Siemens hicom 150 H optiset E standard User manual

Hicom 150 H
Service Manual
HiPath HG 1500
V 2.0

Siemens AG 2001 ●Information and Communication Networks, Hofmannstraße 51, D-81359 München
Reference no.: A31003-K5020-S100-6-7620
Printed in the Federal Republic of Germany. ●
Subject to availability. Right of modification reserved.
*1PA31003-K5020-S100-6-7620*
1P A31003-K5020-S100-6-7620

1
2
3
4
5
6
7
8
9
10
A31003-K5020-S100-6-7620
Hicom 150 H
HiPath HG 1500
V 2.0
Service Manual
Installation
Introduction
--
-
Additional information
Administration
Startup
--
--
--

lan2detoc.fm
A31003-K5020-S100-6-7620
Service Manual 0-1
For internal use only Contents
Contents 0
1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 HiPath HG 1500 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.1.1 Prerequisite . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.2 Short description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.3 Service information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.4 Hicom password concept . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
1.5 Functional environment of HiPath HG 1500 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
1.5.1 Parallel operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
1.5.2 Interworking with features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
1.5.2.1 Least Cost Routing (LCR). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
1.5.2.2 Trunk access/toll restriction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
1.5.3 Gatekeeper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
2 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2.1 HiPath HG 1500 boards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.1.1 HXGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.1.1.1 HXGS V.24 interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.1.2 HXGM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2.1.2.1 HXGM V.24 interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
2.1.3 Interfaces to the LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
2.2 Part numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
2.3 HiPath HG 1500 installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
2.3.1 Installation requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
2.3.2 Slot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
2.3.3 Installation procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
3 Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
3.1 Initial startup of HiPath HG 1500 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.1.1 Initial startup: Remote via modem. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.1.2 Startup via ARP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
3.1.3 Initial startup via the serial interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
3.2 Configuration for gatekeeper mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
3.2.1 Configuration HiPath HG 1500 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
3.2.2 Configuring the NGK 100 gatekeeper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
4 Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
4.1 Tracing with development trace. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.2 Determining the firmware version of the board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
5 Additional information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
5.1 Integrating various network topologies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.1.1 Star topology with hub (10/100 BaseT). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Contents For internal use only
A31003-K5020-S100-6-7620
0-2 Service Manual
lan2detoc.fm
5.1.2 Bus topology (10 Base2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.2 SW upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
5.3 Firmware Download . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

lan2delof.fm
A31003-K5020-S100-6-7620
Service Manual 0-3
For internal use only Figures
Figures 0
Figure 2-1 HXGS interfaces (S30810-Q2931-X/X100). . . . . . . . . . . . . . . . . . . . . . . . 2-3
Figure 2-2 HXGS2 interfaces with 2nd LAN (S30810-Q2939-X000/X100) . . . . . . . . 2-3
Figure 2-3 HXGM interfaces (S30810-Q2930/Q2940-X/X100) . . . . . . . . . . . . . . . . . 2-7
Figure 2-4 Adapter for HXGM backplane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Figure 2-5 LAN adapter cable (U.S. only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Figure 3-1 Installation for gatekeeper mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Figure 5-1 10/100 BaseT cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Figure 5-2 10 Base2 cabling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Figures For internal use only
A31003-K5020-S100-6-7620
0-4 Service Manual
lan2delof.fm

lan2delot.fm
A31003-K5020-S100-6-7620
Service Manual 0-5
For internal use only Tables
Tables 0
Table 1-1 Starting Hicom system administration (Service) . . . . . . . . . . . . . . . . . . . . 1-4
Table 2-1 HXGS application option/slot. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Table 2-2 HXGS hardware variants. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Table 2-3 Contact assignment of the HXGS LAN interfaces. . . . . . . . . . . . . . . . . . . 2-4
Table 2-4 HXGS V.24 interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Table 2-5 HXGM application option/slot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Table 2-6 HXGM hardware variants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Table 2-7 RJ45 socket assignment (HXGM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Table 2-8 Assignment of the SIPAC-RJ45 LAN adapter. . . . . . . . . . . . . . . . . . . . . . 2-9
Table 2-9 Assignment of the CHAMP-RJ45 LAN adapter cable . . . . . . . . . . . . . . . 2-10
Table 2-10 HXGM LED concept . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Table 2-11 Contact assignment of the HXGM LAN interfaces . . . . . . . . . . . . . . . . . 2-11
Table 2-12 V.24 socket assignment (HXGM2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Table 2-13 Slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Table 2-14 Installation procedure in the case of OfficePoint/Com . . . . . . . . . . . . . . 2-15

