SIMOLIO SM-826D User manual

SM-826D
User Manual
SM-826D
2.4GHz Wireless TV Headphones
Sales & Support Email: [e-mail] (for NA/AU)
[e-mail] (for UK)
TECHINICAL SPECIFICATIONS
Signal-to-noise ratio
Transmission mode Automatic Frequency-Hopping Spread Spectrum
Carrier frequency 2.4GHz ISM BAND
Power Supply
output: DC 5V, 1A input : 100~240V
built-in 500mAh Li-ion Battery
Transmitter
Headphone
Frequency response
Distortion ≤1%
20 Hz – 20 KHz
≥70dB
Range: Up to 100 feet (without obstacles)
Working time 10 hours under wireless hearing mode
Charging time 3 hours
plug of power cable : 4.0*1.7mm
USB charging cable
18
This warranty is provided at the discretion of Simolio Ltd. And does not cover
cosmetic damage or damage due to acts of nature, accident, misuse, abuse,
negligence, commercial use, or modification of or to any part of the product.
Accessories such as audio cables, power adapter and perishable items such as ear
tips and batteries are not covered under this warranty.
Please contact: [e-mail] (for NA/AU) or [e-mail]
(for UK) and provide your Amazon order ID to register the warranty.
LIMITED WARRANTY
12 months limited warranty: The 12 months warranty will cover defects in
manufacturing and product failure for a period of 12 months from the original
date of purchase. The warranty period is not extended if we repair or replace a
warranted product.
03
02
01
Headphone
can not be
charged
successfully Faulty Power source.
Please change another power source
like PC USB port, socket, different
USB charger (5V/500mA-2A).
Faulty USB charging cable. Please change another workable USB
charging cable to see if it works.
Phenomena Causes Solutions
Part 3

SAFETY INSTRUCTIONS
1. Please read this instruction manual carefully and completely before using the
products. Keep this manual easily accessible at all times.
2. Always keep the product dry, and do not expose them to extreme temperatures.
3. The receiver must keep the minimum volume before switching the unit on.
High volume may cause hearing damage to persons with normal hearing,
especially to children.
4. Keep devices away from liquid. Before cleaning the product and its accessories,
disconnect the transmitter from the power adapter, and use only a slightly damp
cloth to clean the devices.
5. Use only the supplied power adapter.
6. Use the products with care and set them up on a stable surface of a clean,
dust-free environment.
7. The unit may get hot during use. Ensure the unit has adequate ventilation.
8. Please put the product far away from microwave oven, mobile phones, WiFi
router etc. to avoid unnecessary electronic wave interference.
9. Please switch off the transmitter and receiver after use, and pull out the power
adapter from the wall socket when not using for a long time.
10. Only qualified person can provide services! Do not attempt to open the unit!
01
Pacemaker Safety:
CAUTION!
Before using this product with a pacemaker or other medical device, consult
your physician or the manufacturer of your pacemaker or other medical device.
Thank you for choosing the SIMOLIO SM-826D Wireless TV Headphone. Please
read this guide carefully and keep it in a safe place for future reference. If you need
any further assistance, please contact our customer support team at:
[e-mail] (NA/AU)
[e-mail] (UK)
Response Time: 2-24h, excl. Holidays
Welcome to subscribe to our YouTube channel - “Simolio Direct” for more
product information.
SM-826D
SM-826D
Safety Instruction...................................................................... 01
Overview ................................................................................ 02
Features .................................................................................. 02
Product Diagram ..................................................................... 03
Package Contents .................................................................... 04
LED Indication ....................................................................... 05
How to Use
1. Check Your TV/Audio Source Output Options before the Set up ... 05
2. Turn on the Transmitter and Headphone ................................... 06
2.1 Power the Transmitter ....................................................... 06
2.2 Turn on the Transmitter ..................................................... 06
2.3 Turn on the Headphone ..................................................... 06
3. Connect the Transmitter to Your TV/Audio Source .................... 07
3.1 Digital Optical Connection ................................................ 07
3.2 RCA Analog Connection .................................................... 08
3.3 3.5mm/AUX Analog Connection ........................................ 10
3.4 Other Connections in Special Cases .................................... 11
4. Use Two Sets of SIMOLIO 2.4GHz Wireless TV Headphones
Simultaneously in the Same House ........................................... 14
5. Charge the Headphone ........................................................... 14
6. Customizing your SM-826D ................................................... 15
Troubleshooting ...................................................................... 16
Limited Warranty .................................................................... 18
Technical Specifications ........................................................... 18
...................................................................................
