Sharp R-798-A Instruction Manual

ENGLISH
Important
R-798-A
MICROWAVE OVEN WITH
TOP AND BOTTOM GRILL
OPERATION MANUAL WITH COOKBOOK
OPERATION MANUAL
This operation manual contains important information which you should read carefully
before using your microwave oven.
IMPORTANT: There may be a serious risk to health if this operation manual is not followed or
if the oven is modified so that it operates with the door open.
900 W (IEC 60705)
R-798-A_[EN].qxd 7/16/07 2:52 PM Page 1

1
Dear Customer,
Congratulations on acquiring your new microwave oven with double grill, which from now on will make your
kitchen chores considerably easier.
You will be pleasantly surprised by the kinds of things you can do with a microwave. Not only can you use it for
rapid defrosting or heating up of food, you can also prepare whole meals.
In our test kitchen our microwave team has gathered together a selection of the most delicious international
recipes which are quick and simple to prepare.
Be inspired by the recipes we have included and prepare your own favourite dishes in your microwave oven.
There are so many advantages to having a microwave oven which we are sure you will find exciting:
●Food can be prepared directly in the serving dishes, leaving less to wash up.
●Shorter cooking times and the use of little water and fat ensure that many vitamins, minerals and
characteristic flavours are preserved.
We advise you to read the cookery book guide and operating instructions carefully.
You will then easily understand how to use your oven.
Enjoy using your double grill microwave oven and trying out the delicious recipes.
R-798-A_[EN].qxd 7/16/07 2:52 PM Page 2

2
A. Information on Disposal for Users
(private households)
1. In the European Union
Attention: If you want to dispose of this equipment, please do not use the
ordinary dust bin!
Used electrical and electronic equipment must be treated separately and in
accordance with legislation that requires proper treatment, recovery and
recycling of used electrical and electronic equipment.
Following the implementation by member states, private households within
the EU states may return their used electrical and electronic equipment to
designated collection facilities free of charge*.
In some countries* your local retailer may also take back your old product
free of charge if you purchase a similar new one.
*) Please contact your local authority for further details.
If your used electrical or electronic equipment has batteries or accumulators,
please dispose of these separately beforehand according to local
requirements.
By disposing of this product correctly you will help ensure that the waste
undergoes the necessary treatment, recovery and recycling and thus
prevent potential negative effects on the environment and human health
which could otherwise arise due to inappropriate waste handling.
2. In other Countries outside the EU
If you wish to discard this product, please contact your local authorities and
ask for the correct method of disposal.
For Switzerland: Used electrical or electronic equipment can be returned
free of charge to the dealer, even if you don’t purchase a new product.
Further collection facilities are listed on the homepage of www.swico.ch or
www.sens.ch.
B. Information on Disposal for Business Users
1. In the European Union
If the product is used for business purposes and you want to discard it:
Please contact your SHARP dealer who will inform you about the take-back
of the product. You might be charged for the costs arising from take-back
and recycling. Small products (and small amounts) might be taken back by
your local collection facilities.
For Spain: Please contact the established collection system or your local
authority for take-back of your used products.
2. In other Countries outside the EU
If you wish to discard of this product, please contact your local authorities
and ask for the correct method of disposal.
GB
Attention:
Your product is
marked with this
symbol.
It means that used
electrical and
electronic products
should not be mixed
with general
household waste.
There is a separate
collection system for
these products.
R-798-A_[EN].qxd 7/16/07 2:52 PM Page 3

3
CONTENTS
Operation manual
DEAR CUSTOMER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
RECYCLING INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
OVEN AND ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-1-3
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-3
BEFORE OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-4
SELECTING A LANGUAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-4
ENERGY SAVE MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB-5
USING THE STOP BUTTON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB-5
SETTING THE CLOCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB-6
MICROWAVE POWER LEVELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-6
MICROWAVE COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-7
GRILL COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ... GB-7-8
HEATING WITHOUT FOOD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-8
DUAL COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-9
OTHER CONVENIENT FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB-10-12
AUTOMATIC OPERATION (EXPRESS PIZZA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB-13
EXPRESS PIZZA CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-13
AUTOMATIC OPERATION (PIZZA/FUN
MENUS/AUTO COOK/AUTO DEFROST) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-14-15
PIZZA CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-15
FUN MENUS CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-16
AUTO COOK CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-16
AUTO DEFROST CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-17
RECIPES FOR AUTO COOK AC-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-18
CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-19
SERVICE CALL CHECK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-20
Cookbook
WHAT ARE MICROWAVES? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-X
WHAT YOUR NEW COMBI-MICROWAVE
OVEN CAN DO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-X
SUITABLE COOKWARE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-XX-XX
TIPS AND TECHNIQUES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-XX-XX
HEATING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-XX
THAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-XX
THAWING AND COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-XX
COOKING OF MEAT, FISH AND POULTRY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-XX
COOKING FRESH VEGETABLES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-XX
LEGEND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-XX
TABLES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-XX-XX
RECIPES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-XX-XX
SERVICE ADDRESSES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-12
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
R-798-A_[EN].qxd 7/16/07 2:52 PM Page 4

