Series VMG
Blow Gun
Others 50%
Coolant 30%
∗10% reduction with the “Blow gun (VMG)” only
SMC Conventional model
Blow gun + S coupler + Coil tube
Air 20%
Actuators 10%
Air leakage 20%
Air blow
70%
Air blow
56%
DOWN
20%
왎Amount of electricity used in a factory
New
New
20%reduction20%reduction
in power consumption
with the SMC “Blow gun” + “S coupler”
+ “Coil tube”
Pressure loss 1% or less Pressure loss 1% or less
The electricity used by compressors for air accounts for approximately 20%of that consumed
by the entire factory. Also, 70% of the air consumed in the process is used for air blowing. SMC
blow guns have minimal pressure loss compared with conventional models, so they can achieve
equivalent performance at lower pressures and with less volume of air consumption. As a result,
it is possible to achieve a 20% reduction in power consumption.
CAT.ES50-20D
VMG-D.qxd 10.1.15 4:19 PM Page 1
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: [phone]-Outside Local Area: [phone]-www.stevenengineering.com

0 0.2 0.4 0.6 0.8 1
Supply pressure (MPa)
Pressure loss (MPa)
0
0.1
0.05
0.15
0.2
0.25
0.3
Pressure loss ··· Conventional model
Energy Saving Pneumatic System Proposal
• Blowing distance: 100 mm
• Impact pressure: 0.011 MPa
• Cost of electricity: 15 yen/kWh
• Blow time: 10 seconds
• Frequency: 12 times/hour
• Working hours: 10 hours/day
• Working days: 250 days/year
• Units used: 100
• Resulting total working hours: 8,300 hours
For example,
when you
compare
this:
with this: This is
the result
Conventional
construction
Pressure loss:
0.005 MPa or less
with 0.5 MPa
VMG (Nozzle size: ø2.5)
Effective
area
6mm2
Energy Saving Effects
Valve Construction and Pressure Loss Straighter flowing fluid
“improves pressure loss!”
When the yearly total working hours spent on air blowing amounts to 8,300 hours, use of conventional models
results in power consumption costs totaling 194,220 yen. When using the SMC system (Blow gun + S coupler
+ Coil tube), however, the yearly cost is reduced to 155,625 yen, for a total yearly saving of 38,595 yen, or
20% of the total.
240
220
200
180
160
140
120
100
5,000 6,000 7,000 8,000 9,000 10,000
Total working hours of use
Cost of electricity consumed by
compressor (thousands of yen)
240
220
200
180
160
140
120
100
5,000 6,000 7,000 8,000 9,000 10,000
Total working hours of use
Cost of electricity consumed by compressor
(thousands of yen)
Calculation conditions
Work model
Series VMG
PAT.PEND
Energy saving valve construction
Balance-poppet valve construction
Effective
area
30 mm2
S coupler Coil tube
++
Energy saving effects with Blow gun (VMG)
Blow gun (VMG)
Energy saving effects with only
Conventional
model
10% reduction
Amount saved as a result
of energy saving effects
19,422 yen/year
Blow gun only
¥194,220
¥174,798
8,300 hours
¥194,220
Amount saved as a result
of energy saving effects
38,595 yen/year
¥155,625
8,300 hours
20% reduction
Blow gun + S coupler + Coil tube
Conventional
model
Conventional
model
Features 1
VMG-D.qxd 10.1.15 4:19 PM Page 2
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: [phone]-Outside Local Area: [phone]-www.stevenengineering.com

SMC helps you work toward a revolutionized production system
with a focus on saving-energy.
쎲Effects of lowered
pressure
After
improvement
Before
improvement
After
improvement
Before
improvement
After
improvement
Before
improvement
쎲Effects of reduced
flow volume
쎲Effects of reduced
power consumption
Review the air-blow job and change to the SMC blow gun, S coupler and coil tube to create a larger effec-
tive area.
