Samsung LNT466F User manual

Owner’s
Instructions
Register your product at www.samsung.com/global/register
Record your Model and Serial number here for future reference.
· Model __________ · Serial No. ____________
LN-T466F
TFT-LCD TELEVISION
Contact SAMSUNG WORLDWIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG
customer care center.
Contacte con SAMSUNG WORLDWIDE
Si tiene alguna pregunta o comentario referente a nuestros productos, por favor contacte con nuestro Servicio de
Atención al Cliente.
Country Customer Care Center Web Site Address
CANADA 1-800-SAMSUNG (7267864) www.samsung.com/ca
Samsung Electronics Canada Inc., Customer
Service 55 Standish Court Mississauga,
Ontario L5R 4B2 Canada
Samsung Electronique Canada Inc.,
Service à la Clientèle 55 Standish Court
Mississauga, Ontario L5R 4B2 Canada
U.S.A 1-800-SAMSUNG (7267864) www.samsung.com
Samsung Electronics America, Inc.
105 Challenger Road
Ridgefield Park, NJ 07660-0511
BN68-01273A-00
BN68-01273A-Cover.indd 1 2007-06-29 �� 4:56:29

Precautions When Displaying a Still Image
A still image may cause permanent damage to the TV screen
• Do not display a still image on the LCD panel for more than 2 hours as it can cause screen image retention.
This image retention is also known as "screen burn".
To avoid such image retention, reduce the degree of brightness and contrast of the screen when displaying a still image.
• Watching the LCD TV in 4:3 format for a long period of time may leave traces of borders displayed on the
left, right and center of the screen caused by the difference of light emission on the screen.
Playing a DVD or a game console may cause a similar effect to the screen.
Damages caused by the above effect are not covered by the Warranty.
• Displaying still images from Video games and PC for longer than a certain period of time may produce partial after-images.
To prevent this effect, reduce the ‘brightness’ and ‘contrast’ when displaying still images.
© 2007 Samsung Electronics Co., Ltd. All rights reserved.
Precauciones al mostrar en la pantalla una imagen fija
La imagen fija puede causar daños permanentes en la pantalla del televisor.
• No deje una imagen fija en la pantalla LCD durante más de dos horas ya que se podría producir una retención de la imagen en
la pantalla. Este fenómeno de retención de imágenes también se denomina “quemadura de pantalla”.
Para evitar que se produzca esa persistencia de la imagen, reduzca el nivel de luminosidad y de contraste de la pantalla
cuando muestre imágenes fijas.
• El uso del televisor LCD en formato 4:3 durante un tiempo prolongado puede dejar rastros de bordes en las
partes izquierda, derecha y central de la pantalla debido a las diferencias en la emisión lumínica de la pantalla.
La reproducción de un DVD o el uso de una consola de videojuegos pueden provocar un efecto similar en la
pantalla. Reproducir un DVD o una videoconsola puede causar un efecto similar en la pantalla. La garantía no
cubre estos daños.
• Ver imágenes fijas de videojuegos y PC durante más tiempo del indicado puede producir restos de imágenes parciales.
Para evitar este efecto, reduzca el ‘brillo’ y el ‘contraste’ cuando vea imágenes fijas.
Important Warranty Information Regarding Television Format Viewing
Wide screen format LCD Displays (16:9, the aspect ratio of the screen width to height) are primarily designed to view wide screen
format full-motion video. The images displayed on them should primarily be in the wide screen 16:9 ratio format, or expanded to
fill the screen if your model offers this feature and the images are constantly moving. Displaying stationary graphics and images
on screen, such as the dark side-bars on nonexpanded standard format television video and programming, should be limited to no
more than 5% of the total television viewing per week.
Additionally, viewing other stationary images and text such as stock market reports, video game displays, station logos, web sites
or computer graphics and patterns, should be limited as described above for all televisions. Displaying stationary images that
exceed the above guidelines can cause uneven aging of LCD Displays that leave subtle, but permanent burned-in ghost images in
the LCD picture. To avoid this, vary the programming and images, and primarily display full screen moving images, not stationary
patterns or dark bars.
On LCD models that offer picture sizing features, use these controls to view different formats as a full screen picture.
Be careful in the selection and duration of television formats used for viewing. Uneven LCD aging as a result of format selection
and use, as well as burned-in images, are not covered by your Samsung limited warranty.
U.S.A Only
The product unit accompanying this user manual is licensed under certain intellectual property rights of certain third parties.
In particular, this product is licensed under the following US patents: 5,991,715, 5,740,317, 4,972,484, 5,214,678, 5,323,396,
5,539,829, 5,606,618, 5,530,655, 5,777,992, 6,289,308, 5,610,985, 5,481,643, 5,544,247, 5,960,037, 6,023,490, 5,878,080, and
under US Published Patent Application No. 2001-44713-A1.
This license is limited to private non-commercial use by end-user consumers for licensed contents. No rights are granted for
commercial use. The license does not cover any product unit other than this product unit and the license does not extend to any
unlicensed product unit or process conforming to ISO/IEC 11172-3 or ISO/IEC 13818-3 used or sold in combination with this
product unit. The license only covers the use of this product unit to encode and/or decode audio files conforming to the ISO/IEC
11172-3 or ISO/IEC 13818-3. No rights are granted under this license for product features or functions that do not conform to the
ISO/IEC 11172-3 or ISO/IEC 13818-3.
Other countries
The product unit accompanying this user manual is licensed under certain intellectual property rights of certain third parties.
This license is limited to private non-commercial use by end-user consumers for licensed contents. No rights are granted for
commercial use. The license does not cover any product unit other than this product unit and the license does not extend to any
unlicensed product unit or process conforming to ISO/IEC 11172-3 or ISO/IEC 13818-3 used or sold in combination with this
product unit. The license only covers the use of this product unit to encode and/or decode audio files conforming to the ISO/IEC
11172-3 or ISO/IEC 13818-3. No rights are granted under this license for product features or functions that do not conform to the
ISO/IEC 11172-3 or ISO/IEC 13818-3.
BN68-01273A-Eng-0629.indd 1 2007-06-29 �� 4:50:39