4
ENGLISH
OVEN AND ACCESSORIES
1Control panel
2Oven lamp
3Grill heating element (top grill)
4Waveguide cover
5Oven cavity
6Turntable motor shaft
7Grill heating element (bottom grill)
8Door seals and sealing surfaces
9Door opening handle
10 Ventilation openings
11 Power cord
12 Outer cabinet
ACCESSORIES:
Check to make sure the following accessories are
provided:
13 Turntable 14 Low Rack (height: 2,5 cm)
15 High Rack (height: 10,5 cm)
Place the turntable over the turntable motor shaft on
the floor of the cavity.
Before first using the turntable and racks, clean with
mild soapy water.
Do not cut or scratch the turntable.
1
2
3
12
10
81076 5 4
14
15
NOTE:
When you order accessories, please mention the
following two items: Part name and model name to
your dealer or SHARP authorized service agent.
9
11
WARNING:
The accessories (e.g. turntable) will become
very hot during Grill, Dual and Automatic
operation (except Auto Defrost) modes.
Always use thick oven gloves when
removing the food or turntable from the oven
to prevent burns.
13
7
R-798-A_[EN].qxd 7/16/07 2:52 PM Page 5

5
CONTROL PANEL
Digital display and indicators
1. BOTTOM GRILL indicator
2. TOP GRILL indicator
3. CLOCK SET indicator
4. LESS/MORE indicator
5. INFORMATION indicator
6. TIMER indicator
7. COOKING IN PROGRESS indicator
8. WEIGHT (kg) indicator
9. MICROWAVE indicator
Operating buttons
Operating buttons
10. LANGUAGE button
11. EXPRESS PIZZA button
12. PIZZA button
13. FUN MENUS button
14. AUTO DEFROST button
15. AUTO COOK button
16. COOKING MODE dial
Rotate the dial so that indicator points to
appropriate symbol:
for microwave cooking
for microwave cooking with TOP GRILL
for microwave cooking with BOTTOM GRILL
for TOP GRILL
for BOTTOM GRILL
for TOP & BOTTOM GRILLS
17. + 1 min button
18. TIME/WEIGHT dial
Rotate the dial to enter either the
cooking/defrosting time or weight of food.
19. START button
20. INFO/CLOCK button
21. STOP button
22. MICROWAVE POWER LEVEL button
Press to change the microwave power
setting.
23. LESS/MORE buttons
8
1
2
23 11
12
10
13
14
16
17
18
19
20
15
22
21
4
3
9 7 6 5
R-798-A_[EN].qxd 7/16/07 2:52 PM Page 6