Conventional
coupler model
Conventional
coil tube model
Nozzle ø3
Air gun
Effective area
ratio
0.69 : 1
S2S0to S1
S coupler
Coil tube
After improvement
Filter
regulator
Nozzle ø2.5
VMG
Effective area
ratio
3.04 : 1
S2S0to S1
Conventional coil tube model (I.D. ø5, equivalent length 5 m)
Conventional model
Conventional model (Nozzle size ø3)
6.8 mm2
6 mm2
6.3 mm2
TCU1065-1-20-X6
S coupler
VMG (Nozzle size ø2.5)
13.45 mm2
30 mm2
4.4 mm2
0.011 MPa (at a distance of 100 mm)
0.5 MPa
0.276 MPa
0.011 MPa (at a distance of 100 mm)
0.4 MPa
0.385 MPa
Coupler
Piping
Air gun
Coupler, Piping (S0)
Air gun (S1)
Nozzle (S2)
Impact pressure
Effective area ratio (S0to S1: S2)
Compressor pressure
Air consumption
Power consumption by compressor
Regulator pressure
Pressure inside nozzle
Equipment
Effective
area
Before improvementAfter improvement
0.6 MPa
287 dm3/min (ANR)
1.56 kW
0.5 MPa
257 dm3/min (ANR)
1.25 kW
0.69 : 13.04 : 1
10.4%
reduction in
flow volume
20%
reduction
16.7%
reduction in
pressure
Before improvement
Example of Improvement
Features 2
VMG-D.qxd 10.1.15 4:19 PM Page 3
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: [phone]-Outside Local Area: [phone]-www.stevenengineering.com

For pressure loss improvement S coupler: Series KK
With a structure that employs no steel
balls, the coupler achieves a slim body
without narrowing of the channel, allow-
ing coverage of a wide effective area.
By not blocking the channel with the
valve spring, the loss of effective area
can be minimized.
This structure achieves smooth flow
through the channel.
쮿Conical structure of
check valve tip
쮿Smooth channel with
minimal unevenness
쮿Special method of
connection and fixation
Improved fitting’s restrictor and leakage
The surface-to-surface design allows
super-tight sealing.
쮿Seal structure with
minimal leakage
Blow Gun, Coil Tube and S Coupler Selection
Energy Saving Flow
Related Product
Recommended system in
accordance with the distance
Air guns with an effective area around 6 mm2are most commonly used.
But the SMC blow gun achieves a 30 mm2effective area.
Method
Process
Effects
Features
Energy saving!
So
Thus…
Required less air consumption Effective discharge at low pressure
Smaller nozzle diameter Lower discharge pressure
from compressor
Reduction in the amount of electricity
consumed by compressor
Pressure drop: Small
High pressure right before the nozzle
Effective area: Large
TCU0604-20-1-X6KQ2H06-02SUp to 20 mm VMG1쏔쏔-02-01 KK4P-06H
ø1
TCU0604-20-1-X6KQ2H06-02SUp to 40 mm VMG1쏔쏔-02-02 KK4P-06H
ø1.5
TCU0805-20-1-X6KQ2H08-02SUp to 60 mm VMG1쏔쏔-02-03 KK4P-08H
ø2
TCU1065-20-1-X6KQ2H10-02SOver 60 mm VMG1쏔쏔-02-04 KK4P-10H
ø2.5
Distance Nozzle size Coil tubeFittingBlow gun
Recommended system
S coupler
Energy saving effects are enhanced through the appropriate
blow gun model selection in accordance with the distance from
the target object.
As a result…
Features 3
VMG-D.qxd 10.1.15 4:19 PM Page 4
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: [phone]-Outside Local Area: [phone]-www.stevenengineering.com

Operability, Safety, Environment
Variations
Nozzle type
When using this product even at a high
pressure, the same gripping force is
required as for a lower pressure due to
the unique balance-poppet construction.
Material name is indicated on resin
parts. In addition, all components are
separable according to their material
composition.
