
LEFT
LCD
Screen
Internal
Speakers
On-Unit
Control
Buttons:
Volume
(56)
Channel
(56)
Source
Menu
Power
RECYCLE
All Séura packaging is 100% recyclable. Please
utilize recycling facilities in your area to dispose of
all paper and plastic packaging materials.

6
For more detailed information, visit page 41
2 Channel Amplied
Speaker Out
Internal/External
Sound Selector
RS232
Input
RF Coaxial
Antenna
USB
IR Input (pink)
Line Audio
Out
(black)
15 Pin
VGA
Input
HDMI
Input
Power
Adapter
Input
Stereo Audio
Out
(green)
PC Audio In
(blue)
Composite
Component
Input YPbPr
IR Output (blue)
1.3 Connections
19" LCD
Back View
19" LCD
(BACK VIEW)
BACK VIEW
On-Unit
Control Buttons
(Labeled on
Product)

7
For more detailed information, visit page 41
2 Channel Amplied
Speaker Out
RS232
Input RF Coaxial
Antenna
USB
IR Input (pink)
Line Audio
Out
(black)
15 Pin
VGA
Input
HDMI
Input
Power
Adapter
Input
Stereo Audio
Out
(green)
PC Audio In
(blue)
Composite
Component
Input YPbPr IR Output (blue)
BACK VIEW
10" LCD
Back View
1.3 Connections (cont.)
10" LCD
(BACK VIEW)
Internal/External
Sound Selector
On-Unit
Control Buttons
(Labeled on
Product)

8
2010 Remote Redesign
Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
1
8
7
6
5
2
3
4
9
12
10
11
13
14
Waterproof remote performs best within 20 ft (6 m) of the LCD and within 30º to the left or right of the display.
1-4 Remote Control
REMOTE FUNCTIONS
Power
Turns television mirror on and off
Last
Recalls last channel viewed
Closed Caption
Turns on/off subtitles
Guide
View available electronic program guide
Mute
Turns off/on audio
Sleep
Activates sleep timer
Zoom
Zoom current picture
Input
Selection of content input
Display
Display current program details
Number Pad
Numerical selection for channels
and settings
Enter
Conrms selection
Menu Controls
Allows navigation of main menu settings
Channel
Up/Down selection of channels
Volume
Up/Down selection of volume
1
2
3
4
5
6
7
8
9
10
11
12
13
14

9
2010 Remote Redesign
Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
Remove the battery cover on the bottom of the remote using the
tool included or a coin.
Insert 2 AAA batteries.
Ensure waterproof ring is securely in place before returning cover.
Return cover and turn to “CLOSE” position.
1-5 Insert Remote Control Batteries
Press MENU button on the remote
control to display main menu.
1-6 Menu Controls on Remote
Press menu control arrow buttons to
navigate through menus. Use the right
arrow (4) to move to sub menu of a
selected main menu.
Press EXIT button to return from sub
menu to main menu or from main
menu to menu removal.
To change a selected menu setting,
use Menu control buttons (34).
Functions of the TV set can be controlled by the Menu Control Center on the remote
control. Familiarity with these functions will provide ease of operation.
2010 Remote Redesign
Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
2010 Remote Redesign
Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
2010 Remote Redesign
Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
2010 Remote Redesign
Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit

10
Press MENU to open the menu window. Navigate using 5 or 6 to select the desired menu. Press 4 or OK to enter the menu. Use 5 or 6 within
the selected menu to navigate to a submenu or setting to adjust. Press 4 or OK to enter the submenu or use 3or 4 to adjust selected setting. Press
EXIT at any time, or wait 10 seconds to exit the menu.
1-7 Menu Configuration
OR
1-8 Basic Operation
Power On / Off
Press the Power / Standby button on the remote control or on the side panel to turn
on the unit.
Press Power / Standby button on the remote control or on the side panel again to
return the display to standby (off) mode.
Selection
of Input Mode
Press the Source button to display the signal source menu.
Press 5 or 6to select the signal source you desire, then press OK to conrm.
2010 Remote Redesign
Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
2010 Remote Redesign Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
2010 Remote Redesign Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
2010 Remote Redesign
Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
2010 Remote Redesign
Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
2010 Remote Redesign
Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
2010 Remote Redesign
Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
2010 Remote Redesign
Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
2010 Remote Redesign
Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
2010 Remote Redesign Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
2010 Remote Redesign Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
2010 Remote Redesign
Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
2010 Remote Redesign
Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
2010 Remote Redesign
Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
2010 Remote Redesign
Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit
2010 Remote Redesign
Final
waterproof
last
ok
enter
channel
volume
cc
guide
mute
sleep
zoom
input display menu exit

11
2-1 Recommended Location
2-2 Installation Instructions
2
Installation
WARNINGS
Do not handle or remove your television mirror from the packaging until it is ready to be installed.
To avoid damage to the television mirror, only transport it in a vertical position.
It is highly recommended that at least three (3) persons assist in the installation of the television mirror.
Mirror suction cups are not recommended for use in the installation of your television mirror.
Inspect the desired location for installation and be aware of all electrical wiring pathways, water pipes, gas lines, or
other potentially hazardous conditions that may exist to protect from accidental damage during creation of on-site
conditions.
Ensure all required electrical specications are adhered to and have been installed by the appropriate individuals and
are code approved.
Ensure all framing requirements, if needed have been completed to building code and pose no structural issues.
It is REQUIRED that this product is plugged into an electrical outlet protected by a Ground Fault Circuit Interrupter
(GFCI) to protect against electric shock, re, and/or injury. Failure to do so will void any warranty for this product.
Only qualied individuals should attempt to service the product. Removing covers can expose you to high voltage
and other dangerous conditions.