To avoid overheating and fire, special care must be taken
when cooking or reheating foods with a high sugar or fat
content, for example, Sausage rolls, Pies or Christmas
pudding.
See the corresponding hints in operation manual and the
cookery book section.
To avoid the possibility of injury
WARNING:
Do not operate the oven if it is damaged or
malfunctioning. Check the following before use:
a)The door; make sure the door closes properly and
ensure it is not misaligned or warped.
b)The hinges and safety door latches; check to make sure
they are not broken or loose.
c) The door seals and sealing surfaces; ensure that they
have not been damaged.
d)Inside the oven cavity or on the door; make sure there
are no dents.
e) The power supply cord and plug; ensure that they are
not damaged.
If the door or door seals are damaged, the oven must not be
operated until it has been repaired by a competent person.
Never adjust , repair or modify the oven yourself.
It is hazardous for anyone other than a competent
person to carry out any service or repair
operation which involves the removal of a cover
which gives protection against exposure to
microwave energy.
Do not operate the oven with the door open or
alter the door safety latches in any way.
Do not operate the oven if there is an object
between the door seals and sealing surfaces.
Do not allow grease or dirt to build up on the
door seals and adjacent parts. Clean the oven
at regular intervals and remove any food
deposits. Follow the instructions for “Care and
Cleaning” on page GB-19. Failure to maintain
the oven in a clean condition could lead to a
deterioration of the surface that could
adversely affect the life of the appliance and
possibly result in a hazardous situation.
Individuals with PACEMAKERS should check with
their doctor or the manufacturer of the pacemaker
for precautions regarding microwave ovens.
To avoid the possibility of electric shock
Under no circumstances should you remove the outer cabinet.
Never spill or insert any objects into the door lock openings or
ventilation openings. In the event of a spill, turn off and unplug the
oven immediately, and call an authorised SHARP service agent.
Do not immerse the power supply cord or plug in
water or any other liquid.
Do not let the power supply cord hang over the
edge of a table or work surface.
IMPORTANT SAFETY INSTRUCTIONS: READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
To avoid the danger of fire.
The microwave oven should not be left
unattended during operation. Power
levels that are too high, or cooking times
that are too long, may overheat foods
resulting in a fire.
This oven is designed for counter top or built-in use.
Do not place the oven in a cabinet. When the oven is
to be built-in, the installation frame EBR-4900 licensed
by SHARP must be used. This is available from your
dealer. Refer to the frame installation instructions or ask
your dealer for the proper instruction procedure. Only
the use of this frame will guarantee the safety and
quality of the product.
The electrical outlet must be readily accessible so that
the unit can be unplugged easily in an emergency.
The AC power supply must be 230V, 50Hz, with a
minimum 16A distribution line fuse, or a minimum 16A
distribution circuit breaker.
A separate circuit serving only this appliance should be
provided.
Do not place the oven in areas where heat is
generated. For example, close to a conventional oven.
Do not install the oven in an area of high humidity or
where moisture may collect.
Do not store or use the oven outdoors.
If smoke is observed, switch off or
unplug the oven and keep the door
closed in order to stifle any flames.
Utensils should be checked to ensure that
they are suitable for use in the oven. See
Page GB-XX. Use only microwave safe
containers and utensils on microwave
modes.
When heating food in plastic or paper
containers, keep an eye on the oven due
to the possibility of ignition.
Clean the waveguide cover, the oven
cavity and the turntable after use. These
must be dry and free from grease. Built-
up grease may overheat and begin to
smoke or catch fire.
Do not place flammable materials near the oven or
ventilation openings.
Do not block the ventilation openings.
Remove all metallic seals, wire twists, etc., from food
and food packages. Arcing on metallic surfaces may
cause a fire.
Do not use the microwave oven to heat oil for deep
frying. The temperature cannot be controlled and the
oil may catch fire.
To make popcorn, use only special microwave
popcorn makers.
Do not store food or any other items inside the oven.
Check the settings after you start the oven to ensure the
oven is operating as desired. GB-1
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
R-798-A_[EN].qxd 7/16/07 2:52 PM Page GB-1

