skyvoe NXG-4K User manual

Owner’s Manual
Weatherproof Televisions
IMPORTANT:
Please read this owners manual before
starting or operating the equipment.
NXG-4K
MODEL:
2160P
2160P
4K

Dear SkyVue Customer,
Congratulations on purchasing your new outdoor weather-proof television. We welcome you to our
SkyVue family. To gain the full potential of your new SkyVue Outdoor Television, please read carefully the
instructions within this document. There is a wealth of relevant information to get started and fully utilize all
of the unique capabilities of your new SkyVue Outdoor Television. We sincerely thank you for your purchase
and hope you have several years of enjoyment from your new SkyVue Outdoor Television.
We at SkyVue have taken a studied approach to delivering the highest quality and reliable outdoor
television on the market. SkyVue started with the goals of operating with unparalleled customer service
and extensive research and development. Upon extensive research of national competition, we realized that
yet, all outdoor television manufacturers purchase the circuitry and panels in their products overseas; that
SkyVue is the only manufacturer that completes its designs with all American Made products. Our family
of televisions are re-innovating the ideas, functions, and technologies, in which other outdoor television
manufacturers seemed to have missed. We take pride in every product and are glad to have you as part of
our family.
Customer Service can be directly reached at:
1-(877) 4-SkyVue
1-[phone]
[e-mail]
To inquire about extended warranty information, accessories, or installation FAQs please visit our website
www.skyvue.com.
We Thank You for Your Support,
The SkyVue Management Team

3Table of ConTenTs |Operator’s Manual - Model NXG-4k
Table of Contents
Welcome .......................................................................................................................... 1
TV Models - PS .........................................................................................4
TV Location and Placement - PS..............................................................5
TV Models - FS .........................................................................................6
TV Location and Placement - FS..............................................................7
Important and Safety Information ............................................................8
Unpacking ..................................................................................................................... 14
Rear Panel Component Source...................................................................................... 14
Rear Panel Component Quality...................................................................................... 15
Rear Panel Connections................................................................................................. 16
Manual Controls On TV ................................................................................................. 18
Front Panel Lights and Sensors ..................................................................................... 18
Remote Control Guide ................................................................................................... 19
On-Screen Display (OSD) Functions .............................................................................. 20
On-Screen Display Menu ............................................................................................... 21
Channel Menu ................................................................................................................ 21
Picture Menu.................................................................................................................. 21
Audio Menu.................................................................................................................... 21
Time Menu ..................................................................................................................... 22
Setup Menu.................................................................................................................... 22
Lock Menu ..................................................................................................................... 22
Adjusting On-Screen Displays - Channel Menu ............................................................. 23
Adjusting On-Screen Displays – Picture Menu............................................................... 25
Adjusting On-Screen Displays – Audio Menu................................................................. 26
Adjusting On-Screen Displays – Time Menu .................................................................. 28
Adjusting On-Screen Displays – Setup Menu ................................................................ 30
Adjusting On-Screen Displays – Lock Menu .................................................................. 32
Using the USB Input ...................................................................................................... 35
Troubleshooting.............................................................................................................. 37
Care of SkyVue Outdoor TV ........................................................................................... 39
TV Care & Policy Information .................................................................40
RS232 Control Codes ............................................................................41

4All Rights Reserved. SkyVue®
TV Models - Partial Sun
NXG 4k - Partial Shade
Built for shaded areas that are exposed very limited sunlight.
Location of
Manual Controls Panel
Location of
Manual Controls Panel
43” NXG 4k 500 &700 Nit
55” NXG 4k 500 & 700 Nit

5Owner’s Manual - Model NXG-4k Important InformatIon |
Locations for the TV - Partial Shade
Important: The TV must be installed at least 5 feet from pool, spa, or other body of water.
The Partial Shade TV models should be installed so the screen is not in direct sunlight, if installing in sunlight TV
should be turned away from direct sunlight. Placement should be in an area where the TV viewing is shaded
by trees, landscape and/or structures, or under a patio cover or gazebo. Remember that the position of the
sun changes during the day, as seen in the below. This means that the quality of the picture will change during the
day. If you intend to install the TV in areas where some sunlight will reach it, it’s best to position the TV for optimum
performance during the time of day when you do most of your TV viewing. If the sun shines directly on the TV for
extended periods of time, dark areas may develop on the screen. This may cause permanent damage to the screen
over time.
Sunrise Sunset
Afternoon
TV Placment & Location - Partial Shade
Mounting Placment / Orientation
All Skyvue Landscape TV models should be installed so that the television is in a landscape orientation. Mounting
the television incorrectly may cause damage to the television over time and will void the manufacturers warranty.
The gure below displays the correct orientation.