Tables For internal use only
A31003-K5020-S100-6-7620
0-6 Service Manual
lan2delot.fm

lan2de.c01
A31003-K5020-S100-6-7620
Service Manual 1-1
For internal use only Introduction
1 Introduction
This service manual refers to HiPath HG 1500 V 1.0/V 2.0 as well as Hicom Xpress
@LAN V1.1 with the LAN boards HXGS and HXGM.
HiPath HG 1500 supports the standard functions of ISDN (IP/IPX) routers together
with the additional functionality of a voice gateway (H.323). A virtual CAPI interface
(vCAPI) and a TAPI interface (CSTA) are also provided. The system also facilitates
PC-supported telephony (CTI) and HiPath HG 1500 administration via a LAN PC.
Note
Note that when configuring voice applications, only S30810-Q2930/Q2940-X
(HXGM/HXGM2) and S30810-Q2931/Q2939-X (HXGS/HXGS2) boards may be
used.
1.1 HiPath HG 1500
Hicom Xpress @LAN and HiPath HG 1500 create a bridge between the LAN and the
ISDN network via an integrated HXGS/HXGM board
Suitable for:
●Hicom 150 E Office Version 2.2 and later or Hicom 150 H V 1.0 or later, Office-
Point/OfficeCom/OfficePro model
The following implementation scenarios are possible:
●Voice gateway between LAN (H.323) and standard telephones (e.g. Netmeet-
ing),
●Telephoning from the PC (voice over IP) with Optiset features at the PC or via the
Xpress client,
●WAN connections via the ISDN network, including PPP Multilink,
●Remote access from within company LANs (provided via analog V34, GSM V110
and ISDN),
●Internet access (PPP router, NAT),
7Caution
All safety instructions for service and technical personnel given in the "Important In-
formation" section of the Hicom 150 E Office/Hicom 150 H Service Manual are also
applicable to HiPath HG 1500 and must be observed.
Only authorized staff should work on the system.

Introduction For internal use only
A31003-K5020-S100-6-7620
1-2 Service Manual
lan2de.c01
●vCAPI for client PCs including fax services and CTI,
●SNMP (e.g. statistics and error signaling),
●Routing via the xDSL network (for HXGS with 2nd LAN interface only).
Interfaces:
●10/100BT Autosense Ethernet twisted-pair,
●10BT Ethernet (for HXGS with 2nd LAN interface only) configurable with PPPoE,
●Up to 16 B channels,
●SLIP access (serial line interface) for initial startup, incl. cable (reference no.
S30122-X5468-X3).
1.1.1 Prerequisite
For this application, TCP/IP is implemented as the transport protocol and Win95/98/
NT 4.0 or Windows 2000 as the client operating system. For the routing functionality,
the IP/IPX protocols are transferred transparently, independent of the operating sys-
tem. Call numbers are allocated in HiPath HG 1500 via TCP/IP Address > Call Num-
ber (max. 100 call numbers for vCAPI and max. 48 stations for voice applications).
The assignment of several call numbers to one TCP/IP address may be necessary if
several services are to be configured (voice, fax, file transfer, etc.).
1.2 Short description
HiPath HG 1500 is an expansion card for Hicom 150 E Office/Hicom 150 H Point/
Com/Pro. It is used to connect a "local" LAN to Hicom systems and to link "external"
LANs via the system’s ISDN interface. Telematics and CTI functions are also support-
ed.
The connection to the "local" LAN is set up via an Ethernet twisted-pair interface
(RJ45 connector); see Figure 2-1 and Figure 2-4.
In the case of OfficePoint and Com, the connection to the system is set up via a 50-
pin edge connector of an expansion slot. The connection to the LAN is set up via an
RJ45 connector on the HiPath HG 1500 board.
In the case of OfficePro, the board is connected to the system via the backplane. An
adapter for the backplane (part number C39228-A7195-A10, US backplane: C39195-
Z7404-A10) is used to connect the LAN with an RJ45 connector.
V.24 interface
For loading and administration purposes (SLIP access), each system is provided with
an individual V.24 interface (cable reference no. S30122-X5468-X3). In both sys-
tems, the V.24 connector for SLIP access is located on the board.