12
2-2 Basic Installation Instructions
NOTE: All SÉURA drawing packages indicate generalized nominal residential wood framing construction, and are not indicative of any particular
building code. It is the installers responsibility that all electrical, audio/visual, and framing construction are code compliant to the municipality
in which the product is being installed. Modications made to SÉURA’s recommendations are at the sole discretion of the installer and release
SÉURA of all liability.
1. Reference installation specifications included with your product for specific mounting
instructions designed for your exact mirror size and configuration.
2. Verify that the wall is built to the provided specications.
3. Install mounting brackets.
 •RefertoFastenerPacketfordetailedmountinginstructions.
 •Ensuremountingbracketsaresecurelyfastenedusingwood
framing members where possible.
4. Transport product in a vertical position to desired location to avoid product ex or damage.
5. Connect power supplies and audio/video components.
 •Itisstronglyrecommendedtotestallelectricalandelectronicdevicestoverifyproperintegrationandfunctionalitybeforesecurely
mounting it to the wall.
6. Position television mirror close to wall surface and securely engage mounting brackets.
 •Allowfora1/4”ventilationgapforproperairowandheattransfer.
7. Check to ensure the television mirror is fully engaged and secure to the mounting brackets.
8. Reference the appropriate electronics manual for television mirror operating instructions.
2-1 Recommended Installation Location
The environment in which the television mirror
product is installed will affect the product’s
performance. The key factor to consider for proper
installation is surrounding and ambient light. Use the
following guidelines to maximize the performance of
the SÉURA product:
Type of Lighting: Avoid direct natural sunlight and
excessive uorescent lighting on the television
display. These conditions will diminish the television
brightness, and hinder its performance.
Light Direction: Avoid directing lights toward the
mirror. Position lights such that they provide light on
the person or object to be reected, not the mirror
itself. For example, lights on the wall next to the
mirror are preferred over lights located on the ceiling
in the center of the room.
Background Colors: Sidewalls and furnishings that
are dark, uniform, and non-reective will provide
for better performance of the television quality.
Bright colors, patterns, and contrasting colors will
minimize the quality of the display.
N
N
LCD
1/4"
VENT
GAP
RETAINING
CLIP
MIRROR
SURFACE
INTERLOCKING
Z-BRACKETS
WALL
SURFACE
INTERFACE
PLATE
TYPICAL WALL SURFACE
SHOWING THE NEEDED
ROUGH OPENING
INTERLOCKING
BRACKETS
TYPICAL A/V AND
POWER LOCATION
SHEET
2
Screen Size Class: 32”,40”, 46", & 52”
Panel Type X-GenLCD Panel
10-bit LCD Panel Yes
Pixel Resolution Full1920 x 1080 HD Resolution
Backlight System FullArray LED
Viewing Angles 176ºH / 176º V
LED Life (hours)1 100,000
Audio System 10W+ 10W
120HzFrameRate Yes
Tuning System ATSC/ QAM / NTSC
Spectral Contrast Engine Level MC(over 2,000,000:1)
Aspect Ratio 16:9
Response Time 4ms
Features:
AQUOS® Series Yes
AQUOS Net Yes(N/A on 32” LCD)
AQUOS Advantage SM Support Yes(N/A on 32” LCD)
Digital Still Picture Display Yes
Game-Optimized Yes
Terminals Inputs:
HDMI™ 4 (v1.3 with deep color)
HD Component 2 (1080p compatible)
Composite Video RCA x 2
S-Video 4-pin DIN x 1
Audio Inputs (L/R) 4 RCA
RS-232C 1
PC 1 (15-pin D-sub)
Ethernet Input 1 (N/A on 32” LCD)
Power:
Power Consumption AC (watts) 32” = 130W
40” = 160W
46”= 200W
52”= 250W
32",40",46", 52", 65" PREMIER:
BACK LIGHT: 16
BRIGHTNESS: 0
CONTRAST: 33
COLOR: -9
TINT: 5
SHARPNESS: -4
TOLERANCES
DIMENSIONSARE IN INCHES & [mm]
FRACTIONAL
1/8[3mm]
ANGULAR:MACH
1.0
BEND
1.0
[.5m]
TWOPLACE DECIMAL
.03[.8mm]
THREEPLACE DECIMAL
.015[.4mm]
PROPRIETARYAND CONFIDENTIAL
THEINFORMATION CONTAINED IN
THISDOCUMENT IS THE SOLE
PROPERTYOF THE MANUFACTURER.
ANYREPRODUCTION IN PART, OR
ASA WHOLE, WITHOUT THE WRITTEN
PERMISSIONOF MANUFACTURER, IS
PROHIBITED.
16"
10"
74 1/4"
MIRROR DIMENSION
50"
MIRROR DIMENSION
29 1/8" 29 1/8"
4 1/2" 35 1/2"
19" LCD
SCREEN
1" LIFT-OFF
CLEARANCE
NEEDED TO
MOUNT UNIT
1 7/16"
TOTAL
UNIT DEPTH
3/4"
IN
WALL DEPTH
11/16"
OFF
WALL DISTANCE
3/16"
1"
POLISHED STAINLESS
MIRROR CLIPS
C-R-7450-19.2-EN-NI 74-1/4"(W) x 50"(H) Custom Recessed TV Mirror with 19" LCD and Enhanced Glass
Beyond Audio Video
8045B.10.18.10
18OCTOBER2010
HIS "C"
Sales Order / Inv. Number
Item and Description
Date Created
Reseller
SHEET 1
SIGNATURE
AND DATE
REQUIRED
FRONT VIEW
SIDE VIEW
DATE:
SIGNATURE:
NOTE:
PLEASE SIGN AND DATE THIS PAGE BEFORE RETURNING TO SEURA. ONLY THIS PAGE NEEDS TO BE
RETURNED. BY RETURNING THIS SHEET, YOU ARE AGREEING TO ALL DIMENSIONS SHOWN ON ALL DRAWING
SHEETS. FOR CUSTOM UNITS, WE WILL NOT START THE BUILD PROCESS WITHOUT AN AUTHORIZED SIGNATURE.
FOR DRAWINGS THAT REQUIRE REVISIONS: SEND THE REVISIONS TO SEURA ON THE ORIGINAL DRAWINGS.
DO NOT SIGN UNTIL ALL REQUIRED DIMENSIONS ARE VERIFIED AND ACCEPTED.
AFTER THE DRAWINGS ARE UPDATED, A REVISED DRAWING PACKAGE WILL BE RE-SENT FOR SIGNATURE.
TOLERANCES
DIMENSIONSARE IN INCHES
FRACTIONAL
1/8 [3mm]
ANGULAR:MACH
1.0
BEND
1.0
[.5m]
TWOPLACE DECIMAL
.03 [.8mm]
THREEPLACE DECIMAL
.015 [.4mm]
PROPRIETARYAND CONFIDENTIAL
THEINFORMATION CONTAINED IN
THISDOCUMENT IS THE SOLE
PROPERTYOF THE MANUFACTURER.
ANYREPRODUCTION IN PART, OR AS
AWHOLE, WITHOUT THE WRITTEN
PERMISSIONOF MANUFACTURER, IS
PROHIBITED.
www.seura.com
1.800.95.SEURA
PH. 920.857.9069
FAX [phone]

