Ski-Doo 2006 MX Z Manual

Mmo-2006-007 suppl MX Z X.FH8 Tue Jun 21 08:14:45 2005 Page 1
Composite
C M Y CM MY CY CMY K

SAFETY WARNING
Disregarding any of the safety precautions and instructions
contained in this Operator’s Guide,Safety Videocassette or on-
product warnings may result in injury, including the possibility of
death.
This Operator’s Guide and Safety Videocassette should remain
with the unit at time of resale.
In USA, products are distributed by BRP US Inc.
In Canada, products are distributed by Bombardier Recreational Prod-
ucts Inc.
The following are trademarks of Bombardier Recreational Products
Inc. or its subsidiaries.
SKI-DOO ROTAX®‘
REV®MX-Z®
Printed in Canada. (mmo2006-007 DR)
®™ and the BRP logo are trademarks of Bombardier Recreational Products Inc. or its affiliates.
©2005 Bombardier Recreational Products Inc. and BRP US Inc. All rights reserved.
* Trademark of Bombardier Inc. used under license.

Dear 2006 MX Z XTM 440 owner, informations in the 2006 REV®
Series Operator's Guide (P/N 520 000 547) also apply to your MX
Z X 440 except for the following.
__________________________ 1

TABLE OF CONTENTS
VEHICLE INFORMATION
RACING APPLICATION........................................... 4
CONTROLS/INSTRUMENTS/EQUIPMENT .................... 5
1) Brake/Parking Brake PilotLamp (Red)...................... 5
12) Tether Cord Cut-Out System .............................. 6
13) Engine Cut-Out Switch .................................... 6
14) High Beam/Low Beam Switch ............................ 6
18) Fuel Level .................................................. 7
43) Pre-Heat Switch............................................ 8
44) Primer Button .............................................. 8
RECOMMENDED FUEL AND OIL................................ 9
OPERATING INSTRUCTIONS.................................... 13
Engine Starting Procedure..................................... 13
Suspensions Adjustments..................................... 13
SPECIFICATIONS ................................................. 15
MAINTENANCE INFORMATION
ENGINE SYSTEM................................................. 20
Coolant Pump Shaft Oil Reservoir............................. 20
Cooling System ................................................ 20
DRIVE SYSTEM................................................... 21
Brake Fluid Level............................................... 21
Drive Belt Removal/Installation................................ 21
WARRANTY
LIMITED WARRANTY VALIDATION............................. 26
2__________________________

VEHICLE
INFORMATION
__________________________ 3

RACING APPLICATION
For racing application, the main jets have to be replaced according to
thechartfoundonbeltguard.
4__________________________

CONTROLS/INSTRUMENTS/EQUIPMENT
25
A33A1RC
29
18
34
19
14
43
6 7 9 13
5
12
17
15
27
44
NOTE: See description of numbered items in 2006 REV Series Op-
erator’s Guide (P/N 520 000 547) except for the following.
1) Brake/Parking Brake Pilot Lamp (Red)
This pilot lamp is disabled (does not light up) on the MX Z X 440.
WARNING
Make sure parking brake is fully disengaged before operating
the snowmobile.
When you ride the vehicle, brake that are caused to drag by
a continuous pressure on the lever may cause damage to the
brake system and cause loss of braking capacity and/or fire.
__________________________ 5

12) Tether Cord Cut-Out System
General
The tether cord cut-out system prevents snowmobile to runaway, if
the operator accidently falls off, by shutting off the engine.
WARNING
Always disconnect tether cord when leaving vehicle unattend-
ed and keep in a secured location.
Operation
Attach tether cord to clothing eyelet then snap tether cord cap over
post before starting engine.
To stop engine, completely pull cap from post.
13) Engine Cut-Out Switch
Locatedonrightsideofhandlebarthisswitchisusedtostopthe
engine.
OFF
A33E0HB
ON
OFF
14) High Beam/Low Beam Switch
Allows selection of headlamp high beam or low beam.
6__________________________

1
2
mmo2006-007-002_a
1. Low beam
2. High beam
18) Fuel Level
Open fabric door to see the fuel level through the translucent fuel
tank.
A33H1OA 1
1. Fabric door
__________________________ 7

43) Pre-Heat Switch
Racing Application Only
NOTE: This switch is disabled (not operative) on vehicles modified
forwarrantyvalidation. Torunenginewith91octanenumberfuel
(R + M)/2 inside North America (95 RON outside North America),
this switch must be disabled.
1
A33E0SA
2
1. Button depressed: Pre-heat timing curve
2. Button released: 108 (R + M)/2+ octane timing curve for North America
version (98 RON + Octane timing curve for outside North America)
After starting the engine, push and hold the pre-heat switch button
in order to pre-heat the tuned pipe. Release pre-heat switch button
once the tuned is pre-heated.
44) Primer Button
Pull and push button. It is not necessary when engine is warm.
To prime, activate button until a pumping resistance is felt. From
this point, pump 2 or 3 times to inject fuel in intake manifold. After
priming, ensure that primer button is pushed back.
NOTE: In very cold temperature, it is recommended to rotate primer
button 3-4 turns prior to pull it. This will eliminate the possibility of
sticking.
8__________________________

