Operator’s Manual
Silvan Diaphragm Pumps
BP 20/15, 75/15, 60/20, 125/20, 151/20, 171/20, 265/20, 305/20
MP 20, 30, 40
P48
APS 31, 41, 71, 96, 101,121, 145, 166
IDS 2200, 2600
AUSTRALIA (HEAD OFFICE) NEW ZEALAND
89 Lewis Road, Wantirna South 22 Sunshine Ave, Te Rapa
Victoria, 3152 Hamilton, 2001
Telephone: [phone] Telephone: [phone]
Facsimie: [phone] Facsimie: [phone]
Spare Parts Facsimile: [phone]
www.silvanaust.co
m
www.silvannz.co.nz
MANAPS-2 Rev C 5/06/07

Contents
Page 1
Page
Warranty 2
About your Warranty 3
Safety Information 4
Specification 5
Identification 5
Installation 9
Operation 10
Maintenance 11
Trouble Shooting 12
Notes 13
PUMP DETAILS
Record the details of your pump and the supplying Silvan dealer here for future
reference when discussing service, ordering parts or making a warranty claim.
PUMP MODEL NO. _____________________________
PUMP SERIAL NO. _____________________________
ENGINE MODEL. _____________________________ (If Fitted)
ENGINE SERIAL NO. _____________________________ (If Fitted)
SELLINGDEALER ________________________________________________
ADDRESS ________________________________________________
_____________________________
TELEPHONE _____________________________
CONTACT NAME _____________________________
DATE OF PURCHASE _____________________________

New Product Warranty
Page 2
the Silva
n
Warranty
This warranty is the only warranty applicable to Silvan new products ('Products') and, to the
maximum extent permitted by law, is expressly in lieu of any other conditions or warranties
expressed or implied in relation to the Products.
Subject only to legislative obligations to the contrary, Silvan shall not be liable for incidental or
consequential damage resulting from ownership or use of a Product.
Silvan does not authorize any person to create for it any other obligation or liability in
connection with these products.
Silvan warrants its authorised Dealer, who in turn warrants the original purchaser (owner) of each new
Silvan product that it will repair or replace the product, or, pay the cost of repair or replacement, as
determined by Silvan without charge for labour or any defective or malfunctioning parts in accordance
with the warranty limitations and adjustment schedule below.
The warranty period begins on the date the product is delivered to the first retail purchaser for a period
of 12 months
This Warranty Covers
Only conditions resulting directly from defects in workmanship or material under normal use and
service.
Warranty Exclusions
The Warranty does not cover:
Conditions resulting from misuse, use of incompatible chemicals, exceeding machine
specifications including overloading, impact damage, negligence, accidental damage or failure
to perform recommended maintenance services.
Any product which has been repaired by other than an authorised Silvan service outlet in a
way which, in the sole and absolute judgement of Silvan, adversely affect its performance or
reliability.
The replacement of maintenance items such as diaphragms, batteries, V belts and ground
engaging components, etc.
Loss of time, inconvenience, loss of use of the product liability to third parties or any other
consequential damages.
Incidental costs associated with a warranty repair including any travel costs, out of hour’s
labour charges, cleaning costs, transportation costs, freight costs or any communication costs.
The repair of a defective product qualifying under this warranty will be performed by any authorised
Silvan service outlet within a reasonable time following the delivery of the product, at the cost of the
owner, to the service outlet’s place of business. The product will be repaired or replaced, using new
parts supplied by Silvan. Silvan, in its absolute discretion, may choose to pay the cost of replacement
or repair of the product.
The owner is responsible for the performance of regular maintenance services as specified in the
Owner/Operator Manual applicable to the product. Failure to carry out regular maintenance may
invalidate warranty

About your Warranty
Page 3
Silvan Australia Pty. Ltd. builds equipment to a high level of specification using components from
quality suppliers. The following information is provided to assist you with any repairs required
within the warranty period.
•All warranty repairs on Silvan products are carried out by Silvan dealers. If any
warranty repairs are required on Silvan products, it is recommended that the product be
returned to the place of purchase.
•It is good practice to keep a record of equipment maintenance both during and after the
warranty period.
The previous information on warranty coverage explains the extent and limitations of your
Warranty coverage on Silvan Products.
Honda Engine Warranty (If supplied)
A separate Honda engine manufacturers manual and warranty policy may be supplied if the
pump has been purchased with an Honda engine attached.
Any engine problem should be reported to your Silvan dealer in the first instance, however, any
authorised Honda servicing dealer can carry out warranty repairs on the engine provided all the
details of the purchase and engine are supplied.