13
3-1 Preparation
3-2 Connecting Power
3-3 Connecting TV Antenna
3-4 Connecting VIDEO / S-VIDEO
3-5 Connecting HDMI
3-6 Connecting Component Video
3-7 Connecting PC
3-8 Connecting Speaker Output
3-9 Connecting RS-232C PC Control
3-10 Connecting IR Output
3-11 Connecting IR Input
3
Connection

14
Please read the relevant external equipment operation manual (DVD
player, etc.) carefully before making connections.
3-1 Preparation
3-2 Connecting Power
The TV automatically adjusts voltage.
Power cable is USA A-Type 3-conductor, shielded,
detachable.
AC Receptacles: 110~240v, x 1, 50/60, GFI circuit.
3-3 Connecting TV Antenna
Connect cable to TV Coaxial input connector with an
outdoor or wall outlet antenna output.
Turn on the TV after all connections.
Watching Analog TV & Digital TV
•AnalogTVsignalhasachannelnumberstructure
of 1, 2, 3, 4, 5, etc., but Digital TV signal has a
channel number structure of 1-1, 2-1, 3-1, 4-1,
5-1, etc.
•IfyoupressTVbuttonontheremotecontrol,its
input source changes from Analog to Digital or
Digital to Analog.
Antenna Outlet
Séura TV Mirror (back view)
Video Source
Video Audio
RF Coaxial Antenna
Power Outlet
Séura TV Mirror
(back view)
L R
Séura TV Mirror (back view)
High Definition
Video Source
HDMI
Séura TV Mirror (back view)
Component
Video Source
Séura TV Mirror (back view)
Audio
L
Y Pb Pr
R
External
Speakers
Séura TV Mirror (back view)
PC Source
Séura TV Mirror (back view)
15-Pin VGA PC Audio
Output
(green)
PC Audio In
(blue)
PC Source
Séura TV Mirror (back view)
Antenna Outlet
Séura TV Mirror (back view)
Video Source
Video Audio
RF Coaxial Antenna
Power Outlet
Séura TV Mirror
(back view)
L R
Séura TV Mirror (back view)
High Definition
Video Source
HDMI
Séura TV Mirror (back view)
Component
Video Source
Séura TV Mirror (back view)
Audio
L
Y Pb Pr
R
External
Speakers
Séura TV Mirror (back view)
PC Source
Séura TV Mirror (back view)
15-Pin VGA PC Audio
Output
(green)
PC Audio In
(blue)
PC Source
Séura TV Mirror (back view)
WARNING
Whenever you connect an external audio or video
system to your TV, ensure that all elements are
switched off.
Before connecting power, please
check your power adapter for
compatibility with wall outlet.
Power cable should be rmly
connected to the power source.

