SKIPIO Salad Series User manual

Commercial
Refrigerator
Service Manual
Under Counter Table / Series Salad/ Dual Table Series
SUR9-1 SUF9-1 SGR9-1 SHR9-1 SSR9-1
SUR12-2 SUF12-2 SGR12-2 SHR12-2 SSR12-2 SURF12-2
SUR15-2 SUF15-2 SGR15-2 SHR15-2 SSR15-2 SURF15-2
SUR18-3 SUF18-3 SGR18-3 SHR18-3 SSR18-3 SURF18-3

1
TABLE OF CONTENTS
Section 1General Information ..................................................................................................................................................................................... 4
1-1. How to use Power Cord ?.......................................................................................................................................................................... 4
1-2. How to disconnect the power cord? .................................................................................................................................................... 4
Section 2Installation Instructions............................................................................................................................................................................... 5
2-1. How to remove packing instructions.................................................................................................................................................... 5
2-2. Location Product ............................................................................................................................................................................................ 6
Section 3 ............................................................................................................................................................................................................................... 7
Product Instructions......................................................................................................................................................................................................... 7
3-1. EXPLODE VIEW................................................................................................................................................................................................ 7
3-1-1. SUR 9-1 / SUF9-1/SGR9-1 Explode View.............................................................................................................................. 7
3-1-2. SHR 9-1 /SSR9-1 Explode View................................................................................................................................................. 8
3-1-3. SUR12-2/ SUF12-2/SGR12-2 Explode View ......................................................................................................................... 9
3-1-4. SHR12-2/SSR12-2 Explode View.............................................................................................................................................10
3-1-5. SURF12-2 Explode View ..............................................................................................................................................................12
3-1-6. SUR15-2/ SUF15-2/SGR15-2 Explode View .......................................................................................................................13
3-1-7. SHR15-2/SSR15-2 Explode View.............................................................................................................................................14
3-1-8. SURF15-2 Explode View ..............................................................................................................................................................15
3-1-9. SUR18-3/ SUF18-3/SGR18-3 Explode View .......................................................................................................................16
3-1-10. SHR18-3/SSR18-3 Explode View ..........................................................................................................................................17
3-1-11. SURF18-3Explode View .............................................................................................................................................................19
3-2. Wiring Diagram.............................................................................................................................................................................................20
3-2-1 (SUR 9-1, SUR12-2, SUR15-2, SUR18-3 SGR 9-1, SGR12-2, SGR15-2, SGR18-3).......................................................20
3-2-2. Wiring Diagram (SUF 9-1, SUF12-2, SUF15-2, SUF18-3) ......................................................................................................20
3-2-3. Wiring Diagram (SHR 9-1, SHR12-2, SHR15-2, SHR18-3 SSR 9-1, SSR12-2, SSR15-2, SSR18-3)......................21
3-2-4. Wiring Diagram ( SURF12-2, SURF15-2, SURF18-3)................................................................................................................21
3-4. PCB Control Instruction.............................................................................................................................................................................22

2
3-3-1. Basic Operation...............................................................................................................................................................................22
3-4. PCB Function Manual.................................................................................................................................................................................23
3-4-1.How to set up manual defrost ..................................................................................................................................................23
3-4-2. How to remove the manual defrosting ...............................................................................................................................23
3-4-3. How to set up the correction of inside temperature....................................................................................................24
3-4-4. Correction Temperature on Display PCB.............................................................................................................................24
3-4-5. Change Model .................................................................................................................................................................................25
3-4-6. Change the defrost cycle............................................................................................................................................................25
3-4-7. Change the deforst temperature............................................................................................................................................26
3-4-8. Change Temperature showing method ...............................................................................................................................26
3-4-9. Control Eva fan motor..................................................................................................................................................................27
3-4-10. Verify Error Code..........................................................................................................................................................................27
3-5. PCB function instructionDry –type model ( REF / FRE) .............................................................................................................28
3-6. COMPRESSOR running、starting、stopping ..................................................................................................................................28
3-6-1. COMP running.................................................................................................................................................................................28
Section 4Replacement Of Main Components ...................................................................................................................................................29
4-1. Mullion Heater replacement ...................................................................................................................................................................29
4-2. Cabinet Heater replacement...................................................................................................................................................................30
4-3. Refrigeration compartment replacement .........................................................................................................................................32
4-4.Remove Counter Top ...................................................................................................................................................................................33
4-5.Remove Evap Motor.....................................................................................................................................................................................34
4-6.Remove Evaporator.......................................................................................................................................................................................35
Section 5Customer Support.......................................................................................................................................................................................36
5-1. MAIN COMPONENTS.................................................................................................................................................................................36
5-1-1.COMPRESSOR....................................................................................................................................................................................36
5-1-2.COMPRESSOR RELAY,OVERLOAD .............................................................................................................................................36
5-1-3.COMPRESSOR CAPACITOR ..........................................................................................................................................................37

