Simplified MFG RSP1:2 User manual

RSP1:2
UHD 1x2 HDMI Splitter

1
User manual
Thank you for purchasing this device
The Simplified MFG RSP1:2 is designed to provide years of reliable service. At
Simplified MFG, we want the experience with this device to be the best possible and are
committed to helping achieve that experience.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged
by electrical spikes, surges, electric shock, lightning strikes, etc. Use of surge
protection such as the HDSURGE and other systems is highly recommended
to protect and extend the life of your equipment.

2
Introduction
The RSP1:2 is 1 by 2 HDMI 18gbps UHD Splitter with HDCP 2.2 is an advanced solution for splitting a
single HDMI input to two HDMI outputs. It provides high performance audio and video output through
HDMI cables up to 4K2K@60Hz (YUV444) resolution and is capable of receiving and transmitting up to
18Gbps of bandwidth with no data loss. Supporting the latest features of the most advanced HDMI 2.0b
signals
II. Features
1. Compliant with HDMI2.0, HDCP2.2 and DVI 1.0;
2. Supports video formats up to 4k2k@30Hz with 24bit RGB/YcbCR 4:4:4/YCBCR 4:2:2,
and up to 4k2k@60Hz with 12bit YCBCR 4:4:4;
3. Supports high resolution VESA mode video format up to QSXGA@60Hz;
4. Supports LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master Audio;

3
5. Supports smart EDID control;
III. Contents
1. UHD 1x2 HDMI Splitter ------------------------------------------------------------------ 1PC
2. 5V1A DC Power adapter ----------------------------------------------------------------- 1PC
3. Operation Manual ------------------------------------------------------------------------- 1PC
IV. Specifications
1. Video Bandwidth 600MHz/18Gbps
2. Input Ports 1 × HDMI (Female type)
3. Output Ports 2 × HDMI (Female type),
4. Output Resolution 480i ~1080p50/60, 4Kx2K@24/30, 4k2k@60Hz
5. ESD Protection Human Body model: ±8 kV (air-gap discharge)
±4 kV (contact discharge)
8. Power Supply 5V/1A DC (US/EU standards, CE/FCC/UL certified)

4
9. Dimensions 56 mm (W) × 100 mm (D) × 16 mm (H)
10. Weight 165 g
11. Chassis Material Metal
12. Operating Temperature 0 °C~40 °C/ 32 °F~104 °F
13. Storage Temperature −20 °C ~ 60 °C/−4 °F ~140 °F
14. Relative Humidity 20~90 % RH (non-condensing)
15. Power Consumption (Max) 5W
V. Operation controls and Functions
Front Panel & Rear Panel

5
1. POWER LED: This red LED illuminate when the device is connected to power supply.
2. OUT LED: These blue LEDs will light up to indicate which HDMI outputs are connected
to an active TV/display/monitor.
3. IN LED: This blue LED illuminate when the Source connected to the device.

6
4. EDID STD: When in 'STD' mode, the unit will use its own built-in EDID settings. In this
mode, the video output will be set to 1080p@60Hz and the audio output at LPCM 2CH
Stereo. Use this mode if there are display problems in TV Mode.
5. EDID TV: When in 'TV' mode, the unit will read the EDID settings of the display device
connected to HDMI OUT 1. If it detects a 4K2K capable EDID setting it will transmit the
signal in that format to all outputs. If no 4K2K capable EDID is detected then the unit
will output the best resolution that all displays can support.
6. HDMI OUT 1~2: Connect each of the HDMI outputs to an HDMI display for simultaneous
HDMI distribution, or cascade the output to another transmitter to extend the operating
distance.
7. HDMI IN: Connect the input port to the HDMI or DVI output of your source device such
as a DVD player or set-top box with an HDMI cable.
8. DC 5V: Plug the 5V DC power supply into the unit and connected the adaptor to an AC

7
outlet.
VI. Application Example

8
Warranty
Should you feel your product does not function adequately due to defects in materials or
workmanship, we (referred to as “the warrantor”) will, for the length of the period indicated
below (starting from the original date of purchase) either: a) Repair the product with new or
refurbished parts. or b) Replace it with a new or refurbished product.
All Simplified MFG products are covered by a 3 year PARTS and LABOR warranty. During this
period there will be no charge for unit repair, replacement of unit components or replacement
of product if necessary. The decision to repair or replace will be made by the warrantor. The
purchaser must mail-in the product during the warranty period. This limited warranty only covers the
product purchased as new and is extended to the original purchaser only. It is non-transferable to

9
subsequent owners, even during the warranty period. A purchase receipt or other proof of
original purchase date is required for the limited warranty service.
1. This Limited Warranty ONLY COVERS failures due to defects in materials or
workmanship and DOES NOT COVER normal wear and tear or cosmetic damage.
The limited warranty also DOES NOT COVER damage that occurs in shipment or
failures caused by products not supplied by the warrantor, failures resulting from
accident, misuse, abuse, neglect, mishandling, misapplication, alteration, incorrect
installation, set-up adjustment, implementation of/to consumer controls, improper
maintenance, power line surge, lightening damage, modification, service by
anyone other than a manufacturer-approved service center or factory authorized
personnel, or damage attributable to acts of God.