GB-2
IMPORTANT SAFETY INSTRUCTIONS
Use pot holders or oven gloves when removing food
from the oven to prevent burns.
Always open containers, popcorn makers, oven cooking
bags, etc., away from the face and hands to avoid
steam burns and eruption of boiling.
To avoid burns, always test food temperature
and stir before serving and pay special attention
to the temperature of food and drink given
to babies, children or the elderly.
Accessible
parts may become hot during use. Young
children should be kept away.
Temperature of the container is not a true indication of
the temperature of the food or drink; always check the
food temperature.
Always stand back from the oven door when opening it
to avoid burns from escaping steam and heat.
Slice stuffed baked foods after heating to release
steam and avoid burns.
This appliance is not intended to be operated by means
of an external timer or separate remote-control system.
To avoid misuse by children
WARNING:
Only allow children to use the oven without
supervision when adequate instructions have
been given so that the child is able to use
the oven in a safe way and understands the
hazards of improper use. When the appliance is
operated in the GRILL, CONVECTION, DUAL, and
AUTOMATIC operation (except AUTO DEFROST),
children should only use the oven under adult
supervision due to the temperature generated.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that
they do not play with the appliance.
Do not lean or swing on the oven door. Do not play with
the oven or use it as a toy.
Children should be taught all important safety instructions:
use of pot holders, careful removal of food coverings; paying
special attention to packaging (e.g. self-heating materials)
designed to make food crisp, as they may be extra hot.
Other warnings
Never modify the oven in any way.
Do not move the oven while it is in operation.
This oven is for home food preparation only and may
only be used for cooking food. It is not suitable for
commercial or laboratory use.
Keep the power supply cord away from heated
surfaces, including the rear of the oven.
Do not attempt to replace the oven lamp yourself or
allow anyone who is not an electrician authorised by
SHARP to do so. If the oven lamp fails, please consult
your dealer or an authorised SHARP service agent.
If the power supply cord of this appliance is
damaged, it must be replaced with a special cord.
The exchange must be made by an authorised SHARP
service agent.
To avoid the possibility of explosion and
sudden boiling:
WARNING: Liquids and other foods must not
be heated in sealed containers since they are
liable to explode.
Microwave heating of beverages can result in
delayed eruptive boiling, therefore care must
be taken when handling the container.
Never use sealed containers. Remove seals and lids
before use. Sealed containers can explode due to
a build up of pressure even after the oven has been
turned off.
Take care when microwaving liquids. Use a wide-
mouthed container to allow bubbles to escape.
Never heat liquids in narrow necked
containers such as baby bottles, as this
may result in the contents erupting from the
container when heated and cause burns.
To prevent sudden eruption of boiling liquid and
possible scalding:
1. Do not use excessive amount of time (See page GB-
XX).
2. Stir liquid prior to heating/reheating.
3. It is advisable to insert a glass rod or similar utensil
(not metal) into the liquid whilst reheating.
4. Let liquid stand for at least 20 seconds in the oven at
the end of cooking time to prevent delayed eruptive
boiling.
Do not cook eggs in their shells, and whole
hard boiled eggs should not be heated in
microwave ovens since they may explode
even after microwave cooking has ended.
To cook or reheat eggs which have not been
scrambled or mixed, pierce the yolks and the
whites, or the eggs may explode. Shell and
slice hard boiled eggs before reheating them
in the microwave oven.
Pierce the skin of such foods as potatoes, sausages
and fruit before cooking, or they may explode.
To avoid the possibility of burns
WARNING: The contents of feeding bottles and
baby food jars must be stirred or shaken and
the temperature checked before consumption,
in order to avoid burns.
Untitled-2 GB-2Untitled-2 GB-2 4/7/08 4:49:58 PM4/7/08 4:49:58 PM

Do not use plastic containers for microwaving if the
oven is still hot from using the GRILL, DUAL and
AUTOMATIC operation (except AUTO DEFROST),
because they may melt. Plastic containers must not
be used during above modes unless the container
manufacturer says they are suitable.
NOTE:
If you are unsure how to connect your oven, please
consult an authorised, qualified electrician.
Neither the manufacturer nor the dealer can accept
any liability for damage to the oven or personal
injury resulting from failure to observe the correct
electrical connection procedure.
Water vapour or drops may occasionally form on
the oven walls or around the door seals and
sealing surfaces. This is a normal occurrence and is
not an indication of microwave leakage or a
malfunction.
To promote trouble-free use of your oven
and avoid damage.
Never operate the oven when it is empty except
where recommended in the operation manual, see
Page GB-8. Doing so may damage the oven.
When using a browning dish or self-heating
material, always place a heat-resistant insulator
such as a porcelain plate under it to prevent
damage to the turntable due to heat stress.
The preheating time specified in the dish’s
instructions must not be exceeded.
Do not use metal utensils, which reflect microwaves
and may cause electrical arcing. Do not put cans
in the oven.
Use only the turntable designed for this oven.
Do not place anything on the outer cabinet during
operation.
1. Remove all packing materials from the inside of the
oven cavity. Discard the loose polythene sheet from
between the door and cavity. Remove the feature
sticker, if attached, from the outside of the door.
2. Check the oven carefully for any signs of damage.
3. Place the oven on a flat, level surface strong
enough to support the oven’s weight plus the
heaviest item likely to be cooked.
This oven is designed to be used on a countertop
or built into a kitchen cabinet. When building the
oven into a kitchen cabinet, see "To avoid damage
of the fire" on page GB-1.
4. The oven door may become hot during
cooking. Place or mount the oven so that
the bottom of the oven is 85 cm or more
above the floor. Keep children away
from the door to prevent them burning
themselves.
5. Do not allow the power supply cord to
run over any hot or sharp surfaces,
such as the hot air vent area at the top
rear of the oven.
6.Ensure there is a minimum of free space above the
oven of 19 cm.
7. Securely connect the plug of the oven to a
standard earthed (grounded) household electrical
outlet.
✓Remove this film
19 cm
GB-3
IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
INSTALLATION
R-798-A_[EN].qxd 7/16/07 2:52 PM Page GB-3