............

02
03
0102
OVERVIEW
FEATURES
(1) Hearing Protection Function
Soften the background sounds, make the TV conversations stand out, help people
enjoy TV programs in safe voices, protect people's hearing from the progressive
hearing damage caused by watching TV for a long time with normal headphones.
(2) Long Distance Transmission
Supported with the latest technology, you can have wireless freedom and crystal
clear voice within a range of up to 100 feet.
(3) Voice Highlighting Tech
Reduce background voice in TV to highlight the dialogues, so that words hard to
hear can easily stand out, making television dialogues to be understood easily.
(4) Noise Cancelling Tech (NCT)
Reduce the ambient noise to help the users to focus on listening to the dialogues
in TV.
(5) Automatic Signal Control (ASC)
Our special circuit design can adjust the sudden volume change and make the
output volume stable. It will avoid strong signal hurting the users' hearing.
(6) TONE Control
It is specially designed for people who have different sound frequency
(7) MONO/STEREO Optional
You can switch to STEREO for enjoying Hi-Fi sound quality music or select
MONO for enjoying more clear TV dialogues.
(8) Good Compatibility
Compatible with any brand of TV/Smart TV box/ Cable TV box/Set-top
box/DVD/other audio device that has a Digital Optical, RCA or 3.5mm AUDIO
OUT port(s).
(9) Convenient Charging Methods
The headphone is recharged by the supplied Micro USB cable into a compatible
USB charger (transmitter USB port/PC or TV USB port). It is ok to use most
mobile phone chargers on market.
(10) Headphone Designed with Auto Power Off Function for Power
Saving
When no signal is received for 10 minutes, the headphone will be powered off
automatically.
(11) Audio Sharing Function
You can have another headphone plug into the sharing port on the right side of the
SIMOLIO headphone to share audio with your buddy .
(12) One Transmitter Can Support Multiple Headphones
Additional SIMOLIO 2.4GHz wireless headphone receivers can be added to the
SM-826D system, allowing multiple listeners to enjoy the same audio source.
sensitiveness. They can select TONE (Treble/Normal/Bass) to find the optimum
parameters, and hear the target audio source clearly.
PRODUCT DIAGRAM
1. Receiver
Would you like to watch television with crystal-clear sound that won’t disturb
others in your family? Do you want to avoid hearing damage that could be caused
by wearing normal wireless headphones for a long time? SIMOLIO SM-826D
wireless TV hearing protecting headphone is just made for you.
Apply with the latest 2.4GHz Digital Automatic Frequency-Hopping Spread
Spectrum (FHSS) technology, it gives you crystal-clear sound with the freedom
of a wireless connection - up to 100 feet without obstacles. You can customize
your listening at a most comfortable volume level, via tone controls and
MONO/STEREO function. Our voice highlighting and noise cancelling
technology dynamically reduce TV background sounds and make TV dialogues
stand out. At last you can easily understand the TV dialogues at a healthy volume
without worrying about your hearing being damaged.
It’s compatible with both digital and analog audio output ports and suitable for
almost all TVs and the set-top boxes on the market.
Audio In
Power
ON/OFF
VOLUME
USB Charging
Socket
Power &Working
Indicator (Green)
Charging
Indicator (Red)
SM-826D
SM-826D
03
02
01

2. Transmitter
04
PACKAGE CONTENTS
LED INDICATION
LED Status Transmitter Status
Green LED flashes slowly No audio signal in within 5 minutes
Bright green LED lighting steadily
Dark green LED lighting steadily In standby mode (no audio signal in
for more than 5 minutes)
Wireless working mode
LED Indicators of the Transmitter
User Manual Quick Guide
USA UK
Power Adapter
5. If no Optical Audio Out port available, we suggest to connect the transmitter base to the red and white
RCA ports which labeled as AUDIO OUT of your TV. If the RCA AUDIO OUT port of your TV is unavailable,
you can connect the transmitter base to your
which is hooked up with your TV.
Smart TV box/Cable TV box/Set-top box/DVD/other audio
device
TV Rear
Transmitter 3.5mm
Audio In
Audio Out
TV or Cable Box
QUIC K GUIDE for SM-823D, SM-824D & SM-825D
IMPORTANT:
When use it as a wireless TV headset, the working
indicator is on. As a personal sound amplifier, the MIC indicator is on.
