Siemens SITRANS LR 300 User manual

SITRANS LR 300
Instruction Manual
SITRANS LR 300
July 2002

© Siemens MilltronicsProcessInstruments Inc. 2002
Safety Guidelines
Warning notices must be observed to ensure personal safety as well as that of others, and to
protect the product and the connected equipment. These warning notices are accompanied
by a clarification of the level of caution to be observed.
Qualified Personnel
This device/system may only be set up and operated in conjunction with this manual.
Qualified personnel are only authorized to install and operate this equipment in accordance
with established safety practices and standards.
Warning: This product can only function properly and safely if it is correctly transported,
stored, installed, set up, operated, and maintained.
Note: Always use product in accordance with specifications.
Copyright Siemens Milltronics Process
Instruments Inc.2002.AllRights ReservedDisclaimer of Liability
This document is available in bound version and in
electronic version. We encourage users to
purchase authorized bound manuals, or to view
electronic versions as designed and authored by
Siemens Milltronics Process Instruments Inc.
Siemens Milltronics Process Instruments Inc. will
not be responsible for the contents of partial or
whole reproductions of either bound or electronic
versions.
While we have verified the contents of
this manual for agreement with the
instrumentation described, variations
remain possible. Thus we cannot
guarantee full agreement. The
contents of this manual are regularly
reviewed and corrections are included
in subsequent editions. We welcome
all suggestions for improvement.
Technical data subject to change.
MILLTRONICS®is a registered trademark of Siemens Milltronics Process Instruments Inc.
Contact SMPI Technical Publications at the following address:
Technical Publications
Siemens Milltronics Process Instruments Inc.
1954 Technology Drive, P.O. Box 4225
Peterborough, Ontario, Canada, K9J 7B1
Email: [e-mail]
For the libraryof SMPI instruction manuals, visitour Web site: www.siemens-milltronics.com

7ML19985CL02 SITRANS LR 300 – INSTRUCTION MANUAL Page 1
mmmmm
Table of Contents
Table of Contents
General Information ...........................................................................................................5
The Manual ...............................................................................................................................................5
SITRANS LR 300 ......................................................................................................................................6
SITRANS LR 300 Communications ............................................................................................6
SITRANS LR 300 Applications ....................................................................................................6
SITRANS LR 300 Approvals and Certificates .........................................................................6
Specifications ......................................................................................................................7
Installation .........................................................................................................................13
Mounting Location ................................................................................................................................13
Beam Spreading ..........................................................................................................................14
Polarization Effect .......................................................................................................................14
False Reflections .........................................................................................................................14
Dimensions: SITRANS LR 300 with Rod Antenna .........................................................................15
Dimensions: Threaded Rod ................................................................................................................17
Dimensions: Shielded Rod ..................................................................................................................18
Dimensions: Horn ..................................................................................................................................19
Dimensions: Waveguide ......................................................................................................................20
Dimensions: Sliding Waveguide Configuration .............................................................................21
Dimensions: Sanitary Horn .................................................................................................................23
Dimensions: Sanitary Rod ...................................................................................................................24
Dimensions: Flanges ............................................................................................................................25
Mounting .................................................................................................................................................27
Rod Assembly ...............................................................................................................................28
Rod Extension Requirements ...................................................................................................28
Mounting: Rod Assembly ..........................................................................................................28
Mounting: Threaded Rod Antenna .........................................................................................29
Mounting: Manhole Covers ......................................................................................................29
Mounting: Horn Antennas or Shielded Rod .........................................................................30
Mounting: Waveguide Antenna .............................................................................................30
Mounting: Stillpipe or Sidepipe ...............................................................................................31
Mounting: Horn with Waveguide Extensions ......................................................................32
Mounting: Sanitary Rod Antenna ............................................................................................32
Interconnection .................................................................................................................33
SITRANS LR 300 Terminal Block .............................................................................................33
SITRANS LR 300 Wiring .............................................................................................................34
Communications Installation ..............................................................................................................35
Wiring Guidelines ........................................................................................................................35
Port 1: RS-485 ...............................................................................................................................35
PC Connection ..............................................................................................................................36
Port Configuration .......................................................................................................................36
SITRANS LR 300.book Page 1 Monday, June 10, 2002 7:18 PM

