Talking Thermostat
Key Information
Guide
Models
VT1007, VT2007 & VT2207

Talking Thermostat
Key Information Guide
Models VT1007, VT2007 and VT2207
TOPICS Page(s)
All Settings: Quickly Reviewing ...........................................................12
Bypass Compressor Short Cycle Protector ..........................................5
Calibrate Indoor Temperature................................................................2
Cycle Rate (Setting)...............................................................................3
Fahrenheit to Celsius (Changing to and from).......................................4
Filter, Service and UV Light Alerts –
Default Setting (Months & Optional Hours) ........................................9
Adjusting Months .............................................................................10
Changing to Hours ...........................................................................11
Adjusting Hours ...............................................................................11
Reviewing Months (or Hours) ..........................................................12
Clearing “CHK FILT” Display ............................................................13
Clearing “CFS” Service Display .......................................................13
Clearing “CFS” UV Light Display......................................................13
Resetting Filter Months or Hours (CFS Svc, CFS UVL, CHK FILT ...13
Turning Off CHK FILT Alert .................................................................9
Heat Pump
Activating Emergency Heat (“Eon”)..............................................6, 14
Reducing 2nd Stage Time Delay (“Eon”)................................6, 14, 17
Locking Out Programmable Operation .................................................7
Locking Out All Operations ...................................................................7
Model Number by Type .........................................................................1
Operation Keys (Descriptions & Functions)...........................................1
Program Keys........................................................................................6
Reset Key
Escape Program Mode..........................................................................4
Escapes Faulty Operation (FFr) .............................................................4
Service Alert – (see above Filter, Service and UV Light Alerts)
Troubleshooting Tips ...........................................................................17
Voice On/Off (Set Point Temp UP & DOWN Keys) ................................8
VT2007 2nd Stage Differential – Setting..............................................14
VT2207 2nd Stage Differential – Setting..............................................16
VT2007& VT2207: 2nd Stage Differential Table...................................15

Operation Keys and Alert Light
Model Number by Type
1
For Custom Message / Warranty Information
Press HELP
For Indoor Temperature and Set Point Temperature
(Also reports Check Filter, Low Battery and Call For Service)
Press REPORT
ALERT LIGHT – When Flashing Press REPORT Key to
hear alert message
To Raise Temperature Press UP
To Lower Temperature Press DOWN
FUNCTION Key
Press BRIEFLY to backlight display screen
Press and HOLD to hear revision number
MODEL Number
VT1007 -- Single Stage Heat / Cool
VT2007 – 2 Stage Heat / Single Stage Cool / Heat Pump
VT2207 – 2 Stage Heat / 2 Stage Cool (NOT for Heat Pumps)

Calibrate Indoor Temperature
2
Press the UP and DOWN keys together
and HOLD until INDOOR TEMPERATURE
starts to FLASH. RELEASE. Press the UP
or DOWN key to raise or lower INDOOR
TEMPERATURE to the desired setting.
When finished
press RUN.
NOTE: Indoor Temperature calibration is limited to (+ / -) 3˚ F /
2˚ C from factory default setting. Do not calibrate until unit has
run one complete cycle.

Setting Cycle Rate
3
Press the UP and DOWN keys together
and HOLD until INDOOR TEMPERATURE
starts to FLASH. RELEASE. Press BOTH
again until Cr1 appears in setpoint location.
Press UP and DOWN key to move to the
desired setting. Press Run.
Cr1 will appear here.
NOTE:
Cr1 = 1 Degree
Cr2 = 2 Degrees
Cr3 = 3 Degrees
CR1

Fahrenheit to Celsius
& Reset Key
4
To Change From Celsius to Fahrenheit,
Press and HOLD the YES and NO keys
together for 6 seconds.
Reset Key
The RESET key has two primary functions.
1. Escape Program Mode: If, during programming, you
get lost or wish to quit, press RESET. You will exit the
programming mode without making changes.
2. FFr (Escapes Faulty Operation): Static discharge
can cause faulty operation. To correct, press both
the NO and RESET buttons together until the display
disappears. When it reappears, press the RUN button
to accept the FLASHING INDOOR TEMPERATURE.