TV/Smart TV box/
Cable TV box/Set-top box/DVD/other audio device
1. The unit will not work with the optical audio if the optical cable is carrying a Dolby Digital or DTS signal.
In this case, set the Audio Out Format of your TV and TV related AV devices (e.g., cable box/DVD etc) to
PCM to get the unit to work.
2. Three different audio cords: digital optical cord, RCA cord and 3.5mm cord. In the end, only one of these
cords is needed to complete the installation.
3. This device is a wireless TV headset as well as a personal sound amplifier. You can find a MIC ON/OFF
button at the rear of headset. It is designed for hearing impaired people to clearly hear what people’s
talking to him/her nearby when watching TV. Just press MIC ON/OFF button , you can turn this headset to
a personal sound amplifier which could amplify the people's voice around. When you want to back to
watching TV, just press the MIC button again.
4.We suggest to hook up the transmitter base to the Optical Audio Out port of your
in priority, for enjoying the super sound quality.
For streaming media watching (Netflix, Amazon Prime Video, etc.), place the transmitter base at least 4
feet away from your smart WiFi TV/WiFi TV box/TV sticks to avoid interference.
green
red
Page 1
TONE
TREBLE
NORMALBASS AUDIO IN
STEREO
MONO
OFF
DC 5V
OPTICAL
TONE
TREBLE
NORMALBASS AUDIO IN
STEREO
MONO
OFF
DC 5V
OPTICAL
Optical
Audio Out
TV Rear Optical Splitter
Optical In
Optical Out
Sound Bar Transmitter Audio In
Optical
Optical
Audio Out
TONE
TREBLE
NORMALBASS AUDIO IN
STEREO
MONO
OFF
DC 5V
OPTICAL
Audio In
Optical
TV Rear
Transmitter
If you has a sound bar/HiFi need to be connected
with, we suggest to buy an optical splitter, so you
can connect your sound bar/HiFi and the transmitter
to your TV at the same time, shown as figure 2.
TV or Cable Box TV or Cable Box
R
L
Figure 2
Figure 1
Figure 3 Figure 4
SEVEN F REQUE NCY ASKE D QUESTI ONS (FAQ ) from marketing statistical analysis:
1.Outside noise overpowers the TV voice.
It is possible that the MIC ON/OFF button at the rear of headset is pressed on inadvertently, in this case the MIC
indicator is solid red . To back to watching TV, just press the MIC ON/OFF button again or switch off the headset
and then restart with the red MIC indicator off and the green TV receiving indicator on.
2.The connections are correct and in place, but no TV sound is heard or sound cuts in and out.
1) It is possible that the volume of the audio source is set too low. If you connect STB/Cable box/DVD etc to the
TV to watch programs, then the audio source is the STB/Cable box/DVD etc. Please use the audio source's
remote control to set its volume to a sufficient level to ensure a steady sound signal. If you want to mute the TV
sound and only hear from this headset, please use your TV remote control to click MUTE menu. (For most TVs,
the TV's speakers are separately controlled from the TV's audio out).
2) When do connection with the optical cable, set the Audio Out Format of your TV and TV related AV devices
(e.g., cable box/DVD etc ) to PCM to get the unit to work. ( Settings > Sound > Digital Audio Out Format >
VIDEO IN
COMPONENT
IN
AUDIO IN
RCA
AUDIO OUT
RCA
BASS
TREBLENORMAL
STEREO
TONE
AUDIO IN
MONO
OFF DC 5V
OFF/ON POWER IN
POWER OUT
DC 5V/500mA
OPTICAL IN
BASS
TREBLENORMAL
STEREO
TONE
AUDIO IN
MONO
OFF DC 5V
OFF/ON POWER IN
OPTICAL IN
SM-823D
SM-824D
SM-825D
or
Optical Fiber Cable
Transmitter
Headphone
Micro USB
Charging Cable
-
Audio Cable
Ø3.5mm RCA 3.5mm
Audio Cable
Ø
05
(for headphone)
LED Indicators of the Headphone
Headphone charging
LED Status Headphone Status
Green flashes slowly LED No signal received
Green LED quickly and
headphone beeps every minute
flashes
Green LED lighting steadily Wireless working mode
Low power indication
Red LED on
Headphone charging completed
Red LED off
Note:
• The transmitter will automatically enter standby mode within 5 minutes of no
signal input, and it will automatically restart when there is an audio signal input.
• The headphone will power off automatically after 10 minutes of no audio signal
in. Using it again, you need to slide ON/OFF switch to “OFF” position, then slide
to “ON”.