15
Connect Video/Audio cables to the video ports of
the TV and camcorder, gaming consoles, VCR, DVD
player or Set-Top box.
Press SOURCE on the remote control and select
A/V Video.
3-4 Connecting VIDEO
3-5 Connecting HDMI
Connect HDMI cable to HDMI port of TV and DVD
player, VCR, Set-Top box or camcorder.
Press SOURCE on the remote control and select
HDMI Video.
Antenna Outlet
Séura TV Mirror (back view)
Video Source
Video Audio
RF Coaxial Antenna
Power Outlet
Séura TV Mirror
(back view)
L R
Séura TV Mirror (back view)
High Definition
Video Source
HDMI
Séura TV Mirror (back view)
Component
Video Source
Séura TV Mirror (back view)
Audio
L
Y Pb Pr
R
External
Speakers
Séura TV Mirror (back view)
PC Source
Séura TV Mirror (back view)
15-Pin VGA PC Audio
Output
(green)
PC Audio In
(blue)
PC Source
Séura TV Mirror (back view)
Antenna Outlet
Séura TV Mirror (back view)
Video Source
Video Audio
RF Coaxial Antenna
Power Outlet
Séura TV Mirror
(back view)
L R
Séura TV Mirror (back view)
High Definition
Video Source
HDMI
Séura TV Mirror (back view)
Component
Video Source
Séura TV Mirror (back view)
Audio
L
Y Pb Pr
R
External
Speakers
Séura TV Mirror (back view)
PC Source
Séura TV Mirror (back view)
15-Pin VGA PC Audio
Output
(green)
PC Audio In
(blue)
PC Source
Séura TV Mirror (back view)
Antenna Outlet
Séura TV Mirror (back view)
Video Source
Video Audio
RF Coaxial Antenna
Power Outlet
Séura TV Mirror
(back view)
L R
Séura TV Mirror (back view)
High Definition
Video Source
HDMI
Séura TV Mirror (back view)
Component
Video Source
Séura TV Mirror (back view)
Audio
L
Y Pb Pr
R
External
Speakers
Séura TV Mirror (back view)
PC Source
Séura TV Mirror (back view)
15-Pin VGA PC Audio
Output
(green)
PC Audio In
(blue)
PC Source
Séura TV Mirror (back view)
Connect component cable to component ports
of TV and DVD player, VCR, Set-Top box or
camcorder.
Connect Audio RCA cables to L/R ports.
Press SOURCE on the remote control and select
YPbPr Component Video
3-6 Connecting Component Video

16
3-8 Connecting Speaker Output
Note: When this selector is switched to Fixed, sound is adjusted with the volume buttons on the remote control or the LCD housing. Sound via the
audio output terminal is not adjustable, and outputs maintain a constant level.
Wire Input
DETAIL VIEW
Eurotype Degson
Speaker Connector
2-Channel:
•Leftchannel
•Rightchannel
To use external speakers (Variable audio), switch
the audio selector located on the LCD unit to
Variable. Sound via the audio output terminal
can be adjusted with the volume buttons on
the remote control. When selected, the Variable
option mutes the internal audio system.
3-7 Connecting PC
Connect 15-pin cable to 15-pin port on the TV
and PC.
Connect audio cable to audio output of a PC
(stereo jack) and PC audio input port of the TV.
Press SOURCE on the remote control to select
VGA.
Antenna Outlet
Séura TV Mirror (back view)
Video Source
Video Audio
RF Coaxial Antenna
Power Outlet
Séura TV Mirror
(back view)
L R
Séura TV Mirror (back view)
High Definition
Video Source
HDMI
Séura TV Mirror (back view)
Component
Video Source
Séura TV Mirror (back view)
Audio
L
Y Pb Pr
R
External
Speakers
Séura TV Mirror (back view)
PC Source
Séura TV Mirror (back view)
15-Pin VGA PC Audio
Output
(green)
PC Audio In
(blue)
PC Source
Séura TV Mirror (back view)
Antenna Outlet
Séura TV Mirror (back view)
Video Source
Video Audio
RF Coaxial Antenna
Power Outlet
Séura TV Mirror
(back view)
L R
Séura TV Mirror (back view)
High Definition
Video Source
HDMI
Séura TV Mirror (back view)
Component
Video Source
Séura TV Mirror (back view)
Audio
L
Y Pb Pr
R
External
Speakers
Séura TV Mirror (back view)
PC Source
Séura TV Mirror (back view)
15-Pin VGA PC Audio
Output
(green)
PC Audio In
(blue)
PC Source
Séura TV Mirror (back view)