3
5-1-4.CONDENSER FAN MOTOR...........................................................................................................................................................37
5-1-5.EVAPORATOR FAN MOTOR .........................................................................................................................................................37
5-2. Filter Dryer ....................................................................................................................................................................................................38
5-3. Defrost Heater.............................................................................................................................................................................................38
5-4. Thermal Fuse................................................................................................................................................................................................38
5-5. Capillary Tube Spec ..................................................................................................................................................................................39
5-6. The cycle pressure of model starting (refrigerant weight).....................................................................................................39
5-7. Service Part list

4
Section 1General Information
1-1. How to use Power Cord?
1-1-1. Be sure not put more plug in the socket. Please use the dedicated outlet.
-Overheated wire, which will cause fire or start malfunction
1-1-2. Wet hands off the power.
- Life is in danger
1-2. How to disconnect the power cord?
☞To prohibit leakage or electric shock, please use the prescript method to connect ground.
1-2-1. if there are grounds connectors for 220v units, units don’t need ground while outlet is for AC 220v. (Please
make sure that there are grounds in buildings, then units can use AC 220v outlets with grounds connectors.)
1-2-2. the power is 220v without ground connector, use dedicated outlet to ground.
A. Please connect earth wire to copper, which will be covered under moisture ground. (The depth is more than
17cm)
- Copper item: thickness: >0.7mm square: >900cm2
B. Please connect the dedicated ground outlet.
1-2-3. Prohibition ground places
Gas pipe Water-pipe Telephone lines

5
Section 2Installation Instructions
2-1. How to remove packing instructions
1
Please set doors of products towards the same direction, tie
the packing stick with ropes.
2
Please cut the PE bag, then remove the packing box.
3
Please remove all the packing parts around the products.
4
Lift up the product, disassemble four screws, and then
remove the packing base.
5
Install the fours casters, insert the kitchen board into the
slot.
6
Caution: 1> Please use dedicated outlet.
2> Please let the unit is grounded while you work.
3> Please connect the power with leakage
protector.

6
2-2. Location Product
1
Be sure to set the unit in door!
To prevent damage, leakage!
2
Be sure that the location be chosen has a strong enough
floor to support total weight of the cabinet and any other
contents.
The uneven will make noise and shake!
3
Be sure to avoid corrosive environment!
It will shorten the life of the unit
4
Be sure no object is on top of the product!
The objects will fall to hit the unit!
5
Be sure to avoid damp and dusty environment!
Electric shock
6
Be sure the unit is away from the wall at least 15 ㎝!
Good air circulation
7
Be sure the power cord is connected to the proper voltage!
The Product is special for 220V
It can’t be used with the voltage of 110V
Please connect the power with leakage protector!
8
Please use the casters or legs.