English - 1
Contents
English
GENERAL INFORMATION
List of Features.................................................................... 2
Accessories......................................................................... 2
Viewing the Control Panel .................................................. 3
Viewing the Connection Panel ........................................... 4
Remote Control ................................................................... 5
Installing Batteries in the Remote Control........................... 6
CONNECTIONS
Connecting VHF and UHF Antennas................................... 6
Connecting Cable TV .......................................................... 7
Connecting a VCR............................................................... 8
Connecting a Camcorder ................................................... 9
Connecting a DVD Player/Set-Top Box............................... 9
Connecting a DVD Player/Set-Top Box via HDMI............. 10
Connecting a DVD Player/Set-Top Box via DVI ................ 10
Connecting a Digital Audio System ................................... 11
Connecting an Amplier/DVD Home Theater.................... 11
Connecting a PC ............................................................... 11
OPERATION
Turning the TV On and Off ................................................ 12
Plug & Play Feature .......................................................... 12
Changing Channels........................................................... 13
Adjusting the Volume......................................................... 14
Viewing the Display........................................................... 14
Viewing the Menus............................................................ 15
Memorizing the Channels.................................................. 15
Setting Up Your Remote Control .......................................17
Remote Control Codes...................................................... 19
To Select the Source ......................................................... 22
To Edit the Input Source Name .........................................22
PICTURE CONTROL
Using Automatic Picture Settings ...................................... 23
Adjusting the Color Tone ................................................... 24
Adjusting the Detailed Settings ......................................... 25
Changing the Screen Size................................................. 28
Setting the Active Color..................................................... 29
DNIe (Digital Natural Image engine) ................................. 29
Freezing the Picture ..........................................................30
Setting the Film Mode ...................................................... .30
HDMI Black Level.............................................................. 30
Viewing Picture-in-Picture ................................................. 31
SOUND CONTROL
Customizing the Sound ..................................................... 33
Using Automatic Sound Settings....................................... 33
Setting the TruSurround XT............................................... 34
Choosing a Multi-Channel Sound (MTS) track - Digital .... 34
Choosing a Multi-Channel Sound (MTS) track - Analog ... 35
Automatic Volume Control................................................. 35
Selecting the Internal Mute................................................ 36
Setting the On/Off Melody................................................. 36
Listening to the Sound of the Sub (PIP) Picture................ 37
Resetting the Sound Settings to the Factory Defaults....... 37
Connecting Headphones................................................... 37
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
CHANNEL CONTROL
Selecting the Antenna ....................................................... 38
Clearing Scrambled Channels - Digital ............................. 38
Adding and Erasing Channels.......................................... 39
To set-up Your Favorite Channels ..................................... 40
Using the Channel Lists .................................................... 41
Viewing the Channel Lists................................................. 41
Labeling Channels............................................................. 42
LNA (Low Noise Amplier)................................................. 42
Fine Tuning Analog Channels ........................................... 43
Checking the Digital-Signal Strength................................. 43
PC DISPLAY
Using Your TV as a Computer (PC) Display...................... 44
Display Modes................................................................... 44
Setting up the TV with your PC ......................................... 45
Setting the Home Theater PC ........................................... 46
TIME SETTING
Setting the Clock.............................................................. . 47
FUNCTION DESCRIPTION
Selecting a Menu Language.............................................. 50
Setting the Blue Screen Mode........................................... 51
Using the Game Mode ...................................................... 51
Viewing Closed Captions
(On-Screen Text Messages) - Analog ............................... 52
Viewing Closed Captions
(On-Screen Text Messages) - Digital ................................ 53
Menu Transparency Level................................................. 54
Using the Energy Saving Feature ..................................... 54
Setting the Function Help.................................................. 55
Digital Noise Reduction..................................................... 55
Using the V-Chip ............................................................... 56
Upgrading the Software ....................................................63
WISELINK
Using the WISELINK Function .......................................... 64
Using the WISELINK Menu............................................... 65
Using the PHOTO (JPEG) List.......................................... 66
Using the MP3 List ............................................................ 73
Using the Setup Menu....................................................... 75
ABOUT ANYNET+
What is Anynet+? ................................................................... 77
Connecting Anynet+ Devices.................................................. 77
Setting Up Anynet+................................................................. 78
Scanning and Switching between Anynet+ Devices............... 78
Recording ............................................................................... 79
Listening through a Receiver (Home theater)......................... 80
Check Points before Requesting Service ............................... 80
APPENDIX
Troubleshooting................................................................. 81
Installing the Stand............................................................ 83
Disconnecting the Stand ................................................... 83
Auto Wall-Mount Adjustment (Sold separately)............... 84
Wall Mount Kit Specifications (VESA) ............................... 85
Using the Anti-Theft Kensington Lock ............................... 86
Specications .................................................................... 87
Dimensions......................................................................88
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
English - 1
Symbol Press Important Note One-Touch
Button
BN68-01273A-Eng-0629.indd 1 2007-06-29 �� 4:50:40

English - 2
Accessories
Please make sure the following items are included with your LCD TV.
If any items are missing, contact your dealer.
Remote Control & Batteries (AAA x 2)
(BN59-00599A)
Power Cord
(3903-000144)
Cleaning Cloth
(BN63-01798A)
Cover-Bottom
(BN63-02624A) Owner’s Instructions
Warranty Card / Registration
Card / Safety Guide Manual
(Not available in all locations)
The items color and shape may vary depending on the model.
General Information
List of Features
Adjustable picture settings that can be stored in the TV’s memory.
Automatic timer to turn the TV on and off.
A special sleep timer.
Excellent Digital Interface & Networking :
With a built-in HD digital tuner, non-subscription HD broadcasts can be viewed with no Cable Box/Satellite receiver
(Set-Top Box) needed.
HDMI/DVI connection of your PC to this TV.
Remote Control
The supplied remote can be used to operate the TV as well as most DVD players, Cable Box/Satellite receiver
(Set-Top Box) and VCRs.
Excellent Picture Quality
- DNIe technology provides life-like clear images.
SRS TruSurround XT
- SRS TruSurround XT provides a virtual Dolby surround system.
BN68-01273A-Eng-0629.indd 2 2007-06-29 �� 4:50:42