Page 2 SITRANS LR 300 – INSTRUCTION MANUAL 7ML19985CL02
mmmmm
Table of Contents
Start Up ...............................................................................................................................37
Overview ..................................................................................................................................................37
RUN Mode Display .....................................................................................................................37
PROGRAM Mode Display ........................................................................................................37
Programming ................................................................................................................................38
Dolphin Plus, Simatic PDM, HART Master, or Profibus Master ......................................38
Hand Programmer .......................................................................................................................39
Local Programming .....................................................................................................................39
Accessing PROGRAM Mode ....................................................................................................41
Accessing a Parameter ..............................................................................................................41
Modifying a Parameter Value ...................................................................................................42
Accessing RUN Mode ................................................................................................................43
Quick Start Programming ......................................................................................................... 43
Operation ............................................................................................................................45
Overview ..................................................................................................................................................45
Transceiver ..............................................................................................................................................45
Loss of Echo (LOE) .................................................................................................................................46
Blanking or Auto False Echo Suppression .....................................................................................46
Typical Receiver Signal ...........................................................................................................46
Analog Output ........................................................................................................................................47
Programming ..........................................................................................................................................47
Run ..................................................................................................................................................47
Volume ............................................................................................................................................47
Fail-Safe .........................................................................................................................................47
RUN/PROGRAM ...........................................................................................................................48
Application Examples ......................................................................................................49
Application Example: Asphalt in Storage Tank ....................................................................49
Application Example: Horizontal Tank with Volume ...........................................................50
Application Example: Juice Batch Tank with Sanitary Horn Antenna ...........................51
Application Example: Sliding Waveguide on Anaerobic Digesters ................................52
Application Example: Stillpipe or By-pass Pipe ...................................................................53
Parameter Descriptions ...................................................................................................55
Quick Start Parameters (P001 to P007) ..........................................................................................56
Volume Parameters (P050 to P055) ................................................................................................58
Display and Reading Parameters (P060 to P063) ........................................................................62
Fail-Safe Parameters (P070 to P072) ..............................................................................................63
mA Output Parameters (P201 to P219) ...........................................................................................64
Independent mA Setpoint Parameters (P210 and P211) ...........................................................64
Installation Records Parameters (P340 to P346) .........................................................................66
Range Calibration Parameter (P655) ..............................................................................................68
Rate Parameters (P700 and P701) ..................................................................................................69
Measurement Verification Parameters (P709 to P713) .............................................................70
Communications Parameters (P750 and P752) ............................................................................72
Serial Communication Parameters (P770 to P799) .....................................................................72
Echo Processing Parameters (P800 to P807) ...............................................................................74
Algorithm Parameter (P820) .............................................................................................................76
TVT (Time Varying Threshold) Adjustment Parameters (P830 to P841) ................................76
Test Parameters (P900 to P999) ......................................................................................................80
SITRANS LR 300.book Page 2 Monday, June 10, 2002 7:18 PM