6All Rights Reserved. SkyVue®
TV Models - Full Sun
NXG 4k - Full Sun
Built for Sun exposed areas that will experience direct sunlight.
Location of
Manual Controls Panel
Location of
Manual Controls Panel
43” NXG 4k 500 & 700 Nit
55” NXG 4k 500 & 700 Nit
75” NXG 4k 1500 & 3000 Nit
Location of
Manual Controls Panel

7Owner’s Manual - Model NXG-4k Important InformatIon |
Locations for the TV - Full Sun
Important: The TV must be installed at least 5 feet from pool, spa, or other body of water.
The Full Sun TV model should be installed so the screen is not facing direct sunlight, or can be easily turned away
from direct sunlight. Ideal placement is still in an area where the TV is shaded by trees, landscape and/or structures, or
under a patio cover or gazebo. Remember that the position of the sun changes during the day, as seen in the drawing
on the right. This means that the quality of the picture will change during the day. If you intend to install the TV in areas
where direct sunlight will reach it, it’s best to position the TV for optimum performance during the time of day when
you do most of your TV viewing. If the sun shines directly on the screen for extended periods of time, dark areas may
develop on the screen. This is a normal reaction for the LED panel, and will not cause damage to the screen. Either
turn the screen away from the sun, or apply shade to the TV, and the dark areas will quickly disappear.
Sunrise Sunset
Afternoon
TV Placment & Location - Full Sun
Mounting Placment / Orientation
All Skyvue Landscape TV models should be installed so that the television is in a landscape orientation. Mounting
the television incorrectly may cause damage to the television over time and will void the manufacturers warranty.
The gure below displays the correct orientation.

8All Rights Reserved. SkyVue®
The lightning flash with arrow-head
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous
voltage” within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within a
triangle is intended to alert the user
to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the product.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE
SLOT, FULLY INSERT.
CAUTION:
WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly
approved by the manufacturer could void the user's authority to operate this equipment.
OPERATION MANUAL
IMPORTANT:
To aid reporting in case of loss or theft, please record the
TV's model and serial numbers in the space provided. The
numbers are located at the rear of the TV.
LED TELEVISION
ENGLISH
IMPORTANT INFORMATION
LC-60LE632U70LE732UE.indb1 2011/02/0416:19:25
2012 SKYVUE 3
SKY4230 & SKY4630
2012 SKYVUE 3

9Owner’s Manual - Model NXG-4k Important InformatIon |
INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
DECLARATION OF CONFORMITY:
0364YKS&0224YKS
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
RESPONSIBLE PARTY:
Skyvue Television
2218 N. Dawson Drive, Chester, SC 29706
TEL: [phone]
Visit us online at www.skyvue.com
“Note to CATV system installer: This reminder is provided to call the CATV system installer's attention to Article 820 of the National
Electrical Code that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as practical.”
FCC Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Wireless Radio
For product available in the USA/Canada market, only channel 1–11 can be operated. Selection of other channels is not possible.
This device is going to be operated in 5.15–5.25GHz frequency range, it is restricted in indoor environment only.
Important: Any changes or modifications not expr essly appr oved by the party responsible for compliance could void the user’s
authority to operate the equipment.
FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation of the device. This device and its antenna(s) must not be colocated or
operation in conjunction with any other antenna or transmitter.
Wireless Radio
For product available in the USA/Canada market, only channel 1–11 can be operated. Selection of other channels is not possible.
The device could automatically discontinue transmission in case of absence of information to transmit, or operational failure.
Note that this is not intended to prohibit transmission of control or signaling information or the use of repetitive codes wher e
required by the technology.
Important: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
IC Radiation Exposure Statement: This equipment complies with IC RSS-102 radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator
& your body.
CAUTION:
This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other
equipment. To prevent electromagnetic interference with electric appliances such as radios and televisions, use shielded
cables and connectors for connections.
IMPORTANT INFORMATION
2012 SKYVUE 4
2012 SKYVUE 4