7
Section 3
Product Instructions
3-1. EXPLODE VIEW
3-1-1. SUR 9-1 / SUF9-1/SGR9-1 Explode View
NO
Part Cord
Part Name
No
Part Cord
Part Name
1
KR81410400
MAIN PCB
14
KU91100100
CABINET ASSY
2
KR81410300
FRONT PCB
15
KR92100302
UNIT BRACKET
3
KR81410704
UNIT FRONT COVER
16
KR81900104
UNIT SAID COVER
4
KR89910100
BOTTOM HINGE(R)
17
KF24900105
CONDENSER ASSYREF
30229M0405
BOTTOM HINGE(R)GLASS
5
KR5AF00102
DOOR(R)_1500
18
KF84900105
CONDENSER ASSYFRE
JG5AF00206
ASS'Y GLASS DOOR R
KR94200109
SUCTION PIPE(B)REF
6
KR89910402
TOP HINGE(R)
19
KR84200109
SUCTION PIPE(B)FRE
M722900108
TOP HINGE(R)GLASS
G2R5700200
COMP REF LX110 REF
7
KR91800201
EVAP DRAIN GUIDE
20
G5R5700200
COMP FRE LX125 FRE
BR84100100
FILTER DRYER
8
KR91800102
AIR GUIDE(L/R)
21
M729300102
DRAIN PAN
9
KF81700100
EVA DUCT
22
G8F5000200
CONDENSER FAN OTOR
10
G8F5000100
EVA FAN MOTOR
23
KF82100208
UNIT SIDE BRACKET(A)
11
DK9A100103
EVAP-ASSY(공용)
24
K3F3200901
LEVEL FOOT&CASTER
12
KR9FF00100
COUNTER TOP
25
KG81200100
SMPS
13
KF85220305
EVA FAN AIR GUIDE
26
KG99600102
LED LAMP

8
3-1-2. SHR 9-1 /SSR9-1 Explode View
SHR9-1
SSR9-1

9
No
Part Cord
Part Name
No
Part Cord
Part Name
1
KR81410400
MAIN PCB
16
BR9AB00100
CABINET ASSY
2
KR81410300
FRONT PCB
17
KR92100302
UNIT BRACKET
3
KR81410704
UNIT FRONT COVER
18
KR81900104
UNIT SAID COVER
4
KR89910100
BOTTOM HINGE(R)
19
KF24900105
CONDENSER ASSY 9 12 15
5
KR5AF00102
DOOR(R)_1500
KF84900105
CONDENSER ASSY 18
6
KR89910402
TOP HINGE(R)
20
BR94200206
SUCTION PIPE(B)
7
U609000103
FAN COVER
21
G2R5700200
COMP REF LX110 9 12 15
8
BR91H00100
EVA DUCT SHR
G5R5700200
COMP FRE LX125 18
BR91700106
EVA DUCT SSR
22
23
BR84100100
FILTER DRYER
9
CM25000101
EVA FAN MOTOR
M729300102
DRAIN PAN
10
BR9AD00103
EVAP-ASSY
24
G8F5000200
CONDENSER FAN MOTOR
11
BR91900103
EVA DRAIN GUIDE
25
KF82100208
UNIT SIDE BRACKET(A)
12
S722500104
PAN GUIDE
26
K3F3200901
LEVEL FOOT&CASTER
BR81800400
PAN GUIDE
27
S728900302
HOOD LID
13
BR81800301
PAN GUIDE
28
S725600501
HOOD
14
BS90900100
PAN SUPPORTER SHR
BR91800200
PAN SUPPORTER SSR
15
BS9FE00100
COUNTER TOP SHR
BR9FF00100
COUNTER TOP SSR
3-1-3. SUR12-2/ SUF12-2/SGR12-2Explode View

10
No
Part Cord
Part Name
No
Part Cord
Part Name
1
KR81410400
MAIN PCB
14
DK84400107
EVAP ASSY FRE
2
KR81410300
FRONT PCB
15
KR2FF00100
COUNTER TOP
3
KR81410704
UNIT FRONT COVER
16
KF85220305
EVAP FAN AIR GUIDE
4
KR89940100
BOTTOM HINGE(L)
17
KU21000100
CABINET ASSY
30229M0305
BOTTOM HINGE(L)GLASS
18
KR92100301
UNIT BRACKET
5
KR89910302
TOP HINGE(L)
19
KR81900104
UNIT SAID COVER
M722900208
TOP HINGE(L)GLASS
20
KF24900105
CONDENSER ASSY REF
6
KR2AF00202
DOOR(L)_1200
KF84900105
CONDENSER ASSY FRE
JG2AF00105
ASS'Y GLASS DOOR L
21
KR94200109
SUCTION PIPE(B) REF
7
KR89910100
BOTTOM HINGE(R)
KR84200109
SUCTION PIPE(B) FRE
30229M0405
BOTTOM HINGE(R)GLASS
22
G2R5700200
COMP LX110 REF
8
KR2AF00102
DOOR(R)_1200
G5R5700200
COMP LX125 FRE
JG2AF00205
ASS'Y GLASS DOOR R
23
BR84100100
DRYER
9
KR89910402
TOP HINGE(R)
24
M729300102
DRAIN PAN
M722900108
TOP HINGE(R)GLASS
25
G8F5000200
CONDENSER FAN MOTOR
10
KR91800201
EVAP DRAIN GUIDE
26
KF82100208
UNIT BRACKET(A)
11
KR91800102
AIR GUIDE(L/R)
27
K3F3200901
LEVEL FOOT&CASTER
12
KF81700100
EVA DUCT
28
KG81200100
SMPS
13
G8F5000100
EVA FAN MOTOR
29
KG99600102
LED LAMP
14
DK9A100103
EVAPASSY REF
3-1-4. SHR12-2/SSR12-2Explode View
SHR12-2