GB-4
BEFORE OPERATION
Press LANGUAGE button
once
twice
3 times
4 times
5 times
6 times
LANGUAGE
ENGLISH
DEUTSCH
NEDERLANDS
FRANCAIS
ITALIAN
ESPANOL
1. Choose the desired
language 2. Start the setting. Check the display:
x5 x1
NOTE: The selected language will be memorised, even if the electrical power supply is interrupted.
Example:
Suppose you want to select Italian.
Your oven comes pre-set for Energy Save Mode so
when you first plug it in nothing will appear on the
digital display.
To operate the oven in Energy Save Mode:
1. Plug in the oven. Nothing will appear on the
display at this time.
2. Open the door. The oven display will show
“SELECT LANGUAGE” in 6 languages.
3. Close the door.
4. Select a language (see below).
5. Heat the oven without food (See page GB-8).
NOTE:
You can change to Clock Set Mode if you prefer,
see page GB-6 of the operation manual. If you
decide to set the clock, Energy Save Mode does
not work.
COOKING HINTS:
Your oven has an 'Information Display System' which
allows you to access step by step instructions for each
of the ovens features/buttons. Instructions will appear
in the digital display each time you press a button to
inform you of the next operation step.
In Energy Save Mode, if you do not operate the oven for 3 minutes or more (i.e. closing the door,
pressing the STOP button, or at the end of cooking), you will not be able to operate the oven until you
open and close the oven door.
Your oven initially has English selected as the
language. To change to a language of your choice,
scroll through the options available by pressing the
LANGUAGE button as shown in the table opposite.
Then press the START button.
SELECTING A LANGUAGE
R-798-A_[EN].qxd 7/16/07 2:52 PM Page GB-4

GB-5
ENERGY SAVE MODE
ENGLISH
1. Make sure the
correct time
appears on the
display.
3. Adjust the display
to 0 by rotating the
TIME/WEIGHT
dial.
2. Press the
INFO/CLOCK
button twice.
x1
4. Press START button.
The power will be off and
the display will show
nothing.
Display:
x2
Your oven has two operating modes, Energy Save Mode and Clock Set Mode.
The difference between them is that when you are not using the oven, in Energy save Mode nothing will
appear on the digital display and in Clock Set Mode the time will be shown.
In Energy Save Mode, if you do not operate the oven for 3 minutes or more (i.e. closing the door, pressing
the STOP button, or at the end of cooking), you will not be able to operate the oven.
To restore power on, open the door.
If you set the clock, energy save mode will be cancelled.
To start energy save mode manually, follow the instructions below.
Example:
To start the energy save mode (the current time is 23:35):
Use the STOP button to:
1. Erase a mistake during programming.
2. Stop the oven temporarily during cooking.
3. Cancel a programme during cooking, press
the STOP button twice.
USING THE STOP BUTTON
R-798-A_[EN].qxd 7/16/07 2:52 PM Page GB-5

GB-6
SETTING THE CLOCK
270 WATT = 30 % output
90 WATT = 10 % output
Your oven has 5 power levels. To choose the power level, follow the advice given in the recipe section.
900 WATT = 100 % output
630 WATT = 70 % output
450 WATT = 50 % output
• To select Microwaving, rotate the COOKING MODE dial to the MICROWAVE setting.
• Select the desired microwave power setting by pressing the MICROWAVE POWER LEVEL button.
• If the MICROWAVE POWER LEVEL button is pressed once, (100 %) will be displayed.
If you miss your desired level, continue pressing the MICROWAVE POWER LEVEL button until you reach
the level again.
•If the level is not selected, the level 900 W (100 %) is automatically set.
ENERGY SAVE MODE SET CLOCK”.
If this occurs during cooking, the programme will
be erased. The time of day will also be erased.
5. When you want to reset the time of day, follow the
above example again.
6. If you do not set the clock, press the STOP button
once. “.0” will appear on the display. When the
operation of the oven is finished, “.0” will
reappear on the display instead of the time of day.
7. If you set the clock, energy save mode does not
work.
There are two setting modes: 12 hour clock and 24 hour clock.
x2
1. To set the 12 hour clock, press
the INFO/CLOCK button
twice, as shown:
Example:
To set the 24 hour clock to 23:35:
x3
1. Choose the 24 hour clock by
pressing the INFO/CLOCK
button 3 times.
2. Set the hours. Rotate the TIME/
WEIGHT dial clockwise until the
correct hour is displayed.
3. Change from hours to
minutes by pressing the
INFO/CLOCK button once.
Check the display:
4. Set the minutes. 5. Start the clock.
NOTES:
1. You can rotate the TIME/WEIGHT dial clockwise
or counter clockwise.
2. Press the STOP button if you make a mistake
during programming.
3. If the oven is in cooking mode and you wish to
know the time of day, touch the INFO/CLOCK
button. As long as your finger is touching the
button, the time of day will be displayed.
4. If the electrical power supply to your microwave
oven is interrupted, plug in the oven again, then
open and close the door. The display will show:
“ENERGY SAVE MODE TO GO OUT OF
x3
2. To set the 24 hour clock, press
the INFO/CLOCK button 3
times, as shown:
x1
x1
MICROWAVE POWER LEVELS
R-798-A_[EN].qxd 7/16/07 2:52 PM Page GB-6