7ML19985CL02 SITRANS LR 300 – INSTRUCTION MANUAL Page 3
mmmmm
Table of Contents
Communications: Modbus Register Map ....................................................................83
Product ID (R40,064) ..............................................................................................................................83
Point Data (R41,010 – R41,031) ............................................................................................................84
Input/Output ............................................................................................................................................84
mA Output (R41,110) .....................................................................................................................84
Parameter Access (R43,997 – R46,999) ............................................................................................84
Format Word (R43,997) .........................................................................................................................85
Primary Index (R43,999) and Secondary Index (R43,998) ............................................................86
Reading Parameters ...................................................................................................................86
Writing Parameters .....................................................................................................................86
Communications: Data Types .........................................................................................87
Numeric Values .....................................................................................................................................87
Split Values .............................................................................................................................................87
Text Messages .......................................................................................................................................88
Error Handling ...................................................................................................................89
Modbus Responses ..............................................................................................................................89
Error Handling ........................................................................................................................................89
Troubleshooting .................................................................................................................91
Communication Troubleshooting ......................................................................................................91
Generally: .......................................................................................................................................91
Specifically: ...................................................................................................................................91
Operation Troubleshooting .................................................................................................................92
Maintenance ......................................................................................................................93
Appendix I ..........................................................................................................................95
Alphabetical Parameter List ...............................................................................................................95
Appendix II .........................................................................................................................98
Programming Chart ...............................................................................................................................98
Appendix III ......................................................................................................................101
Ambient/Operating Temperature Specification ...........................................................................101
Appendix IV ......................................................................................................................102
Process Pressure/Temperature de-Rating ................................................................................... 102
Rod Antenna ANSI Hole Pattern, 150#, .............................................................................. 102
Rod Antenna DN Hole Pattern, PN16, ................................................................................ 103
Rod Antenna Threaded Connection .................................................................................... 103
Rod Antenna Sanitary Connection ...................................................................................... 104
Horn Antenna or Wave Guide – ANSI Hole Pattern, 150# ............................................. 104
Horn Antenna or Wave Guide DN Hole Pattern, PN16 ................................................... 105
Horn Antenna Sanitary Connection .................................................................................... 105
Appendix V .......................................................................................................................107
Typical Power Consumption ............................................................................................................ 107
SITRANS LR 300.book Page 3 Monday, June 10, 2002 7:18 PM

Page 4 SITRANS LR 300 – INSTRUCTION MANUAL 7ML19985CL02
mmmmm
Table of Contents
Appendix VI ......................................................................................................................108
HART Communications for the SITRANS LR 300 ....................................................................... 108
HART Device Descriptor (DD) ............................................................................................... 108
Simatic Process Device Manager (PDM): ......................................................................... 108
HART Communicator 275: ....................................................................................................... 109
Supported HART Commands: ..............................................................................................113
Appendix VII: Profibus PA ............................................................................................. 114
Profibus PA Communications for the SITRANS LR 300 .............................................................114
Device Descriptor ......................................................................................................................114
The GSD file ................................................................................................................................114
Bus address (Device Address) ...............................................................................................114
Bus Termination .........................................................................................................................115
Power Demands ........................................................................................................................115
Cyclic versus Acyclic Data ......................................................................................................115
Cyclic Data ..................................................................................................................................115
Status Word ................................................................................................................................117
Diagnostics .................................................................................................................................118
Acyclic Data ................................................................................................................................118
Configuration Example: ............................................................................................................118
Profibus Level Device Design ...........................................................................................................119
Profile 3.0 Class A Design .......................................................................................................119
Block Model .............................................................................................................................119
Transducer Block - Level .........................................................................................................120
Parameter Structure .................................................................................................................121
Sensor Value ............................................................................................................................121
Sensor Unit ...............................................................................................................................121
Level, Primary Value ...............................................................................................................121
Level, Primary Value Unit ......................................................................................................121
Sensor Reference Point ........................................................................................................121
Function Blocks – Analog Input .............................................................................................122
Linear conversion: ..................................................................................................................122
Device Management ................................................................................................................123
Directory................................................................................................................................... 123
Physical Block 1 ......................................................................................................................124
Transducer Block 1 .................................................................................................................125
Function Block 1 - Level ........................................................................................................129
Function Block 2 - Space ......................................................................................................130
Function Block 3 - Distance ..................................................................................................131
Function Block 4 - Volume ....................................................................................................131
Appendix VIII: hazardous area installations .............................................................132
Instructions specific to hazardous area installations ................................................................132
(Reference European ATEX Directive 94/9/EC, Annex II, 1/0/6) ...............................................132
SITRANS LR 300.book Page 4 Monday, June 10, 2002 7:18 PM

