PHX(F) Series Troubleshooting Guide
Power Supply
Output Power to Sign Face
Sign Face
PHX(F) Series 120-277VAC
Message A Lead
(Black Wire)
Neutral
120-277VAC
Line
Neutral (White Wire)
SPST
On/Off Switch
Single Message with Multiple Power Supply Example
Power Interconnect
(Factory installed) Power Supply
Power Supply
Input Power
Pigtail
V Out LED
V Out LED Output ConnectorOutput Connector
Power Interconnect
(Factory installed) Power Supply Input Power Pigtail
Last Update: 07/19/18
Tools Needed:
Philips head screwdriver
Multi-meter
Always turn off the power to the sign prior to opening the cabinet.
Disconnect the power wires going to the sign.
Note: Make appropriate wiring
connections per local codes.
Note: Clear all metal
chips created by drilling
into sign cabinet.
Note: Do not over-
tighten fasteners or
distort back panel.
Diagnostic LEDs are included on the internal power supply to aid in verifying that input power is present and is being transferred to
the sign face through the output connectors.
Description of Normal Operation for the Sign’s Internal Power Supply
V Out LED
This LED illuminates Green when 120-277VAC power is applied to the internal power supply’s input power pigtail.
Note: The transformer on the power supply converts 120-277VAC power to +12V.
Identify the Sign Problem: Pg
Darkband orarea
whenilluminated 2Pg
Amessage islit
thatshouldn’tbe 3Pg
Thedisplayis
ickering 4Pg
Theentire display
isout 5
Follow the owchart to diagnose the symptoms
Output Connectors
These connectors transfer power from the internal power supply to the sign face to illuminate the individual message(s).
For signs with one message and one power supply, the V Out LED should illuminate green when the message is powered. For signs with
multiple message and/or multiple power supplies, the V Out LED on each power supply of the energized message should illuminate.
Note: A longer single message may require multiple power supplies to illuminate the entire message.