HOW TO USE
SM-826D is compatible with OPTICAL output, AUX 3.5mm output, and RCA
(labeled “AUDIO OUT”) (Ref. Fig 1-1)
1. Check Your TV/Audio Source Output Options before the Set up
POWER IN
DC 5V
OFF/ON
OFF/MONO/STEREO
Power &Working
Indicator (Green)
AUDIO IN
TONE
TREBLE/NORMAL/BASS
OPTICAL IN
POWE R OUT
DC 5V/ 500mA
STERE O
MONO
OFF
OFF/ ON
DC 5V
POWER I N
OPTICAL I NAUDIO INBA SS
TREBLENORMAL
TONE
POWER OUT
(charging port)
USB DC 5V
Note:
• Three different audio cables included: digital optical cable, RCA cable and 3.5mm
cable. In the end, only one of these cables is needed to complete the installation.
2.4GHz Wirel ess TV Head pho nes
SM-826D
Use r Manua l
Sale s & Suppo rt Emai l: supp ort@s imoli o.com (f or USA)
supp ort_u k@sim olio.c om (for E urope )
01
02
03
SM-826D
SM-826D
03
02
01

Other RCA
jacks(usually
audio in)
AUDIO IN
Digital Optical
AUDIO OUT
OPTICAL
AUDIO OUT
(need extra 6.35mm
to 3.5mm adapter,
purchase separately)
(need extra digital to
analog converter,
purchase separately)
Digital
AUDIO OUT
Coaxial
COAXIAL
Jack
Options
Natively
supported?
Please refer
to Point
6.35mm
Phone jack
PHONE
3.1
AUX/3.5mm
3.3
RCA jacks
labled
AUDIO OUT
R
L
AUDIO OUT
3.2 N/A 3.4 3.4
Fig 1-1
2.3 Turn on the Headphone
Slide ON/OFF switch to “ON” position.
2.2 Turn on the Transmitter (Ref. Fig 2-2)
Slide OFF/MONO/STEREO switch to “MONO” or “STEREO” position.
STEREO
MONO
OFF
OFF/ON
2.1 Power the Transmitter (Ref. Fig 2-1)
Plug the supplied AC adapter into a standard electrical outlet, plug the other end
of the AC adapter into the port labeled “DC 5V” on the back of the transmitter.
2. Turn on the Transmitter and Headphone
• If your audio source device has an optical audio out port, please connect
SIMOLIO to this port preferentially. If not, you can also connect SIMOLIO to the
RCA or AUX/3.5mm or other audio out port of the audio source device.
Fig 2-2
Transmitter
POWER OU T
DC 5V/500 mA
STEREO
MONO
OFF
OFF/ON
DC 5V
POWER IN
OPTIC AL INAUDIO INBASS
TREBLEN ORMAL
TONE
Fig 2-1
Power in
Power adapter
DC 5V
POWER IN
SM-826D
SM-826D
3.1 Digital Optical Connection
This part will instruct you on how to connect the SIMOLIO SM-826D transmitter
to your television, satellite, or cable box using an optical digital audio cable.
3. Connect the Transmitter to Your TV/Audio Source
CAP
Step 1. Hook up SIMOLIO to the Optical Audio Out Port of the TV/other
Audio Device
Remove the protective plastic caps
from both ends of the optical digital
audio cable.
• Be aware that the base should be placed at least 4 feet away from your Router/
smart WiFi TV/TV sticks/WiFi TV box to avoid interference.
Fig 3-4
• If you cannot get to the back of your TV and you only watch the programs
through a fixed TV box (cable/satellite box/DVD etc.), you can also use these
instructions to install the system to your TV box.
Plug either end of the optical audio cable into the “Digital Audio Out (Optical)”
port on the back of the TV. Plug the other end of the optical digital audio cable
into the port on the back of the transmitter labeled “OPTICAL IN”.
Optical Audio Cable
Digital Audio Out
(Optical)
POWER OUT
DC 5V/500mA
STEREO
MONO
OFF
OFF/ON
DC 5V
POWER IN
OPTICAL IN AUDIO IN BASS
TREBLE NORMAL
TONE
OPTICAL IN
07
06
Fig 2-3
Set the volume of the audio source to a level sufficient for people with normal
hearing to clearly listen to the TV to ensure stable audio output.
i.e. set the TV box VOL ≥ 30 % & TV VOL ≥ 40% (Ref. Fig 3-1) (Ref. Fig 3-2)
For watching TV quietly without disturbing others, the right way is: Mute your TV
by pressing the MUTE button on the remote control or choose any speaker option
other than TV Speaker in the TV Sound Output settings.(Ref. Fig 3-3)
• The above settings may differ from various TVs.
