Skytech FK-180-ESC Service manual

Skytech FK-180-ESC REV 2-26-18 Page 1
Fan
Ground Wire
Power Wires

Electronic
Fan Speed Control
HI
MH
ML
LO
OFF
FAN
SPEED TEST
FANTURNS ON TO
SELECTED SPEED
7 MINUTES AFTER MAIN
FLAME IS TURNED ON
FANTURNS OFF
12 MINUTES AFTER MAIN
FLAME IS TURNED OFF
TEST WILL TURN FAN
ON HIGH AS LONG AS
BUTTON IS PRESSED
2 - 1/4” Female
Connectors
1 - 1/4” Female
Connector
1- 1/4” Ring Connector
1- Polorized Plug

1 - 3/16” Piggyback Connector
1 - 1/4” Male Connector

Model: FK-180-ESC
INSTALLATION AND OPERATION INSTRUCTIONS
INTRODUCTION
1/4” Female Connectors

1
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE
2
34
The FK-180-ESC Fan Kit has been designed to circulate room air through many hearth products in the industry. The FK-
180-ESC operates on 120VAC, 60Hz power. The fan dimensions are 12-3/4” W x 4-3/8” H x 4-5/16” D.
Power must be provided through an approved factory installed junction box from the hearth product’s manufacturer.
A speed control (FK-ESC) is provided with the Fan Kit System to adjust the air output. The speed control will turn ON the
fan automatically 7 minutes after the main ame has been turned ON and turn the fan OFF 12 minutes after the main
ame has been turn OFF. There are four speeds, Hi, Medium Hi, Medium Lo, Lo and OFF. You can manually adjust the
speed by pressing the FAN SPEED button on the FK-ESC. The FK-ESC will remember the last setting used and remain
on that setting until changed.
Compare the contents of your package with the gure drawings below.
1. F-180-1 Fan with two leads and a ground wire
2. FK-ESC (speed control)
3. Jumper Wire (used for IPI valves only)
4. Jumper Wire (used to jump power strip when applicable)

Skytech FK-180-ESC REV 2-26-18 Page 2
PRECAUTIONS
Please read all the instructions before proceeding with installation.
CAUTION: a qualied electrician should complete all wiring. Install following all local codes and in compliance with the
National Electric Code ANSI/AFPA NO. 70 or CSA C22.1 for all of North America.
1/8” to 1/4” Gap
Magnetic Feet

INSTALLATION
WARNING: Turn electrical power OFF at the circuit breaker before beginning
this installation.
1. Unplug the old fan system (if applicable) and remove it from the appliance.
2. Attach the FK-ESC wires to the F-180-1 fan as shown in the wiring diagram below.
3. Install the new F-180-1 fan housing in the rear of the appliance where the previous
fan was installed.
4. Pull the fan housing slightly away from the metal back wall (1/8’’ to 1/4’’) of the
appliance. The magnetic feet will hold the housing in place. (See Fig. 1)
5. Attach the F-180-1 fan ground (green) wire to an accessible ground source.
6. Plug the FK-ESC into an approved electrical junction box and lay inside appliance
accessible for operation.
7. If installing this kit into an appliance with a Millivolt valve system use gure #2. If
installing this kit into an IPI electronic system use gure #3. Fig 1. Side View
Electronic
Fan Speed Control
HI
MH
ML
LO
OFF
FAN
SPEED TEST
FAN TURNS ON TO
SELECTED SPEED
7 MINUTES AFTER MAIN
FLAME IS TURNED ON
FAN TURNS OFF
12 MINUTES AFTER MAIN
FLAME IS TURNED OFF
TEST WILL TURN FAN
ON HIGH AS LONG AS
BUTTON IS PRESSED
Fan Hot (Black)
Fan Netural
(white)
120VAC
Power
Source
Sense -
(black)
Sense +
(red)
Ground
(green)
TH
TP
TH
TP
Millivolt Valve
Terminal
Thermopile
White Red
F-180-1 Fan
FK-ESC
Fig. 2 Millivolt wiring diagram
WIRING NOTES: This is a polarity sensitive system. Ensure you wire it exactly as shown in the dia-
gram above. Thermopile wires must also be located with Red at TH/TP and White at TP on the gas
valve.