Bypass Compressor
Short Cycle Protector
5
If you turn the cooling OFF and back ON in
less than 5 minutes, the unit will activate
the time delay. COOL and DELAY will
FLASH.
Press the NO and FUNCTION keys and
HOLD for 8 seconds. This will disable
the time delay feature for 10 minutes.
COOL will stop FLASHING and DELAY
disappears.
COOL
DELAY

Program Keys
6
PROGRAM ON / OFF KEY
Press to turn program on or off.
WEEKDAY AND WEEKEND KEYS
Press and follow instructions to change program.
DAY / TIME KEY
Press and follow instructions to change the time
and day of the week.
RUN KEY
Press to advance to next step when programming.
NOTE:
On heat pump models, pressing and holding RUN
and YES will send thermostat into emergency or
reserve heat. This also reduces the Time Delay
between 1st & 2nd stage HEAT to 1 minute. To
restore the default 8-minute delay, perform an
“FFr” Reset per instructions on page 4.

Locking Out Programmed Operation
7
Locking Out All Operations
Lock out
prevents users
from accidentally
running
programmable
operation. Press
Full lock
out prevents
unauthorized
users from
making changes.
Press and hold
YES and HELP
keys until you
hear “OFF”.
and hold NO and ON/OFF keys for 6 seconds.
Audio plays “OFF” when any program button is
pressed. To unlock, repeat same.
Locks out all functions except the REPORT
and HELP keys. To unlock, repeat same until
you hear “O”.

Voice On/Off
(When changing Setpoint Temperature)
8
Press and HOLD the UP key for 8
seconds to activate the VOICE ON
when changing setpoint temperature.
Press and HOLD the DOWN key for 8
seconds to activate the VOICE OFF
when changing setpoint temperature

FP (Filter Period), SP (Service Period)
and ULP (UV Light Period) will display here.
NOTE:
Default Period Settings:
FILTER PERIOD (FP): 1 MONTH
(after 1 month CHK FILT appears)
SERVICE PERIOD (SP): 6 MONTHS
(after 6 months CFS appears)
UV LIGHT PERIOD (ULP): 0 MONTHS
(CFS for UV Light is turned off at 0 setting)
FP (Filter Period), SP (Service Period) Range: 1 TO 24 MONTHS
ULP (UV Light Period) Range: 0 TO 24 MONTHS
(Optional) Default Hours Settings
FILTER HOURS: 400 HOURS
after 400 hours CHK FLT appears)
SERVICE HOURS: 3000 HOURS
(after 3000 hours CFS appears)
UV LIGHT HOURS (ULH): 0 HOURS
(CFS for UV Light is turned off at 0 setting)
FH (Filter Hours) and ULH (UV Light Hours) Range:
0 TO 3000 HOURS
SERVICE HOURS Range:
200 TO 3000 HOURS
Note: Check Filter alert can be turned off by setting it to FH 00 00
Note: To change months to hours see page 11
Filter, Service and UV Light Alert
Monthly Settings
9
FP 01

1. Press and HOLD NO, then
2. Press and HOLD WEEK DAY until SET POINT
TEMPERATURE displays FP (Filter Period). The clock
display will begin flashing 01 (1 Month).
3. Press UP or DOWN to change filter months
4. Press RUN to advance to SP (Service Period). The clock
display will begin flashing 06 (6 months)
5. Press UP or DOWN to change service months.
6. Press RUN to advance to ULP (UV Light Period). The clock
display will begin flashing 00 (0 or zero months)
7. Press UP to set UV Light months.
8. Press RUN to finish
Tip: Count number of months to next Filter Check,
System Service CFS or UV Light CFS and enter that
number.
Adjusting Filter, Service
and UV Light Period (Months)
10
FH 04 00