GRILL COOKING
GB-7
MICROWAVE COOKING
ENGLISH
Your oven has 2 grill heating elements, and a combination of 3 grill cooking modes. Select the desired grill
mode by rotating the COOKING MODE dial to the desired setting.
NOTES:
1. When the door is opened during the cooking
process, the cooking time on the digital display
stops automatically. The cooking time starts to
count down again when the door is closed and
the START button is pressed.
2. If you wish to know the power level during
cooking, press the MICROWAVE POWER
LEVEL button. As long as your finger is pressing
the MICROWAVE POWER LEVEL button, the
power level will be displayed.
3. You can rotate the TIME/WEIGHT dial
clockwise or counter-clockwise. If you rotate the
dial counter-clockwise, the cooking time will
decrease from 90 minutes by degrees.
NOTE FOR REHEATING READY MEALS:
Place the ready meal in a heat-resistant flan dish
on the low rack.
Example:
Suppose you want to heat soup for 2 minutes and 30 seconds on 630 W microwave power.
2. Enter desired cooking
time by rotating the
TIME/WEIGHT dial
clockwise.
3. Press the
MICROWAVE
POWER LEVEL button
twice for 630 W
microwave power.
COOKING MODE DIAL GRILL HEATING ELEMENT IN USE
Top and Bottom Grill together
Top Grill
Bottom Grill
DISPLAY
TOP AND BOTTOM
TOP GRILL
BOTTOM GRILL
1. Rotate the COOKING
MODE dial to the
MICROWAVE setting.
x1
4. Press the START
button once to start
cooking.
Cooking Time: Increasing unit:
0-5 minutes 10 seconds
5-10 seconds 30 seconds
10-30 minutes 1 minute
30-90 minutes 5 minutes
Your oven can be programmed for up to 90 minutes.
(90.00). The input unit of cooking (defrosting) time
varies from 10 seconds to five minutes. It depends on
the total length of the cooking (defrosting) time as
shown on the table opposite:
x2
Display:
R-798-A_[EN].qxd 7/16/07 2:52 PM Page GB-7

HEATING WITHOUT FOOD
GB-8
GRILL COOKING
WARNING: The oven door, outer cabinet & oven cavity will become hot.
Take care to avoid burns when cooling the oven down after operation.
WARNING: The oven cavity, door, outer cabinet, turntable, racks, dishes and especially the
bottom grill will become very hot, always use thick oven gloves when
removing the food or turntable from the oven to prevent burns.
You may detect smoke or a burning smell when using the grill(s) or dual grill for the first time. This is normal and
not a sign that the oven is out of order.
To avoid this problem, when first using the oven, operate both top and bottom grills without food for 20 minutes.
IMPORTANT: During grill operation, to allow smoke or smells to disperse open a window or switch the kitchen
ventilation on. Make sure there is no food in the oven.
2. Enter the required
heating time. (20 min.)
1. Rotate the COOKING
MODE dial to the TOP
& BOTTOM GRILL setting.
3. Start cooking by
pressing the
START button.
2. Enter the desired cooking time
by rotating the TIME/WEIGHT
dial clockwise.
1. Rotate the COOKING
MODE dial to the
TOP GRILL setting.
3. Press the START
button to start
cooking.
Example:
Suppose you want to cook cheese on toast for 5 minutes using the top grill only: (Place toast on the high rack.)
x1
1. The high or low racks are recommended when grilling.
2. You may detect smoke or a burning smell when using the grill for the first time, this is normal and not a
sign that the oven is out of order. (Please see heating without food below.)
3. After cooking the display may show ‘NOW COOLING’.
Display:
4. The oven will count
down. When the
oven has finished
cooking, open the
door to cool the
oven cavity.
x1
R-798-A_[EN].qxd 7/16/07 2:52 PM Page GB-8