One-touch fitting type
Top
<White>
Bottom
<Dark blue>
S coupler plug type
Connection type
Plug part no.
Rc, NPT, G 1/4
Rc, NPT, G 3/8
KK4P-02MS
KK130P-02MS
Applicable
tube O.D.
Metric size: ø6, ø8, ø10
Inch size: ø1/4", ø5/16", ø3/8"
Screw-in type
S coupler plug type
One-touch fitting type
Port size
Shock-resistant resin is used in the main
body. No cracks, breaks or other damage
occurred in a drop test from a 2-meter
height or in a human stomp test.
Shock-resistant resin is used in the main
body. No cracks, breaks or other damage
occurred in a drop test from a 2-meter
height or in a human stomp test.
Not affected by supply pressure,
assured operability
Not affected by supply pressure,
assured operability
Components are separable.
Environmentally friendly
Components are separable.
Environmentally friendly
Use of shock-resistant resin
Use of shock-resistant resin
Resin:
PBT
Seals:
NBR
Nozzle:
Brass
Metal:
Aluminum
alloy
Stainless
steel
Recyclable
∗Secures more power even at a greater
distance from a workpiece.
Copper extension nozzle
∗ Achieving lower noise by dividing the air blow slit
Low noise nozzle
Mono-porous nozzle (ø2) 90 to 100 dB
Nozzle length: 300 mm, 600 mm
ø1 x 4 low noise nozzles 80 dB or less
Note) Supply pressure: 0.5 MPa
Measured at a 45 degree angle
according to JIS B 8379
Male thread nozzle
∗Powerful and economical
∗Making use of Bernoulli effect and
achieving high efficiency
High efficiency nozzle
Features 4
VMG-D.qxd 10.1.15 4:19 PM Page 5
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: [phone]-Outside Local Area: [phone]-www.stevenengineering.com

How to Order
Specifications
Blow Gun
Series VMG
VMG 1 10201W
Note) When the copper extension nozzle is ordered in a blow gun set, one
piece of H06-02 self-align fitting is attached.
When a copper extension nozzle is ordered separately, a self-align
fitting will be required for connection. Refer to nozzle models on page 4.
Blow gun
Standard type
Series
Resin body lever type
1
Body color
White
Dark blue
W
BU
Piping entry
Bottom
Top
1
2
Male thread nozzle
High efficiency nozzle
Low noise nozzle
with male thread
Copper Note)
extension
nozzle
Length
300 mm
Length
600 mm
Nozzle
Type Symbol Nozzle model
Without nozzle
KN-R02-100
KN-R02-150
KN-R02-200
KN-R02-250
KNH-R02-100
KNH-R02-150
KNH-R02-200
KNS-R02-075-4
KNS-R02-090-8
KNS-R02-100-4
KNS-R02-110-8
KNL3-06-150
KNL3-06-200
KNL6-06-150
KNL6-06-200
Nozzle size
ø1
ø1.5
ø2
ø2.5
ø1
ø1.5
ø2
ø0.75 x 4
ø0.9 x 8
ø1 x 4
ø1.1 x 8
ø1.5
ø2
ø1.5
ø2
Nil
01
02
03
04
11
12
13
21
22
23
24
31
32
33
34
Fluid
Operating pressure range
Proof pressure
Effective area
Port size
Piping entry
Nozzle port size
Weight
Operational force (when
the valve is fully open)
Air
0 to 1.0 MPa
1.5 MPa
–5 to 60°C (No freezing)
30 mm2(without nozzle)
Rc, NPT, G 1/4, 3/8
Rc 1/4
180 g
7 N
Top
Ambient and fluid
temperature
Bottom
Note 1) S couplers and fittings are included.
Note 2) In the case of S coupler plug type, the port size is Rc 1/4.
Note 3) In the case of metric size one-touch fitting type, the port size is Rc 1/4.
Note 4) In the case of inch size one-touch fitting type, the port size is NPT 1/4.