English - 3
Viewing the Control Panel
Buttons on the Lower-Right Part of the Panel
The buttons on the lower-right panel control your TV’s basic features, including the on-screen menu.
To use the more advanced features, you must use the remote control.
The product color and shape may vary depending on the model.
1 SOURCE
Toggles between all the available input sources
(TV, AV1, AV2, S-Video1, S-Video2, Component1,
Component2, PC, HDMI1, HDMI2, HDMI3).
In the on-screen menu, use this button as you would
use the ENTER button on the remote control.
2 MENU
Press to see an on-screen menu of your TV’s features.
3 + VOL -
Press to increase or decrease the volume.
In the on-screen menu, use the + VOL - buttons as you
would use the ◄ and ► buttons on the remote control.
4 < CH >
Press to change channels.
In the on-screen menu, use the < CH > buttons as you
would use the ▲ and ▼ buttons on the remote control.
5 SPEAKERS
6 (POWER)
Press to turn the TV on and off.
POWER INDICATOR
Blinks and turns off when the power is on and
lights up in stand-by mode.
7 REMOTE CONTROL SENSOR
Aim the remote control towards this spot on the TV.
BN68-01273A-Eng-0629.indd 3 2007-06-29 �� 4:50:42

English - 4
Viewing the Connection Panel
Rear Panel Jacks
Use the rear panel jacks to connect A/V components that will be connected continuously, such as VCR or DVD players.
For more information on connecting equipment, see pages 6-11.
1 AUDIO OUT
Connects to the audio input jacks on your Amplifier/
Home theater.
2 DIGITAL AUDIO OUT (OPTICAL)
Connects to a Digital Audio component.
3 PC IN
Connects to the video and audio output jacks on
your PC.
4 HDMI IN 1,2,3 / DVI IN(HDMI1) (AUDIO R/L)
Connects to the HDMI jack of a device with an HDMI output.
Use the HDMI IN 1 jack for a DVI connection to an
external device.
Use a DVI to HDMI cable or DVI-HDMI adapter
(DVI to HDMI) for video connection and the
DVI IN (HDMI1) ‘R-AUDIO-L’ jacks for audio.
- No sound connection is needed for an HDMI to HDMI
connection
- When using an HDMI/DVI cable connection, you must use
the HDMI IN 1 jack.
5 ANT 1 IN / ANT 2 IN
Connects to an antenna or cable TV system.
6
EX-LINK
Connect this to the jack on the optional wall mount
bracket. This will allow you to adjust the TV viewing angle
using your remote control.
7
COMPONENT IN 1,2
Connects Component video/audio.
8 AV IN 1 / AV IN 2
Video and audio inputs for external devices, such as a
camcorder or VCR.
S-VIDEO
Connects an S-Video signal from a camcorder or VCR.
9 POWER INPUT
Connects the supplied power cord
0 KENSINGTON LOCK
The Kensington lock (optional) is a device used to
physically fix the system when used in a public place.
If you want to use a locking device, contact the dealer
where you purchased the TV.
The location of the Kensington Lock may be different
depending on its model.
! HEADPHONE
Connects a set of external headphones for private
listening.
@ WISELINK
Connect a USB mass storage device to view photo files
(JPEG) and play audio files (MP3).
[Side Panel Jacks]
BN68-01273A-Eng-0629.indd 4 2007-06-29 �� 4:50:43

English - 5
Remote Control
You can use the remote control up to a distance of about 23 feet from the TV. When using the remote, always point it directly at the
TV. You can also use your remote control to operate your VCR, Cable box, DVD player or Cable Box/Satellite receiver
(Set-Top Box)
This is a special remote control for the visually impaired and has Braille
points on the POWER, CH, VOL, STOP and PLAY/PAUSE buttons.
The performance of the remote control may be affected by bright light.
1 POWER
Turns the TV on and off.
2 NUMERIC BUTTONS
Press to change the channel.
3 –
Press to select additional channels(digital
and analog) being broadcast by the same
station. For example, to select channel
“54-3”, press “54”, then press “–” and “3”.
4 CH LIST
Used to display Channel Lists on the
screen.
5 ANTENNA
Press to select “AIR” or “CABLE”.
6 VCR/DVD Functions
- Rewind
- Stop
- Play/Pause
- Fast/Forward
7 VOL / VOL
Press to increase or decrease the
volume.
8 ( MUTE)
Press to temporarily cut off the sound.
9 MENU
Displays the main on-screen menu.
0 S.MODE
Press to select the sound mode.
! RETURN
Returns to the previous menu.
@ P.MODE
Press to select the picture mode.
#
CAPTION
Controls the caption decoder.
$ FAV.CH
Press to switch to your favorite channels.
% SLEEP
Press to select a preset time interval
for automatic Shut off.
^ SRS
Selects SRS TruSurround XT mode.
& SET
Sets the remote to control your
TV, VCR, Cable, DVD, or Set-Top Box
* TV, DVD, STB, CABLE, VCR
Press to operate your TV,DVD, STB,
CABLE (box), or VCR
(See pages 17-21)
( When pressing this button, a number
of buttons on the remote control (e.g.
TV, DVD, STB, CABLE, VCR,
VOL and CH buttons) light up for a few
seconds and then turn off to save
power. This function is convenient for
using the remote at night or when dark.
) SOURCE
Press to display all of the available
video sources.
a PRE-CH
Tunes to the previous channel.
b WISELINK
This function enables you to view and
play photo (JPEG) and audio files
(MP3) from an external device. (Refer
to pages 64 (JPEG) and 74 (MP3))
c
REC
This remote can be used to control
recording on Samsung recorders.
(Refer to page 79)
d
CH
/ CH
Press to change channels.
e
EXIT
Press to exit the menu.
f
UP▲ / DOWN▼ / LEFT◄ /
RIGHT► / ENTER
Use to select on-screen menu items
and change menu values.
g
INFO
Press to display information on the TV
screen.
h
Anynet+
Runs the Anynet+ functions and sets
up Anynet devices.
i
STILL
Press to stop the action during a
particular scene.
Press again to resume normal video.
j
P.SIZE
Picture size selection.
k
PIP
Picture-in Picture ON/OFF.
l
CH
/
Displays the available channels in
sequence. (These buttons change
channels in the PIP window only.)
m
MTS
Press to choose stereo, mono or
Separate Audio Program
(SAP broadcast).
n
RESET
When your remote does not work,
change the batteries and press the
RESET button for 2-3 seconds before
use.
BN68-01273A-Eng-0629.indd 5 2007-06-29 �� 4:50:44

