Sitecom WLX-7000 User manual

WLX-7000
Wi-Fi access point AC1200

Introduction
Thank you for purchasing the Sitecom WLX-7000 AC1200 Wi-Fi Dual-band Access Point.
This Access Point lets you upgrade your home network to enjoy a bigger Wi-Fi range,
faster speeds and better connections. It is extremely easy to setup, works with any
Internet provider and can be connected to any existing (modem) router or set-top box to
improve the home network. You can position the access point standing up, hanging on
the wall or flat on the desk.
The WLX-7000 AC1200 Wi-Fi Dual-band Access Point has strong internal dual-band
antennas that will give you a bigger Wi-Fi range than the (modem) router or set-top box
that you have received from your Internet provider. Connect to the access point’s Wi-Fi
throughout your whole home and browse, shop and watch wherever you want.
The WLX-7000 AC1200 Wi-Fi Dual-band Access Point lets you create a blazing-fast Wi-Fi
network and take advantage of the latest Wi-Fi technology 802.11ac. The access point is
capable of reaching combined Wi-Fi speeds of AC1200. Stream multiple HD movies and
enjoy Netflix, Spotify and many more, without lag and buffering. Wired devices such as
your HD TV or game console can be connected to the access point’s Gigabit ports to
make use of an ultra-stable and reliable connection with wired speeds of up to 1000
Mbps.
Use two Wi-Fi networks at the same time with Simultaneous Dual-band technology. The
standard 2,4 GHz frequency is ideal for lighter tasks such as surfing, mailing and
watching YouTube clips, while the 5 GHz frequency is your fast lane for demanding tasks
such as streaming HD movies with Netflix or playing video games online.
The WLX-7000 AC1200 Wi-Fi Dual-band Access Point is fully Plug & Play out of the box.
Simply connect the access point with the included network cable to a free port of your
(modem) router or set-top box, no installation or configuration necessary. The access
point is secured with a pre-set unique Wi-Fi password (WPA2) and can be found easily in
any list of Wi-Fi networks via the unique Wi-Fi name (SSID).
This product can be used safely in the countries listed below:
This product complies with the following European Union regulations:

Table of Contents
Key Features ............................................................................................. 6
Package Contents....................................................................................... 7
Cautions.................................................................................................... 8
Product Layout........................................................................................... 9
Network + System Requirements ............................................................... 11
Product Installation .................................................................................. 12
Setup your Computer................................................................................ 13
Configuration ........................................................................................... 16
Status .................................................................................................. 17
Wi-Fi Settings ....................................................................................... 22
Toolbox Settings.................................................................................... 30
Addendum A: GNU/GPL Information ........................................................... 33

Key Features
Features
Advantages
Incredible Data Rate up to
300Mbps on 2.4GHz and 866Mbps
on 5GHz*
Heavy data payloads such as MPEG
video streaming
IEEE 802.11ac Compliant and
backwards compatible with
802.11b/g/n
Fully Interoperable with IEEE
802.11b/g/n compliant devices with
legacy protection
Supports DHCP server function
Can act as a DHCP server to handle
all DHCP traffic on the network.
Easy to use web-based GUI
Graphical User Interface for network
configuration and management
purposes.
WPS Buttons
Easily connect the device to your
existing network and your clients
with just the push of a button.
* Theoretical wireless signal rate based on IEEE standard of 802.11b, g, n, ac chipset
used. Actual throughput may vary. Network conditions and environmental factors lower
actual throughput rate. All specifications are subject to change without notice.

Package Contents
Open the package carefully, and make sure that none of the items listed below are
missing. Do not discard the packing materials, in case of return; the unit must be
shipped back in its original package.
1. The WLX-7000 access point AC1200
2. A 110V~240V to 12V 1A Switching Power Adapter
3. A Quick Install Guide
4. An UTP cable

Cautions
This device’s design and manufacturer has your safety in mind. In order to safely and
effectively use this device, please read the following before usage.
Usage Cautions
The user should not modify this device. The environmental temperature should be within
+5 ~ +35 degrees Celsius.
Power
The router’s power voltage is DC 12V 1A.
When using this router, please connect the supplied AC adapter or AC adapter cable to
the router’s power jack. When placing the adapter cable, make sure it can’t get damaged
or be subject to pressure. To reduce the risk of electric shock, unplug the adapter first
before cleaning it. Never connect the adapter to the router in a humid or dusty area. Do
not replace the adapter or cable’s wire or connector.
Repair
If the device has a problem, you should take it to an appointed repair center and let the
specialists do the repair. Never repair the device yourself, you might damage the device
or endanger yourself.
Disposing of the device
When you dispose of the device, be sure to dispose of it appropriately. Some countries
may regulate disposal of an electrical device, please consult with your local authority.
Others
When using this device, please do not let it come into contact with water or other liquids.
If water is accidentally spilled on the device, please use a dry cloth to absorb the spillage.
Electronic products are vulnerable, when using please avoid shaking or hitting the device,
and do not press the buttons too hard.
Do not let the device come into contact with water or other liquid.
Do not disassemble, repair or change the design of the device, any damage done
will not be included in the repair policy.
Avoid hitting the device with a hard object, avoid shaking the device and stay
away from magnetic fields.
If during electrostatic discharge or a strong electromagnetic field the device will
malfunction, unplug the power cable. The product will return to normal
performance the next time it is powered on.