lan2de.c01
A31003-K5020-S100-6-7620
Service Manual 1-3
For internal use only Introduction
1.3 Service information
The unique worldwide Ethernet address (MAC address) is a factory default and can-
not be modified.
Card recognition is performed automatically in Hicom 150 E Office/Hicom 150 H,
Point/Com/Pro. HiPath HG 1500 is installed as an individual board type in Hicom 150
E Office/Hicom 150 H, Point/Com/Pro.
The following items can be administered in Hicom:
●S0 station
●Xpress clients
●IP network lines
●numbering scheme
●associated dialing
●answer group (PC telephone)
●call forwarding (PC to fax)
●suppression of incoming 0
●CSTA interface
Details on the initial startup and on accessing the board can be found in the HiPath
HG 1500 Administration Manual.
A separate tool (Assistant Xpress @LAN/HG 1500) that can also be used by the cus-
tomer or the LAN administrator is provided for entering and modifying data, e.g. the
IP address of the customer LAN or ISDN numbers assigned to a communication part-
ner. The data is permanently stored in HiPath HG 1500. HiPath HG 1500 Assistant
also facilitates the storage of a corresponding configuration file. This can then be re-
trieved if a board needs replacing. The tool also provides a facility for querying the
software version. Access to HiPath HG 1500 administration is password-protected.
This password can be changed; however, the Hicom password concept applies; see
Tabl e 1 - 1 .
Note that only the user and Hicom passwords are allowed.
A simple functional test can be performed directly at the customer PC or on a service
PC with a network card, vCAPI driver and a CAPI-based application.
APS transfer for the HiPath HG 1500 board is usually performed via the LAN using
the Assistant or, in exceptional circumstances, via the V.24 interface using the Load-
er.
Cable with reference number S30122-X5468-X3 (see also Section 2.1.1.1 or
Section 2.1.2.1) is used for the V.24 port of the HiPath HG 1500 board.

Introduction For internal use only
A31003-K5020-S100-6-7620
1-4 Service Manual
lan2de.c01
1.4 Hicom password concept
Further information is contained in the Hicom 150 E Office Rel. 2.0-3.0 Service Man-
ual or Hicom 150 H V1.0.
Table 1-1 Starting Hicom system administration (Service)
Step Input Explanation
1. *95 Start system administration
2. 31994 User: 31994 (default)
3. 31994 Password: 31994 (default)
or
1. ✓Change user and/or password
2. Confirm user and/or password

lan2de.c01
A31003-K5020-S100-6-7620
Service Manual 1-5
For internal use only Introduction
1.5 Functional environment of HiPath HG 1500
1.5.1 Parallel operation
Hicom 150 E Office/Hicom 150 HCom/Pro systems support parallel operation of sev-
eral HiPath HG 1500 boards.
1.5.2 Interworking with features
1.5.2.1 Least Cost Routing (LCR)
In Hicom systems, LCR technology enables the most cost-effective connections via
ISDN.
1.5.2.2 Trunk access/toll restriction
Trunk access is configured in Hicom 150 H/HiPath HG 1500Point/Com/Pro for call
numbers used by Hicom 150 E Office. Hicom toll restriction for outgoing seizure is
performed based on this trunk access in the same way as for outgoing calls.
1.5.3 Gatekeeper
The following functions are performed by a gatekeeper in an H.323 network:
●Registering H.323 end units,
●Managing rights and services,
●Converting station numbers to logical names or IP addresses and vice versa,
●Managing bandwidth on the network side,
●Registering gateways,
●Registering multiconference units,
●Can be linked to neighboring gatekeepers (zones).
The setup procedure for gatekeeper operations is described in Section 3.1.3.
System type Number of boards
OfficePoint 1
OfficeCom 2
OfficePro 3

Introduction For internal use only
A31003-K5020-S100-6-7620
1-6 Service Manual
lan2de.c01
>If no gateways or multiconference units are being used, IP telephony can also be
implemented in H.323 networks without gatekeepers. Note, however, that the con-
nection can only be set up via the IP address in this case, so no authorizations and
bandwidth control are possible.
In general, the following applies: without gatekeepers, many features may be dis-
abled or subject to severe restrictions.

HiPath HG 1500 board
s
lan2de.c02
A31003-K5020-S100-6-7620
Service Manual 2-1
For internal use only Installation
2 Installation
2.1 HiPath HG 1500 boards
HG 1500 supports two function groups: the “voice functionality” with the features
H.323 GW and TFA and the “data functionality” with the features VCAPI and RAS. A
board variant (X100) that only supports the data functionality (Data only) is available;
this board is not equipped with signal processors and the associated logic.
2.1.1 HXGS
Introduction
The HiPath HG 1500 board HXGS connects Hicom 150 E Office/Hicom 150 H Office-
Com/OfficePoint with the LAN environment. The board supports up to 16 B channels.
The following board variants are available:
HiPath HG 1500 HXGS Voice and Data (S30810-Q2931-X)
HiPath HG 1500 HXGS Data only (S30810-Q2931-X100)
HiPath HG 1500 HXGS2 Voice and Data 2nd LAN interface (S30810-Q2939-X000)
HiPath HG 1500 HXGS2 Data only 2nd LAN interface (S30810-Q2939-X100)
Board slot
Table 2-1 HXGS application option/slot
Possible application Boards Slot
OfficePoint Hicom 150 E as of V 2.2
P30370-P722-A680-*
Hicom 150 H as of V 1.0
P30370-P802-A680-*
Hicom 150 H as of V 1.2
P30370-P822-A680-*
1 All slots
OfficeCom
Old HW
CBFC
Hicom 150 E as of V 2.2
P30370-P723-A680-G1 2 * Slots 4 and 5 only
OfficeCom
New HW
CBPC
Hicom 150 E as of V 2.2
P30370-P721-A680-*
Hicom 150 H as of V 1.0
P30370-P801-A680-*
Hicom 150 H as of V 1.2
P30370-P821-A680-*
2 * All slots