English - 6
1. Lift the cover at the back of the remote control upward as shown in the figure.
2. Install two AAA size batteries.
Make sure to match the "+" and "–" ends of the batteries with the diagram inside the compartment.
3. Replace the cover.
Remove the batteries and store them in a cool, dry place if you won’t be using the remote control for a
long time.
The remote control can be used up to about 23 feet from the TV.
(Assuming typical TV usage, the batteries should last for about one year.)
If the remote control doesn’t work, check the following:
1. Is the TV power on?
2. Are the plus and minus ends of the batteries reversed?
3. Are the batteries drained?
4. Is there a power outage, or is the power cord unplugged?
5. Is there a special fluorescent light or neon sign nearby?
Installing Batteries in the Remote Control
Connecting VHF and UHF Antennas
If your antenna has a set of leads that look like the diagram to the right, see "Antennas with
300 Ω Flat Twin Leads" below.
If your antenna has one lead that looks like the diagram to the right, see "Antennas with 75
Ω Round Leads".
If you have two antennas, see "Separate VHF and UHF Antennas".
1. Place the wires from the twin leads under the screws on a 300-75 Ω adapter
(not supplied).
Use a screwdriver to tighten the screws.
2. Plug the adaptor into the ANT 1 IN (AIR) terminal on the back of the TV.
ANT 1 IN
(AIR)
Antennas with 300 Ω Flat Twin Leads
If you are using an off-air antenna (such as a roof antenna or "rabbit ears") that has 300 Ω twin at leads, follow the directions
below.
1. Plug the antenna lead into the ANT 1 IN (AIR) terminal on the back of the TV.
Antennas with 75 Ω Round Leads
ANT 1 IN
(AIR)
Separate VHF and UHF Antennas
If you have two separate antennas for your TV (one VHF and one UHF), you must combine the two antenna signals before con-
necting the antennas to the TV. This procedure requires an optional combiner-adaptor (available at most electronics shops).
1. Connect both antenna leads to the combiner.
2. Plug the combiner into the ANT 1 IN (AIR) terminal on the bottom of the rear panel.
UHF
VHF
ANT 1 IN
(AIR)
UHF
VHF
Connections
BN68-01273A-Eng-0629.indd 6 2007-06-29 �� 4:50:45

English - 7
After you have made this connection, set the A/B switch to the "A" position for normal viewing. Set the A/B switch to the "B" position to
view scrambled channels. (When you set the A/B switch to "B", you will need to tune your TV to the cable box’s output channel, which is
usually channel 3 or 4.)
Connecting to a Cable Box that Descrambles Some Channels
If your cable box descrambles only some channels (such as premium channels), follow the instructions below. You will need a
two-way splitter, an RF (A/B) switch, and four lengths of RF cable. (These items are available at most electronics stores.)
2. Connect this cable to a two-way splitter.
3. Connect an RF cable between the OUTPUT
terminal on the splitter and the IN terminal
on the cable box.
4. Connect an RF cable between the
ANT OUT terminal on the cable box and
the B–IN terminal on the RF(A/B) switch.
1. Find and disconnect the cable that is
connected to the ANT IN terminal on your
cable box.
This terminal might be labeled "ANT IN",
"VHF IN" or simply, "IN".
5. Connect another cable between the other
OUT terminal on the splitter and the A–IN
terminal on the RF (A/B) switch.
6. Connect the last RF cable between the
OUT terminal on the RF (A/B) switch and
the ANT 2 IN (CABLE) terminal on the rear
of the TV.
Splitter
Incoming
cable
Splitter
Cable Box
Incoming
cable
Splitter
Cable Box
RF (A/B)
Switch
Incoming
cable
ANT IN
Splitter
Cable Box
Incoming
cable
RF (A/B)
Switch
Splitter
Cable Box
Incoming
cable TV Rear
RF (A/B)
Switch
ANT 2 IN
(CABLE)
Connecting Cable TV
To connect to a cable TV system, follow the instructions below.
Cable without a Cable Box
1. Plug the incoming cable into the ANT 2 IN (CABLE) terminal on the back of the TV.
Because this TV is cable-ready, you do not need a cable box to view unscrambled cable channels.
Connecting to a Cable Box that Descrambles All Channels
1. Find the cable that is connected to the ANT OUT terminal on your cable box.
This terminal might be labeled "ANT OUT", "VHF OUT" or simply, "OUT".
2. Connect the other end of this cable to the ANT 2 IN (CABLE) terminal on the back of the TV.
ANT OUT
ANT IN
ANT 2 IN
(CABLE)
ANT 2 IN
(CABLE)
BN68-01273A-Eng-0629.indd 7 2007-06-29 �� 4:50:47