TV box VOL ≥ 30 %
Fig 3-1
Mute
Fig 3-3
TV VOL ≥40 %
Fig 3-2
Fig 3-5

08
Step 2. TV Audio Format and Speaker Setting (use TV remote control)
If you can not hear sound from your headphones after connecting:
• Ensure TV Audio Format is set to “PCM” or “Dolby/DTS” is OFF (This is
IMPORTANT, Ref. Fig 3-6)
PS: for certain smart Samsung models, the TV is retaining separate settings for
regular TV and internet TV setup. When you turn to the Smart Hub for Internet
source, please use the TV remote to go to Settings > Sound > Expert Settings >
Audio Format or Digital Output Audio Format, then select PCM.
09
Plug the red and white ends of the audio cable into the analog RCA Audio Out
ports (red and white ports labeled “AUDIO OUT”) on the back of the TV. Plug
the single end of the audio cable into the port labeled “AUDIO IN” on the back of
the transmitter.
• Be aware that the base should be placed at least 4 feet away from your Router/
smart WiFi TV/TV sticks/WiFi TV box to avoid interference.
• If you cannot get to the back of your TV and you only watch the programs
through a fixed TV box (cable/satellite box/DVD etc.), you can also use these
instructions to install the system to your TV box.
Step 1. Hook up SIMOLIO to the RCA Audio Out Port of the TV/other Audio
Device
Notes: If your TV only support single sound out, the TV’s speakers will be either
automatically muted when you plug something into an audio out port (Optical/
AUX/RCA, etc.) or they become disabled once you choose "External Speakers"
as your TV's audio output. It depends on TV circuit design.
• Ensure your TV speaker is set to “External Speakers”. (Ref. Fig 3-7)
Fig 3-6 Fig 3-7
* Setting menu may be different depending on different TV brands and models.
For most TVs, the TV's internal speakers and an external audio device can work
simultaneously. Such as, for some newer LG TVs, when do optical audio
connection, you can set the “Sound Out” to “Internal TV Speaker + Audio Out
(optical)”. And for some newer Samsung TVs, you can enable this feature by
selecting “TV Speaker” from the TV Sound Output lists.
Speakers
Internal speakers
External speakers
Headset
Settings
Audio Format
Dolby Digital
DTS
DTS Neo 2:5
PCM
SM-826D
SM-826D
Fig 3-8
Step 2. TV Audio Out Checking and TV Speaker Setting (use TV remote
control)
If you can not hear sound from your headphones after connecting:
• Ensure use TV Red/White ports labeled “AUDIO OUT” or “OUTPUT”, other
Red/White ports are incorrect. (Ref. Fig 3-9)
• Ensure your TV speaker is set to “External Speakers”. (Ref. Fig 3-10)
RCA Audio Cable
TV REAR
R AUDIO OUT L
POWER OUT
DC 5V/500mA
STEREO
MONO
OFF
OFF/ON
DC 5V
POWER IN
OPTICAL IN AUDIO IN BASS
TREBLE NORMAL
TONE
AUDIO IN
This Part is an alternative to 3.1 on page 7. This part will explain how to connect
the SIMOLIO SM-826D transmitter to your television, satellite, or cable box
using an RCA analog audio cable.
AUDIO OUT
R
L
COMPONENT IN
VIDEO IN
TV REAR
Fig 3-9 Fig 3-10
Speakers
Internal speakers
External speakers
Headset
RCA Audio Cable Fig 3-11
R AUDIO OUT L
• Use the RCA cable to plug the headphone into the RCA output of the TV to test
if you can hear the TV sound. (Ref. Fig 3-11)
03
02
01
3.2 RCA Analog Connection

SETTINGS
ANALOG AUDIO OUT
VARIABLE
FIXED
SOUND / AUDIO
Fig 3-12
* Your TV’s analog audio settings may be set to
“Variable” or “Fixed”. If you want to be able to
control your TV volume level separate from your
SIMOLIO SM-826D volume level, you will need to
make sure your TV is set to “Fixed”. Contact your
TV manufacturer for assistance. (Ref. Fig 3-12)
3.3 3.5mm/AUX Analog Connection
This part is an alternative to 3.1 and 3.2 on page 8-10. This part will explain how
to connect the SIMOLIO SM-826D transmitter to your television, satellite, or
cable box using a 3.5mm/AUX analog audio cable.