Safety Information
Page 4
SThe pump is designed and
manufactured solely for the purpose of
applying agricultural chemicals to
crops. Under no circumstances should it
be used for any other purpose.
SBefore using this pump carefully read
and ensure you understand the contents
of this manual and any other manual
supplied with the pump, sprayer or
machine that the pump is fitted to.
SBefore operating the pump read all the
safety warnings which are carried on
various parts of the machine.
SNever allow an inadequately trained
person to attach or operate the pump.
SDo not operate the pump whilst wearing
loose clothing, unrestrained long hair,
jewellery or anything which could
become entangled in rotating
components or limit your vision.
SDo not operate the pump at speeds
greater than 540 PTO rpm.
SDo not operate the pump without all the
tractor and sprayer or machine safety
shields in place. Carefully check that
PTO and driveline shields are correctly
installed if used.
SDisconnect the tractor PTO or power
supply before performing any operation
on the pump.
SBefore use of any chemicals refer to the
chemical manufacturer’s label and
safety instructions for safe handling
procedures and correct method of use.
Always use the recommended personal
protective clothing and safety
equipment.
SDo not pump flammable liquids or
gases.
SChildren must be kept clear of the
pump.
Before operating the sprayer read the following safety instructions.
Failure to comply with these warnings may result in serious injury or death.
Whilst your pump has been designed and manufactured to incorporate all necessary safety
features it is essential that any person who operates or works on the machine is aware of the
safety precautions that should be exercised.

Specification
Page 5
Pump Identification
On receiving the pump the following data is
found on the name plate.
1. Pump Type
2. Maximum Delivery (at 0 Bar)
3. Delivery at Maximum Pressure
4. Maximum Pressure Permitted in Pump
5. Maximum RPM
6. Manufacture’s Serial No
Component Identification
Refer to the diagrams on the following pages
for the position of the various components
relating to your pump.
1. Mounting Base
2. Ball Valve 3/8”
3. Input / Output shaft
4. Oil Reservoir
5. Pressure Accumulator
6. Pump Head
7. Inlet Hose Barb
8. Inlet Valve Cap
9. Pump Crankcase
10. Bypass Coupling
11. Inlet Manifold
12. Delivery Manifold
13. Oil Level Cap
14. Safety Valve
15. Pump Shaft Protection
16. Delivery Coupling
17. Oil Cap
18. Identification Label
PUMP TYPE No OF
DIAPHRAGM DELIVERY
l/min
PRESSURE
bar p.s.i
POWER
(HP)
Max
RPM
WEIGHT
Kg.
BP 20/15
BP 60/20
BP 75/15
BP 125/20
BP 151/20
BP 171/20
BP 265/20
BP 305/20
2
2
3
3
4
4
6
6
18.7
58
68
117
138
152
252
296
15 215
20 290
15 215
20 290
20 290
20 290
20 290
20 290
0.83
3.3
2.68
6.8
7.8
9.38
14.3
15.8
550
550
550
550
550
550
550
550
7
10
10
13
24
24
55
55
MP 20
MP 30
MP 40, MP40AP
P 48, P 48 AP
2
2
3
2
19
29
39
51
30 435
30 435
30 435
30 435
1.6
2.3
3.2
4.1
550
550
550
550
7
7
9
13
APS 31
APS 41
APS 71
APS 96
APS 101
APS 121
APS 145
APS 166
3
3
3
4
3
3
4
5
25
38
68
89
97
115
141
163
40 580
40 580
40 580
40 580
50 725
50 725
50 725
50 725
2.7
4.1
7.4
9.5
12.3
14.5
18.0
20.5
550
550
550
550
550
550
550
550
10
10
18
22
38
38
48
56
IDS 2200
IDS 2600
6
6
208
249
50 725
50 725
25.8
32.1
550
550
76
76

Identification
Page 6
BP 20 / 15 BP 75 / 15
BP 60 / 20 BP 125 / 20
BP 151 / 20, BP 171 / 20 BP 265 / 20, BP 305 / 20

