Smeg CWC620D User manual



PROFESSIONAL DISHWASHER

‐CW620/630

2
CONTENTS

1PRECAUTIONSFORSAFETYANDUSE.............................................................................3
2TECHNICALDATA...........................................................................................................6
3INSTALLATIONANDPOSITIONING.................................................................................7
4INSTRUCTIONSFORTECHNICALSTAFF..........................................................................8
4.1Plumbinghookup.....................................................................................................8
4.2Electricalconnection.............................................................................................10
5FIRSTSTART‐UP...........................................................................................................12
6SET‐UP.........................................................................................................................13
6.1Dishwasherparametermodificationprocedure:..................................................13
6.2Quit“SET‐UP“menu.........................................................................................16
6.3Rinsingtemperaturesetup...................................................................................16
6.4Washingtemperaturesetup.................................................................................17
6.5Rinseaiddispensingsetup....................................................................................17
6.6Adjustingdetergentdispensing(optionalifinstalled)..........................................17
6.7Autostartfunction.................................................................................................18
6.8Regenerationfrequencysetup(modelswithsoftener)........................................18
6.9tStP(minimumrinsingtemperature)function.....................................................19
6.10Rinseaidpump(displayandifrequiredresetduringmaintenance).................19
6.11Detergentpump(displayandifrequiredresetduringmaintenance)...............19
6.12Energyconsumption–Displayandresetifrequired.........................................20
6.13CustomisationofdurationofprogramP4.........................................................20
6.14Steamextractiontimesetting(optionalifinstalled).........................................20
6.15Servicesetting(forAfter‐SalesServiceonly).....................................................21
6.16Startingtheperistalticpumps–rapidfillingofdetergentandrinseaiddelivery
circuit.21
7MALFUNCTIONSSHOWNONTHEDISPLAY(FORTHETECHNICIAN)...........................22
8INSTRUCTIONSFORTHEUSER....................................................................................24

‐CW620/630

3
8.1Controlpanel........................................................................................................24
8.2Beforewashing.....................................................................................................25
8.3Firstuseeachday(tankandboilerempty)...........................................................25
8.4ChangingtheProgram..........................................................................................27
9CHOOSINGTHEPROGRAM.........................................................................................28
10SUPPLEMENTARYFUNCTIONS.................................................................................28
10.1Selectingthecrys“glassware”function(availableinP1‐P2).............................28
10.2Selectingthe“extrarinse”function(availableinP1‐P2‐P3‐P4)........................29
11MAINTENANCEANDCLEANING...............................................................................30
11.1Dailycleaning.....................................................................................................30
11.2Routineinspectionofthesprayarms................................................................32
11.3Lengthyperiodsoutofuse................................................................................32
12TROUBLESHOOTING.................................................................................................32
13MALFUNCTIONSSHOWNONTHEDISPLAY(FORTHEUSER)...................................34

SMEGThanksyouforchoosingoneofitsproducts.

Readalltheinstructionsinthismanualcarefullytobecomefamiliarwiththerightconditionsforthe
properuseofyourdishwasher.

TECHNICALINSTRUCTIONS


Theseareintendedforthequalifiedstaffwhoaretoinstall,commissionandtest
theapplianceandcarryoutanyservicingandrepairs.

INSTRUCTIONSFORTHEUSER



Theseproviderecommendationsforuse,adescriptionofthecontrolsandthe
correctproceduresforcleaningandmaintainingthedishwasher.
1 PRECAUTIONS FOR SAFETY AND USE


‐CW620/630

4


THEDISHWASHERISINTENDEDFORPROFESSIONALUSEONLYANDMUSTONLYBEUSEDBY
AUTHORISEDSTAFF.ITISDESIGNEDTOWASHTABLEWARE(PLATES,CUPS,BOWLS,OVENDISHES
ANDCUTLERY)ANDSIMILARITEMSINTHERESTAURANTANDINSTITUTIONALCATERINGSECTOR,
ANDCOMPLIESWITHTHEINTERNATIONALSTANDARDSONELECTRICALANDMECHANICALSAFETY
(CEI‐EN‐IEC60335‐2‐58/61770)ANDELECTROMAGNETICCOMPATIBILITY
(CEI‐IEC‐EN55014‐1/‐2,61000‐3;4,50366).