Skytech FK-180-ESC REV 2-26-18 Page 3
Fig. 3. IPI Wiring Diagram
WIRING NOTES: IPI System - When wiring an IPI system the Sense – (black) wire must be secure
to a ground on the gas valve or to metal on the appliance for proper operation.
POWER SOURCE INFORMATION
When plugging in the FK-ESC into a 120VAC power source some replaces use a standard metal junction box and other
replaces may use a power strip. If a power strip is used (as shown below in gure 4) and no power is found in the FAN
outlet use the red jumper wire with the 1/4” connectors and attach as shown below. With the jumper installed the FAN
outlet will provide the power necessary to operate the FK180-1 system.
1/4” Female Connectors

Fig. 4 Power strip jumper connection
NEUTRAL
HOT
5 4 3 2 1
5 4 3 2 1
FAN
REM/AUX
TRANS
Jumper
Wire
Power Strip
Electronic
Fan Speed Control
HI
MH
ML
LO
OFF
FAN
SPEED TEST
FANTURNS ON TO
SELECTED SPEED
7 MINUTES AFTER MAIN
FLAME IS TURNED ON
FANTURNS OFF
12 MINUTES AFTER MAIN
FLAME IS TURNED OFF
TEST WILL TURN FAN
ON HIGH AS LONG AS
BUTTON IS PRESSED
Fan Hot (Black)
Fan Netural
(white)
120VAC
Power
Source
Sense -
(black)
Sense +
(red)
Ground
(green)
Dexen
or SIT IPI
Valves
Jumper Wire
(red)
Disconnect the 3/16” connector
from main coil of gas valve. Place
red jumper with piggyback
connector to valve and reconnect
the main coil wire removed from
valve to piggyback connector.
Main Coil Wire
of Gas Valve

Skytech FK-180-ESC REV 2-26-18 Page 4
OPERATION
The speed control will turn ON the fan automatically 7 minutes after the main  ame has been turned ON and turn the fan
OFF 12 minutes after the main  ame has been turn OFF. There are four speeds, Hi, Medium Hi, Medium Lo, Lo and OFF.
Manually adjust fan speed by pressing the FAN SPEED button on the FK-ESC.
To check the fan for proper wiring press the TEST button. This is a manual override that will operate the fan on HI as long
as the button is depressed. The FK-ESC will remember the last setting used and remain on that setting until changed.
OPTIONAL ACCESSORIES
16 SPT 2 – Optional 16-inch extension cord to plug into junction box for greater mobility of the FK-ESC.
MAINTENANCE
Cleaning on a semi-annual basis is required to keep the warranty in place. Dust or dirt must be removed from the fan
blades, air inlets and blower outlet for the fan kit to maintain the ef ciency of the system. Carefully use a vacuum with a
brush to remove any dust. If unable to reach fan with a vacuum remove the fan from the appliance for easier cleaning.


Recognized component according to UL 1004-1 and UL 1004-3 and CSA C22.2 No. 100-04 and CSA C22.2
No 77-95 R2004
TWO YEAR LIMITED WARRANTY
SKYTECH II warrants this fan system for two years or 24 months from the date of purchase to the original owner. This
warranty is NOT transferable to another person. Should any part fail because of defective workmanship or material from
the original date of purchase SKYTECH II will repair or replace the part at SKYTECH II option.
Damage to the Fan system caused by accident, misuse, abuse, or installation error, whether by a contractor, service com-
pany, or owner is not covered by this warranty. Modi cation of the Fan System will void the warranty.
The owner must provide a bill of sale, to verify purchase date and establish warranty period. SKYTECH II is not respon-
sible for: Travel expenses, Diagnostic costs, and Service labor to repair the defective Fan system. Freight charges will not
be covered on warranty parts or Fan systems.
This warranty does not cover claims, which do not involve defective workmanship or materials.
IN NO EVENT SHALL SKYTECH II BE LIABLE FOR INCIDENTAL AND CONSEQUENTIAL OCCURRENCES, INCLUD-
ING THE IMPLIED WARRANTIES OR MERCHANTABILITY AND FITNESS, ARE LIMITED TO THE DURATION OF THE
THIS WRITTEN WARRANTY. THIS WARRANTY SUPERSEDES ALL OTHER ORAL OR WRITTEN WARRANTIES.
Some states do not allow the exclusion or limitation of incidental and consequential damages or limitation on how long an
implied warranty lasts, so the above limitation may not apply to you. This warranty gives you speci c rights and you may
have other rights, which vary from state, province, and nation.
Warranty claims process will start with all information; SKYTECH II will reserve the right to physically inspect the product
for defects, by authorized representatives.
FOR TECH SERVICE, CALL [phone]
Skytech Products Group
9230 Conservation Way
Fort Wayne, IN 46809
Sales Support: [phone]
Canadian Inquires: [phone]
www.skytechpg.com