17
3-9 Connecting RS-232C PC Control
COMMAND TABLE
COMMANDS NOT INDICATED HERE ARE NOT GUARANTEED TO OPERATE
CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS
POWER ON COMMAND SETTING R S P W 0 _ _ _ OFF THE POWER ON COMMAND REJECTED
1 _ _ _ ON THE POWER ON COMMAND ACCEPTED
POWER SETTING P O W R 0 _ _ _ POWER OFF IT SHIFTS TO STANDBY
1 _ _ _ POWER ON POWER ON
INPUT SELECTION TOGGLE I T G D X _ _ _ (TOGGLE) IT INPUT- SWITCHES BY THE TOGGLE. (IT IS THE SAME AS AN INPUT CHANGE KEY)
TV I T V D 0 _ _ _ IT INPUT- SWITCHES TO TV. (A CHANNEL REMAINS AS IT IS. (LAST MEMORY))
INPUT 1-5 I A V D * _ _ _ INPUT TERMINAL NUMBER IT INPUT- SWITCHES TO INPUT 1-INPUT 5. (1 AV) (2 S-V) (3 COMP) (4 VGA) (5 HDMI)
VOLUME V O L M * * _ _ VOLUME 0-99
VIEW MODE W I D E * _ _ _ 1: S.STRETCH [AV] ALTHOUGH IT CAN CHOOSE NOW, IT IS TOGGLE OPERATION IN INSIDE.
2: SIDE BAR [AV], ONLY AVAILABLE WHEN 4:3 SIGNAL IS BEING INPUT.
3: ZOOM [AV], ONLY AVAILABLE WHEN 4:3 SIGNAL IS BEING INPUT.
4: STRETCH [AV] ONLY AVAILABLE WHEN 4:3 SIGNAL IS BEING INPUT.
5: NORMAL [PC]
6: ZOOM[PC]
7: STRETCH[PC]
8: DOT BY DOT[PC][AV]
9: FULL SCREEN [AV] [AV] ONLY AVAILABLE WHEN 1080i/p IS BEING INPUT.
MUTE M U T E * _ _ _ 1: ON, 2: OFF
SLEEP TIMER O F T M * _ _ _ 0: OFF, 1: OFF TIMER-30 MIN.,
2: OFF TIMER-60 MIN.,
3: OFF TIMER-90 MIN.,
4: OFF TIMER-120 MIN.
CHANNEL DIRECT D A 2 P * * * * (0100-9999) (EX: 50.2=50 02) DIGITAL AIR (TWO-PART NUMBERS, 3-DIGIT PLUS 2-DIGIT)
D C 2 U * * * _ (1-999) (EX: 50.2=050 002) DIGITAL CABLE (TWO -PART NUMBERS, 3-DIGIT PLUS 3 DIGIT)
CHANNEL UP C H U P X _ _ _ THE CHANNEL NUMBER OF TV +(X) IF IT IS NOT TV DISPLAY, IT WILL INPUT-SWITCH TO TV. (SAME FUNCTION AS CH5)
CHANNEL DOWN C H D W X _ _ _ THE CHANNEL NUMBER OF TV -(X) IF IT IS NOT TV DISPLAY, IT WILL INPUT-SWITCH TO TV. (SAME FUNCTION AS CH6)
NOTE:
UNDERSCORES (_) WITHIN THE PARAMETER COLUMN REPRESENT A SINGLE SPACE (hex 20)
ASTERISKS(*) WITHIN THE PARAMETER COLUMN REPRESENT A VALUE WITHIN THE RANGE INDICATED IN THE CONTROL CONTENTS
X WITHIN THE PARAMETER COLUMN REPRESENTS A VALUE WITHIN THE RANGE INDICATED IN THE CONTROL CONTENTS
* ALL COMMANDS MUST END WITH A LINE FEED (hex OA)
Attach RS-232C cable cross-type to the supplied Din/D-Sub RS-232C.
Set the RS-232C communication settings on the PC to match the
communication conditions listed.
Model: 19.3
Baud rate: 9600 bps
Data length: 8 bits
Parity bit: None
Stop bit: 1 bit
Flow control None
Model: 19.3 ALT / Hydra / 10.3
Baud rate: 115200 bps
Data length: 8 bits
Parity bit: None
Stop bit: 1 bit
Flow control None
COMMUNICATION CONDITIONS
Send the control commands from the PC via the RS-232C connector.
1. The LCD operates according to the received command and sends
a response message to the PC. Do not send multiple commands at
the same time.
2.Wait until the PC receives the conrmation response before sending
the next command.
Antenna Outlet
Séura TV Mirror (back view)
Video Source
Video Audio
RF Coaxial Antenna
Power Outlet
Séura TV Mirror
(back view)
L R
Séura TV Mirror (back view)
High Definition
Video Source
HDMI
Séura TV Mirror (back view)
Component
Video Source
Séura TV Mirror (back view)
Audio
L
Y Pb Pr
R
External
Speakers
Séura TV Mirror (back view)
PC Source
Séura TV Mirror (back view)
15-Pin VGA PC Audio
Output
(green)
PC Audio In
(blue)
PC Source
Séura TV Mirror (back view)