7ML19985CL02 SITRANS LR 300 – INSTRUCTION MANUAL Page 5
mmmmm
General Information
General Information
The Manual
Refer to this manual for proper installation, operation, and maintenance of your
IQ Radar 300. The margin tabs denote the sections, and each section presents
SITRANS LR 300 features.
Special attention must be paid to warnings and notes highlighted from the rest of the text
by grey boxes.
Installation: Installing the SITRANS LR 300.
Interconnection: SITRANS LR 300 interconnection instructions.
Start-up: Operating the keypad, programming the unit, and reading the
display.
Operation:SITRANS LR 300 operating instructions.
Applications: Application examples and practical use.
Parameters: Available parameters and a description of function and use.
Please read this section and familiarize yourself with the
parameters available to you, to fully optimize your instrument.
Communications: Configure communication settings.
Troubleshooting: Responses to common installation and application problems.
Appendices: An alphabetical cross-reference of the parameters and their
numbers, a record sheet for jotting down parameter values,
Ambient/Operating Temperature Specifications, Process
Pressure/Temperature de-Rating charts, Typical Power
Consumption charts, detailed information on HART
Communications for the SITRANS LR 300, and on Profibus PA
Communications for the SITRANS LR 300.
WARNING means that failure to observe the necessary precautions
can result in death, serious injury, and/or considerable material
damage.
Note: means important information about the product or that part of the operating
manual.
IMPORTANT:All specifications are subject tochange without notice.
General information.fm Page 5 Monday, July 22, 2002 3:24 PM

Page 6 SITRANS LR 300 – INSTRUCTION MANUAL 7ML19985CL02
mmmmm
General Information
SITRANS LR 300
The SITRANS LR 300 is to be used only in the manner outlined in this manual, otherwise
protection provided by the equipment may be impaired.
SITRANS LR 300 is a versatile process level-monitoring instrument using advanced pulse
radar techniques. The unit consists of an electronic component coupled to the antenna
and process connection.
SITRANS LR 300 Communications
The standard SITRANS LR 300 supports Modbus1or Dolphin protocol, and HART2or
Profibus PA.
Dolphin Plus
Dolphin is a proprietary Siemens Milltronics protocol designed to be used with Dolphin
Plus. For more information on Dolphin Plus or to obtain a copy of the software, please
contact your Siemens Milltronics representative.
SITRANS LR 300 Applications
• liquids, slurries
• process temperatures up to 200°C
• vacuum and pressurized vessels
SITRANS LR 300 Approvals and Certificates
• general and radio
• hazardous
1. Modbus is a registered trademark of Groupe Schneider.
2. HART is a registered trademark of the HART Communications Foundation.
WARNING:ThisproductisdesignatedasaPressureAccessoryper
Directive 97/ 23 / EC and is not intended for use as a safety device.
WARNING: Materials of construction are chosen based on their
chemical compatibility (or inertness) for general purposes. For
exposure to specific environments, check with chemical
compatibility charts before installing.
Note: See Approvals on page 10 for an approvals listing.
PC/Laptop
or HART
modem
HART
Communicator
230 Ω
SITRANS
LR 300
SITRANS LR 300.book Page 6 Monday, June 10, 2002 7:18 PM

7ML19985CL02 SITRANS LR 300 – INSTRUCTION MANUAL Page 7
mmmmm
Specifications
Specifications
SITRANS LR 300
Power
• 24–230 Vac, +15%, 40–70Hz, 28 VA (11W)
or
• 24–230 Vdc, +15%, (9W)
Normal start up takes about 2 seconds to power up the unit. If something (such as
hesitation in plugging in the unit) causes a rapid power fluctuation, the unit will shut
down for 10 seconds to ensure the inrush current will not exceed specified limits.
Fuse
• FU1 & FU2, Fast Acting Ceramic Bussmann ABC fuse, 1 Amp. 250V.
Interface
• analog output: optically-isolated 4–20 mA into 450 Ω max. ± 0.02 mA
accuracy
• serial interface1:isolated
2RS-485 (refer to RS-485 specifications)
• programmer link: infrared receiver (refer to Programmer specifications on
page 10)
• display (local): backlit, alphanumeric, and multi-graphic liquid crystal for
readout and entry
• HART: optional Profibus PA
Notes:
• Safety feature limits the inrush current during start up.
• This instrument features a universal power supply. AC or DC voltage may be applied
to the same terminals.
• Power consumption will vary according to voltage. Please see Appendix V, Typical
Power Consumption, on page 107.
1. This port is used to communicate through Modbus or Dolphin Plus.
2. Although the RS-485 is isolated, its inputs are electrically clamped to earth ground: see
page 35 for more detail.
SITRANS LR 300.book Page 7 Monday, June 10, 2002 7:18 PM