RECOMMENDED FUEL AND OIL
Fuel
Vehicles with Valid Warranty (Pre-Heat Switch Disabled)
Use premium unleaded gasoline, available from most service
stations or oxygenated fuel containing a maximum total of 10%
of ethanol or methanol or both. The gasoline used must have the
following recommended minimum octane number.
LOCATION OCTANE NUMBER
Inside North America 91 (RON + MON)/2
Outside North America 95 RON
Vehicles without Warranty (Pre-Heat Switch Enabled)
Use racing fuel with the following octane number.
MINIMUM
LOCATION OCTANE NUMBER
Inside North America 108 (RON + MON)/2
Outside North America 113 RON
RECOMMENDED
LOCATION OCTANE NUMBER
Inside North America 114 (RON + MON)/2
Outside North America 119 RON
NOTE: The fuel tank cap specifies an octane number of 91 as a min-
imum. A higher octane number is required in racing application.
All Vehicles
CAUTION: Never experiment with other fuels. The use of unrec-
ommended fuel can result in snowmobile performance deterio-
ration and damage to critical parts in the fuel system and engine
components.
__________________________ 9

WARNING
Always stop engine before refueling. Open cap slowly. If a dif-
ferential pressure condition is noticed (whistling sound heard
when loosening fuel tank cap) have vehicle inspected and/or
repaired before further operation. Fuel is flammable and ex-
plosive under certain conditions. Never use an open flame to
check fuel level. Never smoke or allow flame or spark in vicin-
ity. Always work in a well-ventilated area. Never top up the
fuel tank before placing the vehicle in a warm area. As tem-
perature increases, fuel expands and may overflow. Always
wipe off any fuel spillage from the vehicle.
Fuel System Antifreeze
When using oxygenated fuel, additional gas line antifreeze or water
absorbing additives are not required and should be not used.
When using non-oxygenated fuel, we highly recommend the use of
isopropyl base gas line antifreeze in a proportion of 150 mL (5 U.S. oz)
of gas line antifreeze added to 40 liters (10-1/2 U.S. gal) of gas.
This precaution is in order to reduce the risk of frozen carburetors
which may lead, in certain cases, to high fuel consumption or severe
damage to engine.
IMPORTANT: Use only methyl hydrate free gas line antifreeze.
Oil
NOTE: Premix fuel/oil ratio is 33:1
CAUTION: Never experiment with other fuel/oil ratios. Use only
oil that can flow at - 40°C (- 40°F).
Oil must be mixed with fuel at the ratio of 33:1 in a jerrycan then,
be poured in the fuel tank. Refer to chart below as a guideline to
properly premix oil with fuel.
Use only two-stroke engine injection oil, sold by authorized SKI-DOO
dealers.
MODEL OIL TYPE
MX Z X 440 XP-S synthetic 2-stroke oil (1)
(P/N 293 600 045) (12 x 1 L)
10 _________________________

CAUTION: (1) The XP-S synthetic 2-stroke oil is specially formu-
lated and tested for the severe requirements of the 453 engine.
Use of any other brand two-stroke oil may void the limited war-
ranty. Use only XP-S synthetic 2-stroke oil. There is no known
equivalent on the market for the moment. If a high quality equiv-
alent were available, it could be used.
The XP-S synthetic 2-stroke oil provides superior lubrication,
reduced engine component wear and oil deposit, thus maintaining
maximum-level performance and antifriction properties. This syn-
thetic injection oil meets the latest ASTM and JASO standards by
ensuring high biodegradability and low exhaust smoke.
CAUTION: Never use four-stroke petroleum or synthetic motor
oil and never mix these with outboard motor oil. Do not use
NMMA TC-W, TC-W2 or TC-W3 outboard two-stroke engine oils
or ashless two-stroke engine oils. Avoid mixing different brands
of API TC oil as resulting chemical reactions may cause severe
engine damage.
WARNING
Wipe off any oil spills. Oil is highly flammable.
PREMIX FUEL/OIL RATIO
33:1
METRIC (SI): 1 L of oil + 33 L of fuel = 33/1
IMPERIAL: 35 imp. oz of oil + 7.2 imp. gal of fuel = 33/1
1 L of oil + 7.2 imp. gal of fuel = 33/1
UNITED STATES: 34 U.S. oz of oil + 8.8 U.S. gal of fuel = 33/1
1 L of oil + 8.8 U.S. of fuel = 33/1
__________________________ 11