18
3-10 Connecting IR Output
3-11 Connecting IR Input
Using the IR (infrared) Output terminals on the
LCD, you can operate components of your audio
video system that are not in the line of sight of
the remote control, such as a DVD player or
Cablebox.
The IR sensor on the LCD will receive IR
commands from a remote and distribute them
to the 3.5mm IR Output terminals located on the
LCD. For most devices, use an IR emitter with a
3.5mm mono plug. Attach the IR emitter side to
the IR receiver of the device to be controlled and
attach the 3.5mm mono plug to the LCD.
Alternately, if the device being controlled has
3.5mm IR input, simply use a male-to-male
3.5mm mono plug to connect the LCD and
device.
Using the IR (infrared) Input terminal on
the LCD, you can control the LCD using
IR commands sent from a keypad, IR
Receiver, or other AV Control System.
Attach a 3.5mm mono plug into the LCD
and use the discrete IR codes provided at
www.seura.com/IRCodes.doc
Video Source
Cablebox
Séura TV Mirror (back view)
DVD Player Other
Device
IR Receiver, Keypad,
or other AV System Control
Séura TV Mirror (back view)
Control System
Video Source
Cablebox
Séura TV Mirror (back view)
DVD Player Other
Device
IR Receiver, Keypad,
or other AV System Control
Séura TV Mirror (back view)
Control System

