SIRUI C60R User manual

思锐C60R RGB LED摄影灯
使用手册
V3.0 2022.08.30

包 装 清 单
前 言
主 要 特 点
RGB LED摄影灯C60R是一款多用途的长亮摄影灯，轻便和双供电模式设计，可固
定在灯架使用，也可手持移动使用，操作便捷，适用于静物拍摄、视频拍摄、直播、
婚纱摄影、儿童摄影等场景。
（1) 轻巧便携，方便手持，自由布光。
（2) HSI模式、CCT模式、色片模式和16种情景特效模式自由调节。
（3) 高亮度均匀的光输出，使画面更具质感。
（4) 搭配静音风扇散热，保证LED稳定工作的同时不会产生噪音。
（5) 多灯联控，支持手机APP控制。
（6) 宝荣卡口设计，通用主流附件，控光更方便。
反光罩* 1
多功能手柄* 1
电池盒* 1灯体* 1
适配器 * 1
保修卡*1
便携包*1
保 修卡
Warranty Card
V1.0 2021.07
Scan the QR code to download the
instruction or user manual
扫码下载本产品使用说明书或用户手册

产 品 介 绍
1
2
3
4
5
6
7
8
9
10
11
电池盒
柔光罩
灯体
角度调节旋钮
多功能手柄
安装固定旋钮
显示屏
SET旋钮
DIM旋钮
DC电源接口
电源开关
1
4
6
5
3
7
8
9
10
11
2

电 源 管 理
1、适配器供电
输入100-240V,50/60Hz，2.5A,输出：16.8V,5A
2、外置电池供电
电池盒上装2个NP-F970电池，装入顶部卡槽固定即可供电。（电池盒只供电池
放电，不能充电，需两个电池同时使用）
操 作 说 明
1、 开关机
使用适配器供电时，开关往“I”按下开机，往中间复位关机。
使用电池供电时，开关往“II”按下开机，往中间复位关机。
2、 模式选择：短按SET旋钮选择CCT模式/HSI/FX特效模式/CTO色片模式
CCT
100%
2500K
色温 亮度
2.1 CCT模式。
2.1.1色温调节：旋转SET旋钮调节色温，最小变量100K，调节范围2800-6500K。
2.1.2 亮度调节：旋转DIM旋钮，最小变量1%，调节范围0-100%。
2.1.3 G/M值调整：单击DIM旋钮进入G/M值调整模式，调节范围-50—+50。

2.2、FX情景特效模式
2.2.1 转动SET旋钮选择灯光特效，短按DIM选择A、B、C档位，转动DIM旋钮调
整亮度。
2.2.2 亮度调节：旋转DIM旋钮，最小变量1%，调节范围0-100%。
2.2.3 情景特效模式有16类，用户可以根据需求选择：
脉冲
爆炸
电焊
FX
100%A
特效 速率 亮度
序号
1
闪光灯 闪光 发布会
生日会
间歇 频繁 持续
间歇 频繁 持续
间歇 频繁 持续
间歇 频繁 持续
间歇 频繁 持续
短暂 连续 演出
暴闪 频闪 快闪
暴闪 频闪 快闪
暴闪 频闪 快闪
柴火 篝火 火灾
KTV 迪斯科
狗仔队
RGB循环 慢速 中速 快速
慢速 中速 快速
慢速 中速 快速
慢速 中速 快速
迪斯科
闪电
故障灯
电视荧幕
蜡烛
火焰
烟花
警车
消防车
救护车
SOS
2
3
4
5
6
7
8
9
10
11
12
13
15
14
16
显示 显示A 显示B 显示C场景

3、连接手机APP
3.1.长按SET打开蓝牙（再次长按SET关闭蓝牙）
3.2、扫描二维码下载“
Duken Light ”手机APP
3.3、手机打开蓝牙，在“
Duken Light ”APP中连接对应的灯就可通过APP控制灯。
具体操作请参考手机APP使用说明。
4、安装和固定
4.1 用2个NP-F970电池装入电池盒，然后装入灯体，安装好手柄后可以正常使用。
扫码下载App
SIRUI Light
2.3 HSI模式
2.3.1 色相、饱和度调节：短按DIM选择色相H、饱和度S，转动SET旋钮调整对应值。
色相调节范围 0-359°，饱和度调节范围0-100。
2.3.2 亮度调节：旋转DIM旋钮，最小变量1%，调节范围0-100%。
2.4 CTO色片模式
2.4.1 转动SET旋钮选择9种常用色片：红、绿、蓝、橙、紫、3200K、4000K、
5600K、6500K。
2.4.2 亮度调节：旋转DIM旋钮，最小变量1%，调节范围0-100%。