Identification
Page 7
MP20 , MP30 MP40
MP40AP P48
APS 31, APS 41 APS 71

Identification
Page 8
APS 96 APS 101, APS 121
APS 145 APS 166
IDS 2200, IDS 2600

Installation
Page 9
When a dealer or an owner installs a pump,
the following guidelines must be met:
1. The suction hose from the tank to the pump
must be equal to, or greater than the outside
diameter of the pump inlet connector (7).
2. The pump suction hose should be wire
reinforced to prevent collapse and firmly hose-
clamped at the connection.
3. The suction line from the tank to the pump
should be kept as short as possible and must
have a minimum of bends.
4. A suction filter must be fitted between the
tank and the pump.
5. The filter strainer should be approximately
50 mesh. The minimum filter area should be
250cm2per 100 l/min rated delivery of the
pump. eg. BP60/20 has a rated delivery of
58.2 l/min therefore the minimum filter area
would be 250/100 x 58.2 =145.5cm2.
6. The suction hose between the tank and the
filter should have a shutoff valve installed, to
allow the strainer to be cleaned without
emptying the tank. The parts of this valve
must not be smaller than the OD of the pump
inlet connector.
7. The maximum suction lift should be no
more than 1m for continuous operation and
3m for a maximum of 5 min during tank
filling.
8. Do not connect pump suction to mains feed, the
maximum inlet pressure is 1m (1.5psi)
Continuous Use
Tank Fillin
g
Onl
y
- Max 5

Operation
Page 10
This pump has been designed and
constructed solely to pump agricultural liquid
chemicals, normally used for pest, weed and
fungus control.
It must not to be used to pump:
•Liquids with a density and viscosity greater
than water.
•Chemical products if the compatibility with the
materials of the pump is not known.
•Sea water or other salty concentrations.
•Water with a temperature above 40°C and
less than 5°C.
•Any type of varnish.
•Solvents and thinners for any type of varnish.
•Any type of fuel or lubricant.
•Liquids containing granules or floating solid
parts.
•Chlorine.
•For special liquids please contact Silvan
service department.
Pre Operational Checks
1. Check the oil level while the pump is
standing still and sitting horizontally. The oil
must reach the level indicated on the sight
glass (fig 1) or be visible on the oil level plug
(fig 2) depending on the pump model. Top up
with SAE 20W/30 oil if necessary.
2. Adjust the air pressure in the pressure
accumulator if fitted (fig 3) in accordance with
the operating pressure used to spray. Adjust
according to Table A. The pressure can be
measured using a car tyre pressure gauge.
Start Up
1. Ensure the control valve is in the bypass
position and any taps not being used are in
the closed position. For details of the control
valve operation you need to refer to the
operation manual pertaining to the control
valve that will be fitted to your pump.
Repeat this procedure each time the pump
has been emptied of liquid ie. Run dry.
2. Bring the pump to operating speed of
between 400 and 540 Rpm.
3. Switch off the bypass and bring the pump
to operating pressure for the particular
application using the pressure regulator.
4. Check the oil level during the first hours of
operation and top up if necessary.
Shutdown
Flush the pump after use by running clean
water for a few minutes
If there is a risk of freezing run the pump dry
for a few minutes to remove all liquid from the
pump.
Spraying (Bar)
p
ressure (psi)
2 - 5
29 - 73
5 - 10
73 - 145
10 - 20
145 - 290
20 - 50
290 - 725
Surge air (Bar)
pressure (psi)
2
29
2 - 5
29 - 73
5 - 7
73 - 102
7
102
TABLE A