GB-9
DUAL COOKING
ENGLISH
Setting Initial Microwave
power Grill heating
element Display
COOKING MODE
dial
Your oven has 2 DUAL cooking modes to combine the Microwave with the Grill(s). To select the DUAL cooking
mode, rotate the COOKING MODE dial to the desired setting. Generally, dual cooking time shortens the total
cooking time.
2. Enter the desired
cooking time by
rotating the
TIME/WEIGHT
dial clockwise.
1. Rotate the COOKING
MODE dial to the
DUAL 1 setting,
combining microwaving
with the TOP GRILL.
3. Press the
MICROWAVE
POWER LEVEL
button twice for 90 W
microwave power.
Display:
* If you want to adjust the microwave power, press the MICROWAVE POWER LEVEL button.
You can select up to 900 W power.
Example:
Suppose you want to cook for 20 minutes on DUAL 1, combining 90 W (10 %) with the TOP GRILL:
NOTE: After cooking, the display may show “NOW COOLING”.
x1
x2
4. Press the START
button to start
cooking.
WARNING: The oven cavity, door, outer cabinet, turntable, racks, dishes and especially the bottom
grill will become very hot, always use thick oven gloves when removing the food or
turntable from the oven to prevent burns.
DUAL 1
DUAL 2
270 W
270 W
Top grill
Bottom grill
R-798-A_[EN].qxd 7/16/07 2:52 PM Page GB-9

GB-10
OTHER CONVENIENT FUNCTIONS
1. LESS / MORE button.
The LESS ( ▼) and MORE ( ▲) buttons allow you to easily decrease or increase programmed setting times,
(for a less well or more well cooked result), used in automatic operations or cooking time while in operation.
a) Changing the pre-programmed time setting.
Example:
Suppose you want to cook 0.4 kg Grill Skewers using the AUTO COOK button and MORE ( ▲) button.
3. Enter the amount
by rotating the
TIME/WEIGHT
dial clockwise.
1. Choose the desired
result (well cooked)
by pressing the
MORE ( ▲) button
once.
2. Select AUTO COOK
(Grill Skewers) by
pressing the AUTO
COOK button once.
Display:
x1 x1
NOTE:
To cancel LESS or MORE, press the same button again.
To change MORE to LESS simply press the LESS ( ▼) button.
To change LESS to MORE simply press the MORE ( ▲) button.
b) Adjusting the heating time while oven is operating.
The cooking time can be decreased or increased in 1 minute steps each time the LESS ( ▼) and
MORE ( ▲) buttons are pressed.
NOTE:
You can use this function for manual cooking only.
x1
4. Press the START
button to start
cooking.
R-798-A_[EN].qxd 7/16/07 2:52 PM Page GB-10

GB-11
OTHER CONVENIENT FUNCTIONS
ENGLISH
2. MINUTE PLUS function.
The +1min button allows you to operate the two following functions.
a) 1 minute cooking
You can cook on your desired cooking mode for 1 minute without entering the cooking time.
Example:
Suppose you want to cook for 1 minute at 630W microwave power.
1. Rotate the COOKING
MODE dial to the
MICROWAVE setting.
Display:
NOTE:
1. You can use this function for manual cooking only.
2. When the COOKING MODE dial is on microwave ( ) and you press the +1min button, the
microwave power is always 900 W. When the COOKING MODE dial is on dual ( or )
and you press the +1min button, the microwave power is always 270 W.
3. To avoid misuse by children the 1 minute cooking function can be used only within 3 minutes after
the preceding operation, closing the door or pressing the STOP button.
b) Extend the cooking time
You can extend the cooking time in multiples of one minute if the button is pressed while the oven is in
operation.
NOTE:
You can use this function for manual cooking only.
2. Press the MICROWAVE
POWER LEVEL button
twice for 630 W
microwave power.
x1
x2
3. Press the +1min
button to start
cooking.
R-798-A_[EN].qxd 7/16/07 2:52 PM Page GB-11