4.2 通过手柄上角度调节旋钮可以调整灯的角度。
4.3，通过手柄底部固定旋钮，可以将灯固定在灯架上。

产 品 参 数
设计和规格如有变更，恕不另行通知。
型号
产品尺寸
产品重量
LED功率
色温范围
特效模式
裸灯100%光照度
TLCI
CRI
工作环境温度
控制方式
蓝牙无线控制距离 15m
手机APP
-10℃-45℃
96
98
1m距离 2300lux
2800K~6500K
约60W
925g
170*122*120mm
C60R
16类
维 护 保 养
注 意 事 项
·灯体在工作时，如发现异常，应立即关掉电源，查明原因。
·灯体应避免震动，平时注意表面除尘。
·灯体稍有发热为正常现象。
·维修由本厂维修部负责。
·本产品保修一年，消耗品适配器、电源线等不在一年保修范围内。
·经发现，擅自检修此灯的，将取消一年保修期，维修需要收取相关费用。
·如果本品出现故障或者被水淋湿，在专业人员维修后方可继续使用。
·设计和规格如有变更，恕不另行通知。
1、充电不要放置超过24小时。
2、应放置于凉爽、干燥、通风对的地方存储。
3、不要靠近和放置于火中。
4、长期不使用，请充电至70%再放置。
5、为了延长电池使用寿命，建议每三个月进行一次充电保养。
6、电池有一定的寿命限制，使用一定时间后，性能会减弱，属于正常现象。
7、本品使用报废后，电池请按当地的规定处理。
8、请使用配套适配器进行充电，其他规格有可能导致硬件损坏。如使用其他电源适配器
造成的产品故障，不予保修

SIRUI C60R RGB LED Light
Product Manual
V3.0 2022.08.30

What's in the Box
Foreword
Features
This RGB LED Light C60R is a multi-purpose continuous light that can
be powered by batteries and AC/DC adapters. Designed to be portable,
this light can be handheld or attached to a stand for easy operation and
is a perfect lighting solution for stills, videos, live streaming, weddings,
and kids.
1. Compact and lightweight, easy to be held in hand.
2. Lighting modes: HSI mode, CCT mode, GEL mode, and FX mode.
3. Bright even lights.
4. A silent fan is built inside to ensure noiseless running.
5. Support group control and APP control.
6. Common accessories can be attached to the C60R via the Bowens mount.
Reflector* 1
Handheld Grip*1
Battery Case* 1Light Body* 1
Adapter * 1
Warranty Card*1
Carrying Bag*1
保 修卡
Warranty Card
V1.0 2021.07
Scan the QR code to download the
instruction or user manual
扫码下载本产品使用说明书或用户手册

Names of Parts
1
2
3
4
5
6
7
8
9
10
11
Battery Case
Reflector
Light Body
Angle Adjustment Knob
Handheld Grip
Fixing Knob
Display
SET Select Dial
DIM Select Dial
DC Power Socket
Power Switch
1
2
4
6
5
3
7
8
9
10
11

Power Management
1. Adapter Power Supply
Input: 100-240V~50/60Hz 2.5A, output: 16.8V 5A
2. External Battery Power Supply
Load two NP-F970 batteries into the battery compartment. Slide the battery
case on top of the C60R. (The battery case cannot charge the batteries.
Please make sure there are at least two batteries in the compartment.)
Operation
1. Power On/Off
When powered by batteries, press the switch to the right (II) to turn on the
light and return the switch to the middle to turn off the light.
When powered by the adapter, press the switch to the left (I) to turn on the
light and return the switch to the middle to turn off the light.
2. Mode Selection:
Hit the SET dial to choose from the CCT mode, FX mode, HSI mode, and
CTO GEL mode.
CCT
100%
2800K
Color Temperature Brightness
2.1 CCT Mode
2.1.1 Color temperature adjustment: turn the SET dial to adjust the color
temperature in at least 100K increments from 2800K to 6500K.
2.1.2 Brightness adjustment: turn the DIM dial to adjust the brightness in
at least 1% increments from 0% to 100%.
2.1.3 G/M value adjustment: hit the DIM dial to select the G/M value. The
value is adjustable from -50 to +50.