Changing to & Adjusting Filter,
Service and UV Light Hours
11
1. To enter HOURS of operation (instead of MONTHS)
press the DOWN key until FP 00 (zero) appears and
press RUN.
2. Display changes to flashing FH 04 00 (400 hours)
3. Press the UP or DOWN key to change the Filter HOURS
Note: Check Filter alert can be turned off by setting
it to FH 00 00. This is useful for boiler systems without air
filters
4. Press the RUN Key and display changes to flashing SH
30 00 (3000 hours)
5. Press the UP or DOWN key to change the Service
HOURS
6. Press RUN and the displays changes to flashing
ULH 00 00
7. Press UP to change UV Light HOURS
8. Press RUN Key to Finish
FH 04 00

FH 04 00
1. Press and HOLD NO, then
2. Press and HOLD WEEK END until SET POINT
TEMPERATURE displays FP (Filter Period) or FH (Filter
Hours). The number of months that has elapsed or hours the
system has been operating will be displayed.
3. Program will automatically advance to SP (Service Period) or
SH (Service Hours). The number of months that has elapsed
or hours the system has been operating will be displayed.
4. Program will automatically advance to ULP (UV Light Period)
or ULH (UV Light Hours). The number of months that has
elapsed or hours the system has been operating will be
displayed.
Quickly Review All Settings
(Filter, Service, UV Light, Cycle Rate & 2nd Stage
Differential)
To quickly review all settings for CHK Filter, CFS, ULV, Cycle Rate
and 2nd Stage Differential, press and hold NO then WEEKEND.
When FP or FH appears press YES to view all current settings.
Reviewing Filter and
Service Months (or Hours)
12

Clearing and Resetting Period (or Hours)
for CFS (for service), CFS (for UV Light)
and CHK FILT
13
To remove “CFS” for Service Period or Service Hours, Press and HOLD NO
for 6 seconds until “CFS” disappears. Resets Service Period to 0 (zero) months
or Service Hours to 1.
To remove “CFS” for UV Light Period or UV Light Hours, Press and HOLD
YES for 6 seconds until “CFS” disappears. Resets UV Light Period to 0 (zero)
months or UV Light Hours to 1. This also resets Check Filter (see below)
To remove CHK FILT and reset Filter Period to 0 (zero) months or Filter Hours to
1, Press the REPORT key.
To manually reset Filter Period to 0 (zero) months or Filter Hours to 1, Press
and HOLD YES for 6 seconds. This also resets UV Light Period (see above)

VT2007 ONLY
2nd Stage Heat Operation
Setting 2nd Stage Differential & HP Emergency Heat
14
HEAT 2-Stage Operation
In 1st stage, the HEAT icon shines steady.
In 2nd stage, the HI and HEAT icons shine steady.
Note: When 1st stage first cycles on, it WAITS 8 MINUTES before advancing to 2nd
stage. If during this delay demand requires 2nd stage the HI and DELAY icons will flash.
Changing 2nd Stage Differential
Press the UP and DOWN keys together and HOLD until INDOOR TEMPERATURE starts
to FLASH. RELEASE. Then press again until Cr1 appears in setpoint locations. Press again
and HOLD until 2n2 appears in setpoint location. Press UP or DOWN key to move to
desired setting. Then press RUN.
2nd Stage Differential Settings
Please see table on (next) page 15
Activating Emergency Heat (Heat Pumps Only)
To activate EMERGENCY HEAT ONLY on heat pump systems, press and HOLD RUN
and YES until Eon alternately FLASHES with the setpoint temperature. To deactivate
EMERGENCY HEAT ONLY, press and HOLD RUN again until Eof briefly appears and
then disappears. Running EMERGENCY HEAT also reduces the time delay between
stages to 1 MINUTE.
Note: On heat pump systems the GAS/ELECTRIC SWITCH located on CIRCUIT
BOARD below the battery holder must be in the “E” (Electric) position.