THEMANUFACTURERDECLINESALLRESPONSIBILITYFORINJURYORDAMAGECAUSEDBYFAILURE
TOCOMPLYWITHTHEINSTRUCTIONSINTHEMANUAL,BYINCORRECTUSE,BYTAMPERINGWITH
EVENJUSTONEPARTOFTHEAPPLIANCEANDBYTHEUSEOFNON‐ORIGINALSPAREPARTS.


THISAPPLIANCEISTAGGEDUNDEREUROPEANDIRECTIVE2002/96/ECONWASTEELECTRICALAND
ELECTRONICEQUIPMENT(WEE).
BYMAKINGSURETHATTHISPRODUCTISDISPOSEDOFCORRECTLYTHEUSERHELPSTOPREVENT
POTENTIALDETRIMENTALEFFECTSONHEALTHANDTHEENVIRONMENT.
WHENDECOMMISSIONINGTHEAPPLIANCECOMPLYWITHTHELOCALWASTEDISPOSAL
REGULATIONS.
FORFURTHERINFORMATIONONTHETREATMENT,RECOVERYANDRECYCLINGOFTHISPRODUCT,
CONTACTTHECOMPETENTLOCALOFFICE,THEDOMESTICWASTECOLLECTIONSERVICE,ORTHE
SHOPWHERETHEPRODUCTWASPURCHASED.

THISMANUALISANINTEGRALPARTOFTHEDISHWASHERANDMUSTALWAYSBE
KEPTINTACTTOGETHERWITHTHEAPPLIANCE.

POSITIONING,HOOKUP,COMMISSIONING,TROUBLESHOOTINGANDREPLACINGTHE
POWERCABLEMUSTALWAYSBECARRIEDOUTBYQUALIFIEDSTAFF.

THEAPPLIANCEMUSTBEGROUNDEDASREQUIREDBYELECTRICALEQUIPMENT
SAFETYSTANDARDS.

‐CW620/630

5



THESYMBOLOFTHERUBBISHBINWITHABARACROSSITONTHEPRODUCTORINTHE
TECHNICALDOCUMENTATIONINDICATESTHATTHISPRODUCTMUSTNOTBETREATED
ASORDINARYDOMESTICWASTEBUTMUSTBECONSIGNEDTOTHESPECIAL
COLLECTIONPOINTFORTHERECYCLINGOFELECTRICALANDELECTRONICEQUIPMENT.


NEVERPLACESOLVENTSSUCHASALCOHOLORTURPENTINE,WHICHMIGHTCAUSEAN
EXPLOSION,INSIDETHEAPPLIANCE.NEVERLOADDISHESDIRTYWITHASH,WAXOR
PAINTS.


DONOTDRINKANYWATERLEFTINTHEDISHESORDISHWASHERATTHEENDOFTHE
WASHINGPROGRAM.


THEAPPLIANCEISNOTSUITABLEFORUSEBYJUVENILESORPERSONSWITHREDUCED
PHYSICAL,SENSORIALORMENTALCAPACITIES,ORTHOSEWITHOUTTHENECESSARY
KNOWLEDGEANDEXPERIENCE.SUCHPERSONSMAYONLYUSETHEAPPLIANCEUNDER
THESUPERVISIONOFAPERSONRESPONSIBLEFORTHEIRSAFETY.