10 All Rights Reserved. SkyVue®
Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage
if improperly handled. This product has been engineered and manufactured with the highest priority on safety.
However, improper use can result in electric shock and/or fire. In order to prevent potential danger, please
observe the following instructions when installing, operating and cleaning the product. To ensure your safety
and prolong the service life of your LED Television, please read the following precautions carefully
before using the product.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Clean only with dry cloth.
6) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
7) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
8) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
09) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
10) Only use attachments/accessories specified by the manufacturer.
11) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
12) Unplug this apparatus during lightning storms or when unused for long periods of time.
13) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, does not operate normally, or has
been dropped.
Additional Safety Information
14) Power Sources—This product should be operated only from the type of power source indicated on the
marking label. If you are not sure of the type of power supply to your home, consult your product dealer or
local power company. For products intended to operate from battery power, or other sources, refer to the
operating instructions.
15) Overloading—Do not overload wall outlets, extension cords, or integral convenience receptacles as this
can result in a risk of fire or electric shock.
16) Damage Requiring Service—Unplug this product from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
a) When the AC cord or plug is damaged,
b) If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions as an improper adjustment
of other controls may result in damage and will often require extensive work by a qualified technician
to restore the product to its normal operation,
c) If the product has been dropped or damaged in any way, and
d) When the product exhibits a distinct change in performance - this indicates a need for service.
17) Replacement Parts—When replacement parts are required, be sure the service technician has used
replacement parts specified by the manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other hazards.
18) Safety Check—Upon completion of any service or repairs to this product, ask the service technician to
perform safety checks to determine that the product is in proper operating condition.
19) Wall or ceiling mounting—When mounting the product on a wall or ceiling, be sure to install the product
according to the method recommended by the manufacturer.
DEAR SKYVUE CUSTOMER
Thank you for your purchase of the SKYVUE LED Television. To ensure safety and many years
of trouble-free operation of your product, please read the Important Safety Instructions carefully before
using this product.
IMPORTANT SAFETY INSTRUCTIONS
LC-60LE632U70LE732UE.indb3 2011/02/0416:19:25
2012 SKYVUE 5
2012 SKYVUE 5
.