HiPath HG 1500 boards
Installation For internal use only
A31003-K5020-S100-6-7620
2-2 Service Manual
lan2de.c02
Interfaces/connectors
The LAN port is linked at the X3/X4 connectors. For connector assignment, see
Tabl e 2 - 3 .
The board is equipped with a 50-pin edge connector to the system, two Western
sockets (8-pin, 10-pin shielded) to the LAN and a shielded MiniDin socket (6-pin) for
the V.24 interface:
●X1: 50-pin to the system
●X2: 6-pin shielded MiniDin socket for V.24 interface, see Section 2.1.1.1
The following connection option is provided for connection to a LAN:
●X3: 8-pin Western socket for LAN 10/100 Base-T, RJ45 socket (twisted pair)
for station
●X4: 8-pin Western socket for LAN 10 Base-T, RJ45 socket (twisted pair)
for trunk connection (for HXGS2 board with 2nd LAN interface only)
* = 2 boards may be operated in parallel
OfficeCom, old HW, CBFC: S30810-Q2950-X
OfficeCom, new HW, CBPC: S30810-Q2932-A201
Table 2-2 HXGS hardware variants
System type Services DSPs Board ID
OfficeCom/Point Data only 0 HXGS
OfficeCom/Point Voice/Data 4 HXGS
OfficeCom/Point Data only (2nd LAN) 0 HXGS2
OfficeCom/Point Voice/Data (2nd
LAN) 4 HXGS2
2 simultaneous Voice over IP connections are possible for each DSP (Digital Signal
Processor).
Table 2-1 HXGS application option/slot
Possible application Boards Slot

HiPath HG 1500 board
s
lan2de.c02
A31003-K5020-S100-6-7620
Service Manual 2-3
For internal use only Installation
A twisted-pair cable is used as the transmission medium for 10/100 Base-T and 10
Base-T.
Figure 2-1 HXGS interfaces (S30810-Q2931-X/X100)
Figure 2-2 HXGS2 interfaces with 2nd LAN (S30810-Q2939-X000/X100)
LAN
connec-
tion to
CUC/
CUP
HXGS
V. 2 4X2
10/100 Base-TX3
50
X1
2
LAN
connec-
tions to
CUC/
CUP
HXGS2
with 2nd LAN interface
V. 2 4X2
10/100 Base-T (station)X3
50
X1
2
10 Base-T (trunk)X4

HiPath HG 1500 boards
Installation For internal use only
A31003-K5020-S100-6-7620
2-4 Service Manual
lan2de.c02
The cable is connected to the HiPath HG 1500 HXGS/HXGS2 (OfficeCom and Offi-
cePoint) via the 8-pin Western socket (X3) located on the MDF side of the circuit
board, see Figure 2-1, or X3 and X4, see Figure 2-2.
Notes
Direct Ethernet twisted-pair connection to HiPath HG 1500
The RJ45 cable must be crossed as follows:
A ferrite kit must be installed on the LAN 1 and LAN 2 lines on the RJ45 cable.
2.1.1.1 HXGS V.24 interface
The Serial Interface Cable (SIC, S30122-K5468-X3-*) can be connected via a 6-pin
MiniDin socket on the front panel of the HXGS. The SIC performs level conversion
from TTL signals (HXGS) to V.24 (9-pin Sub-D socket). Depending on the SIC, the
maximum authorized transmission rate for the V.24 interface is 19.2 kBit/s. Asynchro-
nous transmission only is supported.
The interface is used for administration purposes. It can be used for software updates
or board configuration. It can also be used for software debugging.
Table 2-3 Contact assignment of the HXGS LAN interfaces
X3
10/100 Base-T
X4
10 Base-T
Function
1 1 Transmit: + wire
2 2 Transmit: - wire
3 3 Receive: + wire
6 6 Receive: - wire
4+5+7+8 4+5+7+8 not used
1<>32<>63<>16<>2

HiPath HG 1500 board
s
lan2de.c02
A31003-K5020-S100-6-7620
Service Manual 2-5
For internal use only Installation
Table 2-4 HXGS V.24 interface
Pin Signal I/O Function
1GND
2 TXD O Transmit Data
3 CTS I Clear to Send
4 RXD I Receive Data
5 RTS O Request to Send
6+5V
(7) GND
