SKC 223-105A User manual

Page 1 007-02-004 Issue A June 2011
www.skcltd.com
Standard Five Station Chargers
Operating Instructions
Standard five station charger models -
• 223-102A Five station charger for 222 series pumps
• 223-103A Five station charger for Sidekick EX / TX / MTX series pumps, Universal
EX / TX / MTX / MA / AZ / MAZ series pumps and AirChek 52 pump
• 223-105A Five station charger for Universal XR series pumps
• 223-106A Five station charger for AirChek 2000 pump
• 223-109A Five station charger for AirChek 3000 pump
Please read these instructions before using the charger!
Specifications
Model Input Output x5 Battery Pack Specification
223-102A 100-240V ~ 50/60Hz 55mA NiCd 2cell 2.4V 0.55Ah
223-103A 100-240V ~ 50/60Hz 180mA NiCd/NiMH 4cell 4.8V 2.0Ah
223-105A 100-240V ~ 50/60Hz 180mA NiCd/NiMH 5cell 6.0V 2.0Ah
223-106A 100-240V ~ 50/60Hz 180mA NiCd/NiMH 4cell 4.8V 2.0Ah
223-109A 100-240V ~ 50/60Hz 180mA NiMH 4cell 4.8V 2.0Ah
Introduction
The SKC Ltd five station chargers provide five charging outputs with a fixed 15 hour
constant current charge for SKC NiCd and NiMH battery packs. At the end of the 15
hour charge, the chargers automatically switch each of the five outputs individually to a
trickle charging rate to prevent overcharging.
The chargers are supplied with four inter-changeable electrical supply input plugs
suitable for use in the United Kingdom, Europe, USA / Canada and Australia / New
Zealand.
Warnings
These chargers are designed for use specifically with the stated SKC pump models and
are not intended for use with any other SKC or non-SKC products.
These chargers must not be used to charge non-rechargeable batteries.
These chargers are for indoor use only, with enclosure rating of IP40, and must
therefore be protected against exposure to moisture.
Operating temperature range - 0°C to +40°C, 95% RH non-condensing.
Use of a non-SKC charger to charge SKC pump battery packs may cause damage to
the battery pack and / or pump and will void the battery pack and / or pump warranty,
also the intrinsic safety rating of the pump may be invalidated.

Page 2 007-02-004 Issue A June 2011
Charger Operation
1. Select the correct electrical supply input plug for your region and fit it to the
charger power supply unit.
2. Plug the charger power supply unit into an electrical supply socket and switch on
the electrical supply. The ‘power’ LED indicator will illuminate, alternating between
red and yellow. If the ‘power’ LED indicator illuminates red continuously this
indicates a fault in the charger timing circuit - refer to SKC Ltd customer support.
3. Plug a charger output connector into the charging socket on a battery pack.
The charger output LED indicator will illuminate continuously to indicate that the
charger is charging at full rate. Any combination of the five charger outputs may
be used simultaneously and battery packs can be connected at any time, as each
charger output is individually controlled.
4. After the fixed 15 hour charging period the charger will automatically switch the
output to a trickle charging rate, and the output LED indicator will flash on and off
to indicate this.
5. It is recommended to disconnect the charger from the battery pack after a period
of 24hours to maintain optimum battery life and performance.
6. It is recommended to disconnect the charger from the electrical supply when not
in use to save the energy the charger consumes when on standby.
The WEEE Directive
This product is marked with the crossed out wheelie bin symbol, which identifies that it
falls within the scope of the EC Directive 2002/96/EC on waste electrical and electronic
equipment (WEEE). At the end of it’s useful life, this product must be disposed of in
an environmentally sound way as detailed in the Directive. Please contact your local
distributor or SKC Ltd for further details on how to comply with the requirements of the
WEEE Directive. SKC Ltd’s producer registration number is WEE/KH0054TQ.
Battery Disposal
SKC battery packs fall within the scope of the EC Directive 2006/66/EC on batteries
and accumulators and waste batteries and accumulators and equivalent legislation in
other regions. Batteries must be collected and treated separately from other waste,
and those containing mercury, cadmium and lead are subject to special treatment.
Please contact your local distributor or SKC Ltd for further details on how to comply
with the requirements of the Batteries Directive. SKC Ltd’s batteries producer
registration number is BPRN00454.