English - 8
Connecting a VCR
These instructions assume that you have already connected your TV to an antenna or a cable TV system (according to the
instructions on pages 6-7). Skip step 1 if you have not yet connected to an antenna or a cable system.
1. Unplug the cable or antenna
from the back of the TV.
2. Connect the cable or antenna
to the ANT IN terminal on the
back of the VCR.
3. Connect an RF Cable between
the ANT OUT terminal on the
VCR and the ANT 1 IN (AIR) or
ANT 2 IN (CABLE) terminal on
the TV.
4. Connect a Video Cable
between the VIDEO OUT jack
on the VCR and the AV IN 1
(or AV IN 2) [VIDEO] jack on
the TV.
5. Connect Audio Cables
between the AUDIO OUT
jacks on the VCR and the
AV IN 1 (or AV IN 2)
[R-AUDIO-L] jacks on the TV.
If you have a “mono”
(non-stereo) VCR, use a
Y-connector (not supplied)
to hook up to the right
and left audio input jacks
of the TV. If your VCR
is stereo, you must
connect two cables.
Follow the instructions in “Viewing a VCR or Camcorder Tape” to view your VCR tape.
Each VCR has a different back panel configuration.
When connecting a VCR, match the color of the connection terminal to the cable.
TV Rear Panel
RF Cable (Not supplied)
3
VCR Rear Panel
2Video Cable (Not supplied)
4
Audio Cable (Not supplied)
5
Your Samsung TV can be connected to an S-Video signal from an VCR.
(This connection delivers a better picture as compared to a standard VCR.)
1. To begin, follow steps 1–3
in the previous section to
connect the antenna or
cable to your VCR and
your TV.
2. Connect an S-Video Cable
between the S-VIDEO OUT
jack on the VCR and the
AV IN1 [S-VIDEO] jack on
the TV.
3. Connect Audio Cables
between the AUDIO OUT
jacks on the VCR and the
AV IN1 [R-AUDIO-L] jacks
on the TV.
An S-Video cable may be included with a VCR. (If not, check your local electronics store.)
Each VCR has a different back panel configuration.
When connecting a VCR, match the color of the connection terminal to the cable.
VCR Rear Panel
RF Cable (Not supplied)
1
Audio Cable (Not supplied)
3
TV Rear Panel
S-Video Cable (Not supplied)
2
Video Connection
S-Video Connection
ANT 1 IN
(AIR) ANT 2 IN (CABLE)
BN68-01273A-Eng-0629.indd 8 2007-06-29 �� 4:50:48

English - 9
Connecting a DVD Player or Cable Box/Satellite receiver (Set-Top Box)
The rear panel jacks on your TV make it easy to connect a DVD Player or Cable Box/Satellite receiver (Set-Top Box) to your TV.
1. Connect a Component
Cable between the
COMPONENT IN(1 or 2)
[Y, PB, PR] jacks on the TV
and the COMPONENT
[Y, PB, PR] jacks on the
DVD Player or Cable Box/
Satellite receiver (Set-Top
Box).
2. Connect Audio Cables
between the COMPONENT
IN(1 or 2) [R-AUDIO-L]
jacks on the TV and the
AUDIO OUT jacks on the
DVD Player or Cable Box/
Satellite receiver (Set-Top
Box).
Component video separates the video into Y (Luminance (brightness)), Pb (Blue) and
Pr (Red) for enhanced video quality.
Be sure to match the component video and audio connections.
For example, if connecting the video cable to COMPONENT IN, connect the audio cable
to COMPONENT IN also.
Each DVD Player or Cable Box/Satellite receiver (Set-Top Box) has a different back panel
configuration.
When connecting a DVD Player or Cable Box/Satellite receiver (Set-Top Box), match the color
of the connection terminal to the cable.
DVD Player or Cable Box /
Satellite receiver (Set-Top Box)
TV Rear Panel
Component Cable (Not supplied)
1
Audio Cable (Not supplied)
2
Connecting a Camcorder
The side panel jacks on your TV make it easy to connect a camcorder to your TV.
They allow you to view the camcorder tapes without using a VCR
1. Connect a Video Cable
(or S-Video Cable) between
the AV IN2 [VIDEO]
(or S-Video) jack on the TV
and the VIDEO OUT jack on
the camcorder.
2. Connect Audio Cables
between the AV IN2
[R-AUDIO-L] jacks on the
TV and the AUDIO OUT
jacks on the camcorder.
Camcorder
TV Side Panel
S-Video Cable (Not supplied)
1
Audio Cable (Not supplied)
2
Each Camcorder has a different back panel configuration.
When connecting a Camcorder, match the color of the connection terminal to the cable.
Video Cable (Not supplied)
1
or
BN68-01273A-Eng-0629.indd 9 2007-06-29 �� 4:50:49

English - 10
Connecting a DVD Player or Cable Box/Satellite receiver (Set-Top Box) via HDMI
This connection can only be made if there is an HDMI Output connector on the external device.
DVD Player or Cable Box/Satellite receiver
(Set-Top Box) TV Rear Panel
HDMI Cable (Not supplied)
Connecting a DVD Player or Cable Box/Satellite receiver (Set-Top Box) via DVI
This connection can only be made if there is a DVI Output connector on the external device.
Each DVD Player or Cable Box/Satellite receiver (Set-Top Box) has a different back
panel configuration.
When connecting a DVD Player or Cable Box/Satellite receiver (Set-Top Box), match
the color of the connection terminal to the cable.
When using an HDMI/DVI cable connection,you must use the HDMI IN1 jack.
TV Rear Panel
DVD Player or Cable Box/
Satellite receiver (Set-Top Box)
Audio Cable (Not supplied)
2
DVI to HDMI Cable (Not supplied)
1
1. Connect an HDMI Cable
between the HDMI IN
(1,2 or 3) jack on the
TV and the HDMI jack
on the DVD Player or
Cable Box/Satellite receiver
(Set-Top Box)
1. Connect a DVI to HDMI
Cable or DVI-HDMI Adapter
between the HDMI IN 1
jack on the TV and the DVI
jack on th DVD Player or
Cable Box/Satellite receiver
(Set-Top Box)
2. Connect Audio Cables
between the DVI IN (HDMI 1)
[R-AUDIO-L] jack on the
TV and the DVD Player or
Cable Box/Satellite receiver
(Set-Top Box)
Side Panel Jacks
or
What is HDMI?
• HDMI(High-Definition Multimedia Interface), is an interface that
enables the transmission of digital audio and video signals using a single cable.
• The difference between HDMI and DVI is that the HDMI device is smaller in
size and has the HDCP (High Bandwidth Digital Copy Protection) coding feature
installed
Each DVD Player or Cable Box/Satellite receiver (Set-Top Box) has a different back
panel configuration.
When connecting via HDMI, you do not need to connect Audio Cables. You only need
to connect Audio cables when connecting via HDMI/DVI.
The TV may not output sound and pictures may be displayed with abnormal color
when DVD players/Cable Boxes/Satellite receivers supporting HDMI versions older
than 1.3 are connected. When connecting an older HDMI cable and there is no
sound, connect the HDMI cable to the HDMI IN 1 jack and the audio cables to the
DVI IN (HDMI1) [R-AUDIO-L] jacks on the back of the TV. If this happens, contact
the company that provided the DVD player/Cable Box/Satellite receiver to confirm the
HDMI version, then request an upgrade.
HDMI cables that are not 1.3 may cause annoying flicker or no screen display.
BN68-01273A-Eng-0629.indd 10 2007-06-29 �� 4:50:50