Disco KTV Disco
2.2 FX Mode
2.2.1 Turn the SET dial to select a special effect. Hit the DIM dial to adjust
the speed (A, B, C). Turn the DIM dial to adjust the brightness.
2.2.2 Brightness adjustment: turn the DIM dial to adjust the brightness in at
least 1% increments from 0% to 100%.
2.2.3 There are 16 situational special effects for your choice:
FX
100%A
Special Effect Speed Brightness
Flash Flash Press
Conference
Frequent Sustainable
Discontinuous Frequent Sustainable
Discontinuous Frequent Sustainable
Discontinuous Frequent Sustainable
Frequent Sustainable
Discontinuous
Discontinuous
Brief Continuous Show
Firewood Campfire Fire Hazard
Paparazzi
Slow Medium Quick
Slow Medium Quick
Slow Medium Quick
Broken Bulb
TV
Candle
Fire
Firework
Impulse
Blast
Welding
SOS
Lightning
No.
1RGB Cycle Slow Medium Quick
Police Car Strong Fash Quick Flash
Fire Truck Strong Fash Frequent Flash Quick Flash
Ambulance Strong Fash Frequent Flash Quick Flash
2
3
4
5
6
7
8
9
10
11
12
13
15
14
16
DisplayA DisplayB DisplayCSituationDisplay
Birthday Party
Frequent Flash

2.3. HSI Mode
2.3.1 Hue/Saturation adjustment: Hit the DIM dial to select the Hue/
Saturation. Turn the SET dial to adjust the Hue from 0° to 359°
or Saturation from 0 to 100.
2.3.2 Brightness adjustment: turn the DIM dial to adjust the brightness
in at least 1% increments from 0% to 100%.
Scan the QR code
to download the App.
SIRUI Light
4. Installation
4.1 Load two NP-F970 batteries into the battery compartment and slide the
battery case on top of the C60R. Attach the grip to the bottom of the C60R
for handheld use.
2.4. CTO GEL Mode
2.4.1 Turn the SET dial to choose from 9 common gels: red, green, blue,
orange, purple, 3200K, 4000K, 5600K, and 6500K.
2.4.2 Brightness adjustment: turn the DIM dial to adjust the brightness in
at least 1% increments from 0% to 100%.
3. APP Control
3.1 Press and hold the SET dial to turn on Bluetooth. (Press and hold the
SET dial again to turn off Bluetooth.)
3.2 Scan the QR code to download the "Duken Light" App.
3.3 Turn on Bluetooth on the phone and enter the "SIRUI Light" App.
Select "C60R LED Light" from the device list.
* For detailed steps, please refer to the APP instruction manual.

4.3 Fix the light to a stand via the fixing knob.
4.2 Adjust the angle of the light via the angle adjustment knob.

15m
-10℃- 45℃
96 on average
98 on average
2800K~6500K
about 60W
925g/2.04lbs
170*122*120mm
C60R
16
APP Control
2300 lux at 1m
Maintenance
Warning
1. If there is something wrong with the light when it is working, please turn it
off first.
2. Avoid sudden impacts and the product should be dedusted regularly.
3. It is normal that the light gets a bit hot when it is working.
4. Maintenance must be performed by the authorized maintenance department
which can provide original accessories.
5. This product, except for consumables, supports a one-year warranty.
6. Unauthorized service will void the warranty.
7. If the product had failures or was wetted, do not use it until it is repaired by
professionals.
8. Changes made to the specifications or designs may not be reflected in this
manual.
1. The product should be kept in a cool, dry and ventilated place.
2. Do not look directly at the LED lamp beads when the light is on.
3. Do not put the light near flammable and volatile solvents.
4. Avoid using the light in humid, dusty, overheated environments.
5. Use of unauthorized power adapter may cause damage to the product
and void the warranty.
6. Please remove the protect cover before using the light.
Specifications
* Product design and specifications are subject to change without notice.
Model
Size
Weight
Power
Color Temperature Range
Special Effect
100% Illuminance (LUX)
TLCI
CRI
Working Temperature
Control Method
Wireless Bluetooth Control Distance
