Instruction ManualM2600 / M2605

I
This household sewing machine is designed to comply with IEC/EN/CSA C22.2 No. 60335-1 &
60335-2-28 and UL1594.
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using this household sewing machine.
When using an electrical appliance, basic safety precautions should always be followed,
including the following:
Keep the instructions at a suitable place close to the machine. Make sure to hand them over if
the machine is given to a third party.
This appliance is intended for use by adults. The appliance can be used with adult supervision by
(i) children aged from 8 to 12 years and (ii) persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given instruction concerning
use of the appliance in a safe way and understand the hazards involved. Cleaning and user
maintenance shall not be made by children without supervision. It is not allowed for anyone to
playwith the machine. Children up to 8 years are not allowed to use the machine.
WARNING – To reduce the risk of burns, re, electric shock,
or injury to person:
- A sewing machine should never be left unattended when plugged in. The electrical socket,

II
to which the machine is plugged in should be easily accessible. Always unplug this sewing
machine from the electric outlet immediately after using and before cleaning, removing
covers, lubricating or when making any other user servicing adjustments mentioned in the
instruction manual.
- Do not allow to be used as a toy. Close attention is necessary when this sewing machine is
used by or near children.
- Use this sewing machine only for its intended use as described in this manual. Use only
attachments recommended by the manufacturer as contained in this manual.
- Never operate this sewing machine if it has a damaged cord or plug, if it is not working
properly, if it has been dropped or damaged, or dropped into water. Return the sewing
machine to the nearest authorized dealer or service center for examination, repair, electrical
or mechanical adjustment.
- Never operate the sewing machine with any air openings blocked. Keep ventilation openings
of the sewing machine and foot control free from the accumulation of lint, dust, and loose
cloth.
- Keep ngers away from all moving parts. Special care is required around the sewing machine
needle.
- Always use the proper needle plate. The wrong plate can cause the needle to break.
- Do not use bent needles.
- Do not pull or push fabric while stitching. It may deect the needle causing it to break.
- Wear safety glasses.

III
- Switch the sewing machine o󰀨 (“0”) when making any adjustment in the needle area, such as
threading needle, changing needle, threading bobbin, or changing presser foot, etc.
- Never drop or insert any object into any opening.
- Do not use outdoors.
- Do not operate where aerosol (spray) products are being used or where oxygen is being
administrated.
- To disconnect, turn all controls to the o󰀨 (“0”) position, then remove plug from outlet.
- Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
- The foot control is used to operate the machine. Never place other objects on the foot control.
- Do not use the machine if it is wet.
- If the LED lamp is damaged or broken, it must be replaced by the manufacturer or its service
agent or a similarly qualied person, in order to avoid a hazard.
- If the cord connected with the foot control is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualied person, in order to avoid a hazard.
SAVE THESE INSTRUCTIONS

IV
The noise level under normal operating conditions is less than 75dB(A).
The machine must only be used with foot control of type
KD-1902, FC-1902.FC-1902A (110-120V) / KD-2902, FC-2902A, FC-2902C, FC-2902D, (220-
240V) manufactured by Zhejiang Founder Motor Corporation, LTD. (Vietnam)
4C-316B (110-125V) / 4C-316C (127V) /4C-326C (220V) / 4C-326G (230V) / 4C-336G (240V)
4C-315A(100V)/4C-326C (220V~240)/ 4C-336G (220-240V) manufactured by Wakaho Electric
Ind. Co., Ltd. (Vietnam).

V
List of contents
Machine Basics
Principal Parts of the Machine ..................................................................................................................................................1
Connecting Machine to Power Source......................................................................................................................................3
Two Step Presser Foot Lifter.....................................................................................................................................................4
Adjusting Presser Foot Pressure ..............................................................................................................................................4
Accessories...............................................................................................................................................................................5
Threading the Machine
Winding the Bobbin ...................................................................................................................................................................6
Inserting the Bobbin ..................................................................................................................................................................7
Thread Tension..........................................................................................................................................................................8
Threading the Upper Thread.....................................................................................................................................................9
Automatic Needle Threader ....................................................................................................................................................10
Raising the Bobbin Thread......................................................................................................................................................11
Sewing
How to Choose Your Pattern ..................................................................................................................................................12
Stitch Length Dial ...................................................................................................................................................................13
Sewing Straight Stitch .............................................................................................................................................................14
Reverse Sewing ......................................................................................................................................................................15
Removing the Work.................................................................................................................................................................15
Cutting the Thread...................................................................................................................................................................15
Choosing Stretch Stitch Patterns ............................................................................................................................................16
Blind Hem................................................................................................................................................................................17
Buttonholes .............................................................................................................................................................................18
Sewing on Buttons ..................................................................................................................................................................19
Zippers and Piping ..................................................................................................................................................................20
General Information
Installing the Removable Extension Table ..............................................................................................................................21
Changing the Presser Foot .....................................................................................................................................................22
Needle/ Fabric/ Thread Chart .................................................................................................................................................23
Darning Plate...........................................................................................................................................................................24
Maintenance and Troubleshooting
Inserting the Needle ................................................................................................................................................................25
Maintenance............................................................................................................................................................................26
Troubleshooting Guide ............................................................................................................................................................27