10
2. There are no express warranties except as listed under “limited warranty
coverage.” The warrantor is not liable for incidental or consequential damage
resulting from the use of this product or arising out of any breach of this
warranty. For example: damages for lost time, the cost of having a
person/persons remove or re-install previously installed equipment, travel to and
from service location, loss of or damage to media, images, data or other
recorded/stored content. The items listed here are not exclusive, but are for
illustration only. Parts and service not covered by this limited warranty are not the
responsibility of the warrantor and should be considered the responsibility of the
individual.

11
Simplified MFG Publication Disclaimer
The material contained in this document consists of information that is the sole property of
Simplified MFG. This document is intended to provide information to allow interfacing to the
relevant Simplified MFG equipment by third party products. Simplified MFG IS NOT
RESPONSIBLE FOR MALFUNCTIONS AND/OR THE IN-OPERABILITY WHICH MAY BE CAUSED
BY THE APPLICATION OF THIS INFORMATION, WHETHER EXPECTED OR NOT. Simplified
MFG reserves the right to change software, control codes and specifications without notice.
Simplified MFG will not be liable for any use of this information or any changes it may make to
those products. The use of this information constitutes an agreement by the user to these
limitations and exclusions.

12
Contact
Sales and Tech Support
P 1-833-HDMI-411
E [email protected]

Simplified MFG • 550 W Baseline Road Ste 102-121 • Mesa, AZ 85210 • www.simplifiedmfg.com • 833-HDMI-411 (436-4411)
RSP1:2 Quick Start Guide
• The RSP1:2 is a HDMI 2.0b (18Gbps) 4K
splitter that takes one input and splits it to
two outputs.
• The RSP1:2 copies the EDID of output 1 and
shows that EDID to the source, unless the
EDID switch is set to “Std” which will
override the displays EDID request and
show the source a 1080p EDID
• The RSP1:2 is compact and good for fixing
clock issues, EDID, and as a splitter
HDMI SourceHDMI Source
4K Display
4K Display
HDMI
HDMI
HDMI

RSP1:2
HDMI 2.0b (18Gbps) 1:2 Splitter
• Supports the entire HDMI 2.0b
format
• Supports all Digital audio formats
• EDID copy feature (Output 1)
• EDID override for troubleshooting
or to supply needed 1080p EDID
• Compact size
• 3-Year Warranty
833-HDMI–411 (436-4411) • www.simplifiedmfg.com • 550 W Baseline Rd., Ste #102-121 • Mesa, AZ 85210
Specifications:
The RSP1:2 is a HDMI 2.0b (18Gbps)
HDMI splitter device. The RSP1:2
has 1 HDMI Input and 2 HDMI Out-
puts. The EDID is preset to copy the
EDID of OUTPUT 1. By switching dis-
plays on the outputs, EDID shown to
the source can be manipulated.
There is an EDID switch that over-
rides the display’s request and is set
to 1080p
Features:
Technical
HDMI
Compliance HDMI 2.0b
HDCP
Compliance HDCP 2.2/HDCP 1.4
Video Bandwidth (600MHz/18Gbps)
Video
Resolutions Up to 4K2K @50/60Hz. (YUV4:4:4), 4K 30Hz., & 1080p @ 60Hz.
Color Space RGB, YCbCr 4:4:4, YCbCr 4:2:2
Color Depth 8 Bit, 10-Bit, 12 Bit
HDMI Audio
Formats
(Pass-Through)
LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digi-
tal+, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos,
DTS:X
ESD Protection Human body model — ±8kV (air-gap discharge) & ±4kV
(contact discharge)
Connections
Inputs
1x HDMI Type A [19-pin female]
Outputs
2x HDMI Type A [19-pin female]
DC Power 1x 5V Screw Down connector
Mechanical
Housing Metal Enclosure
Color Black
Dimensions 100mm [W] x 56mm [D] x 16mm [H] 4”x 2.2” x .63”
Weight 165g /5.8 Oz.
Power Supply
Input: AC100 - 240V 50/60Hz
Output: DC 5V/1A (US/EU standards, CE/FCC/UL certi-
fied)
Power
Consumption 5W (Max)
Operation
Temperature 32 - 104°F / 0 - 40°C
Storage
Temperature -4 - 140°F / -20 - 60°C
Relative
Humidity 20 - 90% RH (no condensation)
