Silicon Solar PatioPal GS SpotLight 24 User manual

Silicon Solar Inc | 2917 State Hwy 7, Bainbridge, N.Y. 13733 | Ph 800.786.0329 | www.SiliconSolar.com
SOLAR LED SPOT LIGHT
OPERATION INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS BEFORE OPERATING YOUR SOLAR LIGHT. SAVE
THIS MANUAL FOR FUTURE REFERENCE.
1. PARTS CONTAINED
To check if the following parts contained for each light set.
1) battery box with dual spot light 1pc
2) solar panel 1pc
3) ground stakes 2pcs
2. INSTALLATION
Solar spot light must be installed in a sunny location where it can receive maximum sunlight at
daytime. ny cover, shade or shadowing will affect the solar penal to absorb sunlight and its
function will be decreased.
The selected location should not be near a nighttime light source such as a porch light, street light,
etc., as these lights might prevent the solar spot light from automatically turning on.
Battery b x can be insert into ground by using provided ground stakes..
Make sure that the solar panel should face sun to make the solar panel to absorb maximum sunlight.
ngle of battery box can be readjusted.
Light Head can be inserted into ground by provided stakes too. Carefully to do it. Don’t damage
wires when connecting light head and battery box.
Turn power switch at ON position the light will operate automatically.
3. TROUBLESHOOTING INFORMATION
The performance of solar powered light depends upon the amount of sunlight available during
daylight hours. If your solar light can not operate properly you
can check it and find out the cause as listed below.
1) Light dim
Battery is not fully charged or needs replacement.

Silicon Solar Inc | 2917 State Hwy 7, Bainbridge, N.Y. 13733 | Ph 800.786.0329 | www.SiliconSolar.com
a. Make sure your solar light is located in an area where the solar panel gets the maximum
amount of full, direct sunlight every day.
b. If the weather has been rainy or overcast during the day, the battery will not be charged for
operation at night. This is normal. The solar light must have direct sunlight every day to fully
charge the battery. If the solar light does not receive enough sunlight one day, it will recharge
the next sunny day and resume normal operation.
c. Check for obstructions to solar collector panel: over hanging branches, shade from bushes,
trees, fences, buildings and the like. Rel cate the light t a sunnier l cati n.
d. Dirty solar panel: a dirty solar panel will not allow the battery to fully charge. This will shorten
the life of the battery and cause the light to malfunction. Clear regularly with a dampened
cl th r paper t wel. D n’t use str ng detergents r acid based cleaners.
After c rrecting the pr blem, check the light perati n immediately after dark r in a
dark r m. If the light will nly perate f r a sh rt time, the battery needs recharging.
2) Light ut
a. Check for an external light source: street light, porch light, flood light may be preventing light
from automatically turning on at night.
b. Rechargeable battery needs recharging.
c. Old battery may wear out and not accept charge. Replace with new battery of same kind and
size: lithium battery , 3.7V, 2000 h*3pcs, maintenance free.
4. BATTERY CHANGING
Change battery in following steps:
1) Screw off screws and remove bottom plate from the battery box.
2) Screw off screws and remove two U- shaped plates which fix the battery..
3) Pull out two terminals from battery and take off old battery.
4) Replace new battery and remount in reverse steps as done above.
NOTE: DON’T LITTER OLD BATTERY. IT SHOULD BE RECYCLED.