11
SSR12-2
No
Part Cord
Part Name
No
Part Cord
Part Name
1
KR81410400
MAIN PCB
16
BR2AB00100
CABINET ASSY
2
KR81410300
FRONT PCB
17
KR92100302
UNIT BRACKET
3
KR81410704
UNIT FRONT COVER
18
KR81900104
UNIT SAID COVER
4
5
KR89910100
BOTTOM HINGE(R)
19
KF24900105
CONDENSER ASSYREF
KR2AF00102
DOOR(R)_1200
KF84900105
CONDENSER ASSYFRE
6
7
KR89910402
TOP HINGE(R)
20
BR24200105
SUCTION PIPE(B) 12 15
U609000103
FAN COVER
21
G2R5700200
COMP REF LX110 REF
8
BR21H00100
EVA DUCT SHR
G5R5700200
COMP FRE LX125 FRE
BR21700107
EVA DUCT SSR
22
BR84100100
FILTER DRYER
9
CM25000101
EVA FAN MOTOR
23
M729300102
DRAIN PAN
10
BR2AD00103
EVAP-ASSY
24
G8F5000200
CONDENSER FAN OTOR
11
BR21900104
EVA DRAIN GUIDE
25
KF82100208
UNIT SIDE BRACKET(A)
12
S722500104
PAN GUIDE
26
K3F3200901
LEVEL FOOT&CASTER
BR81800400
PAN GUIDE
27
KR89940100
BOTTOM HINGE(L)
13
BR81800301
PAN GUIDE
28
KR2AF00202
DOOR(L)_1200
14
BS20900100
PAN SUPPORTER SHR
29
KR89910302
TOP HINGE(L)
BR21800200
PAN SUPPORTER SSR
30
S488900302
HOOD LID
15
BS2FE00100
COUNTER TOP SHR
31
S485600202
HOOD
BR2FF00100
COUNTER TOP SSR

12
3-1-5. SURF12-2 Explode View
No
Part Cord
Part Name
No
Part Cord
Part Name
1
KRF2500700
MAIN PCB
15
KR2FF00100
COUNTER TOP
2
KRF2500600
FRONT PCB
16
KF85220305
EVAP FAN AIR GUIDE
3
KR81410704
UNIT FRONT COVER
17
KRF2000100
CABINET ASSY
4
KR89940100
BOTTOM HINGE(L)
18
KR92100301
UNIT BRACKET
5
KR89910302
TOP HINGE(L)
19
KR81900104
UNIT SAID COVER
6
KR2AF00202
DOOR(L)_1200
20
KF84900105
CONDENSER ASSY
7
KR89910100
BOTTOM HINGE(R)
21
KRF2600201
SUCTION PIPE(B)
8
KR2AF00102
DOOR(R)_1200
22
G5R5700200
COMP LX125
9
KR89910402
TOP HINGE(R)
23
BR84100100
DRYER
10
KRF2900100
EVA DRAIN GUIDE REF
24
M729300102
DRAIN PAN
KR91800203
EVA DRAIN GUIDE FRE
25
G8F5000200
CONDENSER FAN MOTOR
11
U609000103
FAN COVER REF
26
KF82100208
UNIT BRACKET(A)
12
KRF2100400
EVAP DUCT REF
27
K3F3200901
LEVEL FOOT&CASTER
KF81700104
EVAP DUCT FRE
28
KG81200100
SMPS
13
CM25000101
EVA FAN MOTOR REF
29
KG99600102
LED LAMP
G8F5000100
EVA FAN MOTOR FRE
30
KR91800102
AIR GUIDE(L/R)
14
KRF1222100
EVAP ASSY REF
31
K1D6900100
STRING MOTOR
DK9AI00104
EVAP ASSY FRE