Note 5) ( ): Applicable tube O.D.
Connection size
Piping connection type Symbol Size/Part no.
Fitting
part no.
Fitting
part no.
Port size
Plug
part no.
Rc 1/4
Rc 3/8
NPT 1/4
NPT 3/8
G 1/4
G 3/8
KK4P-02MS
KK130P-02MS
KQ2H06-02S (ø6)
KQ2H08-02S (ø8)
KQ2H10-02S (ø10)
KQ2H07-35S (ø1/4")
KQ2H09-35S (ø5/16")
KQ2H11-35S (ø3/8")
02
03
N02
N03
F02
F03
11
12
H06
H08
H10
H07
H09
H11
Screw-in type
Inch size
one-touch fitting type
Metric size
one-touch fitting type
S coupler plug type
1
RoHS
RoHS-VMG-6.qxd 10.7.29 11:46 AM Page 1
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: [phone]-Outside Local Area: [phone]-www.stevenengineering.com

1
2
3
4
5
6
7
8
9
10
11
12
13
14
Body L
Body R
Main valve
Valve guide
Nozzle holder
Port
Elbow
Cover
Ring
Arm L
Arm R
Spring
Main valve seal
Lever
Material
Chromated
Anodized
Anodized
Only for VMG12첸
Only for VMG11첸
Combined with the
elbow in u.
PBT
PBT
PBT
Aluminium alloy
Aluminium alloy
Aluminium alloy
PBT
Stainless steel
Stainless steel
PBT
PBT
Stainless steel
HNBR
PBT
15 Piping (bottom) POM
16
17
18
19
20
O-ring
O-ring
Parallel pin
Cross recessed round head screw
Hexagon nut
NBR
NBR
Stainless steel
Stainless steel
Stainless steel
Note
Component Parts
i
y
ureqw
o
t
!3!7
!2
!5
!6
!1 !0
!8
@0 !9
!4
600
500
400
300
200
100
0
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
KN-R02-250
KN-R02-200
KN-R02-100
400
350
300
250
200
150
100
50
0
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
KNH-R02-200
KNH-R02-150
KNH-R02-100
400
350
300
250
200
150
100
50
0
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
KNL3-06-200
KNL3-06-150
KNL6-06-200
KNL6-06-150
900
800
700
600
500
400
300
200
100
0
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
KNS-R02-110-8
KNS-R02-090-8
KNS-R02-100-4
KNS-R02-075-4
Supply pressure [MPa]
Flow rate [l/min (ANR)]
Supply pressure [MPa]
Flow rate [l/min (ANR)]
Supply pressure [MPa]
Flow rate [l/min (ANR)]
Supply pressure [MPa]
Flow rate [l/min (ANR)]
Male thread nozzle High efficiency nozzle
Low noise nozzle with male thread Copper extension nozzle
KN-R02-150
Note) Grease is used on rubber and sliding sections.
Note) Values when the main valve is fully open
DescriptionNo.