11Owner’s Manual - Model NXG-4k Important InformatIon |
IMPORTANT SAFETY INSTRUCTIONS
• Outdoor Antenna Grounding — If an outside antenna is
connected to the television equipment, be sure the antenna
system is grounded so as to provide some protection against
voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANSI/NFPA 70,
provides information with regard to proper grounding of the
mast and supporting structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
ANTENNA
LEAD IN WIRE
GROUND
CLAMP
NEC — NATIONAL ELECTRICAL CODE
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250)
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
• Stand — Do not place the product on an unstable cart, stand, tripod or table. Placing the product
on an unstable base can cause the product to fall, resulting in serious personal injuries as well as
damage to the product. Use only a cart, stand, tripod, bracket or table recommended by the
manufacturer or sold with the product. When mounting the product on a wall, be sure to follow
the manufacturer's instructions. Use only the mounting hardware recommended by the manufacturer.
• Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these vents
and openings since insufficient ventilation can cause overheating and/or shorten the life of the product. Do not place
the product on a bed, sofa, rug or other similar surface, since they can block ventilation openings. This product is not
designed for built-in installation; do not place the product in an enclosed place such as a bookcase or rack, unless proper
ventilation is provided or the manufacturer's instructions are followed.
• The front panel used in this product is made of glass. Therefore, it can break when the product is dropped or applied with
impact. Be careful not to be injured by broken glass pieces in case the panel breaks.
• Heat — The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
• The LED panel is a very high technology product with 2,073,600 pixels, giving you fine picture details.
Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green or red
blue, green, red or yellow. Please note that this does not affect the performance of your product.
• Lightning — For added protection for this television equipment during a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to
the equipment due to lightning and power-line surges.
• Power Lines — An outside antenna system should not be located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
• To prevent fire, never place any type of candle or flames on the top or near the TV set.
• To prevent fire or shock hazard, do not place the AC cord under the TV set or other heavy items.
• Do not display a still picture for a long time, as this could cause an afterimage to remain.
• Do not insert foreign objects into the product. Inserting objects in the air vents or other openings may
result in fire or electric shock. Exercise special caution when using the product around children.
Precautions when transporting the TV
• When transporting the TV, never carry it by holding or otherwise putting pressure onto the display. Be sure to always
carry the TV by two people holding it with two hands — one hand on each side of the TV.
Caring for the cabinet
• Use a soft cloth (cotton, flannel, etc.) and gently wipe the surface of the cabinet.
• Using a chemical cloth (wet/dry sheet type cloth, etc.) may deform the components of the main unit cabinet or cause
cracking.
• Wiping with a hard cloth or using strong force may scratch the surface of the cabinet.
• If the cabinet is very dirty, wipe with a soft cloth (cotton, flannel, etc.) soaked in neutral detergent diluted with water and
thoroughly wrung out, and then wipe with a soft dry cloth.
• Avoid using benzene, thinner, and other solvents, as these may deform the cabinet and cause the paint to peel off.
• Do not apply insecticides or other volatile liquids.
Also, do not allow the cabinet to remain in contact with rubber or vinyl products for a long period of time. Plasticizers
inside the plastic may cause the cabinet to deform and cause the paint to peel off.
LC-60LE632U70LE732UE01.indd4 2011/02/2115:45:56
2012 SKYVUE 6
2012 SKYVUE 6
IMPORTANT SAFETY INSTRUCTIONS
• Outdoor Antenna Grounding — If an outside antenna is
connected to the television equipment, be sure the antenna
system is grounded so as to provide some protection against
voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANSI/NFPA 70,
provides information with regard to proper grounding of the
mast and supporting structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
ANTENNA
LEAD IN WIRE
GROUND
CLAMP
NEC — NATIONAL ELECTRICAL CODE
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250)
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
• Stand — Do not place the product on an unstable cart, stand, tripod or table. Placing the product
on an unstable base can cause the product to fall, resulting in serious personal injuries as well as
damage to the product. Use only a cart, stand, tripod, bracket or table recommended by the
manufacturer or sold with the product. When mounting the product on a wall, be sure to follow
the manufacturer's instructions. Use only the mounting hardware recommended by the manufacturer.
• Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these vents
and openings since insufficient ventilation can cause overheating and/or shorten the life of the product. Do not place
the product on a bed, sofa, rug or other similar surface, since they can block ventilation openings. This product is not
designed for built-in installation; do not place the product in an enclosed place such as a bookcase or rack, unless proper
ventilation is provided or the manufacturer's instructions are followed.
• The front panel used in this product is made of glass. Therefore, it can break when the product is dropped or applied with
impact. Be careful not to be injured by broken glass pieces in case the panel breaks.
• Heat — The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
• The LED panel is a very high technology product with 2,073,600 pixels, giving you fine picture details.
Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green or red
blue, green, red or yellow. Please note that this does not affect the performance of your product.
• Lightning — For added protection for this television equipment during a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to
the equipment due to lightning and power-line surges.
• Power Lines — An outside antenna system should not be located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
• To prevent fire, never place any type of candle or flames on the top or near the TV set.
• To prevent fire or shock hazard, do not place the AC cord under the TV set or other heavy items.
• Do not display a still picture for a long time, as this could cause an afterimage to remain.
• Do not insert foreign objects into the product. Inserting objects in the air vents or other openings may
result in fire or electric shock. Exercise special caution when using the product around children.
Precautions when transporting the TV
• When transporting the TV, never carry it by holding or otherwise putting pressure onto the display. Be sure to always
carry the TV by two people holding it with two hands — one hand on each side of the TV.
Caring for the cabinet
• Use a soft cloth (cotton, flannel, etc.) and gently wipe the surface of the cabinet.
• Using a chemical cloth (wet/dry sheet type cloth, etc.) may deform the components of the main unit cabinet or cause
cracking.
• Wiping with a hard cloth or using strong force may scratch the surface of the cabinet.
• If the cabinet is very dirty, wipe with a soft cloth (cotton, flannel, etc.) soaked in neutral detergent diluted with water and
thoroughly wrung out, and then wipe with a soft dry cloth.
• Avoid using benzene, thinner, and other solvents, as these may deform the cabinet and cause the paint to peel off.
• Do not apply insecticides or other volatile liquids.
Also, do not allow the cabinet to remain in contact with rubber or vinyl products for a long period of time. Plasticizers
inside the plastic may cause the cabinet to deform and cause the paint to peel off.
LC-60LE632U70LE732UE01.indd4 2011/02/2115:45:56
2012 SKYVUE 6
2012 SKYVUE 6