‐CW620/630

6
2 TECHNICAL DATA

SupplyvoltageV400V3N~
FrequencyHz50
Max.powerabsorptionat400V3N~kW10.8
Boilerheatingelementpowerat400V3N~kW9.0
TankheatingelementpowerkW1.8
WaterintakepressurekPa(bar)100‐600(1÷6)
Waterintaketemperature°C15°C–60°C
Waterintakehardness°f<15°f
Rinsecyclewaterconsumptionl3.2
Boilercapacityl8
Tankcapacityl22
Duréecyclestandardavecalimentationd’eauà50°Cs60/90/150/variable
DegreeofprotectionIPX5
Netweightkg120/149
FuseA4
Powersupplycabletype◄HAR►H07RN‐F
SupplyvoltageV400V3N~
FrequencyHz50


400V3N~
C SC=PowerSupplyCableS=masterswitch
10.8kW5X4□32A




‐CW620/630

7
3 INSTALLATION AND POSITIONING

INSTALLATIONandPOSITIONING


Bringthehooddishwashertotheinstallationsite,removethepackagingandchecktheapplianceand
componentsfordamage;anydamagefoundmustbereportedtothetransporterinwriting.
Thepackagingcomponents(plasticbags,expandedpolystyrene,nails,etc.)mustnotbeleftwithinreach
ofchildrenandpetssincetheyarepotentiallydangerous.Allpackagingmaterialsusedareenvironment‐
friendly.Theycanbekeptwithoutconstitutinganyhazard,ormaybedisposedofataspecialistwaste
disposalcentre.Theplasticcomponentssuitableforrecyclingaremarkedasfollows:PEpolyethylene:
externalpackagingfilm,bagcontainingtheinstructions,protectivebags.PPpolypropylene:straps.PS
expandedpolystyrene:cornerguards,topofpackaging.Woodenandcardboardcomponentscanbe
disposedofinaccordancewiththerelevantregulations.Whentheproductisdecommissioneditmust
notbedumpedintheenvironment;itmustbedisposedofinaccordancewiththerelevantregulations.
Allmetalpartsareinstainlesssteelandcanberemoved.Theplasticpartsaremarkedwiththesymbol
identifyingthematerialusedandmustbedisposedofinaccordancewiththerelevantregulationsWhen
theproductisdecommissioneditmustnotbedumpedintheenvironment;itmustbedisposedofin
accordancewiththerelevantregulations.
POSITIONING:










Caution:theindoorsystemandpremisesinwhichequipmentforinstitutionsisinstalled
mustcomplywiththerelevantregulations.

Themanufacturerdeclinesallliabilityfordirectorindirectinjuryordamagederivingfromfailure
tocomplywiththeseregulations.
Beforeinstallation,checkthattherearenoobjectsormaterialsinthevicinitywhichmaybe
damagedbysteamorsplashesofwashingsolution,orthatanysuchitemsaresuitablyprotected.
Placethedishwasherinthechosenpointandremovetheprotectivefilm.
Levelthedishwasher(withtheaidofaspiritlevel)onitsadjustablefeettoensurethatitisstable;
allothermountingsolutionsmustbeapprovedbythemanufacturer.


‐CW620/630

8
C SOLENOIDVALVE
Q EARTHTERMINAL
E ELECTRICITYSUPPLYCABLE
D PERISTALTICHOSES
S DRAINHOSE

4 INSTRUCTIONS FOR TECHNICAL STAFF
4.1 Plumbinghookup

Watersupplyanddrainhookup
Thewaterpipelinesandelectricitysupplycableleadoutofthebottomright‐
handcorneroftheappliance.Connectthewaterintakehosetoaconnector
with¾”gasthreadedfitting,fittingthefilterAprovided(inmodelswith
Aquastop,thefilterandring‐nutformasingleunit).
Theconnectiontothewatermainsmustonlybemadewithnewhoses;the
useofoldorwornhosesisnotpermitted.
Thedynamicwatersupplypressuremustbebetween1and6bar;ifitishigher,installationofa
pressurereducerisnecessary.
Itisessentialtofitamainstoptaponthewaterintakedeliverpipeline;thetapmustbeaccessible
afterinstallationoftheappliance,sodonotinstallitbehindthedishwasher.Thestatedcycle
durationappliestoappliancessuppliedwithhotwater>50°C<60°C.Ifthedishwasherissupplied
withcoldwater,thecycledurationmightincreasedependingontheintakewatertemperature.The
dishwasherisfittedwithadrainpumpandcanoperatewithdrainconnectionsonthefloororwall.

