Siemens SN Series User manual

en Instruction manual
Dishwasher
SN.../SX...

(08@HP`h)")*)2):)B)JX)R
1"1*121:1B1J1R1Z1b1j9"9*929:9B9J

Ù






5HVHWVHF
6HWXSVHF

  


















en
3
Table of contents
enInstruction manual
8Intended use . . . . . . . . . . . . . . . 5
(Safety instructions. . . . . . . . . . . . 5
Before you switch ON the appliance 5
Delivery. . . . . . . . . . . . . . . . . . . . . . . . 5
Installation. . . . . . . . . . . . . . . . . . . . . . 6
In daily use . . . . . . . . . . . . . . . . . . . . . 7
Damage . . . . . . . . . . . . . . . . . . . . . . . 7
Disposal . . . . . . . . . . . . . . . . . . . . . . . 7
Door lock . . . . . . . . . . . . . . . . . . . . . . 8
7Environmental protection . . . . . . 9
Packaging. . . . . . . . . . . . . . . . . . . . . 10
Old appliances . . . . . . . . . . . . . . . . . 10
*Getting to know your appliance 10
Control panel . . . . . . . . . . . . . . . . . . 10
Appliance interior . . . . . . . . . . . . . . . 10
Info button . . . . . . . . . . . . . . . . . . . . 11
Time setting . . . . . . . . . . . . . . . . . . . 11
Initial start-up . . . . . . . . . . . . . . . . . . 11
Settings. . . . . . . . . . . . . . . . . . . . . . . 12
oHome Connect . . . . . . . . . . . . . . 14
Setting up the App . . . . . . . . . . . . . . 14
Setting up Home Connect . . . . . . . . 14
Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . 15
Network login . . . . . . . . . . . . . . . . . . 15
Connect to App . . . . . . . . . . . . . . . . 15
Remote start button . . . . . . . . . . . . . 16
Wi-Fi without a connection to the Home
Connect server . . . . . . . . . . . . . . . . . 16
Setting up energy manager . . . . . . . 16
Activating energy manager . . . . . . . 17
Deactivating energy manager . . . . . 17
Software update . . . . . . . . . . . . . . . . 17
Remote diagnostics . . . . . . . . . . . . . 18
Declaration of Conformity . . . . . . . . . 18
+Water softening system / special
salt . . . . . . . . . . . . . . . . . . . . . . . 18
Water hardness table . . . . . . . . . . . . 19
Adjusting the water softening system 19
Using special salt . . . . . . . . . . . . . . . 19
Detergents with salt replacement
substances . . . . . . . . . . . . . . . . . . . . 20
Switching off water softening system. 20
,Rinse aid. . . . . . . . . . . . . . . . . . . 20
Setting amount of rinse aid . . . . . . . . 20
Switching off rinse aid refill indicator
21
-Utensils. . . . . . . . . . . . . . . . . . . . 21
Not suitable . . . . . . . . . . . . . . . . . . . . 21
Glass and utensil damage. . . . . . . . . 21
Loading the dishwasher . . . . . . . . . . 21
Upper basket. . . . . . . . . . . . . . . . . . . 22
Lower basket. . . . . . . . . . . . . . . . . . . 22
Cutlery basket . . . . . . . . . . . . . . . . . . 23
Cutlery drawer . . . . . . . . . . . . . . . . . . 23
Etagere . . . . . . . . . . . . . . . . . . . . . . . 23
Folding spikes . . . . . . . . . . . . . . . . . . 24
Small items holder. . . . . . . . . . . . . . . 24
Knife rack . . . . . . . . . . . . . . . . . . . . . 24
Baking sheet spray head. . . . . . . . . . 24
Unloading the dishwasher . . . . . . . . . 25
Adjusting the height of the basket. . . 25
.Detergent . . . . . . . . . . . . . . . . . . 26
Adding detergent. . . . . . . . . . . . . . . . 27
Combination detergent . . . . . . . . . . . 27
/Overview of programmes . . . . . 29
Programme selection . . . . . . . . . . . . 30
Information for test institutes . . . . . . . 30