POWER OUT
DC 5V/500mA
STEREO
MONO
OFF
OFF/ON
DC 5V
POWER IN
OPTICAL IN AUDIO IN BASS
TREBLE NORMAL
TONE
AUX/3.5mm Audio Cable
H/P or Audio Out
Fig 3-13
Plug one end of the 3.5mm audio cable into the “Audio Out” port on the back of
the TV. Plug the other end of the audio cable into the port labeled “AUDIO IN” on
the back of the transmitter.
• If you cannot get to the back of your TV and you only watch the programs
through a fixed TV box (cable/satellite box/DVD etc.), you can also use these
instructions to install the system to your TV box.
• If you connect the 3.5mm audio cable to the 3.5mm Audio Out port which is
usually a Headphone port on your TV, your SIMOLIO SM-826D will still
function properly, but the sound to your TV internal speakers will be muted. The
port is usually labeled with an headphone icon.
• Be aware that the base should be placed at least 4 feet away from your
Router/smart WiFi TV/TV sticks/WiFi TV box to avoid interference.
*Setting menu may be different depending on
different TV brands and models.
Step 1. Hook up SIMOLIO to the 3.5mm Audio Out Port of the TV/other
Audio Device
AUDIO IN
Notes:
* If your TV only support single sound out, the TV’s speakers will be either
automatically muted when you plug something into an audio out port (Optical/
AUX/RCA, etc.) or they become disabled once you choose "External Speakers"
as your TV's audio output. It depends on TV circuit design.
For most TVs, the TV's internal speakers and an external audio device can work
simultaneously. Such as, for some newer LG TVs, when do analog RCA audio
connection, you can set the “Sound Out” to “Internal TV Speaker + Headphones”.
And for some newer Samsung TVs, you can enable this feature by selecting “TV
Speaker” from the TV Sound Output lists.
Fig 3-14
Step 2. TV Audio Out / TV Speaker Setting (use TV remote control)
If you can not hear sound from your headphones after connecting:
3.5mm Audio Cable
Notes:
* Your TV’s audio settings may be set to “Variable”
or “Fixed”. We recommend that you set your audio
settings to “Fixed” for better audio quality when
using this installation option. If you want to be able
to control your TV volume level separate from your
SIMOLIO SM-826D volume level, you will need to
make sure your TV is set to “Fixed”. Contact your
TV manufacturer for assistance.
• Use the AUX/3.5mm cable to plug the headphone into the headphone/3.5mm
audio output of the TV to test if you can hear the TV sound. (Ref. Fig 3-15)
Fig 3-15
Fig 3-16
• Ensure your TV speaker is set to “Headset”. (Ref. Fig 3-14)
H/P or Audio Out
10 11
SETTINGS
ANALOG AUDIO OUT
VARIABLE
FIXED
SOUND / AUDIO
Speakers
Internal speakers
External speakers
Headset
1) TV/Audio Source only has Digital Coaxial Audio Out port
3.4 Other Connections in Special Cases
Step1. Purchase a Digital to Analog Converter and Set up as Shown in Fig 3-17
If your TV/Audio Source only has a digital coaxial audio out port, you will need a
digital to analog converter (DAC) for installation.
* Setting menu may be different depending on different TV brands and models.
03
02
01
SM-826D
SM-826D

Pho nes
AV Receiver
6.35mm Audio adapter
(purchase separately)
3.5mm Audio Cable
6.35mm Phone jack
POWER OUT
DC 5V/500mA
STEREO
MONO
OFF
OFF/ON
DC 5V
POWER IN
OPTICAL IN AUDIO IN BASS
TREBLE NORMAL
TONE
Fig 3-22
AUDIO IN
wireless
transmitter
Coaxial
Digital Out
AUDIO IN
Digital to Analog Converter
RCA OUT
L
R
COAXIAL IN
POWER OUT
DC 5V/500mA
STEREO
MONO
OFF
OFF/ON
DC 5V
POWER IN
OPTICAL IN AUDIO IN BASS
TREBLE NORMAL
TONE
Step 2. TV Audio Format and Speaker Setting (use TV remote control)
If you can not hear sound from your headphones after connecting:
Fig 3-17
• Ensure TV Audio Format is set to “PCM” or “Dolby/DTS” is OFF (This is
IMPORTANT, Ref. Fig 3-18)
PS: for certain smart Samsung models, the TV is retaining separate settings for
regular TV and internet TV setup. When you turn to the Smart Hub for Internet
source, please use the TV remote to go to Settings > Sound > Expert Settings >
Audio Format or Digital Output Audio Format, then select PCM.