‐CW620/630

9
Drainage:

Thedishwasherisfittedwithadrainpumpandcanoperate
withdrainconnectionsonthefloororwall.







Caution:makesurethattheintakeanddrainhoses
arenotbent,constrictedorcrushedafter
installation.

Warning!Maximumheightofdrainhose!




Iftheapplianceisfittedwithawatersoftener,thedrainmustnotbeconnectedtoasiphonwith
valve.

Refertotheconnectiondiagramforthemaximumpermittedheightofwalldrains–(seeTECHNICAL
DATA)



Caution:makesurethattheintakeanddrainhosesarenotbent,constrictedorcrushed
afterinstallation.





‐CW620/630

10
4.2 Electricalconnection
















Thedishwasherandanyadditionalequipmentmustbeconnectedtotheelectrical
systembyauthorised,skilledstaff,inaccordancewiththerelevantregulations;also
complywiththetechnicalinstructionsfortheconnection.
Thetotalratedpowerisstatedontheappliance’stechnicaldataplate.
Theelectricalprotectiondevicesfittedforthedishwashermustservethisappliance
only.
Theusermusthaveamasterswitchandadifferentialsafetybreaker,withrating
suitablefortheappliance’scharacteristics,installedontheelectricitysupplylinein
accordancewiththerelevantregulations.
Theseswitchesmustbeinstalledclosetothedishwasher,beeasilyaccessibleafter
installation,andprovidecompletedisconnectionfromtheelectricalmainsin
overvoltageclassIIIconditions.


Warning!!!
Thedishwasherisalwayspoweredupunlessthemasterswitchisturnedoff.


Connecttheappliancetotheuser’searthsystem.Theterminalfortheconnectionis
inthebottomright‐handcorneroftheappliance.
Theearthwire(PE)isyellow‐greenincolour,theneutralwire(N)isblueandthelive
wires(L1,L2,L3)areblack,greyandbrown.
Intheeventofsingle‐phaseconnection(230V‐1N~),theconnectiontotheelectrical
mainsmustbemadeusingacablewithplugcompliantwiththerelevantregulations.


THEPOWERSUPPLYCABLEMUSTBEREPLACEDBYTHEMANUFACTURERORAN
AUTHORISEDSERVICECENTRETOPREVENTALLRISKS.


‐CW620/630

11
Figure1–Applianceelectricalconnectiondiagram

‐CW620/630

12
5 FIRST START-UP
Firststart‐up
Theelectricalprotectionsystemmustundergoafunctionaltestbeforetheapplianceisputinto
operation.
Theappliancemustbeinstalledand/orinspectedbyqualifiedstaff,whowillstartitupforthefirst
timeandprovidetherelevantoperatinginstructions.


Preparingforuse(important)
Therinseaiddispenserisfittedonallmodels,thedetergentdispenseronlyonsome.
Ifbothdispensersarepresentputtheexternaldetergentandrinseaidcontainersinplaceand
inserttherespectiveintakehosesontherearoftheapplianceintothem.
Redhose:detergent
bluehose:rinseaid



Beforeinsertingthehosesintothecontainers,fittheweights(needed
toensurethattheyalwaysdrawinliquidfromthebottomsofthe
containers)andthefiltersontotheirendsasshown.
Ifthedetergentdispenserisnotfactory‐fitted,itcanberetrofitted
afterorderingtherelativekit.


Asanalternativeanexternaldispensercanbefitted,makingtheelectricalconnectionbymeansof
anH05RN‐F2x0.5mmelectricalcable,whichcanbelaidalongtherouteshownintheTECHNICAL
DATAdiagram.Theelectricalconnectionmustbemadeinaccordancewiththeelectricalsystem
diagramsuppliedwiththedishwasher,disconnectingtheinternaldispenser,ifany,andmakingthe
connectiontotheexternalunit.
Thedispensermustoperateon230V/50Hzwithmaximumpowerabsorptionof15W.
Connecttothedetergentdispenseroutsidethedishwasherusingtheredhosementionedabove.