en
4
0Additional functions . . . . . . . . . 30
Save time (VarioSpeedPlus) . . . . . . .30
Half load . . . . . . . . . . . . . . . . . . . . . .30
HygienePlus (HygienePlus) . . . . . . . .31
IntensiveZone . . . . . . . . . . . . . . . . . .31
ExtraDry . . . . . . . . . . . . . . . . . . . . . . .31
Shine and Dry . . . . . . . . . . . . . . . . . .31
Energy Save . . . . . . . . . . . . . . . . . . .31
1Operating the appliance . . . . . . 31
Programme data . . . . . . . . . . . . . . . .31
Changing the settings . . . . . . . . . . . .31
AquaSensor . . . . . . . . . . . . . . . . . . . .32
Zeolith drying. . . . . . . . . . . . . . . . . . .32
Time display . . . . . . . . . . . . . . . . . . .32
Sensor setting . . . . . . . . . . . . . . . . . .32
extraDry . . . . . . . . . . . . . . . . . . . . . . .33
Eco forecast . . . . . . . . . . . . . . . . . . .33
Auto Power Off . . . . . . . . . . . . . . . . . 33
EmotionLight . . . . . . . . . . . . . . . . . . .33
Front display . . . . . . . . . . . . . . . . . . .33
timeLight . . . . . . . . . . . . . . . . . . . . . .33
infoLight . . . . . . . . . . . . . . . . . . . . . . .33
Changing start programme . . . . . . . .34
Tone volume . . . . . . . . . . . . . . . . . . .34
Button volume . . . . . . . . . . . . . . . . . .34
Child-proof lock . . . . . . . . . . . . . . . . .34
Greeting. . . . . . . . . . . . . . . . . . . . . . .34
Factory setting . . . . . . . . . . . . . . . . . .34
Switching the appliance on . . . . . . . . 34
Time preselection . . . . . . . . . . . . . . . 34
Programme end. . . . . . . . . . . . . . . . .35
Switching off the appliance . . . . . . . .35
Interrupting the programme . . . . . . . .35
Terminating the programme . . . . . . .35
Changing the programme . . . . . . . . .35
2Cleaning and maintenance . . . 35
Overall status of the dishwasher . . . . 36
Machine Care . . . . . . . . . . . . . . . . . . 36
Special salt and rinse aid . . . . . . . . .37
Filters. . . . . . . . . . . . . . . . . . . . . . . . .37
Spray arms . . . . . . . . . . . . . . . . . . . .38
3Fault, what to do? . . . . . . . . . . .38
Error message . . . . . . . . . . . . . . . . . 38
Waste water pump . . . . . . . . . . . . . . 38
Fault table . . . . . . . . . . . . . . . . . . . . 39
4Customer service . . . . . . . . . . . .48
5Installation and connection. . . .48
Contents of package . . . . . . . . . . . . 49
Safety instructions . . . . . . . . . . . . . . 49
Delivery . . . . . . . . . . . . . . . . . . . . . . 49
Technical specifications . . . . . . . . . . 49
Installation . . . . . . . . . . . . . . . . . . . . 49
Drainage connection . . . . . . . . . . . . 50
Drinking water connection . . . . . . . . 50
Warm water connection . . . . . . . . . . 50
Electrical connection . . . . . . . . . . . . 50
Removal . . . . . . . . . . . . . . . . . . . . . . 51
Transporting . . . . . . . . . . . . . . . . . . . 51
Protection against frost (Emptying
the appliance) . . . . . . . . . . . . . . . . . 51

Intended use en
5
8Intended use
I nt ended use ■This appliance is intended
for use in the home and
domestic environments.
■Use the dishwasher only in
the home and only for its
designated purpose: for
washing domestic dishes.
■This appliance is intended
for use up to a maximum
altitude of 2500 metres
above sea level.
(Safety instructions
Safety instructions This appliance may be used by
children over the age of 8 years
old and by persons with
reduced physical, sensory or
mental capabilities or by
persons with a lack of
experience or knowledge if they
are supervised or are instructed
by a person responsible for
their safety how to use the
appliance safely and have
understood the associated
hazards.
Children must not play with, on,
or around the appliance.
Children must not clean the
appliance or carry out general
maintenance unless they are at
least 8 years old and are being
supervised.
Keep children below the age of
8 years old at a safe distance
from the appliance and power
cable.
Before you switch ON the
appliance
Please read the instructions for
use and installation carefully.
They contain important
information on how to install,
use and maintain the appliance.
Retain all documents for later
use or for the subsequent
owner.
You can download the
instructions for use from our
website free of charge. The
relevant Internet address can
be found overleaf on these
instructions for use.
Delivery
1. Check the packaging and
dishwasher immediately for
damage caused in transit.
Do not switch on a damaged
appliance, but contact your
supplier.
2. Please dispose of the
packaging material in an
environmentally friendly
manner.
3. Do not let children play with
packaging and its parts.
There is a risk of suffocation
from collapsible boxes and
film.

