Shenzhen GPT26 User manual

① A Micro SIM Card needed，do not support CDMA2000 ；
NOTICE
② GPRS of Sim Card must be opened；
Traffic, SMS, Calls and other SIM card service fee charged by operators;
③ Positioning / Remote Power off / Remote command fucntion rely on
the network of base station. Device may not work well if the network
signal is not very good;
④ Product should stay away from fire, high temperature, heat and other
extreme environments;
SIM
Micro SIM
Nano SIM

INTRODUCTION
GPS (GPS Satellite signal,Blue)
Quick flash: Searching for GPS
Satellite signals (Not positioned);
Slow flash: Found GPS signals ;
( Positioned by GPS )
Blue LED Long light after charging.
GSM LED ( LBS / Base signal, Red )
Quick flash: Searching for base signals
( Not connect yet) ;
Slow flash: Found base signals ;
( Base Connected and LBS start )
Red LED Long light when charging.
Recharge Hole
Power button : Press >3s to power on (No power off button, use app to power off)
SOS：Press >3s to send SOS alarm to web platform and APP when device is working.
USB Plug
Power On
SOS
LED Indicator
SIM Slot

GPS Positioning Accuracy 5-15m (Depend GPS signal)
About 200m (Depend Bases Density)
1575 MHz
7000 mAh
180 g
108.5(L)×66.5(W)×22.4(H)
20%~80%RH
-20℃~65℃
850/900/1800/1900 MHz
<3秒，<15秒，<60秒
LBS Positioning Accuracy
GPS Frequency
GSM Frequency
Hot/Warm/Cold Start Time
Battery Capacity
Dimensions (mm)
Temperature
Humidity
Weight
Funcon/Parameter
GPS/LBS double-Positioning mode, intelligent switching
For various application scenarios of vehicle tracking
Built-in magnets, can be adsorbed on iron
IP67 waterproof
Emergency SOS for help
Real-time tracking on Platform & APP ,playback track in 90 days
Receive SOS alarm, fence alarm, low battery alarm on APP

Q & A
Q：Positioned by GPS / LBS ?
A：GPS called“Global Positioning System”,GPS device can be positioned by GPS
satellite outdoor. Device also can be positioned by base stations of operator
which call LBS ,mainly for assistance positioning.
Q：Location is not accurate?
A：If need accurate positioning, use device outdoor where GPS signal is good and
start GPS tracking mode.
Device indoor mainly positioned by LBS, the accuracy lower than GPS
Q：Standby time can be longer?
A：Device need Internet connection. Standby time will be different by different
using environment and working mode.
Q：Device offline?
A：The conditions below results in offline.
① No balance or No SIM ② No GSM or GSM signal is weak ③ Battery runs out
Attention for more services:
QQ Group of Keelin UsersKeelin MallWechat Official Account

Long Standby GPS Tracker
EELINK Communication Technology CO.LTD
Address: 3 Floor, Yu yang mansion, 2nd Road of Langshan,
Science and Technology Park, Nanshan District, ShenZhen, CHINA
TEL : [phone]
Mail : [e-mail]
e
2
Link

Insert SIM,Charge & Boot,Installaon
Begin experience of GPS tracker
1
Open USB plug and insert SIM to device, notice direction.
To remove SIM card , please pull out metal sheet first.
Make sure UBS plug is completely plugged, otherwise it will
affect waterproof performance.
Absorb magnet-side on iron or stick on board with 3M.
Press power on or connect USB charger to boot , It takes 10
hours from low power to fully charged.

Install KEELIN APP, Acvate device
2
可依恋
®
Scan QR below to download Keelin APP
Launch APP , Scan QR on Label to register & activate device
Begin experience of Keelin APP

Standby King
GPT26 Quick Start Guide