GB-12
OTHER CONVENIENT FUNCTIONS
3. TO CHECK THE POWER LEVEL
To check the microwave power level during cooking press the MICROWAVE POWER LEVEL button.
As long as your finger is pressing the button, the power level will be displayed.
The oven continues to count down, although the display shows the power level.
1. Choose the
INFO/CLOCK
button function.
2. Press the AUTO COOK
button twice to select the
AUTO COOK menu AC-2.
4. INFORMATION button
Each button carries useful information. If you wish to get the information, press the INFO/CLOCK button
before pressing the desired button.
Example:
Suppose you want to get information about AUTO COOK menu number 2, Grilled Chicken:
NOTE:
1. The information message will be repeated twice, and then the display will show the time of day, if set.
2. If you want to cancel the information press the STOP button.
x1
Check the
Display:
x2
R-798-A_[EN].qxd 7/16/07 2:52 PM Page GB-12

EXPRESS PIZZA CHART
GB-13
AUTOMATIC OPERATION (EXPRESS PIZZA)
ENGLISH
WARNING:
The oven cavity, door, outer cabinet, turntable, racks, dishes and especially the bottom
grill will become very hot, always use thick oven gloves when removing the food or
turntable from the oven to prevent burns.
The EXPRESS PIZZA function automatically cooks frozen pizza very quickly.
What you need to know when using this automatic function:
1. The EXPRESS PIZZA can only be input within 3 minutes after cooking completion, closing the door or
pressing the STOP button.
2. To increase the weight press the EXPRESS PIZZA button until the desired weight is displayed.
Enter the weight of the food only.
For food weighing more or less than the weights given in the cooking chart, cook using PIZZA function
(see pages GB-14-15) or manual operation.
3. The programmed cooking time is an average time. If you want to alter the cooking time, use the
LESS ( ▼) or MORE ( ▲) buttons before pressing the EXPRESS PIZZA button (see page GB-10).
If you want the best pizza result, use the PIZZA function (P-1 Frozen Pizza), see pages GB-14-15.
4. The oven will start to cook instantly after the weight has been input.
NOTE:
The final temperature will vary according to the initial temperature. Check food is piping hot after cooking.
If necessary, you can extend the cooking time manually.
Example: To cook Frozen Pizza 0,3 kg.
1. To select the menu required and
weight range, press the EXPRESS
PIZZA button once.
After 2 seconds the oven will start to
cook automatically.
x1
MENU
Express Frozen
Pizza
"Stone oven" Pizza
(thin base, pre-baked)
WEIGHT (Increasing
Unit) / UTENSILS
0,30/0,35/0,40 kg (50 g)
(initial temp -18° C)
Directly on the turntable
PROCEDURE
• Remove the ready prepared frozen pizza
from the packaging and place on the
turntable.
• After cooking, place on a plate for serving.
BUTTON
EXPRESS
R-798-A_[EN].qxd 7/16/07 2:52 PM Page GB-13

GB-14
AUTOMATIC OPERATION
(PIZZA/FUN MENUS/AUTO COOK/AUTO DEFROST)
WARNING: For all menus except AUTO DEFROST:
The oven cavity, door, outer cabinet, turntable, racks, dishes and especially the bottom grill will
become very hot. Use thick oven gloves when removing food or the turntable from the oven to
prevent burns.
When action is required (e.g. to turn food over) the
oven stops, the audible signals sound and the
display shows the necessary action. To continue
cooking, press the START button.
These functions automatically work out the correct cooking mode and cooking time to get the best results.
You can choose from the 3 PIZZA, 3 FUN MENUS, 4 AUTO COOK and 5 AUTO DEFROST menus.
What you need to know when using these automatic
functions:
1. Menu can be input by pressing the PIZZA, FUN
MENUS, AUTO COOK or AUTO DEFROST button
until the desired menu number is displayed.
2.The weight of the food can be input by rotating the
TIME/WEIGHT dial until the desired weight is
displayed.
Enter the weight of the food only. Do not include the
weight of the container.
For food weighing more or less than weights/
quantities given in the cooking chart, cook using
manual operation.
3. The programmed cooking times are average times.
If you want to alter cooking times pre-programmed in
the automatic operations, use the LESS ( ▼) or
MORE ( ▲) buttons. For best results follow the
cooking chart instructions, pages GB-15-17.
4. Press the START button to start cooking.
TIME/WEIGHT dial
LESS/MORE buttons
START button
The final temperature will vary according to the initial temperature. Check food is piping hot after cooking.
If necessary, you can extend the cooking time and change the power level.
PIZZA button
FUN MENUS button AUTO COOK button AUTO DEFROST button
PIZZA button
1.
2.
3.
4.
R-798-A_[EN].qxd 7/16/07 2:52 PM Page GB-14