Page 8 SITRANS LR 300 – INSTRUCTION MANUAL 7ML19985CL02
mmmmm
Specifications
Performance1
• frequency: 5.8 GHz (U.S.A. 6.3 GHz)
• accuracy at 20° C: ±15mm from 0.4m to 10m
± 0.15% from 10m to 20m
• temperature drift: <±0.25% of range from –40 to 60° C ( –40 to 140° F)
• measuring range: 0.4m to 20m (minimum range may be extended or
maximum range reduced, depending on the specific
antenna system installed)
• repeatability: ± 2mm for range < 3m
± 3mm for range < 5m
± 5mm for range < 10m
± 10mm for range < 20m
• Fail-Safe: mA and “reading” programmable high,low, or hold, upon
Loss of Echo (LOE) condition
Mechanical
Process Connections: (Please refer to Appendix IV on page 102 for pressure/
temperature limitations.)
• flat-faced flanges: 316 stainless steel
ANSI #150/#300 2", 3", 4", 6", 8"
DIN PN16/PN25/PN40 50mm, 80mm, 100mm, 150mm,
200mm
JIS 10K 50mm, 80mm, 100mm, 150mm, 200mm
• threaded connection: 316 stainless steel, 1-1/2” or 2”
NPT, BSP, or G
• sanitary connection: 316 stainless steel, 2”, 3”, or 4” tri-clamp
Antennas:
• dielectric rod: Teflon 2 (PTFE)
length 41cm (16.3”), including integral gasket
• horn: 316 stainless steel
diameters 100mm (4”), 150mm (6”), 200mm (8”)
emitter cone, PTFE
waveguide extensions optional
• waveguide: 316 stainless steel
emitter cone PTFE
1. Reference conditions.
2. Tef lonis a registered trademark of Du Pont.
WARNING:ThisproductisdesignatedasaPressureAccessoryper
Directive 97/ 23 / EC and is not intended for use as a safety device.
Note:See Appendix III, Ambient/Operating Temperature Specification on page 101,
and Approvals on page 10, for the specific configuration you are about to use or install.
Specifications.fm Page 8 Monday, July 22, 2002 3:28 PM

7ML19985CL02 SITRANS LR 300 – INSTRUCTION MANUAL Page 9
mmmmm
Specifications
Sanitary Antennas (FDA approved materials):
• dielectric rod: one piece UHMW-PE; optional PTFE
2”, 3”, 4” tri-clamp connection
• horn: 304 stainless steel
horn with integral 4” tri-clamp connection
PTFE emitter
Enclosure (electronic):
• construction: aluminum, epoxy-coated; or 316 stainless steel
• conduit: 2 x 1/2" NPT or M 20 x 1.5 entry
• ingress protection: Type 4X / NEMA 4X, Type 6 / NEMA 6, IP 67: (see note
below)
Weight:
• 7.5 kg (16.5 lb) with 2"/150 psi flange (aluminum); 13.6 kg (30 lb) stainless steel
• weight will vary with flange size and rating
Environmental:
• location: indoor/outdoor
• altitude: 2000m max.
• ambient temperature: −40 to 60° C (−40 to 140° F)1
• relative humidity: suitable for outdoor
• installation category: II
• pollution degree: 4
1. See Appendix III (Ambient/Operating Temperature Specification) on page 101, and
Approvals on page 10
WARNING: Materials of construction are chosen based on their
chemical compatibility (or inertness) for general purposes. For
exposure to specific environments, check with chemical
compatibility charts before installing.
Notes:
•SeeAppendix III, Ambient/Operating Temperature Specification on page 101,
and Approvals on page 10, for the specific configuration you are about to use or
install.
• The use of approved watertight hubs/glands is required for Type 4X / NEMA 4X, Type
6 / NEMA 6, IP 67 (outdoor applications).
SITRANS LR 300.book Page 9 Monday, June 10, 2002 7:18 PM