19
Remote Hexadecimal Codes
Power Toggle
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 0047 000A 0047 000A 001F 000A 0047 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 0718 000A 0047 000A 001F 000A 001F
000A 001F 000A 001F 000A 0047 000A 001F 000A 001F 000A 0047 000A 001F
000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 06A0
Menu
0000 006B 0000 0020 000A 0048 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 001F 000A 001F 000A 001F 000A 001F 000A 0047 000A 001F
000A 001F 000A 0047 000A 001F 000A 0768 000A 0048 000A 001F 000A 001F
000A 001F 000A 001F 000A 0048 000A 0048 000A 0048 000A 0048 000A 0048
000A 001F 000A 0048 000A 0048 000A 001F 000A 0048 000A 0654
Source
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 0047
000A 001F 000A 0047 000A 001F 000A 06C8 000A 0047 000A 001F 000A
001F 000A 001F 000A 001F 000A 0047 000A 001F 000A 001F 000A 001F
000A 0047 000A 001F 000A 001F 000A 0047 000A 001F 000A 0047 000A 06F2
Display
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 0047 000A 0047 000A 001F 000A 0047 000A 0047 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 06D4 000A 0047 000A 001F 000A
001F 000A 001F 000A 001F 000A 001F 000A 001F 000A 0047 000A 001F 000A
001F 000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 06C7
Exit
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 0047 000A 0047 000A 001F 000A 001F 000A 0047 000A 0047 000A 0047
000A 0047 000A 0047 000A 001F 000A 0685 000A 0047 000A 001F 000A 001F
000A 001F 000A 001F 000A 001F 000A 001F 000A 0047 000A 0047 000A 001F
000A 001F 000A 001F 000A 001F 000A 001F 000A 0047 000A 071A
Up
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 001F 000A 0047
000A 001F 000A 0047 000A 001F 000A 06C8 000A 0047 000A 001F 000A
001F 000A 001F 000A 001F 000A 001F 000A 001F 000A 001F 000A 0047
000A 001F 000A 0047 000A 001F 000A 0047 000A 001F 000A 0047 000A 06F6
Down
0000 006B 0000 0020 000A 0048 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 001F 000A 001F 000A 0047 000A 0048 000A 001F 000A 0048
000A 001F 000A 0048 000A 001F 000A 0718 000A 0047 000A 001F 000A 001F
000A 001F 000A 001F 000A 0047 000A 0047 000A 0047 000A 001F 000A 001F
000A 0048 000A 001F 000A 0047 000A 001F 000A 0047 000A 06A4
Left
0000 006B 0000 0020 000A 0048 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 001F 000A 001F 000A 0047 000A 0048 000A 001F 000A 0048
000A 001F 000A 0048 000A 001F 000A 0718 000A 0047 000A 001F 000A 001F
000A 001F 000A 001F 000A 0047 000A 0047 000A 0047 000A 001F 000A 001F
000A 0048 000A 001F 000A 0047 000A 001F 000A 0047 000A 06A4
Right
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 0047 000A 0047 000A 001F 000A 0047 000A 0047 000A 0047
000A 0047 000A 0047 000A 001F 000A 06A0 000A 0047 000A 001F 000A
001F 000A 001F 000A 001F 000A 0047 000A 001F 000A 001F 000A 0047 000A
001F 000A 001F 000A 001F 000A 001F 000A 001F 000A 0047 000A 071B
Enter
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 0047 000A 0048 000A 0047 000A 001F 000A 0048 000A 0048 000A 0047
000A 0048 000A 0048 000A 001F 000A 0678 000A 0048 000A 001F 000A 001F
000A 001F 000A 001F 000A 001F 000A 001F 000A 001F 000A 0048 000A 001F
000A 001F 000A 001F 000A 001F 000A 001F 000A 0047 000A 074E
Sleep
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 0047 000A 0047 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 06FC 000A 0047 000A 001F 000A
001F 000A 001F 000A 001F 000A 0047 000A 001F 000A 0047 000A 001F 000A
001F 000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 059B
Zoom
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 001F 000A 001F 000A 001F 000A 001F 000A 0047 000A 001F
000A 0048 000A 0048 000A 001F 000A 0740 000A 0048 000A 001F 000A 001F
000A 001F 000A 001F 000A 0048 000A 0048 000A 0047 000A 0048 000A 0047
000A 001F 000A 0048 000A 001F 000A 001F 000A 0047 000A 068B
EPG
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 0047 000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 001F
000A 001F 000A 0047 000A 001F 000A 06C8 000A 0047 000A 001F 000A
001F 000A 001F 000A 001F 000A 001F 000A 001F 000A 001F 000A 001F 000A
0047 000A 001F 000A 0047 000A 0047 000A 001F 000A 0047 000A 06EE
Mute
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 06D4 000A 0047 000A 001F 000A
001F 000A 001F 000A 001F 000A 001F 000A 001F 000A 001F 000A 0047 000A
001F 000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 06C9
ch+
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 0047 000A 001F 000A 001F 000A 001F 000A 0048 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 0740 000A 0047 000A 001F 000A 001F
000A 001F 000A 001F 000A 001F 000A 0047 000A 0047 000A 0047 000A 001F
000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 067E
ch-
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 001F 000A 0048 000A 001F 000A 001F
000A 001F 000A 0048 000A 001F 000A 0740 000A 0047 000A 001F 000A 001F
000A 001F 000A 001F 000A 0048 000A 001F 000A 0048 000A 0048 000A 001F
000A 0047 000A 0048 000A 0048 000A 001F 000A 0047 000A 0683
vol+
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 001F 000A 0047 000A 001F 000A 0047 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 0740 000A 0047 000A 001F 000A 001F
000A 001F 000A 001F 000A 0047 000A 0047 000A 001F 000A 0047 000A 001F
000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 067C
vol-
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 0047 000A 001F 000A 0047 000A 001F 000A 0047 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 0718 000A 0047 000A 001F 000A 001F
000A 001F 000A 001F 000A 001F 000A 0047 000A 001F 000A 0047 000A 001F
000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 06A8
1
0000 006C 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 0047 000A 001F 000A 001F 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 074A 000A 0047 000A 001F 000A
001F 000A 001F 000A 001F 000A 001F 000A 0047 000A 0047 000A 0047
000A 0047 000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 0652
2
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 0768 000A 0047 000A 001F 000A 001F
000A 001F 000A 001F 000A 0047 000A 001F 000A 0047 000A 0047 000A 0047
000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 0651