11
1. Thread tension dial
2. Presser foot pressure adjustment
3. Thread take-up lever
4. Thread cutter
5. Presser foot
6. Needle plate
7. Removable extension table/ accessory storage
8. Reverse sewing lever
9. Bobbin winding stopper
10. Stitch length dial
11. Pattern selector dial
12. Needle threader
Unpacking
- Place the box on a steady, at surface. Lift your machine
out of the box and remove the outer packaging.
- Remove all other packing material and the plastic bag.
10
11
12
Principal Parts of the Machine
Machine Basics

2
Principal Parts of the Machine
1. Horizontal spool pin
2. Bobbin winder spindle
3. Hole for auxiliary spool pin
4. Handwheel
5. Power and light switch
6. Main plug socket
7. Bobbin thread guide
8. Upper thread guide
9. Face plate
10. Handle
11. Presser foot lifter
12. Foot speed control
13. Power cord

3
Connect the machine to a power source as illustrated. (1)
This appliance is equipped with a polarized plug which must
be used with the appropriate polarized outlet. (2)
Attention:
Unplug power cord when machine is not in use.
Foot control
The foot control pedal regulates the sewing speed. (3)
Attention:
Consult a qualied electrician if in doubt of how to connect
machine to power source.
Sewing light
Press main switch (A) to “ l “ for power and light.
IMPORTANT NOTICE
For appliance with a polarized plug (one blade is wider
than the other). To reduce the risk of electric shock, this
plug is intended to t in a polarized outlet only one way. If
it does not t fully in the outlet, reverse the plug. If it still
does not t, contact a qualied electrician to install the
proper outlet. Do not modify the plug in any way.
a. Polarized attachment plug
b. Conductor intended to be grounded
Connecting Machine to Power Source

4
When sewing several layers or thick fabrics, the presser foot
can be raised to a higher position for easy positioning of the
work. (A)
Attention:
Your SINGER®machine is adjusted to provide the best
stitch result at normal room temperature. Extreme hot and
cold temperatures can a󰀨ect the sewn result.
Two Step Presser Foot Lifter
The presser foot pressure of the machine has been pre-set
and requires no particular readjustment according to the type
of fabric (light-or-heavy weight).
However, if you need to adjust the presser foot pressure, you
may turn the presser adjusting screw with a coin.
For sewing very thin fabric, loosen the pressure by turning
the screw counter counterclockwise, and for heavy fabric,
tighten by turning it clockwise.
Adjusting Presser Foot Pressure

5
Standard accessories
a. All purpose foot
b. Zipper foot
c. Buttonhole foot
d. Button sewing foot
e. L-screwdriver
f. Seam ripper/ brush
g. Pack of needles
h. SINGER®Class 15 bobbins (4x)
i. Edge/ quilting guide
j. Darning plate
k. Spool holder
l. Soft cover
Optional Accessories:
For information about additional presser feet, attachments
and accessories that may be available for your machine, visit
www.singer.com
Accessories
a b c d
f
jl
e
ki
hg

6
Winding the Bobbin
- Place thread and corresponding spool holder on to spool
pin. (1/2)
- Snap thread into thread guide. (3)
- Wind thread clockwise around bobbin winder tension
discs. (4)
- Thread bobbin as illustrated and place on spindle. (5)
- Push bobbin spindle to right. (6)
- Hold thread end. (7)
- Step on foot control pedal. (8)
- Release the pedal after a few turns. Release the thread
and cut as close as possible to the spool. Press the pedal
again. Once the spool is full, it rotates slowly. Release the
pedal and cut thread. (9)
- Push bobbin spindle to left (10) and remove.
Please Note:
When the bobbin winder spindle is in “bobbin winding”
position, the machine will not sew and the hand wheel will
not turn. To start sewing, push the bobbin winder spindle
to the left (sewing position).