• Ensure your TV speaker is set to “External Speakers”. (Ref. Fig 3-19)
• Take turns to test RCA connection and 3.5mm headphone connection.
• Use the AUX/RCA cable to plug the headphone into the headphone or RCA
output of the DAC to test if you can hear the TV sound. (Ref. Fig 3-20)
Fig 3-18 Fig 3-19
Speakers
Internal speakers
External speakers
Headset
Settings
Audio Format
Dolby Digital
DTS
DTS Neo 2:5
PCM
13
12
Note:
Setting menu may be different depending on different TV brands and models.
RCA
OUT
L
R
COAXIAL IN
Connect TV/
Cable box/
STB etc.
RCA Audio Cable
H/P
L
R
COAXIAL IN
3.5mm Audio Cable
Connect TV/
Cable box/
STB etc.
or
Fig 3-20
SM-826D
SM-826D
2) If your TV/Audio Source’s Digital Optical Audio Out port is occupied
by soundbar, you will need an optical splitter for installation.
Step 2. If you can not hear sound from your headphones after connecting,
follow the part of 3.1 on page 8-9 to check your settings.
Step 1. Purchase an Optical Splitter and Set up as Shown in Fig 3-21
Optical Splitter
Optical Fiber
Cable
Sound Bar
Optical Fiber
Cable
SM-826D
(Transmitter)
Fig 3-21
Step 1. Purchase a 6.35mm to 3.5mm Adapter and Set up as Shown in Fig 3-22
3) Connect SIMOLIO SM-826D to your AV Receiver with 6.35mm
PHONE jack
SM-826D is not compatible with ANY RCA(L/R) ports on your AV Receiver,
ONLY use the BIG 6.35mm PHONE OUT on front side of your AV Receiver
with the 6.35mm to 3.5mm adapter (purchase separately).
Digital Optical
Audio Out
• Use the AUX cable and 6.35 to 3.5mm converter to plug the headphone into the
port on AV receiver to check whether the sound is normal.
If you can not hear sound from your headphones after connecting:
Step 2. Check the Performance of the AV Receiver's Audio Output as Shown
in Fig 3-23
03
02
01
03
02
01
03
02
01

15
•
headphone and make sure the green LED indicators are facing towards each other
for about 5 seconds.
Take the headphone close to the transmitter, then turn on the transmitter and
Note: If two headphones are used on
the same TV, only one transmitter
needs to be connected, because one
transmitter supports multiple
headphones to work simultaneously.
• The two sets of SIMOLIO 2.4GHz units should be put at least 10 meters away
from each other when using them simultaneously.
Fig 3-23
AV Receiver
6.35mm Audio adapter
(purchase separately)
3.5mm Audio Cable
6.35mm Phone jack
4. Use Two Sets of SIMOLIO 2.4GHz Wireless TV Headphones
Simultaneously in the Same House
Fig 4-1
room 1 room 2
SM-826D
(Transmitter 2)
SM-826D
(Transmitter 1)
Distance >10M (at least)
Pho nes
14
SM-826D
SM-826D
Notes: The charging time is approx. 3 hours. Before using the spare rechargeable
battery for the first time, charge it for at least 3 hours. The headphone battery will
last around 10 hours on a full charge, but will last a lesser or greater amount of
time depending on the average volume level of the headphone.
1) Please make sure the headphones are being worn properly. Each side of the
headphone has a letter to guide the wearer: "L" for left and "R" for right. You can
adjust the retractable headband to fit you better.
6. Customizing your SM-826D
POWER OUT
DC 5V/500mA
STEREO
MONO
OFF
OFF/ON
DC 5V
POWER IN
OPTICAL IN AUDIO IN BASS
TREBLE NORMAL
TONE
(Transmitter)
micro USB charging cable
B: Through the universal USB charger/outlet
You can charge your headphone by plugging the micro USB power cable into a
phone charger (5V/500mA-2A output), PC USB port, TV USB port or any other
USB outlet. You don't need to go back to the transmitter base next to the TV to
charge. It takes about 3 hours to fully charge the headphones. The LED will turn
RED during charging and turn off once charging is completed.