Construction
Flow-rate Characteristics
2
Blow Gun
Series VMG
VMG-D.qxd 10.1.15 4:19 PM Page 7
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: [phone]-Outside Local Area: [phone]-www.stevenengineering.com

S coupler plug
mounting
(KK130P-02MS)
One-touch fitting
mounting
(Series KQ2H)
32 Note)
BNote)
S coupler plug
mounting
(KK130P-02MS)
One-touch fitting
mounting
(Series KQ2H)
32 Note)
BNote)
170.8 Note)
CNote)
23
23
A
172.5 Note)
34.2 Note)
30
147
117.5
102
A
156
117.5
102
S coupler plug
mounting
(KK4P-02MS)
Rc, NPT, G 1/4, 3/8
Width across flats 22
Rc, NPT, G 1/4, 3/8
Width across flats 22
VMG12/Piping entry: Top
VMG11/Piping entry: Bottom
S coupler plug
mounting
(KK4P-02MS)
Rc 1/4
34.2
Note)
Nozzle
Nozzle
Type Nozzle model
Male thread
nozzle
High efficiency
nozzle
Nozzle size ANote)
Note) Reference dimensions after installation
Note) Reference dimensions after installation
Note) Reference dimensions after installation
(mm)
KN-R02-100
KN-R02-150
KN-R02-200
KN-R02-250
KNH-R02-100
KNH-R02-150
KNH-R02-200
KNS-R02-075-4
KNS-R02-090-8
KNS-R02-100-4
KNS-R02-110-8
KNL3-06-150
KNL3-06-200
KNL6-06-150
KNL6-06-200
ø1
ø1.5
ø2
ø2.5
ø1
ø1.5
ø2
ø0.75 x 4
ø0.9 x 8
ø1 x 4
ø1.1 x 8
ø1.5
ø2
ø1.5
ø2
23.4
23
22.5
22.1
44
44
44
12
12
12
12
305.3
305.3
605.3
605.3
Type
Metric size
one-touch fitting
Inch size
one-touch fitting
BNote) CNote)
(mm)
One-touch fitting model
KQ2H06-02S
KQ2H08-02S
KQ2H10-02S
KQ2H07-35S
KQ2H09-35S
KQ2H11-35S
17
20.5
27.5
17
20.5
27.5
158
161.5
168
158
161.5
168
Low noise nozzle
with male thread
Copper extension
nozzle
Rc 1/4
30
Dimensions
3
Series VMG
VMG-D.qxd 10.1.15 4:19 PM Page 8
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: [phone]-Outside Local Area: [phone]-www.stevenengineering.com

øD
L1
Outside diameter
A
L1
øD
H1
Connection thread
øD
2
A
L1
Connection
thread
H1
A
L1
øD
H1
Connection thread
KNL3-06-150A02
KNL3-06-200A02
KNL6-06-150A02
KNL6-06-200A02
KNL3-06-150 (1 pc.)
KNL3-06-200 (1 pc.)
KNL6-06-150 (1 pc.)
KNL6-06-200 (1 pc.)
Contents
H06-02-X2 (1 pc.)
H06-02-X2 (1 pc.)
H06-02-X2 (1 pc.)
H06-02-X2 (1 pc.)
Set no.
Male thread nozzle: KN (mm)
Self-align fitting (for copper extension nozzle connection)
Male connector
H06-02-X2
Dimensions: Nozzles/Series KN
KN-R02-100
KN-R02-150
KN-R02-200
KN-R02-250
ø1
ø1.5
ø2
ø2.5
R 1/4
R 1/4
R 1/4
R 1/4
14
14
14
14
31.4
31
30.5
30.1
25.4
25
24.5
24.1
Model
∗ Reference dimensions after R thread installation
Nozzle size
D
Connection
thread L1A∗
Width across flats
H1
High efficiency nozzle: KNH (mm)
KNH-R02-100
KNH-R02-150
KNH-R02-200
ø1
ø1.5
ø2
R 1/4
R 1/4
R 1/4
14
14
14
52
52
52
46
46
46
Model
∗ Reference dimensions after R thread installation
Nozzle size
D
Connection
thread L1A∗
Width across flats
H1
Low noise nozzle with male thread: KNS (mm)
KNS-R02-075-4
KNS-R02-090-8
KNS-R02-100-4
KNS-R02-110-8
ø0.75 x 4
ø0.9 x 8
ø1 x 4
ø1.1 x 8
R 1/4
R 1/4
R 1/4
R 1/4
14
14
14
14
20
20
20
20
14
14
14
14
Model
∗ Reference dimensions after R thread installation
Nozzle size
D
Connection
thread L1A∗
Width across flats
H1
Copper extension nozzle: KNL (mm)
KNL3-06-150
KNL3-06-200
KNL6-06-150
KNL6-06-200
ø1.5
ø2
ø1.5
ø2
300
300
600
600
ø6
ø6
ø6
ø6
Model Outside diameter
Nozzle size
DL1
Nozzle Self-align fitting Note)
Note) The self-align fittings ordered in sets are nickel plated.