Page 10 SITRANS LR 300 – INSTRUCTION MANUAL 7ML19985CL02
mmmmm
Specifications
Process
• material dielectric: εr> 1.8
for εr< 3, you should use a waveguide antenna or stillpipe
(see Mounting: Waveguide Antenna on page 30 , or
Mounting: Stillpipe or Sidepipe on page 31)
• temperature: UHMW-PE −40 to 80°C (−40 to 176°F)
PTFE −40 to 200°C (−40 to 392°F)1
• pressure (vessel): dependent on process connection type and temperature
(refer to Appendix IVon page 102 for charts, or obtain
the reference drawing listed on the device process tag)
Approvals (verify against device nameplate)
•General: CSA
US/C, FM, CE, 3A Sanitary
• Radio: Europe, Industry Canada, FCC
• Hazardous: Europe; EEx de IIC T6
ATEX II 1/2G, EEx de IIC T6 or EEx d IIC T6
U.S.; Class I, Div. 1, Gr. A,B,C,D (Class I, Zone 1, IIC T6)
Class II, Div. 1, Gr. E,F,G
Class III
Canada; Class I, Div. 1, Gr. A,B,C,D (Class I, Zone 1, IIC T6)
Class II, Div. 1, Gr. E,F,G
Class III
WARNING:ThisproductisdesignatedasaPressureAccessoryper
Directive 97/ 23 / EC and is not intended for use as a safety device.
Notes:
•SeeAppendix III, Ambient/Operating Temperature Specification, on page 101, and
Approvals on this page, for the specific configuration you are about to use or install.
• For instructions relating to ATEX-approved instruments, please see Appendix VIII:
hazardous area installations on page 132.
SITRANS LR 300.book Page 10 Monday, June 10, 2002 7:18 PM

7ML19985CL02 SITRANS LR 300 – INSTRUCTION MANUAL Page 11
mmmmm
Specifications
Programmer (remote keypad)
Intrinsically Safe Programmer (I.S.) Model for hazardous locations: (battery is non-
replaceable)
• approval: EEx ia IIC T4, SIRA certificate Ex002030
• ambient temperature: −20 to 40° C (−5 to 104° F)
• interface: proprietary infrared pulse signal
• power: 3V lithium battery
• weight: 150g (0.3 lb)
•color: black
Note: See Appendix III, Ambient/Operating Temperature Specification, on page 101,
and Approvals on page 10, for the specific configuration you are about to use or install.
SITRANS LR 300.book Page 11 Monday, June 10, 2002 7:18 PM

Page 12 SITRANS LR 300 – INSTRUCTION MANUAL 7ML19985CL02
mmmmm
Specifications
SITRANS LR 300.book Page 12 Monday, June 10, 2002 7:18 PM

7ML19985CL02 SITRANS LR 300 – INSTRUCTION MANUAL Page 13
mmmmm
Installation
Installation
Mounting Location
• Do not mount in direct sunlight without the use of a sun shield. Refer to Appendix III,
Ambient/Operating Temperature Specification, on page 101 .
Notes:
• Installation shall only be performed by qualified personnel and in accordance with
local governing regulations.
• This product is susceptible to electrostatic shock. Follow proper grounding
procedures.
• Do not use a Ground Fault Interrupt (G.F.I.) with the SITRANS LR 300. The ground path
is used for filtering purposes in conjunction with the universal power supply.
WARNING:Thisproductisdesignated as a PressureAccessory per
Directive 97/ 23 / EC and is not intended for use as a safety device.
WARNING: Improper installation may result in loss of process
pressure.
Note:Avoidmountingtheunitatthe centre:there is a greater likelihood of false
readings.
Fl at
Conical
Flat
Parabolic
preferred
undesirable
SITRANS LR 300.book Page 13 Monday, June 10, 2002 7:18 PM