12 All Rights Reserved. SkyVue®
IMPORTANT SAFETY INSTRUCTIONS
Caring for the front panel
• Turn off the main power and unplug the AC cord from the GFI wall outlet before handling.
• Gently wipe the surface of the front panel with a soft cloth (cotton, flannel, etc.).
To protect the front panel, do not use a dirty cloth, liquid cleaners, or a chemical cloth (wet/dry
sheet type cloth, etc.). This may damage the surface of the front panel.
• Wiping with a hard cloth or using strong force may scratch the surface of the front panel.
• Use a soft damp cloth to gently wipe the front panel when it is really dirty.
(It may scratch the surface of the front panel when wiped strongly.)
• If the front panel is dusty, use an anti-static brush, which is commercially available, to clean it.
• To avoid scratching the frame or screen, please use a soft, lint free cloth for cleaning.
CHILD SAFETY:
It Makes A Difference How and Where You Use Your Flat Panel Display
Congratulations on your purchase! As you enjoy your new product, please keep these safety tips in mind:
THE ISSUE
• The home theater entertainment experience is a growing trend and larger flat panel displays
are popular purchases. However, flat panel displays are not always supported on the proper
stands or installed according to the manufacturer’s recommendations.
• Flat panel displays that are inappropriately situated on dressers, bookcases, shelves, desks,
speakers, chests or carts may fall over and cause injury.
THIS MANUFACTURER CARES!
• The consumer electronics industry is committed to making home entertainment enjoyable
and safe.
TUNE INTO SAFETY
• One size does NOT fit all. Follow the manufacturer’s recommendations for the safe installation
and use of your flat panel display.
• Carefully read and understand all enclosed instructions for proper use of this product.
• Don’t allow children to climb on or play with furniture and television sets.
• Don’t place flat panel displays on furniture that can easily be used as steps, such as a chest
of drawers.
• Remember that children can become excited while watching a program, especially on a
“larger than life” flat panel display. Care should be taken to place or install the display where it
cannot be pushed, pulled over, or knocked down.
• Care should be taken to route all cords and cables connected to the flat panel display so that
they cannot be pulled or grabbed by curious children.
WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:
• Use a mount that has been recommended by the display manufacturer and/or listed by an independent laboratory (such
as UL, CSA, ETL).
• Follow all instructions supplied by the display and wall mount manufacturers.
• If you have any doubts about your ability to safely install your flat panel display, contact your retailer about professional
installation.
• Make sure that the wall where you are mounting the display is appropriate. Some wall mounts are not designed to be
mounted to walls with steel studs or old cinder block construction. If you are unsure, contact a professional installer.
• A minimum of two people are required for installation. Flat panel displays can be heavy.
Note: CEA is the preeminent trade association promoting growth in the $161 billion U.S.
consumer electronics industry. More than 2,200 companies enjoy the benefits of CEA
membership, including legislative advocacy, market research, technical training and
education, industry promotion and the fostering of business and strategic relationships.
LC-60LE632U70LE732UE.indb5 2011/02/0416:19:25
2012 SKYVUE 7
2012 SKYVUE 7

