SOLDER PEAK ZD-153 User manual

Fume Extractor - Model: ZD-153
1.

2. Features
• Removes solder fumes efficiently.
• Adjustable angle for accurate placement, high performance and low noise fan.
• Replaceable activated carbon filter made of high quality PU foam.
• Can significantly reduce headaches, eye irritation and nausea.
• Both regular and ESD versions are available.
• Absorption capacity: 1m³/min(Max).
3. Specifications
Power: 23W
Dimensions: 220(W)×270(H)×168(D)mm
Weight: 1.4kg
Spare parts: 2pcs of filter
4. Operation
1. Take the fume extractor out of the package and put it on the table.
2. Adjust the angle of the fan as needed.
3. Plug in and switch it on. Your work is ready to go.
4. The filter should be replaced once a month under normal use as its absorption ability has declined.
5. Warning
• Read this manual carefully and use the item only according to this manual.
• This item is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the item by a person responsible for their safety.
• If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly
qualified person in order to avoid hazard.
• Observe the valid safety regulations for your workplace.
• Work only in well ventilated places.
• Do not run the power cord around sharp edges or over hot surfaces.
• Do not work on electrically live parts.
• During breaks and after work, do not leave the item unattended while it is turned on. Keep children

away from the item while it is in operation.
• Unplug it when it is not in use or being cleaned. Do not pull on the power cord, always grasp the plug.
• Always allow the item to cool down completely before cleaning or storing it.
• Do not immerse the item in liquids of any kind.
• Do not disassemble the item and do not attempt to repair it yourself. It does not contain any serviceable
parts for you. In case of questions or problems turn to our customer service.
• Waste electrical products should not be disposed of with household waste.
• Recycle where facilities exist. Check with you local Authority or retailer for recycling advice.