en Safety instructions
6
Installation
■Following installation, ensure
that the back of the
dishwasher is not freely
accessible (protection
against contact due to hot
surface).
■Install and connect the
appliance according to the
installation and assembly
instructions.
■Prior to installation,
disconnect the dishwasher
from the power supply.
■Ensure that the protective
conductor system of the
domestic supply has been
correctly installed.
■The electrical connection
conditions must correspond
with the specifications on the
dishwasher rating plate 9J.
■If the power cord of this
appliance is damaged, it
must be replaced with a
particular power cord.
To prevent injury, the power
cord may be purchased from
customer service only.
■If the dishwasher is installed
in a high-sided unit, the unit
must be secured properly.
■If the dishwasher is installed
below or above other
domestic appliances, follow
the information for
installation in combination
with a dishwasher in the
installation instructions for
the particular appliances.
■Also follow the installation
instructions for the
dishwasher to ensure that all
appliances are operated
safely.
■If there is no information or if
the installation instructions
do not include the
appropriate information,
contact the manufacturer of
these appliances to ensure
that the dishwasher can be
installed above or below
these appliances.
■If you cannot obtain any
information from the
manufacturer, you must not
install the dishwasher above
or below these appliances.
■Install built-under or
integratable appliances only
under continuous worktops
which have been screwed to
adjacent cupboards to
ensure stability.
■Do not install the appliance
near heat sources (radiators,
heat storage tanks, cookers
or other appliances which
generate heat) and do not
install under a hob.
■Please note that the
insulation material of the
dishwasher power cord may
melt next to heat sources
(e.g. heating / hot water
installations) or hot
appliance parts. Make sure
that the power cord of the
dishwasher never comes into
contact with heat sources or
hot appliance parts.

Safety instructions en
7
■After installing the appliance,
ensure that the plug is easily
accessible. ~"Electrical
connection" on page 50
■For some models:
The plastic housing on the
water connection contains an
electric valve. The supply
hose contains electrical
connection cables. Do not
cut through the supply hose.
Do not immerse the plastic
housing in water.
In daily use
Read and observe the safety
information and instructions for
use on the packaging for
cleaning and rinsing agents.
Ensure that you follow the
safety instructions, even when
operating the appliance via the
Home Connect app, which are
out of sight when you are away
from home. Follow the
instructions in the app.
Damage
■The appliance may be
repaired and opened up by a
technician only. To do this,
disconnect the appliance
from the power supply. Pull
out the mains plug or switch
off the fuse. Turn off the tap.
■If the appliance is damaged,
especially the control panel
(cracks, holes, broken
buttons), or the door function
is impaired, stop operating
the appliance. Pull out the
mains plug or switch off the
fuse. Turn off tap, call
customer service.
Disposal
1. Make redundant appliances
unusable to prevent
subsequent accidents.
2. Dispose of the appliance in
an environmentally friendly
manner.
:Warning
Risk of injury!
■To prevent injuries, e.g.
caused by stumbling, open
the dishwasher only briefly in
order to load and unload the
dishwasher.
■Knives and other utensils
with sharp points must be
placed with the points
downwards in the cutlery
basket*9" or horizontally
on the knife shelf* or in the
cutlery drawer*1*.
■Do not lean or sit on the
open door.
■In the case of free-standing
appliances, ensure that the
baskets are not overloaded.
The appliance could tip.