Copper Extension Nozzle + Self-align Fitting/Set No.
Note) When a copper extension nozzle is ordered separately, a self-align fitting will be
required for connection with the blow gun. Order with the below set number.
4
Blow Gun
Series VMG
VMG-D.qxd 10.1.15 4:19 PM Page 9
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: [phone]-Outside Local Area: [phone]-www.stevenengineering.com

Series VMG
Specific Product Precautions 1
Be sure to read this before handling.
Male thread
R 1/4
R 3/8
Tightening torque N⋅m
12 to 14
22 to 24
Port
Spanner
Wrapping
direction
Pipe tape
Expose approx. 2 threads.
Nozzle tightening torque range 12 to 14 N폷m
Nozzle holder
Spanner
Insufficient tightening may cause loosening of the nozzle.
1. Do not apply the blow gun to flammable,
explosive or toxic substances such as gas,
fuel gas or refrigerant. Such substances
may exude from inside the blow gun.
1.
Install a stop valve on the supply pressure
side of the blow gun to enable emergency shut
off in case of unexpected leakage or damage.
2. When installing a nozzle on the blow gun, wrap
pipe tape around the threads of the nozzle.
3. When installing the nozzle, secure the
nozzle holder of the blow gun by applying a
spanner of 22 mm width across flats to the
two chamfered surfaces of the holder
without applying force to the body. Then,
tighten the nozzle with force within the
below torque range. As a guideline, it is
equivalent to 2 to 3 additional turns with a
tool after manual tightening.
1.
Check the specifications.
The products in this catalog are designed to be used in
compressed air systems only. If the products are used in an
environment where pressure or temperature is out of the specified
range, damage and/or malfunction may result. Do not use under
such conditions.
Selection
Mounting
Warning
Warning
1. Check the model, type and size before
installation.
Also, confirm that there is no scratches, gouges or cracks on the
product.
2. Before piping
Before piping, it should be thoroughly blown out with air (flushing)
or washed to remove chips, cutting oil and other debris from
inside the pipe.
Piping
Caution
Caution
3. Wrapping of pipe tape
When screwing together pipes and fittings, etc., be certain that
chips from the pipe threads and sealing material do not get inside
the blow gun. Also, when the pipe tape is used, leave 1.5 to 2
thread ridges exposed at the end of the threads.
Piping
Caution
4. When tightening the threads, secure the
nozzle holder of the blow gun by applying a
spanner of 22 mm width across flats to the
two chamfered surfaces of the holder
without applying force to the body. Then,
tighten the nozzle with torque specified in
the below table. As a guideline, it is
equivalent to 2 to 3 additional turns with a
tool after manual tightening.
Be careful that tightening with torque beyond the ranges in the
below table may cause damage to the body.
5. Allow extra length when connecting a tube
to accommodate changes in tube length due
to pressure.
6. Confirm that no twisting, turning or tensile
force or moment load is applied to the port
or tube. This may cause fittings to fracture
or tubes to be crushed, burst or come loose.
7.
Do not abrade, entangle or scratch the tube.
This may cause the tube to be crushed,
burst or come loose.
1. Use clean air.
Do not use compressed air which includes chemicals, synthetic
oils containing organic solvents, salt or corrosive gases, etc., as it
can cause damage or malfunction.
Air Supply
Warning
1. Do not lubricate the product.
It may contaminate or damage the target object.
Lubrication
Warning
5
VMG-D.qxd 10.1.15 4:19 PM Page 10
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: [phone]-Outside Local Area: [phone]-www.stevenengineering.com

Series VMG
Specific Product Precautions 2
Be sure to read this before handling.
Hook
Air Supply
9. When the blow gun is used or stored, con-
firm that no twisting, turning or tensile force
or moment load is applied to the port or
tube. This may cause fittings to fracture or
tubes to be crushed, burst or come loose.