13Owner’s Manual - Model NXG-4k Important InformatIon |
SkyVue OutdOOr tV Safety InStructIOnS
Ventilation: Adequate ventilation must be maintained to ensure reliable and continued operation, Skyvue recomends
that no materal or additional covering be placed infront of the screen while in in use. To protect the television
from overheating there must be at least 1.5” of space on all sides.
Power cord protection: The power cord must be routed properly to prevent people from stepping on it, or objects
from resting on it. Check the cords at the plugs and product.
Power source: This product must operate on a power source specied on the specication label. If you are unsure
of the type of power supply used in your home, consult your dealer or local power company.
Do not let metal pieces or objects of any kind fall into the television from ventilation holes. High voltage ows in
the product, and inserting an object can cause electric shock and/or short internal parts.
Do not mount SkyVue Outdoor TV’s near heat sources such as radiators, heaters, stoves and other heat-
generating products (including ampliers).
Do not submerge SkyVue Outdoor TV’s in water:
The SkyVue Outdoor TV’s will resist water exposure from normal rain, sprinklers, garden hoses, etc.; however, it is
not designed to withstand pressure washers, high-pressure water jets, hurricane-type weather or be submerged in
water.
Repair:
If any of the following conditions occurs, unplug the power cord, and call SkyVue Outdoor TVs Technical Service
Department for repairs:
• When power cord or plug is damaged.
• When objects have fallen into the product.
• If unit was submerged in water or pressure-washed.
• When product does not operate properly as described in the operating instructions. Do not touch the
controls other than as described in the operating instructions. Improper adjustments of controls not
described in the instructions can cause damage, which can require extensive repair work by a qualied
technician.
• When the product has been dropped or damaged.
• When the product displays an abnormal condition. Any noticeable abnormality in the product indicates that
the product needs servicing.
Replacement parts:
In case the product needs replacement parts, make sure that the you or your service person uses replacement parts
provided by SkyVue Outdoor TV. Use of unauthorized parts can result in re, electric shock and/or other dangers.

14 All Rights Reserved. SkyVue®
Unpacking
After unpacking the SkuVue Outdoor TV, please make sure that all items included in the carton are in good condition.
If items are damaged or missing, contact your dealer immediately.
Rear Panel Component Source
WARNING: Do not connect the power source before making connections.
Internal Component Source
The Internal Component Source allows you to easily connect to the Audio, Video, Digital Audio Out, HDMI, Audio Out,
and RF connectors.
1. The Internal Component Source is inside the Component Cover located on the back of the unit.
2. Loosen all thumbscrews located on the back cover of your SkyVue TV , and pull off the cover to reveal the
Component Source.
3. Route cables to the proper inputs, and place the cable cords over the Rubber Sealing Gasket.
4. Close the cover.
5. Press rmly on the cover, and tighten the thumbscrews.
Tighten ThumbscrewsLoosen Thumbscrews CABLE PASSAGE

15TV InsTallaTIon & ConneCTIons |Operator’s Manual - Model NXG-4k
QUALITY
Terminal
Port Typical Devices Used for This Input
HD IMAGE
HDMI
(Digital HD)
Blue-Ray DVD Player,
HD-DVD Player,
HD Cable or Satellite Box,
HDCP devices
STANDARD
Component
(HD)
Blue-Ray DVD Player,
HD-DVD Player,
HD Cable or Satellite Box,
HDCP devices,
Skyvue Speakerbar
ATSC/NTSC
(Digital HD) Antenna or Digital Cable (With out cable box)
VGA
(HD) PC or MAC with VGA Connection
Cable Name Cable End Images
HDMI or HDMI-DVI
Coaxial RF
VGA
Component
3.5 mm Mini-jack
Coaxial SPDIF
AC Power
Connections Cable to Use Input to Select
HDMI OR HDMI-DVI HDMI
COAXIAL RF TV (CABLE/AIR)
VGA PC
Component Componet
USB USB
Switching Inputs:
Your SkyVue TV offers several options when connecting your
devices to the TV. The chart below will help you understand
which input you select for each of the connections.
Connections Cable Name
Speaker Bar Audio
(Female)
Rear Panel Component Quality