English - 11
Connecting an Amplier/DVD Home Theater
1. Connect Audio Cables
between the AUDIO OUT
[R-AUDIO-L] jacks on the TV
and AUDIO IN [R-AUDIO-L]
jacks on the Amplifier/DVD
Home Theater.
When an audio amplifier is
connected to the "AUDIO
OUT [R-AUDIO-L]"
jack: Decrease the
volume of the TV and adjust
the volume level with the
Amplifier’s volume control.
Amplier/DVD Home Theater
TV Rear Panel
Audio Cable (Not supplied)
Each Amplifier/DVD Home Theater has a different back panel configuration.
When connecting an Amplifier/DVD Home Theater, match the color of the connection
terminal to the cable.
English - 11
Connecting a Digital Audio System
1. Connect an Optical Cable
between the “DIGITAL
AUDIO OUT (OPTICAL)”
jacks on the TV and the
Digital Audio Input jacks on
the Digital Audio System.
When a Digital Audio
System is connected to the
“DIGITAL AUDIO OUT
(OPTICAL)” jack:
Decrease the volume
of the TV and adjust the
volume level with the
system’s volume control.
Digital Audio System
TV Rear Panel
Optical Cable (Not supplied)
5.1CH audio is possible when the TV is connected to an external device supporting 5.1CH.
Each Digital Audio System has a different back panel configuration.
If you have an external device (DVD, Cable/Set top box) connected via HDMI to the TV,
audio is not output from the Optical jack.
When the COMPONENT IN or HDMI IN jacks are connected, the Optical jack on the TV
outputs 2 channel audio only. If you want to hear 5.1 channel audio, connect the DIGITAL
AUDIO OUT (OPTICAL) jack on the DVD player or Cable/Satellite Box directly to an
Amplifier or Home Theater, not the TV.
The rear panel jacks on your TV make it easy to connect a Digital Audio System to your TV.
Connecting a PC
PC
TV Rear Panel
D-Sub Cable (Not supplied)
1
PC Audio Cable (Not supplied)
2
1. Connect a D-Sub Cable
between PC IN [PC]
connector on the TV and
the PC output connector
on your computer.
2.
Connect a PC Audio
Cable between the PC IN
[AUDIO] jack on the TV
and the Audio Out jack of
the sound card on your
computer.
Each PC has a different back panel configuration.
When connecting a PC, match the color of the connection terminal to the cable.
When using an HDMI/DVI cable connection, you must use the HDMI IN1 terminal.
3.5 mm Stereo mini-plug/2RCA Cable (Not supplied)
2
HDMI/DVI Cable (Not supplied)
1
Using the D-Sub Cable
Using the HDMI/DVI Cable
TV Rear Panel
Using the D-Sub Cable
1.
Connect a HDMI/DVI cable
between the HDMI IN 1
jack on the TV and the
PC output jack on your
computer.
2.
Connect a 3.5 mm Stereo
mini-plug/2RCA Cable
between the DVI IN(HDMI1)
[R-AUDIO-L] jack on the
TV and the Audio Out jack
of the sound card on your
computer.
Using the HDMI/DVI Cable
PC
BN68-01273A-Eng-0629.indd 11 2007-06-29 �� 4:50:52

English - 12
Plug & Play Feature
When the TV is initially powered on, basic settings proceed automatically and subsequently:
1. Press the POWER button on the remote control.
The message “Menu language, Shop Mode, Channels and Time will be set.” is
displayed.
Press the ENTER button, then “Select the language of the OSD” menu
is automatically displayed.
2. Press the ▲ or ▼ button to select language, then press the ENTER button.
The message “Select Home Mode when installing this TV at home.” is displayed.
3. Press the ◄ or ► button to select “Shop” or “Home”, then
press the ENTER button.
The message “Select the antennas to memorize.” is displayed.
We recommend setting the TV to Home mode for the best picture in your
home environment.
Shop mode is only intended for use in retail environments.
If the unit is accidentally set to Shop mode and you want to return to Dynamic
(Home) mode, press any Volume button and then hold down the MENU button
for five seconds on the side panel of the TV.
4. Press the ▲ or ▼ button to memorize the channels of the selected connection.
Press the ENTER button to select “Start”.
If the antenna is connected to ANT 1(AIR), select “Air” and if it is connected to
ANT 2 (CABLE), select “Cable”.
If both ANT 1 (AIR) and ANT 2 (CABLE) are connected, select the “Air + Cable”.
In Cable mode, you can select the correct signal source among STD, HRC,
and IRC by pressing the ▲ or ▼ button, then press the ENTER button.
Contact your local cable company to identify the type of cable system that
exists in your particular area.
5. The TV will begin memorizing all of the available channels.
After all the available channels are stored, the Auto program menu reappears.
Press the ENTER button when channel memorization is complete.
The message “Select the clock mode.” is displayed.
To stop the search before it has finished, press the ENTER button with stop
selected.
6. Press the ENTER button.
Press the ▲ or ▼ button to select “Auto”, then Press the ENTER button.
The message “Set to daylight savings time.” is displayed.
If you select "Manual", "Set current date and time." is displayed.
(See page 47)
Turning the TV On and Off
Press the POWER button on the remote control.
You can also use the POWER button on the TV.
Operation
Select Home Mode when installing this TV at home.
Plug & Play
Plug & Play
Clock Set
Menu Language :
Plug & Play
English
Español
Français
Move Enter Skip
Shop
Menu language, Shop Mode,
Channels and Time will be set.
Start
Select the language of the OSD.
Home
Move Enter Skip
Select the antennas to memorize.
Start
Air
Plug & Play
Cable
Air+Cable
Start
Start
Move Enter Skip
Clock Mode :
Move Enter Skip
Select the clock mode.
Plug & Play
Manual
Auto
35%
Stop
Enter Skip
Auto Program in progress. Air Channel 50
Plug & Play
Plug & Play
Auto Program is complete.
16 Channels were memorized.
Air : 16, Cable : 0.
Enter Skip
OK
Plug & Play
BN68-01273A-Eng-0629.indd 12 2007-06-29 �� 4:50:54