13
3-1-6. SUR15-2/ SUF15-2/SGR15-2Explode View
No
Part Cord
Part Name
No
Part Cord
Part Name
1
KR81410400
MAIN PCB
14
DK84400107
EVAP ASSY FRE
2
KR81410300
FRONT PCB
15
KR2FF00100
COUNTER TOP
3
KR81410704
UNIT FRONT COVER
16
KF85220305
EVAP FAN AIR GUIDE
4
KR89940100
BOTTOM HINGE(L)
17
KU21000100
CABINET ASSY
30229M0305
BOTTOM HINGE(L)GLASS
18
KR92100301
UNIT BRACKET
5
KR89910302
TOP HINGE(L)
19
KR81900104
UNIT SAID COVER
M722900208
TOP HINGE(L)GLASS
20
KF24900105
CONDENSER ASSY REF
6
KR5AF00202
DOOR(L)_1500
KF84900105
CONDENSER ASSY FRE
JG5AF00105
ASS'Y GLASS DOOR L
21
KR94200109
SUCTION PIPE(B) REF
7
KR89910100
BOTTOM HINGE(R)
KR84200109
SUCTION PIPE(B) FRE
30229M0405
BOTTOM HINGE(R)GLASS
22
G2R5700200
COMP LX110 REF
8
KR5AF00102
DOOR(R)_1500
G5R5700200
COMP LX125 FRE
JG5AF00205
ASS'Y GLASS DOOR R
23
BR84100100
DRYER
9
KR89910402
TOP HINGE(R)
24
M729300102
DRAIN PAN
M722900108
TOP HINGE(R)GLASS
25
G8F5000200
CONDENSER FAN MOTOR
10
KR91800201
EVAP DRAIN GUIDE
26
KF82100208
UNIT BRACKET(A)
11
KR91800102
AIR GUIDE(L/R)
27
K3F3200901
LEVEL FOOT&CASTER
12
KF81700100
EVA DUCT
28
KG81200100
SMPS
13
G8F5000100
EVA FAN MOTOR
29
KG59600102
LED LAMP
14
DK9A100103
EVAPASSY REF

14
3-1-7. SHR15-2/SSR15-2Explode View
SHR15-2
SSR15-2
No
Part Cord
Part Name
No
Part Cord
Part Name
1
KR81410400
MAIN PCB
16
BR5AB00100
CABINET ASSY
2
KR81410300
FRONT PCB
17
KR92100302
UNIT BRACKET
3
KR81410704
UNIT FRONT COVER
18
KR81900104
UNIT SAID COVER
4
5
KR89910100
BOTTOM HINGE(R)
19
KF24900105
CONDENSER ASSYREF
KR5AF00102
DOOR(R)_1500
19
KF84900105
CONDENSER ASSYFRE

15
6
KR89910402
TOP HINGE(R)
20
BR24200105
SUCTION PIPE(B) 12 15
7
U609000103
FAN COVER
21
G2R5700200
COMP REF LX110 REF
8
BR51H00100
EVA DUCT SHR
G5R5700200
COMP FRE LX125 FRE
BR51700108
EVA DUCT SSR
22
BR84100100
FILTER DRYER
9
CM25000101
EVA FAN MOTOR
23
M729300102
DRAIN PAN
10
BR2AD00103
EVAP-ASSY
24
G8F5000200
CONDENSER FAN OTOR
11
BR21900104
EVA DRAIN GUIDE
25
KF82100208
UNIT SIDE BRACKET(A)
12
S722500104
PAN GUIDE
26
K3F3200901
LEVEL FOOT&CASTER
BR81800400
PAN GUIDE
27
KR89940100
BOTTOM HINGE(L)
13
BR81800301
PAN GUIDE
28
KR5AF00202
DOOR(L)_1500
14
BS50900100
PAN SUPPORTER SHR
29
KR89910302
TOP HINGE(L)
BR51800200
PAN SUPPORTER SSR
30
BS50200100
HOOD LID
15
BS5FE00100
COUNTER TOP SHR
31
BS50100100
HOOD
BR5FF00100
COUNTER TOP SSR
3-1-8. SURF15-2 Explode View
No
Part Cord
Part Name
No
Part Cord
Part Name
1
KRF2500700
MAIN PCB
15
KR5FF00100
COUNTER TOP
2
KRF2500600
FRONT PCB
16
KF85220305
EVAP FAN AIR GUIDE
3
KR81410704
UNIT FRONT COVER
17
KRF5000100
CABINET ASSY
4
KR89940100
BOTTOM HINGE(L)
18
KR92100301
UNIT BRACKET
5
KR89910302
TOP HINGE(L)
19
KR81900104
UNIT SAID COVER