3
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 0047 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 0723 000A 0047 000A 001F 000A 001F
000A 001F 000A 001F 000A 001F 000A 001F 000A 0047 000A 0047 000A 0047
000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 067D
4
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 001F 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 0768 000A 0047 000A 001F 000A 001F
000A 001F 000A 001F 000A 0047 000A 0047 000A 001F 000A 0047 000A 0047
000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 054F
5
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 0047 000A 001F 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 0740 000A 0047 000A 001F 000A 001F
000A 001F 000A 001F 000A 001F 000A 0047 000A 001F 000A 0047 000A 0047
000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 067E
6
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 0047 000A 0047 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 0718 000A 0047 000A 001F 000A 001F
000A 001F 000A 001F 000A 001F 000A 001F 000A 001F 000A 0047 000A 0047
000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 06A7
7
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 0047 000A 0047 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 0718 000A 0047 000A 001F 000A 001F
000A 001F 000A 001F 000A 001F 000A 001F 000A 001F 000A 0047 000A 0047
000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 06A6
8
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 001F 000A 001F 000A 0047 000A 001F 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 0768 000A 0047 000A 001F 000A 001F
000A 001F 000A 001F 000A 0047 000A 0048 000A 0047 000A 001F 000A 0047
000A 0047 000A 0048 000A 0047 000A 001F 000A 0048 000A 065B
9
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 0047 000A 001F 000A 001F 000A 0047 000A 001F 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 0740 000A 0047 000A 001F 000A 001F
000A 001F 000A 001F 000A 001F 000A 0047 000A 0047 000A 001F 000A 0047
000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 067E
0
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 0047 000A 001F 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 0740 000A 0047 000A 001F 000A 001F
000A 001F 000A 001F 000A 0047 000A 001F 000A 0047 000A 001F 000A 0047
000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 0678
. (Dot)
0000 006C 0000 0020 000A 0046 000A 001E 000B 001E 000A 001E 000B
0047 000A 001E 000B 0046 000A 001E 000B 0046 000A 0046 000A 0046
000B 001E 000A 001E 000B 0046 000B 001D 000B 06A5 000B 0046 000B
001E 000A 001E 000A 001E 000A 0046 000B 0046 000A 001E 000B 0046
000A 001F 000A 001E 000A 001E 000A 0046 000A 0046 000A 001E 000A
0045 000A 0696
Enter
0000 006B 0000 0020 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F
000A 0047 000A 0047 000A 001F 000A 0047 000A 001F 000A 001F 000A 001F
000A 001F 000A 0047 000A 001F 000A 06FC 000A 0047 000A 001F 000A
001F 000A 001F 000A 001F 000A 001F 000A 001F 000A 0047 000A 001F
000A 0047 000A 0047 000A 0047 000A 0047 000A 001F 000A 0047 000A 06A1
Discrete Remote Hexadecimal Codes
Power On(only)
0000 006d 0000 0020 000a 0047 000a 001e 000a 001e 000a 001e 000a 0047
000a 001e 000a 0047 000a 001e 000a 0047 000a 001e 000a 001e 000a 0047
000a 001e 000a 0047 000a 001e 000a 068b 000a 0047 000a 001e 000a 001e
000a 001e 000a 0047 000a 0047 000a 001e 000a 0047 000a 001e 000a 0047
000a 0047 000a 001e 000a 0047 000a 001e 000a 0047 000a 068b
Power Off(only)
0000 006d 0000 0020 000a 0047 000a 001e 000a 001e 000a 001e 000a 0047
000a 0047 000a 0047 000a 001e 000a 0047 000a 001e 000a 001e 000a 0047
000a 001e 000a 0047 000a 001e 000a 068b 000a 0047 000a 001e 000a 001e
000a 001e 000a 0047 000a 001e 000a 001e 000a 0047 000a 001e 000a 0047
000a 0047 000a 001e 000a 0047 000a 001e 000a 0047 000a 068b
AV (INPUT 1)
0000 006d 0000 0020 000a 0047 000a 001e 000a 001e 000a 001e 000a 001e
000a 001e 000a 0047 000a 001e 000a 001e 000a 0047 000a 0047 000a 001e
000a 001e 000a 0047 000a 001e 000a 068b 000a 0047 000a 001e 000a 001e
000a 001e 000a 001e 000a 0047 000a 001e 000a 0047 000a 0047 000a 001e
000a 001e 000a 0047 000a 0047 000a 001e 000a 0047 000a 068b
S-VIDEO (INPUT 2)
0000 006d 0000 0020 000a 0047 000a 001e 000a 001e 000a 001e 000a 001e
000a 0047 000a 0047 000a 001e 000a 001e 000a 0047 000a 0047 000a 001e
000a 001e 000a 0047 000a 001e 000a 068b 000a 0047 000a 001e 000a 001e
000a 001e 000a 001e 000a 001e 000a 001e 000a 0047 000a 0047 000a 001e
000a 001e 000a 0047 000a 0047 000a 001e 000a 0047 000a 068b
COMPONENT (INPUT 3)
0000 006d 0000 0020 000a 001e 000a 0047 000a 0047 000a 0047 000a 0047
000a 0047 000a 0047 000a 001e 000a 001e 000a 001e 000a 001e 000a 001e
000a 0047 000a 0047 000a 001e 000a 068b 000a 001e 000a 0047 000a 0047
000a 0047 000a 0047 000a 001e 000a 001e 000a 0047 000a 0047 000a 0047
000a 0047 000a 0047 000a 001e 000a 001e 000a 0047 000a 068b
VGA (INPUT 4)
0000 006d 0000 0020 000a 001e 000a 0047 000a 0047 000a 0047 000a 0047
000a 0047 000a 001e 000a 001e 000a 001e 000a 001e 000a 001e 000a 001e
000a 0047 000a 0047 000a 001e 000a 068b 000a 001e 000a 0047 000a 0047
000a 0047 000a 0047 000a 001e 000a 0047 000a 0047 000a 0047 000a 0047
000a 0047 000a 0047 000a 001e 000a 001e 000a 0047 000a 068b
HDMI (INPUT 5)
0000 006d 0000 0020 000a 0047 000a 001e 000a 001e 000a 001e 000a 001e
000a 0047 000a 0047 000a 001e 000a 001e 000a 0047 000a 001e 000a 0047
000a 0047 000a 0047 000a 001e 000a 068b 000a 0047 000a 001e 000a 001e
000a 001e 000a 001e 000a 001e 000a 001e 000a 0047 000a 0047 000a 001e
000a 0047 000a 001e 000a 001e 000a 001e 000a 0047 000a 068b
ANT
0000 006d 0000 0020 000a 0047 000a 001e 000a 001e 000a 001e 000a 001e
000a 0047 000a 001e 000a 001e 000a 0047 000a 001e 000a 0047 000a 001e
000a 0047 000a 0047 000a 001e 000a 068b 000a 0047 000a 001e 000a 001e
000a 001e 000a 001e 000a 001e 000a 0047 000a 0047 000a 001e 000a 0047
000a 001e 000a 0047 000a 001e 000a 001e 000a 0047 000a 068b
3-11 IR Input (cont.)
Download these codes at http://www.seura.com/IRCodes.doc

20
4-1 The Menu System
4-2 Video Menu
4-3 Audio Menu
4-4 TV Menu
4-5 Setup Menu
4-6 Parental Menu
4
Menu
