SimPal SimPal-T40 User manual

SimPal-T40
SimPal-T20
Wireless PowerSocket
UserManual
Manualversion1.0

SimPal
-
T40/T20
POWER SOCKET USER MANUAL
SimPal-T40/T20GSMPowerSocket
Thank youforpurchasingtheSimPal-T40/T20.
SimPal-T40 GSMpowersocketis aremotecontrolledsocketconsistingofaGSMmodule.
The powersupplyoutputcan be turnedonoroff remotelybytheSMScommand or local
controlled bypressingbutton.
SimPal-T20 slavesocketconnectwith T40,up to30metersrangebetween T20 and T40
connection.You can control one T40and fourT20 withoneSIMcard.
BothT20 and T40socketsupporttemperaturemonitor,temperature control,calendar control
anddelaycontrolbysendingSMSfromyourmobilephone.
All servicesandfunctionsneed tobe supportedbytheGSMnetworkandaSIMcard.
This brochuresuits for SimPal-T40andSimPal-T20 model.
Detailsofthefunctioningandadvanced operationofthissocketaredescribedinthis
instructionmanual.

SimPal
-
T40/T20
POWER SOCKET USER MANUAL
Foryoursafety......................................................................................................................... 7
Exceptionclause...................................................................................................................... 9
1.1Packagecontents ............................................................................................................. 10
1.2 Socketsinstructions................................................................................................11
1.3Lightindicator................................................................................................................. 13
2.1Userauthorization level................................................................................................... 14

SimPal
-
T40/T20
POWER SOCKET USER MANUAL
2.2AbouttheSMSCommand................................................................................................. 15
3.1Starttouse....................................................................................................................... 15
3.2.1RegisterMaster-number................................................................................................ 17
3.2.2ChangeMasternumber................................................................................................. 18
3.4Pairingslavesocket......................................................................................................... 19
3.5Controlsocketpower....................................................................................................... 21
3.6Delaycontrolthesocketoutput........................................................................................ 21

SimPal
-
T40/T20
POWER SOCKET USER MANUAL
3.7Calendarcontrol.............................................................................................................. 23
3.8Temperaturecontrol......................................................................................................... 26
3.9Temperaturealarm........................................................................................................... 28
3.10SocketoutputchangeSMS alert..................................................................................... 30
3.11MainspowerchangeSMSalert...................................................................................... 30
3.12SMS notificationtoUser................................................................................................ 31
3.13Check status................................................................................................................... 32

SimPal
-
T40/T20
POWER SOCKET USER MANUAL
3.14WeakGSMsignalnotification........................................................................................ 33
3.15Resettingthesocket........................................................................................................ 34
4. MainTechnicalParameters............................................................................................... 35
Appendix:SMScommandslist................................................................................................. 37

SimPal
-
T40/T20
POWER SOCKET USER MANUAL
1.PurchaseaGSMSIM card(mobilephonecard)fromGSMnetwork
serviceproviderand install itinthesocket.ThisSIM cardnumber
isreferredasSimPal-T40number on thisbrochure.
2.TheuserneedstoactivatetheCallerIDPresentationfunction of
SIMcard, and deactivatePINcodeoftheSIM.ContactwithGSM
networkserviceproviderfor support.

SimPal
-
T40/T20
POWER SOCKET USER MANUAL
Foryoursafety
§This socketwasdesignedfor homeorofficeuse.Donotuseit ontheelectricalappliance
whichis for industryorbusiness operation,for example,iatricalappliances, largeheaters
andrefrigerates.
§Beforeusingthis socket, makesurethatthe mobilephonescan beused wellinthe area,
otherwise,do notput this socket intooperation.
§The powerconsumptionoftheappliancesconnected withthe socketcannotexceed
3600Wand thecurrentcannot exceed 16A.
§The electricalappliancewhichpowerconsumptionishigher than1500Wmust be
grounded.
§Donot maketwoplugsofsocket shortcircuit.
§Donot touchthe socket jackbyanymetal objects orhand.
§This socketwasdesignedfor indoor use.Don tuseit inwet, chemically aggressiveor dusty
environment.
§Donotopenthe caseunlessmaintenanceneeded.

SimPal
-
T40/T20
POWER SOCKET USER MANUAL
§Donot keepshaking or fall downthissocket, otherwiseit can be damaged.
§This socketis awireless signaltransmission socket. Keep it awayfrom electronic
equipment likelytointerfere withthe wireless signals, inordertoavoidsignals interference.
§Switchoff this socketandmobilephonewhenenteringareasmarked "Explosive","Might
explode", "Closedwireless transceiver sockets"etc.
§Donot cast this socket inafire, asthis maycauseexplosion.
§This socketshouldonlybeoperated from powerapproved bythesocketmanufacturer.The
useofanyothertypesofpower maydamage the socket.
§Keep thesocket anditsaccessories out of thechildrenreach.