16
6
KR5AF00202
DOOR(L)_1500
20
KF84900105
CONDENSER ASSY
7
KR89910100
BOTTOM HINGE(R)
21
KRF2600201
SUCTION PIPE(B)
8
KR5AF00102
DOOR(R)_1500
22
NEK2150GK
9
KR89910402
TOP HINGE(R)
23
BR84100100
DRYER
10
KRF5900100
EVA DRAIN GUIDE REF
24
M729300102
DRAIN PAN
KR91800203
EVA DRAIN GUIDE FRE
25
G8F5000200
CONDENSER FAN MOTOR
11
U609000103
FAN COVER REF
26
KF82100208
UNIT BRACKET(A)
12
KRF5200400
EVAP DUCT REF
27
K3F3200901
LEVEL FOOT&CASTER
KF81700104
EVAP DUCT FRE
28
KG81200100
SMPS
13
CM25000101
EVA FAN MOTOR REF
29
KG99600102
LED LAMP
G8F5000100
EVA FAN MOTOR FRE
30
KR91800102
AIR GUIDE(L/R)
14
KRF1522100
EVAP ASSY REF
31
K1D6900100
STRING MOTOR
DK9AI00104
EVAP ASSY FRE
3-1-9. SUR18-3/ SUF18-3/SGR18-3Explode View
No
Part Cord
Part Name
No
Part Cord
Part Name
1
KR81410400
MAIN PCB
15
DK84400107
EVAP ASSY FRE
2
KR81410300
FRONT PCB
16
KR8FF00100
COUNTER TOP
3
KR81410704
UNIT FRONT COVER
17
KF85220305
EVAP FAN AIR GUIDE
4
KR89940100
BOTTOM HINGE(L)
18
KU81000100
CABINET ASSY
30229M0305
BOTTOM HINGE(L)GLASS
19
KR92100301
UNIT BRACKET
5
KR89910302
TOP HINGE(L)
20
KR81900104
UNIT SAID COVER
M722900208
TOP HINGE(L)GLASS
21
KF84900104
CONDENSER ASSY
6
KR8AF00202
DOOR(L)_1800
22
KR94200109
SUCTION PIPE(B) REF
JG8AF00105
ASS'Y GLASS DOOR L
KR74200103
SUCTION PIPE(B) FRE
7
KR89910100
BOTTOM HINGE(R)
23
G5R5700200
COMP LX125 REF

17
30229M0405
BOTTOM HINGE(R)GLASS
COMP NEK2150GK FRE
8
KR8AF00302
DOOR_1800(M)
24
BR84100100
DRYER
JG8AF00205
ASS'Y GLASS DOOR R
25
M729300102
DRAIN PAN
9
M722900106
DOOR_1800(R)
26
G8F5000200
CONDENSER FAN MOTOR
JG8AF00205
ASS'Y GLASS DOOR R
27
KF82100208
UNIT BRACKET(A)
10
KR89910402
TOP HINGE(R)
28
K3F3200901
LEVEL FOOT&CASTER
M722900108
TOP HINGE(R)GLASS
29
KG81200100
SMPS
11
KR91800201
EVAP DRAIN GUIDE
30
KG89600102
LED LAMP
12
KR91800102
AIR GUIDE(L/R)
13
KF81700100
EVA DUCT
14
G8F5000100
EVA FAN MOTOR
15
DK8A100104
EVAP ASSY REF
3-1-10. SHR18-3/SSR18-3Explode View
SHR18-3