7
When inserting or removing the bobbin, the needle must
be fully raised.
- Open the hinged cover. (1)
- Pull the bobbin case tab (a) and remove the bobbin case.
(2)
- Hold the bobbin case with one hand. Insert the bobbin so
that the thread runs in a clockwise direction (arrow). (3)
- Pull the thread through the slit and under the nger. Leave
a 6 inch tail of thread. (4)
- Hold the bobbin case by the hinged latch. (5)
- Insert it into the shuttle. (6)
Attention:
Turn power switch to o󰀨 (“O”) before inserting or removing
the bobbin.
Inserting the Bobbin

8
Upper thread tension
Basic thread tension setting: “4”.
To increase the tension, turn the dial to the next number up.
To reduce the tension, turn the dial to the next number down.
1. Normal thread tension for straight stitch sewing.
2. Thread tension too loose for straight stitch sewing. Turn
dial to higher number.
3. Thread tension too tight for straight stitch sewing. Turn
dial to lower number.
4. Normal thread tension for zig zag and decorative sewing.
Correct thread tension is when a small amount of the
upper thread appears on the bottom side of fabric.
Lower thread tension
The bobbin tension has been set correctly at the factory, so
you do not need to adjust it.
Please note:
- Proper setting of tension is important to good sewing.
- There is no single tension setting appropriate for all stitch
functions, thread or fabric.
- A balanced tension (identical stitches both top and bottom)
is usually only desirable for straight stitch construction
sewing.
- 90% of all sewing will be between ”3” and ”5”.
- For zig zag and decorative sewing stitch functions, thread
tension should generally be less than for straight stitch
sewing.
- For all decorative sewing you will always obtain a nicer
stitch and less fabric puckering when the upper thread
appears on the bottom side of your fabric.
Thread Tension

9
This is a simple operation but it is important to carry out
correctly as by not doing so several sewing problems could
result.
- Raise the needle to its highest position by turning the
handwheel towards you (counterclockwise) so that the
mark on the handwheel points directly up. Raise the
presser foot to release the tension discs. (1)
Note: For safety, it is strongly suggested you turn o󰀨 the
power before threading.
- Lift up the spool pin. Place the spool of thread on the
holder with the thread coming o󰀨 the spool as shown. For
small thread spools, place small side of spool holder next
to spool.(2)
- Draw thread from spool through the upper thread guide (3)
and pulling thread through pre-tension spring as illustrated.
(4)
- Thread tension module by leading thread down right
channel and up left channel. (5) During this process it is
helpful to hold the thread between the spool and thread
guide.
- At the top of this movement pass thread from right to
left through the slotted eye of the take-up lever and then
downwards again. (6)
- Now pass thread behind the thin wire needle clamp guide
(7) and then down to the needle which should be threaded
from front to back.
- Pull about 6-8 inches of thread to the rear beyond the
needle eye. Trim thread to length with built in thread cutter.
(8)
Threading the Upper Thread

10
- Raise the needle to its highest position.
- Pass thread around thread guide (A). (1)
- Press lever (B) down as far as it will go. (2)
- The threader automatically swings to the threading
position (C).
- Pass the thread in front of the needle around the hook (D)
from bottom to top.
- Release lever (B). (3)
- Pull the thread through the needle eye.
Attention:
Turn power switch to o󰀨 (“O”)!
Automatic Needle Threader

11
Hold the upper thread with the left hand. (1)
Turn the handwheel towards you (counterclockwise) lowering,
then raising needle.
Note:
If it is di󰀩cult to raise the bobbin thread, check to make
sure the thread is not trapped by the hinged cover or the
Removable Extension Table.
Raising the Bobbin Thread
Gently pull on the upper thread to bring the bobbin thread up
through the needle plate hole. (2)
Lay both threads to the back under the presser foot. (3)

12
To select a stitch, simply turn the pattern selector dial. The
pattern selector dial may be turned in either direction.
For straight stitch, select pattern " " with the pattern
selector dial.
For zigzag stitch, select pattern " " with the pattern
selector dial.
To obtain the other patterns, turn the stitch length dial to "S1",
select the pattern desired with pattern selector dial.
a. Reverse Sewing Lever
b. Stitch Length Dial
c. Pattern Selector Dial
How to Choose Your Pattern
Sewing
c

13
Function of stitch length dial for when straight stitching
For straight stitch sewing, turn the Pattern Selector Dial to
the straight stitch setting. (1)
Turn the Stitch Length Dial, and the length of the individual
stitches will decrease as the dial approaches "0". The length
of the individual stitches will increase as the dial approaches
"4". (2)
Generally speaking, use a longer stitch length when sewing
heavier weight fabrics or when using a thicker needle or
thread. Use a shorter stitch length when sewing lighter weight
fabrics or when using a ner needle or thread.
Function of stitch length dial while zig-zag stitching
Turn the Pattern Selector Dial to " " . (3)
The density of zig-zag stitches increases as the setting of
stitch length dial approaches "0".
Neat zig-zag stitches are usually achieved at "2.5" or below.
Dense zig-zag stitches are called satin stitches. (4)
Stitch Length Dial