SimPal
-
T40/T20
POWER SOCKET USER MANUAL
Exceptionclause
1. Weoperate onapolicyofcontinuousdevelopment.Wereserve the right to makechanges
andimprovements toanyof the sockets describedinthis document withoutprior notice.
2.For thelatest socketinformation,pleasevisit: http://www.simpal.cn. Wedon tguaranteefor
the documentveracity,reliability oranycontentexceptregulateinproperlaws. Includingno
guaranteefor socket suitablemarket or suitablearea promise.
3.Weholdnoresponsibilityfortheillegal useof this socket.
4.Weholdno responsibilityforanyloss of income oranyspecial, incidental, consequentialor
indirect damageshowsoevercaused.
5.The contents ofthis documentare provided “asis”.Except asrequiredby applicablelaw,no
warrantiesofanykind,either expressed or implied,including,butnotlimited tothe
accuracy,reliabilityorcontents ofthis document. Wereservethe righttorevisethis
documentor cancel somefunctions atanytime without priornotice

SimPal
-
T40/T20
POWER SOCKET USER MANUAL
1.1Packagecontents

SimPal
-
T40/T20
POWER SOCKET USER MANUAL
1.2Socketsinstructions
Note: Slave socket T20 without SIM card slot

SimPal
-
T40/T20
POWER SOCKET USER MANUAL
Figure 2: TemperaturesensorInstruction

SimPal
-
T40/T20
POWER SOCKET USER MANUAL
1.3Light indicator
Model Indicator Action Status
SimPal-T40
andSimPal-20
Power Socket
Power LED Turning off Socket power output OFF
Constant light Socket power output ON
Wireless signal
LED
Flashslowly Searchingnetwork (SimPal-T40)
Lost connection with T40 (SimPal-T20)
Slowly breathWorking instandby mode.
Two fastand
oneslow Flash Socket inpairing mode
Continues light
in3 seconds Rest to factory setting
Flashfast Process SMS command

SimPal
-
T40/T20
POWER SOCKET USER MANUAL
2.1Userauthorizationlevel
Socket settings canbe setor adjustedviaaSMScommand.
Therearetwomobilephoneuser controlling levels:
Master-user(“Master”):
Onlyone Master hasauthorization touseall featuresof SimPal-T4.
Inordertoenableall thefunctionsonthesocket, the Master muststorehis/her mobile
numberinthesockets memory.Onlyone Master s mobilenumberis allowedfor asocket.
Family users(“Family”):
Therearefour families haveauthorizationtousecommandsofswitchonorcutoffthe
socket output, checksocket temperaturevalue or receivepowerstatuschangealert.
Theothermobilephoneusers haveno authorization tocontrolthesocket.

SimPal
-
T40/T20
POWER SOCKET USER MANUAL
2.2About the SMSCommand
•SMScommand format: #code#content#.
•The maximumdigits thatare allowsforthe phonenumberis sixteen.
•SimPal-T40 will replytotheuserafteritreceivestheSMScommand.
%Note
•The “#”symbol must notbe ignoredwhen typinganSMScommand.
•Noallowanyspacewithinthecommands.
3.1Start touse
§Installed SIMcard toSimPal-T40GSMpower socket; youwill see aSIMcard slotatthe
side,maketheSIMcardmetalcontact upside and hardlypushtheSIMcard until SIMcard
fixed.
§Insert the temperature sensor intotheI/O portuntilit is seized.

SimPal
-
T40/T20
POWER SOCKET USER MANUAL
Power on:
1. Plug the SimPal-T40 inanAC powersocket.
The GSMLED will beflashingslowly forabout15seconds,andturntoslowlybreathestatus,
breatheLED means the socketalready registerGSMnetwork, its readytoworking.
The socket default poweroutput is OFF.
2. Insert the plugof electronicapplianceintheSimPal-T40electricaloutlet.
3.Mbutton (See 5onFigure1) can be pressed for aboutonesecondtoswitchon oroff the
socket output.
After adding usernumberstothe socket, userscansend SMScommand tocontrolthe
powersupplyoutput.
%Note:
1.IftheGSMindicatorlightisflashslowlyall thetime,whichimplytheSIM card
working abnormally,allfunctionsofthissocketareinvalid.
2.CheckGSMnetwork signaloftheusing place:
•GSMnetworkssignalstrengthmayaffectthesocketfeature.Therefore,before

SimPal
-
T40/T20
POWER SOCKET USER MANUAL
using,theusershouldensurethatSimPal-T40isusedinanarea withastrong
GSM networksignal.
•For thefirsttimeuse,theusershouldperformatest-runbysendingSMStothe
socket. Thisallowstheusertocheck theGSMnetworkconnectionof thesocket.
3.2.1RegisterMaster-number.
Sending followingSMStosocket SIMcardnumberfromyour mobilephone(thephone number
will be the Master number):
RegisterMaster-numberonthesocket:#00# (1)

SimPal
-
T40/T20
POWER SOCKET USER MANUAL
3.2.2Change Masternumber
Master sends following SMSmessageinorderto:
Changemaster-number: #14#NewMasterNumber (2)
•NewMasterNumber shouldbethe newMastermobilephone number.
3.3.1Register Family-number
Upto4Family-number canbestored onGSMsocket.
Family-number havetheauthoritytosendSMScommandto switchonorcutoffthe
SimPal-T40 orSimPal-T20poweroutput.
ÌMethod
Master sends following SMSmessageinorderto:
RegisteraFamily: #06#Family-Number#(3)
•Family-Number shouldbethe User smobilephone number.

SimPal
-
T40/T20
POWER SOCKET USER MANUAL
3.3.2CheckFamilynumber
Master sendingSMStocheckFamilynumber:#06# (4)
3.3.3DeleteFamily
ÌMethod
Master sends following SMSmessageinorderto:
Delete aFamily: #15#Family-Number #(5)
Delete allFamiles: #15# (6)
3.4Pairingslavesocket
Master sendsSMStoparing slavesocketT20 withT40 GSMsocket, beforeparing,need to
makesureT20resetfactorysetting,iftheT20alreadypairedwith otherT40before,needto
keep press T20 Mbutton for5secondstoresettheT20tofactorysetting.Sendingfollowing
SMSmessageto
GSM
socket inorder to:
