Singer QUANTUM QUILTER 7350 Operation instructions

RIBBING APPLICATION
ELASTIC APPLICATION
NARROW CASING
BLINDHEM
BARTACK BUTTONHOLE
BUTTON SEWING-ATTACHING A BUTTON
COUCHING I
COUCHING II
SCALLOPED EDGE
BOBBIN WORK
SHELLEDGING
WING NEEDLE WORK
ROLLED AND WHIPPED EDGE
LACE INSERTION
TWIN NEEDLE PINTUCKS
FAGOTING
FAUX TATTED/CROCHETED EDGING
APPLIQUE WITH BLANKET STITCH
APPLIQUE WITH BLINDHEM STITCH
CRAZY QUILTING
CREATE TRIPLE STRAIGHT STITCH
BLANKET STITCH EDGING
NOTE: “QQ” will appear when the technique or
step applies only to the Quantum Quilter.

1
RIBBING APPLICATION
The Overedge Stretch Stitch joins and finishes stretch seams in one step.
This is ideal for applying ribbing in T-shirts and sweatshirts.
Machine Setup
Stitch: Overedge Stretch Stitch P
Presser Foot: Overcasting Foot E
Stitch Length: S
Stitch Width: 6 or 7
Needle: Yellow Band 90/14
Materials
Medium to heavy weight knit fabric - 6” x 6” square
Ribbing - 3” x 6”
Procedure
Cut a curve in the knit fabric to resemble a neckline.
Fold ribbing in half lengthwise.
Starting at the left side of the knit curve, place ribbing on front side of curve.
Match all 3 cut edges and place under the foot.
Line up fabric edges with quide on foot E and stitch the length of the seam.
Stretch ribbing slightly to fit the cut edge of the knit.
When finished, lift foot and pull threads and fabric straight back behind foot and
trim.
NOTE:
The overdege stretch stitch makes sewing seams in knits look as though
they were finished on a serger. This stitch is stronger and more
durable than overlock stitching.

2
ELASTIC APPLICATION
Using stitches with built-in stretch, elastic can be applied directly to the fabric
without having thread breakage when stretching the elastic.
Machine Setup
Stitch: Multi-Zigzag Stitch F (for sample)
Honeycomb Stitch F
Presser Foot: General Purpose Foot C
Stitch Length: 1.5
Stitch Width: 7
Needle: Yellow Band 90/14
Materials
Nylon Tricot 4” x 8”
3/8” wide elastic - 7” strip
Procedure
Position elastic on fabric, end of elastic extending slightly beyond side of fabric,
and keep elastic even with 5/8” seam line.
Hold elastic in front of and behind foot, and stretch slightly while sewing.
Trim top of fabric even with top edge of elastic.
Draw a line 5/8” away from top edge of tricot wrong side.
Position one end of elastic slightly off drawn line on tricot.
Lower presser foot and press needle up/down button to hold elastic in place
(QQ). [For 7350, manually lower needle into elastic.]
Start stitching and hold elastic separately while stitching down center of elastic,
pull slightly on elastic to create gathering.
Trim 5/8” edge flush with elastic edge.

3
NARROW CASING
Create a narrow casing for application of narrow ribbons, braids or elastic with the
Closed Zigzag Stitch, Zigzag Stitch, or Blanket Stitch.
Machine Setup
Stitch: Closed Zigzag Stitch E (for sample)
Zigzag Stitch (alternative)
Blanket Stitch (alternative)
Presser Foot: General Purpose Foot C
Stitch Length: S
Stitch Width: 5
Materials
Batiste or other medium to lightweight base fabric
1/8” wide ribbon
Procedure
Position ribbon end on right side of fabric.
Stitch over the ribbon using the Closed Zigzag Stitch, being careful that the
needle does not penetrate the ribbon on either edge.
Note:
Substitute narrow elastic for ribbon to make easy casings. Elastic can be easily
adjusted to fit area. Perfect for gathered areas on children’s clothes.

4
BLINDHEM
Provides a fast way to finish hems securely.
Machine Setup 1 (for raw edge finish)
Stitch: Zigzag Stitch B
Presser Foot: Overcast Foot E
Stitch Length: 1.0
Stitch Width: 5
Needle: Red Band 80/11
Machine Setup 2 (to baste the fold)
Stitch: Straight Stitch A
Presser Foot: General Purpose C
Stitch Length: 4
Stitch Width: 0 (Center Needle Position)
Tension Dial: 2
Machine Setup 3 (to create the hem)
Stitch: Blindhem Stitch C
Presser Foot: Blindhem Foot F
Stitch Length: 2.5-3.5
Stitch Width: 3.4
Tension Dial: 2
Materials
Medium weight linen or shirting-type fabric
60-80 weight thread
Procedure
Fold under 1” and baste in place.
Position sample with wrong side facing up, and turn the hem back to the right
side, creating a soft fold at the top edge of the hem. The bulk of the fabric is to
the left of the foot.
Begin stitching – making sure the forward stitches fall near the ¼” fold, and the
needle swing just bites into the fold, catching only 2 or 3 threads.
Note:
Use stitch D for hemming fabrics with light stretch.

5
BARTACK BUTTONHOLE
Provides a sturdy utilitarian buttonhole.
Machine Setup
Stitch: Buttonhole Stitch
Presser Foot: Buttonhole Foot
Stitch Length: 0-1 Buttonhole Symbol
Stitch Width: 5 (adjust to personal preference)
Materials
Shirting fabric
Button to establish length of buttonholes
Interfacing or tear-away stabilizer
Procedure
Place button in buttonhole foot to establish length.
Fold fabric in half crosswise, with interfacing between layers.
Place fabric under the foot in marked location.
Lower presser foot.
Lower Buttonhole Lever, and press toward back.
Begin sewing buttonhole.
Note:
Reset foot after each buttonhole by pushing the buttonhole lever toward
the back of the machine.

6
BUTTON SEWING - ATTACHING A 2 OR 4 HOLE BUTTON
Easily attaches buttons using the basic Zigzag Stitch.
Machine Setup
Stitch: Zigzag Stitch B
Presser Foot: Button Sewing Foot
Stitch Width: Determined by button (usually 3mm)
Feed Dogs: Down Position
Materials
Shirting
One 2-hole button
Procedure
Fold fabric in half and place under foot.
Position the button on the fabric so that the holes in the button are between the
toes of the foot.
Lower the presser foot to hold the button in place.
Turn the hand wheel towards front of machine and into the right or left hole.
Adjust the stitch width dial to fine tune the swing of the needle into the other
hole.
Recheck the swing of the needle into the other hole and then use foot control to
stitch 5-6 stitches.
Before removing the button and fabric from the machine, dial to straight stitch.
Leave width at current setting and stitch in place for three stitches. This forms a
tie-off on the back side to secure button.
Apply a liquid fray-preventer on the backside of fabric on the knots. Trim
threads after they dry, being careful not to cut thread knots.
Note:
- Remember to raise the feed dogs. Use the needle up/down button twice to
bring up feed dogs easily (QQ).
- You can also use the button sewing foot for attaching curtain rings, snaps and
hook and eye closures.

7
COUCHING I
Couching is the process of applying cords, pearls, braids, ribbons, or other trims
to the right side of the fabric.
Machine Setup
Stitch: Zigzag B or Decorative Stitch E
Presser Foot: General Purpose Foot C
Stitch Length: 3 or 4
Stitch Width: Adjust according to trim width
Material
Monofilament Thread
String Pearls
Felt or Stabilized Woven Fabric
Procedure
Lay pearls or other couching trim on top of fabric.
Stitch, adjusting width to ensure the stitch slightly encases trim.

8
COUCHING II
Machine Setup
Stitch: H
Presser Foot: General Purpose Foot C
Stitch Length: 4
Stitch Width: 7
Material
Felt or Stabilized Fabric
2 strands 1/8” wide ribbon (satin or grosgrain works best)
Decorative thread to coordinate or contrast with ribbon
Procedure
Lay ribbon, braid, or other trim on fabric.
Stitch ribbon in place, taking care to avoid piercing the trim with the needle.

9
SCALLOPED EDGE
This delicate scallop stitch creates a beautiful, delicate edging for dresses,
blouses, lingerie and children’s clothing.
Machine Setup
Stitch: Scallop Stitch N
Presser Foot: General Purpose Foot C
Stitch Length: 0-1 Buttonhole Symbol
Stitch Width: 7
Materials
Light weight fabric, such as batiste
Rinse-away stabilizer
30 weight decorative thread
Procedure
Fold fabric in half.
Place stabilizer under fold, extending 1” beyond fabric edge.
Stitch a row of scallops. Align center of foot on folded edge.
Trim away excess stabilizer, then rinse with water to remove remaining
stabilizer.
stabilizer

10
BOBBIN WORK
Threads, ribbons or fine trims that are too large for the eye of the needle can be
placed in the bobbin. Wind the thread, ribbon or trim onto the bobbin and sew
with fabric’s wrong side face up. The ribbon will stitch on fabric’s right side,
creating a bold, textured effect to projects.
Machine Setup
Stitch: Double Reinforced Blanket Stitch H (for sample)
Stitch I (alternative)
Stitch Q (alternative)
(Any open stitch that does not have too
much forward/reverse or side-to-side
movement works well.)
Presser Foot: General Purpose Foot C
Stitch Length: 3
Stitch Width: 7
Materials
Felt or Stabilized Fabric (for sample)
2mm Silk Ribbon
Procedure
Hand-wind ribbon onto bobbin, insert bobbin into the machine.
Place matching thread through the needle.
With wrong side of the fabric facing up, stitch a row of stitch H.
Stop with the needle in the far right position, with the needle down.
Pivot the work and stitch in the opposite direction, aligning the
stitches so that they meet the previous row in the center.
Note:
- Use this technique to create textured effects for use in crazy quilts.
- Experiment with other stitches.

11
SHELL EDGING
This stitch provides a delicate decorative edging on stretch or lingerie fabrics.
Machine Setup
Stitch: Overedge Stitch
Presser Foot: General Purpose Foot C
Stitch Length: 2
Stitch Width: 4
Materials
Nylon Tricot 5” x 8”
Procedure
Fold fabric up 1” in on the long edge of the fabric.
Sew a row of stitching, allowing the needle to slightly fall off the fold when it
swings to the right.
Trim excess fabric 1/4” away from straight edges.
Note:
This stitch also works well on lightweight woven fabrics cut on the bias.

12
WING NEEDLE WORK
Wonderful effects can be created by simply stitching geometric shapes, straight
lines, cross-hatching, etc., with a wing needle. This is an unique embellishment
for ready-to-wear garments, such as a linen blouse, lingerie or special occasion
gowns.
Machine Setup
Stitch: Feather Stitch G
Presser Foot: General Purpose Foot C
Needle: Wing Needle
Stitch Length: S
Stitch Width: 4-7
Note:
Do not use built-in needle threader with wing needle in machine.
Materials
Linen or other natural fiber fabric – spray starched for added firmness
60-80 weight white sewing thread
60-80 weight white sewing thread in bobbin
Procedure
Trace a design onto fabric using chalk, water-soluble or air-soluble
marker. (use stencils, templates or create a design)
Stitch along the drawn lines of the design.
Note:
For best results in wing needle stitching, the stitch needs forward-back movement,
so that the needle penetrates the same hole more than once. By reducing the
width of the feather stitch to zero, this action is accomplished, and the desired
holes will remain in the fabric.

13
ROLLED AND WHIPPED EDGE
This is an heirloom sewing technique, in which a small amount of fabric is rolled to
finish the edge of fine fabrics, also making the edge more durable.
Machine Setup
Stitch: Zigzag Stitch B
Presser Foot: General Purpose Foot C
Stitch Length: 1
Stitch Width: 3
Needle: Red Band 80/11
Materials
Batiste
Flat cotton lace
60-80 weight cotton embroidery thread
Procedure
Starch lace on both sides.
Place lace on fabric, right sides together. Fabric should extend 1/8” beyond
lace.
Set width of the zigzag so the left swing of the needle stitches into the lace
header, and the right swing extends over the fabric edge.
The fabric will roll up as the needle swings back to the left.
Note:
Upper tension may need to be reduced.
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

14
LACE INSERTION
Stitch the lace on top of the fabric, then trim fabric away from underneath to
create a beautiful heirloom lace insertion.
Machine Setup
Stitch: Zigzag Stitch B
Presser Foot: General Purpose Foot C
Stitch Length: 1.0
Stitch Width: 2.0-2.5
Needle: Red Band 80/11
Note:
Adjust width as desired.
Materials
Batiste
Strip of lace
60-80 weight fine cotton thread
Procedure
Starch lace and batiste.
Center lace right side up lengthwise on batiste.
Stitch lace to fabric by sewing a zigzag stitch down edges of lace. Try to just
clear the heading on the lace.
Carefully cut the fabric under the lace down the center.
Turn these raw edges back away from the lace and finger press.
Finish fabric’s edges by sewing a small zigzag through all layers, being careful
not to catch too much lace.
Turn fabric over and trim excess fabric seam allowances away.
Note:
A nice touch can be added by stitching a row of Hemstitching down each
side of the lace. Use the Feather Stitch G with length at 2 and width at 0,
and a wing needle.

15
TWIN NEEDLE PINTUCKS
Use a twin needle and a straight stitch to make raised “tucks” in fabric. Pintucking
adds an elegant touch to heirloom work, an interesting effect to crazy quilting, and
texture to wearable art.
Machine Setup
Stitch: Straight Stitch A
Presser Foot: General Purpose Foot C
Stitch Length: 2
Tension: 6
Materials
Batiste
2.0 Twin Needle
Accessory Spool Pin (optional accessory) required
Note:
Do not use Built-in Needle Threader.
Procedure
Refer to manual for threading.
Pull thread in the fabric to establish straight line for first tuck.
Stitch guiding the space between the two needles over the area of the pulled
threads.
Stitch several rows of pintucks. Use edge of foot as a guide against previous
pintuck to keep rows straight.
Note:
- Spray starch may be needed for additional sizing on some fabrics – especially
the polyester blends.
-Try Shadow Pintucks – use dark color thread in bobbin.
- Try Corded Pintucks – feed cord through a hollow plastic coffee stir stick taped to
the bed of the machine, in front of the foot.
- Optional Pintuck Foot is available to help space pintucks closer together without
flattening.

16
FAGOTING
The Fagoting stitch can be used to join two fabrics with an open lattice-like effect.
Machine Setup 1
Stitch: Straight Stitch A
Presser Foot: General Purpose C
Stitch Length; 4
Stitch Width: 0 (center needle position)
Tension: 2
Machine Setup 2
Stitch: Feather Stitch G
Presser Foot: General Purpose Foot C
Stitch Length: 2 to 3
Stitch Width: 7
Needle: Red Band 90/14
Materials
Linen-like fabric 8” x 4”, cut into two 4” x 4” pieces
Rinse-away stabilizer
25 wt. cotton thread in bobbin and needle
Procedure
Fold 4” pieces in half and press.
Lay stabilizer under one piece of fabric, extending away from folded edge 1”.
Set machine for Setup 1.
Baste stabilizer to fold by stitching 1/2” away from folded edge.
Repeat step with other edge, leaving approximately 1/4” gap between the two
folded edges.
Set machine for Setup 2.
Center open area with stabilizer under the foot.
Stitch down the stabilizer, slightly catching the edges of the folds.
Remove basting stitches and stabilizer.
Note:
- Create rolled and whipped edges on both fabric pieces before doing the fagoting,
for a more secure finish.
-Fabric can also be secured to stabilizer by means of adhesive spray.

17
FAUX TATTED/CROCHETED EDGING
This technique creates an elegant lacy edge that appears to have been either
tatted or crocheted by hand. It is a lovely finish on collars, cuffs, linen towels,
valance hems, and many other projects.
Machine Setup
Stitch: Multi-Zigzag F
Presser Foot: General Purpose Foot C
Stitch Length: 1
Stitch Width: 7
Needle: Red Band 90/14
Materials
Linen-like fabric – starched, with one long edge hemmed
25 wt. cotton thread in both needle and bobbin
Rinse-away stabilizer – folded to create double layer
Procedure
Position stabilizer under the hemmed edge of the fabric, with the bulk of the
fabric to the left of the presser foot.
Stitch so that the left swing of the needle just penetrates the folded edge of the
fabric, and the rest of the stitch penetrates the stabilizer.
Secure thread tails on both ends by tying square knots before trimming them.
A drop of liquid fray preventer will ensure that stitching will not come undone.

18
APPLIQUE WITH REINFORCED BLANKET STITCH
This unique reinforced blanket stitch provides durability when securing
dimensional appliqués. The stitch is ideal for appliquéing polar fleece or thick
fabrics. It is also perfect for creating a “country-look” or “hand-picked” look
appliqué.
Machine Setup
Stitch: Blanket Stitch H
Presser Foot: General Purpose Foot C
Stitch Length: 1-3
Stitch Width: 3-7
Materials
Polar fleece, felt, or stabilized background fabric
Polar fleece appliqué shape
25 wt. cotton thread
Tear-away stabilizer
Spray-on adhesive
Procedure
Fuse appliqué shape in place using spray-on adhesive.
Lay tear-away stabilizer under background fabric.
Position stitch H so that the straight stitches penetrate the background fabric,
and the needle swing penetrates the appliqué piece. Stitch counterclockwise.
Trim any excess polar fleece away from outside of appliqué.
Note:
- For an invisible “hand-picked” look use monofilament thread.
- Use the needle up/down to stop needle in down position when turning curves on
appliqué. (QQ)
- Experiment with stitches G or I for another “country-style” look.