16 All Rights Reserved. SkyVue®
1. RS-232C - Long established standard connection (“C” is the current version) that describes the physical
interface and protocol for relatively slow data communications between computers and related devices.
2. Headphones Out - Use a 3.5 mm mini-jack for use with standard headphones.
3. Digital Audio Out - This type of jack is used for the digital audio inputs and/or outputs on A/V components such
as receivers, CD players, DVD players, and more. Coaxial digital jacks are also sometimes found on
higher-end PC soundcards for digital audio input and output.
4. Composite Audio In - Used in accompanyment with composite Video and component video jacks, AV audio in
(L/R) delivers analog sound from gaming consoles, dvd players, and VCRs.
5. Component Video Jacks - This 3-cable connection allows the chrominance (color) and luminance (brightness)
portions of a video signal to be processed separately. Component video improves color accuracy further by split-
ting the chrominance signal into two portions.
6. HDMI 1
Please note: This port does not support MHL devices.
7. HDMI 2
Please note: This port does not support MHL devices.
8. HDMI 3
Please note: This port does not support MHL devices.
1 2 3 678
45
COAXIAL
(AUDIO OUT)
Rear Panel Connections
Optional Inputs - NXG 4k
The following input connections are available on all NXG 4k Model Televisions.

17TV InsTallaTIon & ConneCTIons |Operator’s Manual - Model NXG-4k
9. HDMI 4 MHL - Use this port for Integrated Internet Streaming Devices Connects to devices that use HDMI
cables such as Blu-ray or HD DVD/Blu-ray player or HD cable / satellite set-top box. This connection port re-
ceives pure digital audio and high denition signal through one single cable. This port also can accept a HDCP
video device for video or PC for monitor display usage. Use the SOURCE button to select HDMI4 on your MAIN
SOURCE to view this connection.
Please note: when using HDMI, your sound signal must be PCM for the TV to decode digital audio. When using
this source for PC display, you must connect the audio cable to VGA Stereo Input for audio.
9a. HDMI 4 extension (optional)
10. VGA - This connection port connects to a PC for video using VGA cable. Be sure to connect your audio cable to
the VGA Stereo input if you want sound out of the VGA video source. Use the SOURCE button to select VGA on
your MAIN SOURCE to view this connection.
11. 5V DC Power - This connection port is for integraded devices that may require additional power to work. This
port has a max power output of 3.5 amps.
12. ATSC/NTSC – This connection is for digital or analog cable without the cable box or over-the-airwave
antennas. The tuner is a hybrid tuner that tunes to both analog and digital channels. This connection uses
coaxial RF cable. For over- the airwave digital stations please check http://www.antennaweb.org.
13. USB - The USB and high speed serial port allows viewers access to les stored on a USB memory device. See
“Using USB” Sections for further details.
14. CVBS - Composite video is usually in standard formats such as NTSC, PAL, and SECAM and is often designat-
ed by the CVBS initialism, for color, video, blanking and sync, or simply as video.
9a (Optional)
9121110 13 14
CABLE / ANTENNA
5V DC POWER
3.5A MAX

18 All Rights Reserved. SkyVue®
Connecting the Power Cord
WARNING: TV and AC receptacle must be installed at least
5 feet away from standing water, such as (but not limited to) a
pool or spa. Please allow for additional clearance if TV is in use
on a SkyVue Portable Cart.
Connect the power cord after you have made connections to your video equipment. Connect the power cord to
an outdoor AC outlet that is in compliance with local regulations. Once the TV is installed it remain plugged into a
stable and consistent 120V, 60HZ power source at all times.
Manual Controls Panel
The control Panel can be found in different locations based on your TV model please see the front of the manual to
see where the manual control panel is located for your TV model.
Front Panel Lights and Sensors
INPUT This button switches between the different sources of the TV. When the On-Screen Display (OSD) is active, this
button acts as the enter button and confirms the menu selection.
CH+/CH- These buttons change the TV channel up or down. If the OSD is active, these buttons function as up or down
controls for the menu.
MENU This button activates the OSD. If a sub-menu is active, pressing this button will return selection to the previous
menu level.
VOL+ / VOL- These buttons increase or decrease the volume. If a sub-menu is active, pressing these buttons will move the
selection left or right. If the OSD is active, Vol+/Vol- is used to select the highlighted options.
POWER Turn on the TV by pressing the button once. Press the button again to turn off the TV.
Ambient Light Sensor
IR - Remote Sensor
Power Indicator Light