1.
Install air filters.
Install air filters at the upstream side of blow gun. Choose the
filtration degree of 5 µm or finer.
2. Install an after-cooler, air dryer or water
separator, etc.
Air excessive drainage may cause malfunction of blow gun and
contaminate or damage the target object. To prevent this, install
an after-cooler, air dryer or water separator, etc.
Caution
1. Do not use in an atmosphere of corrosive
gases, chemicals, sea water, water or water
vapor or in an environment where such
substances may adhere.
2.
Provide shading in an environment where
the product is exposed to the sunlight.
3.
Do not use in an environment where a heat
source is at a close distance.
4.
Do not use in an environment where static
electricity is a problem. It may cause
malfunction or failure of the system. Contact
SMC for use in such an environment.
5.
Do not use in an environment where spatters
are generated. There is danger of fires
caused by spattering. Contact SMC for use
in such an environment.
6.
Do not use in an environment where the
product is exposed to cutting oil, lubricating
oil or coolant oil. Contact SMC for use in an
environment where the product is exposed
to such liquid as cutting oil, lubricating oil or
coolant oil.
Operating Environment
Warning
1. In periodical inspections, check the follow-
ing items and replace the parts if necessary.
a) Scratches, gouges, abrasion, corrosion
b) Air leakage
c) Twisting, crushing and turning of connected tubes
d) Hardening, deterioration and softening of connected tubes
e) Loosening of nozzles
2. When removing the product, first stop the
pressure supply, exhaust compressed air in
the piping and confirm the condition of
atmospheric release.
3.
Do not disassemble or remodel the body of
the product.
Maintenance
Caution
1. To prevent lurching of the nozzle due to air
pressure, confirm that the nozzle is not
loosened or rattling by pulling it by hand
before operation.
2.
Make sure to wear safety goggles to protect
yourself from splashed substances.
3.
Do not direct the tip of the nozzle at the face
or other parts of a human body. It may cause
danger to personnel.
4.
Do not use the product to clean or remove
toxic substances or chemicals.
5.
Do not drop, step on or hit the product. It
may cause damage to the product.
6.
Do not use the product to disturb public
order or public hygiene.
7.
This product is not a toy.
8. After blowing, make sure to hang the prod-
uct on a hook, etc.
If leaving the product in a dusty place, particles will enter the
product and may result in malfunction.
Handling
Warning
6
VMG-D.qxd 10.1.15 4:19 PM Page 11
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: [phone]-Outside Local Area: [phone]-www.stevenengineering.com

Akihabara UDX 15F,
4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021, JAPAN
Phone: [phone] Fax: [phone]
URL http://www.smcworld.com
© 2010 SMC Corporation All Rights Reserved
Specifications are subject to change without prior notice
and any obligation on the part of the manufacturer.
1st printing GZ printing OO 6000SZ Printed in Japan.D-DN
Safety Instructions Be sure to read “Handling Precautions for SMC Products” (M-E03-3) before using.
∗Related products KK/KKH series S coupler, changed to the model
change products.
∗High efficiency nozzle data listed. JR
∗Best Pneumatics No.1 (Pages 1889 to 1899) extracted. NS
∗Added the KK130 series S coupler and one-touch fitting type.
∗Number of pages from 16 to 12. OO
Revision history
Edition B
Edition C
Edition D
1. The compatibility of the product is the responsibility of the
person who designs the equipment or decides its specifications.
Since the product specified here is used under various operating conditions, its
compatibility with specific equipment must be decided by the person who designs
the equipment or decides its specifications based on necessary analysis and test
results. The expected performance and safety assurance of the equipment will be
the responsibility of the person who has determined its compatibility with the
product. This person should also continuously review all specifications of the
product referring to its latest catalog information, with a view to giving due
consideration to any possibility of equipment failure when configuring the
equipment.
2. Only personnel with appropriate training should operate
machinery and equipment.