Page 14 SITRANS LR 300 – INSTRUCTION MANUAL 7ML19985CL02
mmmmm
Installation
Beam Spreading
Polarization Effect
Mounting the unit too close to a wall may cause echoes to disappear at specific levels
due to wave cancellation. A strong false reflection from an internal tank obstruction can
be reduced or eliminated by rotating the unit to reduce this polarization effect.
False Reflections
Flat obstructions and struts perpendicular to the emission cone cause large false
reflections. They reflect the radar signal with high amplitude. Round profile interfering
surfaces diffuse reflections of the radar signals and cause false reflections with low
amplitude.
Minimize false reflections first by rotating the instrument for best signal (lowest false
echo amplitude). Then use the TVT shaper parameters (P831, 832, 837 and 838) to prevent
false echo detection.
(rod antenna or 150mm [6”]
horn antenna)
(200mm [8”] horn antenna)
(100mm [4”] horn antenna)
Keep the emission cone (12o,
20oor 28o, depending on
configuration), free of
obstructions.
Due to the polarization effect of
the microwave signal related to
the wall of the vessel, we
recommend locating the
SITRANS LR 300 a minimum of
30cm (1’) away from the sidewall
for every 3m (10’) of vessel
SITRANS LR 300.book Page 14 Monday, June 10, 2002 7:18 PM

7ML19985CL02 SITRANS LR 300 – INSTRUCTION MANUAL Page 15
mmmmm
Installation
Dimensions: SITRANS LR 300 with Rod Antenna
* Flange thickness 25mm (1") nominal.
** Standard length, 50mm and 100mm (2” and 4") extensions available.
Note: Please see next page for notes on process temperature and pressure
capabilities, as well as enclosure recommendations.
WARNING: The user is responsible for the selection of bolting and
gasket materials which will fall within the limits of the flange and
its intended use and which are suitable for the service conditions.
earth
connection
flange
antenna
(rod)
245mm
(9.6")
enclosure
/
electronic
s
process
device tag
412 mm **
(16.3")
100mm (4.0")
136mm
(5.4")
75mm
(3.0")
64mm
(2.5")
239mm
(9.4")
183mm
(7.2")
60mm (2.36")
SITRANS LR 300.book Page 15 Monday, June 10, 2002 7:18 PM

Page 16 SITRANS LR 300 – INSTRUCTION MANUAL 7ML19985CL02
mmmmm
Installation
Notes:
• Process temperature and pressure capabilities are dependent upon information on
the process device tag. Reference drawing listed on the tag is available upon
request.
• For information on temperature and pressure ratings, see Appendix IV on page 102.
• The use of approved watertight hubs/glands is required for Type 4X / NEMA 4X, Type
6 / NEMA 6, IP 67 (outdoor applications)
• The Process Device Tag shall remain with the process pressure boundary assembly.
In the event the instrument package is replaced, the Process Device Tag shall be
transferred to the replacement unit.
SITRANS LR 300.book Page 16 Monday, June 10, 2002 7:18 PM

7ML19985CL02 SITRANS LR 300 – INSTRUCTION MANUAL Page 17
mmmmm
Installation
Dimensions: Threaded Rod
Notes:
• The use of Teflon tape or other appropriate sealant may be used to aid in sealing
tapered threaded connections for use in pressure applications.
• Process temperature and pressure capabilities are dependent upon information on
the process device tag. Reference drawing listed on the tag is available upon
request.
• The Process Device Tag shall remain with the process pressure boundary assembly.
In the event the instrument package is replaced, the Process Device Tag shall be
transferred to the replacement unit.
process device
tag
412 mm
(16.3")
SITRANS LR 300.book Page 17 Monday, June 10, 2002 7:18 PM

Page 18 SITRANS LR 300 – INSTRUCTION MANUAL 7ML19985CL02
mmmmm
Installation
Dimensions: Shielded Rod
Notes:
• The use of Teflon tape or other appropriate sealant may be used to aid in sealing
tapered threaded connections for use in pressure applications.
• Process temperature and pressure capabilities are dependent upon information on
the process device tag. Reference drawing listed on the tag is available upon
request.
• The Process Device Tag shall remain with the process pressure boundary assembly.
In the event the instrument package is replaced, the Process Device Tag shall be
transferred to the replacement unit.
Shield Length S.L. = min. 100 mm (3.9")
[customer specified]
Overall Length L = 374 mm (14.7")
+ shielded length
active antenna
S.L.
L.
process device tag
antenna shield
(inactive length
SITRANS LR 300.book Page 18 Monday, June 10, 2002 7:18 PM