English - 13
7. Press the ▲ or ▼ button to select “Off” or “On”, then the ENTER button.
The message “Select the time zone in which you live.” is displayed.
8. Press the ▲ or ▼ button to highlight the time zone for your local area.
Press the ENTER button. If you have received a digital signal, the time will be set
automatically.
If not, see page 48 to set the clock.
9. The message “Enjoy your watching.” is displayed.
When you have finished, press the ENTER button.
If you want to reset this feature...
1. Press the MENU button to display the menu.
Press the ▲ or ▼ button to select "Setup", then press the ENTER button.
2. Press the ENTER button again, to select "Plug & Play".
3. The message “Menu language, Shop Mode, Channels and Time will be set.”
is displayed.
Daylight Savings Time :
Set the daylight savings time.
Plug & Play
On
Off
Select the time zone in which you live.
Plug & Play
Newfoundland
Atlantic
Eastern
Central
Mountain
Pacific
Alaska
Hawaii
Enjoy your watching.
OK
Setup
Plug & Play ►
Language : English ►
Time ►
Game Mode : Off ►
V-Chip ►
Caption ►
Menu TransParency : High ►
▼More
TV
Move Enter Return
Menu language, Shop Mode,
Channels and Time will be set.
Start
Move Enter Skip
Move Enter Skip
Changing Channels
1. Press the CH or CH button to change channels.
When you press the CH or CH button, the TV changes channels in
sequence.
You will see all the channels that the TV has memorized. (The TV must have
memorized at least three channels). You will not see channels that were either
erased or not memorized. See page 16 to memorize channels.
Using the Channel Buttons
1. Press the number buttons to go directly to a channel. For example, to select
channel 27, press 2, then 7. The TV will change channels when you press the
second number.
Using the Number Buttons
The “-” button is used to select stations that broadcast a digital signal.
1.
For example, for Channel 7-1, press 7, then -, then 1.
HD indicates the TV is receiving a Digital High Definition signal. SD indicates
the TV is receiving a Standard Definition signal.
For quick channel change, press the number buttons, then press the ENTER
button.
Using the “-” Button
BN68-01273A-Eng-0629.indd 13 2007-06-29 �� 4:50:56

English - 14
Adjusting the Volume
1. Press the VOL or VOL buttons to decrease or increase the volume.
Using the MUTE button
At any time, you can cut off the sound using the MUTE button.
1. Press MUTE button and the sound cuts off.
The word " " will appear in the lower-left corner of the screen.
2. To turn mute off, press the MUTE button again, or simply press the
VOL or VOL buttons.
Viewing the Display
1. Press the INFO button on the remote control.
The TV will display the channel, the type of sound,
and the status of certain picture and sound settings.
Press the INFO button once more or wait approximately 10 seconds and the
display disappears automatically.
The display identies the current channel and the status of certain audio-video settings.
Air 7
Mono
Picture Mode : Dynamic
Sound Mode : Custom
MTS : Stereo
05 : 54 pm
1. Press the PRE-CH button.
The TV will switch to the last channel viewed.
To quickly switch between two channels that are far apart, tune to one channel,
then use the number button to select the second channel.
Then use the PRE-CH button to quickly alternate between them.
Using the PRE-CH Button to select the Previous Channel
BN68-01273A-Eng-0629.indd 14 2007-06-29 �� 4:50:57

English - 15
Viewing the Menus
1. With the power on, press the MENU button.
The main menu appears on the screen. The menu’ s left side has five icons:
Picture, Sound, Channel, Setup, Input.
2. Use the ▲ or ▼ button to select one of the five icons.
Then press the ENTER button to access the icon’s sub-menu.
3. Press the EXIT button to exit.
The on-screen menus disappear from the screen after about one minutes.
Memorizing the Channels
Your TV can memorize and store all of the available channels for both "off-air" (Air) and "Cable" channels. After the available
channels are memorized, use the CH or CH buttons to scan through the channels. This eliminates the need to change
channels by entering the channels digits. There are three steps for memorizing channels: selecting a broadcast source,
memorizing the channels (automatic) and adding or deleting channels (Channel Lists ).
Selecting the Video Signal-source
Before your television can begin memorizing the available channels, you must specify the
type of signal source that is connected to the TV (i.e. an Air or a Cable system).
1. Press the MENU button to display the menu.
Press the ▲ or ▼ button to select "Channel", then press the ENTER button.
2. Press the ENTER button select “Antenna”.
Press the ▲ or ▼ button to select “Air” or “Cable”, then press the ENTER button.
Press the EXIT button to exit.
Antenna : Air ►
Auto Program ►
Clear Scrambled Channel ►
Channel List ►
Name ►
Fine Tune ►
Signal Strength ►
LNA : On ►
Channel
Move Enter Return
TV
Channel
Move Enter Return
TV
Antenna : Air
Auto Program
Clear Scrambled Channel
Channel List
Name
Fine Tune
Signal Strength
LNA : On
Air
Cable
Move Enter Exit
Mode : Dynamic ►
Contrast 100
Brightness 50
Sharpness 85
Color 55
Tint G 50 R 50
Balck light 10
▼More
PictureTV
BN68-01273A-Eng-0629.indd 15 2007-06-29 �� 4:50:58