The product specified here may become unsafe if handled incorrectly. The
assembly, operation and maintenance of machines or equipment including our
products must be performed by an operator who is appropriately trained and
experienced.
3. Do not service or attempt to remove product and
machinery/equipment until safety is confirmed.
1. The inspection and maintenance of machinery/equipment should only be
performed after measures to prevent falling or runaway of the driven objects
have been confirmed.
2. When the product is to be removed, confirm that the safety measures as
mentioned above are implemented and the power from any appropriate source
is cut, and read and understand the specific product precautions of all relevant
products carefully.
3. Before machinery/equipment is restarted, take measures to prevent
unexpected operation and malfunction.
4. Contact SMC beforehand and take special consideration of safety
measures if the product is to be used in any of the following
conditions.
1. Conditions and environments outside of the given specifications, or use
outdoors or in a place exposed to direct sunlight.
2. Installation on equipment in conjunction with atomic energy, railways, air
navigation, space, shipping, vehicles, military, medical treatment, combustion
and recreation, or equipment in contact with food and beverages, emergency
stop circuits, clutch and brake circuits in press applications, safety equipment
or other applications unsuitable for the standard specifications described in the
product catalog.
3. An application which could have negative effects on people, property, or
animals requiring special safety analysis.
4. Use in an interlock circuit, which requires the provision of double interlock for
possible failure by using a mechanical protective function, and periodical
checks to confirm proper operation.
Warning
Limited warranty and Disclaimer/
Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer”
and “Compliance Requirements”.
Read and accept them before using the product.
1. The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in
manufacturing industries.
If considering using the product in other industries, consult SMC beforehand and
exchange specifications or a contract if necessary.
If anything is unclear, contact your nearest sales branch.
Caution
Limited warranty and Disclaimer
1. The warranty period of the product is 1 year in service or 1.5 years after
the product is delivered.∗2)
Also, the product may have specified durability, running distance or
replacement parts. Please consult your nearest sales branch.
2. For any failure or damage reported within the warranty period which is clearly our
responsibility, a replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any
other damage incurred due to the failure of the product.
3. Prior to using SMC products, please read and understand the warranty terms
and disclaimers noted in the specified catalog for the particular products.
∗2) Vacuum pads are excluded from this 1 year warranty.
A vacuum pad is a consumable part, so it is warranted for a year after it is delivered.
Also, even within the warranty period, the wear of a product due to the use of the vacuum pad
or failure due to the deterioration of rubber material are not covered by the limited warranty.
Compliance Requirements
1. The use of SMC products with production equipment for the manufacture of
weapons of mass destruction (WMD) or any other weapon is strictly prohibited.
2. The exports of SMC products or technology from one country to another are
governed by the relevant security laws and regulations of the countries involved
in the transaction. Prior to the shipment of a SMC product to another country,
assure that all local rules governing that export are known and followed.
These safety instructions are intended to prevent hazardous situations and/or
equipment damage. These instructions indicate the level of potential hazard with
the labels of “Caution,” “Warning” or “Danger.”They are all important notes for
safety and must be followed in addition to International Standards (ISO/IEC)∗1),
and other safety regulations.
∗1) ISO 4414: Pneumatic fluid power – General rules relating to systems.
ISO 4413: Hydraulic fluid power – General rules relating to systems.
IEC 60204-1: Safety of machinery – Electrical equipment of machines.
(Part 1: General requirements)
ISO 10218-1: Manipulating industrial robots - Safety.
etc.
Caution indicates a hazard with a low level of risk
which, if not avoided, could result in minor or
moderate injury.
Warning indicates a hazard with a medium level of
risk which, if not avoided, could result in death or
serious injury.
Caution:
Warning :
Danger : Danger indicates a hazard with a high level of risk
which, if not avoided, will result in death or serious
injury.
Safety Instructions
VMG-D.qxd 10.1.15 4:19 PM Page 12
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: [phone]-Outside Local Area: [phone]-www.stevenengineering.com