Asanalternativeanexternaldispensercanbefitted,makingtheelectricalconnectionbymeansof
anH05RN‐F2x0.5mmelectricalcable,whichcanbelaidalongtherouteshownintheTECHNICAL
DATAdiagramandconnectedasshowninthewiringdiagramsuppliedwiththedishwasher.
Thedispensermustoperateon230V/50Hzwithmaximumpowerabsorptionof15W.
Connecttothedetergentdispenseroutsidethedishwasherusingtheredhosementionedabove.


‐CW620/630

13

6 SET-UP

6.1 Dishwasherparametermodificationprocedure:
Onlyaccessibleafterfillingiscompleteorwiththehoodopen.

Access“programmingmode”bypressingthebuttonfor
afewsecondswiththeapplianceonwiththehoodopen
andthetankempty(afterthefillingandheatingphases).
ThedisplayshowsUnLo1:58;whenthebeepsounds,
releasethebuttonandpressitagainatonce.Keep
pressingthebuttonagaintoscrollthroughallthe
modifiableparametersinthefollowingorder:

Rinsingtemperature(boilertemperature)




IMPORTANT: 

Wheneverthetypeofdetergentorrinseaidischanged,itisABSOLUTELYESSENTIALtoflushout
theperistalticpumpsbyplacingtheexternalintakepipesinwaterforafewcycles.

Alwaysuseonlyproductsspecificallyrecommendedforuseinadishwasher.

Failuretocomplywiththisrecommendationleadstoforfeitureofthewarrantyentitlementon
theappliance’swatersystem.

TheinternalpipesofthedetergentandrinseaidpumpsshouldbereplacedbytheAfter‐Sales
Serviceevery12monthsor15,000washcyclesandoperationofthediaphragmrinseaidpump
shouldbechecked.


Set‐up
Duringfirststart‐up,thefunctions/parameterslistedbelowmustbesetoradjusted:

‐CW620/630

14
Washingtemperature(tanktemperature)

Quantityofrinseaiddispensed,OPT,onlyifinstalled(the
numberindicatesthenumberofsecondsforwhichthe
peristalticpumpisoperated)


Quantityofdetergentdispensed,OPT,onlyifinstalled(the
numberindicatesthenumberofsecondsforwhichthe
peristalticpumpisoperated)


Start‐on/start‐off
Setat“on”tostartthecyclewhenthehoodisclosed.
Setat“off”forcyclestartafterconfirmationwiththestart
button 


Waterhardnesssetting(OPT,onmodelswithsoftener
only)


tStPon/off
“on”=minimumrinsingtemperatureasset,regardlessof
intakewatertemperature;thecycledurationmaybeafew
secondslongerthanthenominallength.
“off”=theminimumrinsingtemperaturemightbeafew
degreeslowerthanthesettingifhotintakewaterisnot
used. 


‐CW620/630

15
Rinseaidpumptotaloperatingminutesdisplay.
Thisvaluecanberesetafterpumpmaintenance‐see
below.


Detergentpumptotaloperatingminutesdisplay.
Thisvaluecanberesetafterpumpmaintenance‐see
below.


Energyconsumption(kW)display
ThePcoptionindicatesthetotalkWconsumedsince
installationofthedishwasherorsincethelatestreset.


Displayofthenumberofcyclesperformed
Whenscrollingthroughtheapplianceparameters,the“tc
88888”itemwillalsoappear;thisisthecountofthetotal
cyclesperformedbythedishwashersinceinstallation.
Thisparametercannotbemodifiedorresetunlessthe
softwareisreprogrammed.


CustomisationofdurationofprogramP4.




‐CW620/630

16
Steamextractionsystemoperatingtimedisplayand
setting




Thissubmenuandtherelativefunctionscanonlybe
accessedwiththeaidofapasswordavailableon
SmegTechandonlybytechnicalstaff.


6.2 Quit“SET‐UP“menu
Waitmorethan10secondswithoutpressinganybuttonandtheappliancequitsthismenu
automatically,
orpresstheon/off buttontoexit.