en Safety instructions
8
■If the appliance is not in a
cavity and a side panel is
accessible, the door hinge
area must be covered at the
side for reasons of safety
(risk of injury). The covers
are available as optional
accessories from customer
service or specialist outlets.
* depending on the features of
your dishwasher
:Warning
Risk of explosion!
■Do not add any solvents to
the rinsing compartment.
Danger of explosion!
■If you use highly caustic
alkaline or highly acidic
cleaning agents, in particular
commercial or industrial
cleaning agents (e.g. for the
machine cleaning cycle), do
not put aluminium parts in
the dishwasher. Danger of
explosion!
:Warning
Risk of scalding!
Open the door carefully when
the programme is still running.
There is a risk of hot water
spraying out of the appliance.
:Warning
Risk to children!
■If fitted, use the childproof
lock.
■Do not allow children to play
with or operate the
appliance.
■Keep children away from
detergents and rinse aid.
These may cause chemical
burns in the mouth, throat
and eyes or asphyxiation.
■Keep children away from
open dishwasher. There may
be small parts in the
dishwasher which children
could swallow and the water
inside the dishwasher is not
drinking water as it may
contain detergent residue.
■Ensure that children do not
place fingers in the tablet
collecting tray 1B. Small
fingers could become caught
in the slots.
■When opening and closing
the door on an eye-level
appliance, ensure that
children do not become
jammed or crushed between
the appliance door and the
cupboard door below.
■Children could become
locked in the appliance
(danger of suffocation) or get
into another dangerous
situation.
Redundant appliances: Pull
out the mains plug, sever
and dispose of the power
cord. Destroy the door lock
so that the door can no
longer be closed.
Childproof lock (door lock) *
Do o r lock The child-proof lock (door lock)
protects children from potential
hazards which the dishwasher
poses.

Environmental protection en
9
:Warning
Risk of suffocation!
Children may become locked in
the dishwasher and suffocate.
Always completely close the
appliance door when leaving
the dishwasher.
Activate the child-proof lock
(door lock) as follows:
1. Pull the catch of the
child-proof lock towards
yourself (1).
2. Close the door (2).
The child-proof lock is
activated.
Open the door with activated
child-proof lock (door lock) as
follows:
1. Press the catch of the
child-proof lock to the right
(1).
2. Open the door (2).
Deactivate the child-proof lock
(door lock) as follows:
1. Press the catch of the
child-proof lock to the right
(1).
2. Press the catch of the
child-proof lock backwards
(2).
The childproof lock is
deactivated.
* depending on the features of
your dishwasher
7Environmental
protection
En v i r o n ment al pr ot e c t i on Both the packaging of new appliances
and the old appliances themselves







en Getting to know your appliance
10
contain valuable raw materials and
recyclable materials.
Please dispose of the individual parts
separated according to type.
Please ask your dealer or inquire at
your local authority about current means
of disposal.
Packaging
All plastic parts of the appliance are
identified with internationally
standardised abbreviations (e.g. PS
polystyrene). Therefore, plastic waste
can be sorted out when the appliance is
being disposed of.
Please follow the safety instructions
under “Delivery” ~Page 5.
Old appliances
Please follow the safety instructions
under “Disposal of your appliance”
~Page 7.
*Getting to know your
appliance
Get t i ng to k now your appl i anc e Diagrams of the control panel and the
interior of the appliance can be found at
the front of the manual. Individual
positions are referred to in the text.
Control panel
* depending on the features of your
dishwasher
** number depending on the features of
your dishwasher
Appliance interior
* depending on the features of your
dishwasher
This appliance has been
identified in accordance with the
European Directive 2012/19/EU
on Waste Electrical and
Electronic Equipment (WEEE).
The directive provides a
framework for the collection and
recycling of old appliances,
which is valid across the EU.

(On/off switch
0Programme buttons **
8Info button {
@Display window at top
HRinse aid refill indicator
PSalt refill indicator
XWLAN display
`Selection buttons
hTime preselection
)" Remote start button
)* Additional functions/programme
buttons **
)2 START button
): Front display *
)B Door opener
)J Remote start display *
)R < > button
1" Interior light *
1* Cutlery drawer *
12 Top basket
1: Upper spray arm
1B Tablet collecting tray
1J Intake opening
1R Blow opening (Zeolith container)
1Z Lower spray arm
1b Dispenser for special salt
1j Filters
9" Cutlery basket *
9* Bottom basket
92 Dispenser for rinse aid
9: Detergent dispenser
9B Lock for detergent dispenser
9J Rating plate