Product Layout
Description
Network Ports
You can use this port to connect to a wired modem or
router to add wireless functionality. You can also use
these ports to connect additional wired devices.
Backlabel and Network Details Folder
The Network Details Folder describes the IP address, login details, network name,
security code and OPS button functionality.
Button
Description
OPS BUTTON
Press 2 seconds for WPS/OPS mode
Press both buttons 15+ Seconds to reset to factory
defaults.

LED Description
From top to bottom:
LED
Color
Description
OPS
(White)
Shows OPS activity.
Power
(Red)
Shows the device is turned on.
5GHz WiFi
(Blue)
Shows 5GHz WiFi activity.
2.4GHz WiFi
(Blue)
Shows 2.4GHz WiFi activity.
LAN
(Blue)
Shows the cable is connected.
LAN
(Blue)
Shows the cable is connected.
LAN
(Blue)
Shows the cable is connected.
LAN
(Blue)
Shows the cable is connected.
LAN
(Blue)
Shows the cable is connected.

Network + System Requirements
To begin using the WLX-7000, make sure you meet the following as minimum
requirements:
Network Requirements
An Ethernet-based broadband modem
Web-based
Configuration
Computer with the following:
-Windows®, Macintosh, or Linux-based
operating system
-An installed Ethernet adapter or wireless
adapter
-Supported Browsers:
Internet Explorer 9 or higher
Firefox
Safari 4 or higher
Chrome

Product Installation
You can place the access point on a desk or other flat surface, or you can mount it on a
wall. For optimal performance, place your access point in the center of your home (or
your office) in a location that is away from any potential source of interference, such as a
metal wall or microwave oven. This location must be close to a power connection and
your ADSL/Cable modem.
Connect the supplied power-adapter to the power inlet port and connect it to a wall outlet.
Switch the access point on by flipping the switch on the back of the device. The access
point automatically enters the self-test phase. During self-test phase, the Power LED will
be lit continuously to indicate that this product is in normal operation.

Setup your Computer
Windows, Manual Connection
Click on the icon for wireless connectivity. This is usually located in the System
Tray, next to the clock.
Select the Sitecom network. The correct network name can be found on the
sticker on bottom of the router, or in the Network Details Folder.
Fill in the password for the wireless network. The correct password can be found
on the sticker on the bottom of the router, or in the Network Details Folder.
Wait for the icon to display that it’s connected to the network.

Windows, OPS Connection
Click on the icon for wireless connectivity. This is usually located in the System
Tray, next to the clock.
Select the Sitecom network. The correct network name can be found on the
sticker on bottom of the router, or in the Network Details Folder.
Push the OPS Button on the router. For 2.4GHz, press the 2.4GHz button. For
5GHz, press the 5GHz button.
Wait for the icon to display that it’s connected to the network.

Mac OSX
Click on the icon for wireless connectivity. This is usually located in the System
Tray, next to the clock.
Select the Sitecom network. The correct network name can be found on the
sticker on bottom of the router, or in the Network Details Folder.
Fill in the password for the wireless network. The correct password can be found
on the sticker on the bottom of the router, or in the Network Details Folder.
Wait for the icon to display that it’s connected to the network.

Configuration
LOGIN procedure
1. OPEN your browser (e.g. Internet Explorer).
2. Type http://sitecom.ap in the address bar and press [Enter]
3. Type user name and password (default username is ‘admin’, the password can be
found on the back of the Access Point).
4. Click OK.
5. You will see the home page of the WLX-7000.

Status
System Status
The System status section allows you to monitor the current status of your device, the
UP time, hardware information, serial number as well as firmware version information is
displayed here.

LAN settings
This device provides some control functions including IP address management, and DHCP
server function.
IP Address You can change the IP address of this device, so it can become a
part of your local network. Please remember this address or you will
not be able to connect the configuration menu of device.
Default Gateway Please input the IP address of default gateway of your network here.
DHCP Server If you want to activate the DHCP server function of this device,
please select ‘Enabled’ in the ‘DHCP Server’ option, and see the next
Section for detailed instructions. If you don’t want to use the DHCP
server function of this device, or there’s another DHCP server on the
network this device connects to, please select ‘Disable’. After you
finish, please go to the bottom of this page and click ‘Apply’.
Lease Time Please choose a lease time (the duration that every computer can
keep a specific IP address) of every IP address assigned by this
access point from dropdown menu.
DHCP Start IP Please input the start IP address of the IP range.
DHCP End IP Please input the end IP address of the IP range.
Hostname If you wish, you can also optionally input the domain name for your
network. This is optional.
After you finish, please click ‘Apply’.

Device Status
View the router’s current configuration settings. Device Status displays the configuration
settings you’ve configured in the Internet Settings and WiFi Settings sections.

Log
This page shows the current system log of the access point. It displays any event that
occurred during or after system start up. At the bottom of the page, the system log can
be saved <Save> to a local file for further processing or the system log can be cleared
<Clear> or it can be refreshed <Refresh> to get the most updated information. When
the system is powered down, the system log will disappear if not saved to a local file.