Caution:thetankandboilertemperaturesshownonthedisplaymaybedifferentfromtheactual
temperaturesbyafewdegrees,especiallyintransientphases(justaftertheFILLiscompleted,justafter
theendofthecycle,etc.)duetotheinertiaofthemeasurementprobe.


6.3 Rinsingtemperaturesetup

Modifythevalueoftheparameterbypressing.

‐CW620/630

17
6.4 Washingtemperaturesetup

Modifythevalueoftheparameterbypressing.


6.5 Rinseaiddispensingsetup


Modifythevalueofthe
parameterbypressing
.
RINSEAID
Deliverytime
(s)
Delivery
quantity(c.c.)
 
00,0
60.6


*defaultvalue(factorypreset)

121.2
181.8
242.4
30*3.0
363.6
424.2
6.6 Adjustingdetergentdispensing(optionalifinstalled)


Modifythevalueofthe
parameterbypressing
.
DETERGENT
Deliverytime
(s)
Delivery
quantity(c.c.)
00.0
41.4
82.8

*defaultvalue(factorypreset)

12*4.3
166.7
207.1
248.5
  3011.7
  3613.3


4215.0

‐CW620/630

18
6.7 Autostartfunction
Modifytheparameter(ON/OFF)bypressing .
Setat“on”tostartthecyclewhenthehoodisclosed.
Setat“off”forcyclestartafterconfirmationwiththestartbutton 

6.8 Regenerationfrequencysetup(modelswithsoftener)
(Defaultvalue:H03;modifytheparametertosuitthemainswaterhardness.
Atfirstuse,thesalttankhastobefilled.Itissubsequentlysufficientsimplytofillupwith
regeneratingsaltwhennecessary.





Modifythe
valueofthe
parameter
bypressing
.
Hardness
(°dHGerman
degrees)
Hardness(°dF
French
degrees)
Setting
level
Regeneration
offRegenerationoffH00
8.515H01
1120H02
1730H03
22.540H04
2850H05
Important:
Duringnormaloperation,thedishwasherwillperform
anumberofwashingcycleswhileregenerationisin
progress.Duringthistime(5‐6cycles)theintake
waterwillnotbetreated,butthiswillnotaffectthe
washingquality.

33.5
60
H06

Withvaluesover60°fanexternalwatertreatmentdevicemustbeusedandtheregenerationfrequency
mustbesetonH00.

‐CW620/630

19
6.9 tStP(minimumrinsingtemperature)function

Modifytheparameter(ON/OFF)bypressing .

Setat“on”forminimumrinsingtemperatureasset;setat“off”forrinsingregardlessofboiler
temperature.
Iftheparameterissetas“off”andhotintakewaterisnotused,theminimumrinsingtemperature
mightbeafewdegreeslowerthanthesetting.

Ifthethermostopdeviceisset“off”therinsingT°arenolongermonitoredandtheuseris
responsibleforensuringthattheminimumcorrectT°aremaintainedforthetankandboiler.Itis
particularlyimportanttochecktheintakewatertemperature.
Alsorefertotheinsufficientwashing/drying/foamintankpointofthe“troubleshooting”section:
restoreTStopONand/orconnecttheappliancetoahotwatersupply

6.10Rinseaidpump(displayandifrequiredresetduringmaintenance)

Toreset,press for3seconds.
6.11Detergentpump(displayandifrequiredresetduringmaintenance)

Toreset,pressfor3seconds.

‐CW620/630

20
6.12Energyconsumption–Displayandresetifrequired
Toreset,press for3seconds.
6.13CustomisationofdurationofprogramP4.
ThedurationofprogramP4canbecustomisedfrom3to10minutes


Accesstheprogrammingprocedureandscrollthroughto
“ınF”usingthebutton,thenscrollthroughto03:00and
pressthebuttontosetthetimerequired(from3to10
minutes)

Afterafewsecondswithouttheuserpressinganybuttons,
thedisplaywillreturntothenormaloperatingstatusandthe
modificationswillbesaved.
6.14Steamextractiontimesetting(optionalifinstalled)

Steamextractionsystemoperatingtimedisplayandsetting