12 _________________________

OPERATING INSTRUCTIONS
Engine Starting Procedure
•Re-check throttle control lever operation.
•Ensure that the emergency cut-out switch is in the ON position.
•Ensurethetethercut-outcapisinpositionandthatthecordis
attached to your clothing.
•To prime, activate button until a pumping resistance is felt. From
this point, pump 2 or 3 times to inject fuel in intake manifold.
After priming, ensure that primer button is pushed back.
NOTE: In very cold temperature, it is recommended to rotate primer
button 3 - 4 turns prior to pull it. This will eliminate the possibility of
sticking.
NOTE: Priming is not necessary when engine is warm.
Suspensions Adjustments
NOTE: There is no rear shock motion ratio adjustment on the
MX Z X 440.
In addition to all suspension adjustments described in REV Series
Operator’s Guide, take note of the 2 following points.
Shocks
All 4 shocks feature 2 adjustments.
Low Speed Compression Adjuster
The low speed adjuster modifies the damping force for small suspen-
sion velocities —less than 0.75 m/s (2.5 ft/s). It tunes the vehicle
for braking, cornering, hole shot and all the bumps that create low
speed movement in the suspension. This adjuster has 4 turns of
adjustment. Use a flat screwdriver to adjust it. Turning it clockwise
increases shock damping action (stiffer) for these low compression
speeds.
High Speed Compression Adjuster
The High speed adjuster modifies the damping force for high sus-
pension velocities —more than 0.5 m/s (1.6 ft/s). It tunes the ve-
hicle for hoops or bumps that create high speed movement in the
suspension. This adjuster has 3 turns of adjustment. Use a 17 mm
wrench to adjust it. Turning it clockwise increases shock damping
action (stiffer) for these high compression speeds.
__________________________ 13

A33F0DA 12
1. Low speed compression adjuster (flat screwdriver)
2. High speed compression adjuster (17 mm wrench)
Center and Front Springs
CAUTION: Make sure that center spring and both front springs
are still preloaded when front of vehicle is off the ground. Max-
imum spring preload is 25 mm (1 in). Otherwise, spring will be
coil bound when fully compressed.
14 _________________________

SPECIFICATIONS
NOTE: Because of its ongoing commitment to product quality and
innovation, BRP reserves the right, at any time, to make changes in
design and specifications and/or to make additions to, or improve-
ments in its products without imposing any obligation upon itself to
install them on its products previously manufactured.
MODEL MX Z X 440
ENGINE SYSTEM
Engine type 453
Cylinders 2
Displacement cc (in3)436.7 (26.6)
Bore mm (in) 65.0 (2.56)
Stroke mm (in) 65.8 (2.59)
Maximum power engine
speed ± 100 RPM 8400
Carburetion 2 x TMX-34
Exhaust system Single tuned pipe,
baffle muffler
DRIVE SYSTEM
Drive pulley type TRA III light
Driven pulley type Team rapid reaction
Engagement 5700 RPM
Small sprocket number of teeth 21
Large sprocket number of teeth 45
Drive sprocket number of teeth 9
Brake system Hydraulic caliper,
self adjusting
Track nominal width 381 mm (15 in)
Track nominal length 3074 mm (121 in)
Track profile height 44.5 mm (1.75 in)
__________________________ 15

MODEL MX Z X 440
Deflection 30 - 35 mm
(1-3/16-1-3/8in)
Track tension
Force (1) 7.3 kg (16 lb)
Track alignment Equal distance between
edges of track guides and
slider shoes
Drive belt part number 417 300 297
Wear limit width mm (in) 34.7 (1-3/8)
SUSPENSION
Front suspension R.A.S. (A-Arm/sway bar)
Rear suspension SC-4
ELECTRICAL
Lightning system output 360 Watts
Headlamp bulb HI/LOW
beam 2 x 60/55 Watts (H-4)
Type NGK BR9ECS (2)
Spark plug Gap 0.45 ± 0.05 mm
( .018 ± .002 in)
DIMENSIONS
Vehicle overall length mm (in) 2882 (113)
Vehicle overall width mm (in) 1217 47.9)
Vehicle overall height mm (in) 1022 (40)
Official dry weight kg (lb) 197 (435)
Ski stance mm (in) 1080 (42.5)
LIQUIDS
Type
Fuel Minimum octane See RECOMMENDED FUEL
Type XP-S synthetic 2-stroke oil
(P/N293600045)(12x1L)
Mixing oil
Premix ratio 33:1
Brake system fluid SRF (DOT 4) or
GTLMA (DOT 4)
16 _________________________

MODEL MX Z X 440
Chaincase oil type XP-S synthetic chaincase oil
(P/N 413 803 300) (12
x355mL)
Mixture
Ethyl glycol/water mix (50%
coolant, 50% distilled water)
Use coolant specifically
designed for aluminum
engines
Coolant
Premix (P/N 413 711 802)
(16 x 1 L)
Coolant pump shaft oil
XP-S mineral injection
oil (P/N 413 802 900)
(12 x 1 L)
CAPACITIES
Fuel tank L (U.S. gal) 21 (5.5)
Chaincase mL (U.S. oz) 250 (8.5)
Cooling system L (U.S. oz) 3.5 (118)
(1) Measure gap between slider shoe and bottom inside of track when exerting a
downward pull to the track.
(2) CAUTION: Do not attempt to adjust gap on spark plug BR9ECS.
__________________________ 17

18 _________________________