Maintenance
Page 11
SDisconnect the tractor PTO or power
supply before performing any operation
on the pump.
Oil
The level and condition of oil should be
frequently checked (eg. each time the tank is
filled) as it effects the operation of the pump
and the condition and life of the diaphragm. It
is advised to replace the oil every 300 hours
of work or annually, whichever occurs first
and at anytime the diaphragms are replaced.
Oil Level
When the pump is stationary the oil level must
correspond to the reference indicator found on
the oil sight glass (fig 2) or oil level cap (fig 1)
depending on the type of pump. The oil level
may vary when the diaphragm pump is
working: As the pump is started the oil level
will initially drop and then return to functioning
level when the liquid begins to pump.
During operation pay attention to any drop in
the oil level:
a) If this happens during the first few hours of
operation it is normal and it is sufficient to top
up with SAE 20W/30 type oil as in fig. 1. For
pumps BP 60/20 and P48 where the oil sight
glass is not present, remove the pressure
accumulator assembly (fig 3). When
remounting the manifold tighten the
connecting plate screws to a torque of 17 Nm
b) If this happens after many hours of
operation and continues after 1 or 2 top ups, it
is a symptom of diaphragm swelling caused
by restricted suction (dirty filter, collapsed
suction hose or chemical attack to
diaphragm). In this case check the filter and
suction system and/or refer to your Silvan
dealer to check the diaphragm.
Diaphragm Failure
If the oil becomes white (water present in oil),
it may be a symptom of breakage of one or
more diaphragms. It is necessary to stop work
and inspect the condition of the diaphragms.
If broken, it is necessary to replace the
complete set.
Continued use with water in the oil will cause
serious damage to internal parts of the pump
If it is not possible to replace broken
diaphragms within one day of failure, empty
the crankcase of water and pour in oil or
diesel oil to stop rust from forming on the
internal components.
Suction
The suction system must be inspected to
ensure:
1. There are no suction air leaks. Check for
entry of air caused by:
- entry of air caused by hose wear;
- loose fittings;
- worn joints;
2. There are no small leaks or drips when the
pump is stationary. If this occurs it means air
will enter the pump when in operation.
3. The filter is be kept clean with frequent
inspections (after every tank load) especially if
powder based products are used.
Pump Mounting
Periodically check, especially when there is
vibration during use that the pump mounting
bolts on the machine frame are tightened and
if necessary re-tighten.
Pressure Accumulator
Check the inflation of the pressure
accumulator, if fitted, according to Table A
especially if there are vibrations on the
delivery hose and/or the pressure gauge.
Freezing Conditions
If frosts or freezing conditions are likely to
occur then drain all water from the pump to
ensure the pump is not damaged by freezing
water expanding inside the pump.
Diaphragm Replacement
At the end of every season it is advised to
check the condition of the diaphragms and
replace if worn or distorted. If the pump heads
and/or diaphragms are removed the retaining
bolts should re-tensioned according to the
Silvan Torque Specifications chart.
Inlet and Outlet Valves
Periodically check (every 300 hours under
normal working conditions) the condition of
the inlet and outlet valves. The check must
be more frequent if sandy liquid or abrasive
liquids are used. They must also be carried
out if changes of pressure, irregular
functioning and strange noises are apparent.

Lubrication and Maintenance
Page 12
Maintenance Program Chart
Trouble Shooting
Pump does not prime
•No liquid in tank or not covering suction inlet.
•Suction filter blocked.
•Suction filter stop valve closed.
•Suction filter bowl loose or missing O-ring.
•Suction line loose allowing pump to suck air
•Control lever not in by-pass position.
•Pump valve springs broken or valves worn.
Pump does not reach correct pressure
•Pump not operating at full 540 rpm.
•Suction filter blocked.
•Suction filter stop valve partly closed
•Pressure regulator not correctly adjusted
•Pressure regulator valve and seats worn.
•Pressure gauge faulty
•Pump diaphragms ruptured (pump oil grey or
milky).
•Worn nozzles or capacity of nozzles
greater than capacity of the pump.
•Worn pump inlet / outlet valves
Pump and hoses vibrating.
•Pump surge chamber pressure incorrectly
adjusted or surge diaphragm ruptured.
•Air entering the suction line through loose
or damaged fittings.
•Pump valves or valve springs worn or
damaged.
•Worn nozzles or capacity of nozzles
greater than capacity of the pump.
•Air trapped in filter or suction lines.
Water in Oil
•Broken diaphragms
OPERATION Every
8 hours
Every
50
hours
Every
300
hours
End of
Season
CHECK LEVEL OIL X
CHECK PRESSURE ACCUMULATOR X
CHECK SUCTION FITTINGS X
CHECK AND CLEAN SUCTION FILTER X
CHECK PUMP MOUNTING X
CHECK DIAPHRAGM O
CHANGE OIL O(1) O(2)
CHECK INLET/OUTLET VALVES O
CHECK TIGHTENING OF PUMP BOLTS O
Note: X operation to be carried out by the operator
O operation to be carried out by specialised technician
(1) Every 300 hours or annually, whichever occurs first.
(2) To be carried out same at same time as diaphragm change
MAINTENANCE INTERVALS

NOTES
Page 13

NOTES
Page 14

SILVAN AUSTRALIA PTY. LTD.
ABN 48 099 851 144
AUSTRALIA (HEAD OFFICE)
89 Lewis Road, Wantirna South
Victoria, 3152
Telephone: [phone]
Facsimie: [phone]
Spare Parts Facsimile: [phone]
www.silvanaust.com
NEW ZEALAND
22 Sunshine Ave, Te Rapa
Hamilton, 2001
Telephone: [phone]
Facsimie: [phone]
www.silvannz.co.nz