English - 16
Storing Channels in Memory (Automatic Method)
1. Press the MENU button to display the menu.
Press the ▲ or ▼ button to select “Channel”, then press the ENTER button.
2. Press the ▲ or ▼ button to select "Auto Program", then press the ENTER button.
3. Press the ▲ or ▼ button to select the antenna connection, then press the
ENTER button.
Air: “Air” antenna signal.
Cable: “Cable” antenna signal.
Air+Cable: “Air” and “Cable” antenna signals.
4. When selecting the Cable TV system : Press the ENTER button to start the auto
program. By default, the cable TV system is set to “STD”. If you want to select
another type of cable system, press the ▲ or ▼ button to select
“STD”, “HRC” or “IRC”.
STD, HRC and IRC identify various types of cable TV systems. Contact your
local cable company to identify the type of cable system that exists in your
particular area. At this point the signal source has been selected.
Press the ENTER button to start the auto program.
To stop the search before it has finished, press the ENTER button with stop
selected.
5. After all the available channels are stored, the “Auto Program” menu reappears.
Press the EXIT button to exit.
Move Enter Return
Select the antennas to memorize.
Channel
Move Enter Return
TV
Start
Air
Cable
Air+Cable
Start
Start
Move Enter Return
Select the cable system.
Auto Program
Move Enter Return
TV
Analog
Start
STD
HRC
IRC
Digital
STD
HRC
IRC
Auto Program
Cable Channel 50
50%
Stop
Enter Return
Auto Program in Progress.
Antenna : Air ►
Auto Program ►
Clear Scrambled Channel ►
Channel List ►
Name ►
Fine Tune ►
Signal Strength ►
LNA : On ►
Channel
Move Enter Return
TV
Auto Program
Enter Return
Auto Program is complete.
16 Channels were memorized.
Air : 16, Cable : 0.
OK
BN68-01273A-Eng-0629.indd 16 2007-06-29 �� 4:51:00

English - 17
After the television has been set up properly, your remote control can operate in five
different modes: TV, DVD, Cable, Set-Top Box, VCR. Pressing the corresponding
button on the remote control allows you to switch between these modes, and control
whichever piece of equipment you choose.
The remote control might not be compatible with all DVD Players, VCRs, Cable boxes,
and Set-Top Boxes.
Setting Up the Remote to Operate Your VCR
1. Turn off your VCR.
2. Press the VCR button on your TV’s remote control.
3. Press the SET button on your TV’s remote control.
4. Using the number buttons on your remote control, enter three digits of the VCR code
listed on page 19 of this manual for your brand of VCR. Make sure you enter three
digits of the code, even if the first digit is a “0”.
(If more than one code is listed, try the first one.)
5. Press the POWER button on the remote control.
Your VCR should turn on if your remote is set up correctly.
If your VCR does not turn on after set up, repeat steps 2, 3 and 4, but try one of the
other codes listed for your brand of VCR.
If no other codes are listed, try each VCR code, 000 through 080.
Note on Using Remote Control Modes: VCR
When your remote control is in “VCR” mode, the volume buttons still control your
TV’s volume.
Setting Up the Remote to Operate Your Cable Box
1. Turn off your cable box.
2. Press the CABLE button on your TV’s remote control.
3. Press the SET button on your TV’s remote control.
4. Using the number buttons on your remote control, enter three digits of the cable box code
listed on page 20 of this manual for your brand of cable box. Make sure you enter three
digits of the code, even if the first digit is a “0”. (If there is more than one code listed, try
the first one.)
5. Press the POWER button on the remote control.
Your cable box should turn on if your remote is set up correctly.
If your cable box does not turn on after set up, repeat steps 2, 3 and 4, but try one of the
other codes listed for your brand of cable box. If no other codes are listed, try each code,
000 through 046.
Note on Using Remote Control Modes: Cable Box
When your remote control is in “CABLE” mode, the volume buttons still control your
TV’s volume.
Setting up your Remote Control
BN68-01273A-Eng-0629.indd 17 2007-06-29 �� 4:51:00

English - 18
Setting Up the Remote to Operate Your DVD
1. Turn off your DVD.
2. Press the DVD button on your TV’s remote control.
3. Press the SET button on your TV’s remote control.
4. Using the number buttons on your remote control, enter three digits of the DVD code
listed on page 20~21 of this manual for your brand of DVD.
Make sure you enter three digits of the code, even if the first digit is a “0”.
(If there is more than one code listed, try the first one.)
5. Press the POWER button on the remote control.
Your DVD should turn on if your remote is set up correctly.
If your DVD does not turn on after set up, repeat steps 2, 3 and 4, but try one of the
other codes listed for your brand of DVD.
If no other codes are listed, try each code, 000 through 141.
Note on Using Remote Control Modes: DVD
When your remote control is in “DVD” mode, the volume buttons still control your
TV’s volume.
Setting Up the Remote to Operate Your STB
1. Turn off your STB.
2. Press the STB button on your TV’s remote control.
3. Press the SET button on your TV’s remote control.
4. Using the number buttons on your remote control, enter three digits of the STB code
listed on page 21 of this manual for your brand of STB.
Make sure you enter three digits of the code, even if the first digit is a “0”.
(If there is more than one code listed, try the first one.)
5. Press the POWER button on the remote control.
Your STB should turn on if your remote is set up correctly.
If your STB does not turn on after set-up, repeat steps 2, 3 and 4, but try one of the
other codes listed for your brand of STB.
(If no other codes are listed, try each code, 000 through 074.)
Note on Using Remote Control Modes: STB
When your remote control is in “STB” mode, the volume buttons still control your
TV’s volume.
BN68-01273A-Eng-0629.indd 18 2007-06-29 �� 4:51:01