18
SSR18-3
No
Part Cord
Part Name
No
Part Cord
Part Name
1
KR81410400
MAIN PCB
16
BR8AB00100
CABINET ASSY
2
KR81410300
FRONT PCB
17
KR92100302
UNIT BRACKET
3
KR81410704
UNIT FRONT COVER
18
KR81900104
UNIT SAID COVER
4
5
KR89910100
BOTTOM HINGE(R)
19
KF24900105
CONDENSER ASSYREF
KR8AF00102
DOOR(R)_1200
KF84900105
CONDENSER ASSYFRE
6
7
KR89910402
TOP HINGE(R)
20
BR84200105
SUCTION PIPE(B) 18
U609000103
FAN COVER
21
G2R5700200
COMP REF LX110 REF
8
BR81H00100
EVA DUCT SHR
G5R5700200
COMP FRE LX125 FRE
BR81700106
EVA DUCT SSR
22
BR84100100
FILTER DRYER
9
CM25000101
EVA FAN MOTOR
23
24
M729300102
DRAIN PAN
10
BR8AD00103
EVAP-ASSY
G8F5000200
CONDENSER FAN OTOR
11
BR81900103
EVA DRAIN GUIDE
25
KF82100208
UNIT SIDE BRACKET(A)
12
S722500104
PAN GUIDE
26
K3F3200901
LEVEL FOOT&CASTER
BR81800400
PAN GUIDE
27
KR89940100
BOTTOM HINGE(L)
13
BR81800301
PAN GUIDE
28
KR8AF00202
DOOR(L)_1800
14
BS80900100
PAN SUPPORTER SHR
29
KR89910302
TOP HINGE(L)
BR81800200
PAN SUPPORTER SSR
30
KR8AF00302
DOOR(M)_1800
15
BS8FE00100
COUNTER TOP SHR
31
S488900302
HOOD LID
S728900302
HOOD LID
BR8FF00100
COUNTER TOP SSR
32
S485600202
HOOD
S725600501
HOOD

19
3-1-11. SURF18-3Explode View
No
Part Cord
Part Name
No
Part Cord
Part Name
1
KRF2500700
MAIN PCB
16
KF85220305
EVAP FAN AIR GUIDE
2
KRF2500600
FRONT PCB
17
KRF8000100
CABINET ASSY
3
KR81410704
UNIT FRONT COVER
18
KR92100301
UNIT BRACKET
4
KR89940100
BOTTOM HINGE(L)
19
KR81900104
UNIT SAID COVER
5
KR89910302
TOP HINGE(L)
20
KF84900105
CONDENSER ASSY
6
KR8AF00202
DOOR(L)_1800
21
KRF2600201
SUCTION PIPE(B)
7
KR89910100
BOTTOM HINGE(R)
22
NEK2150GK
8
KR8AF00102
DOOR(R)_1800
23
BR84100100
DRYER
9
KR89910402
TOP HINGE(R)
24
M729300102
DRAIN PAN
10
BR91900101
EVA DRAIN GUIDE REF
25
G8F5000200
CONDENSER FAN MOTOR
KR91800203
EVA DRAIN GUIDE FRE
26
KF82100208
UNIT BRACKET(A)
11
U609000103
FAN COVER REF
27
K3F3200901
LEVEL FOOT&CASTER
12
KRF8100600
EVAP DUCT REF
28
KG81200100
SMPS
KF81700104
EVAP DUCT FRE
29
KG99600102
LED LAMP FRE
13
CM25000101
EVA FAN MOTOR REF
KG59600102
LED LAMP REF
G8F5000100
EVA FAN MOTOR FRE
30
KR91800102
AIR GUIDE(L/R)
14
KRF1822100
EVAP ASSY REF
31
K1D6900100
STRING MOTOR
DK9AI00104
EVAP ASSY FRE
32
KR8AF00302
DOOR(M)_1800
15
KR8FF00100
COUNTER TOP
This manual suits for next models
24
Table of contents
Popular Refrigerator manuals by other brands

Brandt
Brandt BFC644ZNX instruction manual

LG
LG LFX28995 Series Service manual

Monogram
Monogram ZIS36N Custom options guide and installation instructions

LG
LG LFX29927SB owner's manual

Kuppersbusch
Kuppersbusch CN228220X Instructions for use

Hotpoint
Hotpoint 22 Series Owner's manual and installation instructions