(Headphone)
micro USB charging cable
(phone charger / PC USB port/
TV USB port / any other USB outlet)
A: Through the USB charging port on the rear of the transmitter base
You can use the included micro USB charging cable to connect the headphone to
the USB charging port on the rear of the transmitter base for charging.(make sure
the transmitter base is powered on)
5. Charge the Headphone
Fig 5-1
Fig 5-2
Power
adapter
03
02
01
Fig 6-1
(Headphone)
Wireless Receiving
Indicator (Green)
(Transmitter)
Power &Working
Indicator (Green)
POWER OUT
POWER OUT
DC 5V/500mA
STEREO
MONO
OFF
OFF/ON
OFF/ON
DC 5V
POWER IN
POWER IN
OPTICAL IN AUDIO IN
BASS
TREBLE NORMAL
TONE
TONE
Fig 4-2
(Receiver)
LR LR
03
02
01
03
02
01

Phenomena Causes Solutions
Sound cuts
in and out
or
some noise
is occurred
The connection between the
transmitter and the audio source is
wrong.
Make sure the connection is correct and
in place between the transmitter and the
audio source.
The audio sources (TV and TV
related AV devices) are not turned
on or their volume are set too low.
Turn on the audio source, and adjust its
volume to a sufficient level.
The headphone is out of the
transmitting range.
Move the headphone closer to the
transmitter.
The battery’s power is too low. Charge the battery fully.
The transmitter is placed too close
to metalworks or other
electromagnetic wave objects.
Put the transmitter far away from the
interference sources.
The headphone is powered off
automatically. Switch the headphone off, then on.
The audio out port of the
connected audio device is
defective (no sig al out ).n
Connect to another audio out port .
TV audio output is disabled or not
activated.
Follow the instructions in your TV user
manual to change the TV’s AUDIO OUT
setting to "External TV Speakers".
Set it to PCM. For example: Settings >
Sound > Digital Audio Out Format>
Dolby/DTS/PCM, menu depends on TVs.
The audio out format of TV and
TV related AV devices (e.g.,
Cable box,STB, DirecTV, etc.)
is not set toPCM.
The analog audio cable is plugged
into the AUDIO IN jack of the
transmitter when connecting with
the optical cable.
Unplug the analog audio cable from the
transmitter.
TV volume is turned down to
ZERO.
Adjust the TV volume to a sufficient level.
If you want to mute the TV, please click
the MUTE key on the TV remote control
or go to TV settings to OFF the Internal
TV speaker.
The audio source’s volume is set
too low. Adjust its volume properly.
Part 2
17
Fig 6-2
TONE
TREBLE/NORMAL/BASS
POWER OUT
DC 5V/500mA
STEREO
MONO
OFF
OFF/ON
DC 5V
POWER IN
OPTICAL IN AUDIO IN BASS
TREBLE NORMAL
TONE
(Transmitter)
AUDIO IN BASS
TREBLE
NORMAL
TONE
16
SM-826D
SM-826D
OFF/ON
OFF/MONO/STEREO
3) Mono/Stereo option: You can switch to STEREO for enjoying Hi-Fi sound
quality music or select MONO for enjoying more clear TV dialogues. If, despite a
correct balance adjustment, you can hear the sound only with one ear: Set the
STEREO/MONO switch on the transmitter to MONO. (Ref. Fig 6-3)
STEREO
MONO
OFF
OFF/ON
Fig 6-3
TROUBLESHOOTING
Phenomena Causes Solutions
The transmitter is not connected
well.
Make sure the AC adapter and the audio
cable of the transmitter are plugged in place.
Switch to MONO or STEREO to power the
transmitter on.
The transmitter is not powered on.
Part 1
Headphone
doesn’t
work, or
no voice
received
The audio out function of the
connected audio device is
defective(poor signal out).
The connection between the
transmitter and the audio source
isnot in place.
Make sure the connection is firm between
the transmitter and the audio source.
Connect to another audio out port .
Place the transmitter base at least 4 feet
away from smart WiFi TV/WiFi TV box/
TV sticks to avoid interference.
The headphone is used for listening
to streaming media (Netflix,
Amazon Prime Video etc).
If you are using RCA connection,
the RCA audio cable connecting
the transmitter and your TV/audio
source is NOT FULLY plugged at
BOTH ends.
Try to wiggle the audio cable or unplug
and plug the audio cable from both the
ends on TV/audio source and the
transmitter .
The voice
is heard
onlywith
one ear Switch the transmitter to MONO.
The audio out signal of audio
source is mono, but the transmitter
is switched to STEREO.
Faulty cable/audio out port issue Try another audio cable or another audio
device.
Headphone
doesn’t
work, or
no voice
received
2) Tone Control: Select the TONE (TREBLE/NORMAL/BASS) at the rear of
transmitter to find the best feature, make sure you can hear the TV voice clearly.