VT2007 and VT2207
2nd Stage Differential Settings
15
Differential Setting 2nd Stage ON
Fº (Cº) Differential
from 1st Stage
2nd Stage OFF
Fº (Cº) Differential
from 1st Stage
Comment
2n0 None None 2nd Stage is not
activated. Use the
setting on single
stage systems
2n1 0.5º F (.25º C) 0.5º F (.25º C) Takes out 2nd
Stage before
satisfied
2n2
(Default Setting) 1.0 F (.50º C) 0.5º F (.25º C) Takes out 2nd
Stage before
satisfied
2n3 1.5 F (.75º C) 0.5º F (.25º C) Takes out 2nd
Stage before
satisfied
2n4 2.0 F (1.0º C) 0.5º F (.25º C) Takes out 2nd
Stage before
satisfied
2n5
(for 2 Stage Heat)* 1.0 F (1.0º C) Same as 1st Stage 2nd Stg stays energized until 1st
Stg satisfied
2n6
(for 2 Stage Heat)* 1.0 F (1.0º C) Same as 1st Stage 2nd Stg stays energized until 1st
Stg satisfied
2n7
(for Dual Fuel)** 1.0 F (.50º C) Same as 1st Stage VT2007 Only (locks out 1st
Stage on call for
2nd stage)
2n8
(for Dual Fuel)** 2.0 F (1.0º C) Same as 1st Stage VT2007 Only (locks out 1st
Stage on call for
2nd stage)
• 2nd Stage Differential is the sum of “Cycle Rate” (See Page 4) and the “2nx”
selected (below)
• When thermostat is running in 2nd Stage, the HEAT and HI icons or (VT2207
only) the COOL and HI icons are displayed
• To reduce the 8 min delay between 1st and 2nd Stage, move the HEAT/
COOL switch to OFF and then press and hold YES & RUN together for 10
seconds.
* 2n5 and 2n6 are for 2 Stage Electric Heat systems and run 1st Stage until
1st Stage is satisfied.
** 2n7 and 2n8 are for Dual Fuel / Hybrid systems andlocks out 1st Stage
when 2nd Stage is energized (VT2007 only).

VT2207 ONLY
2nd Stage Heat / Cool Operation
Setting 2nd Stage Differential Not for Heat Pumps
16
HEAT 2-Stage Operation
In 1st stage the HEAT icon shines steady
In 2nd stage the HI and HEAT icon shines steady
Note: When 1st stage first cycles on it waits 8 minutes before advancing to
2nd stage. If during this delay demand requires 2nd stage the HI and DELAY
icons will flash.
COOL 2-Stage Operation
In 1st stage the COOL Icon shines steady
In 2nd stage the HI and COOL Icon shines steady
For more details of operation see User’s Guide (in product box) page 7.
Note: When 1st stage first cycles on it waits 3 minutes before advancing to
2nd stage. If during this delay demand requires 2nd stage the HI and DELAY
icons will flash.
Changing 2nd Stage Differential
See page 14 VT2007 “Setting 2nd Stage Differential” and the “2nd
Stage Differential Table” on page 15.
NOT for Heat Pumps
Note: The VT2207 is NOT designed to operate 2 Stage Heat Pump
Systems

Note! Unlike other programmable thermostats most Talking
Thermostat problems can be corrected over the phone.
Calibration
• Never calibrate thermostat until system has run through one
complete cycle. If calibration is required see page 2.
• HEAT Mode Complaints Calibration Solution
“Gets too hot” Raise the Indoor Temp 1 or 2 degrees
“Too cold when shuts off” Lower Indoor Temp 1 or 2 degrees
• COOL Mode Complaints Calibration Solution
“Gets too cold” Raise Indoor Temp 1 or 2 degrees.
“Too warm when shuts off” Lower Indoor Temp 1 or 2 degrees.
Improper or Erratic Operation
(no heat or cool, incorrect display screen characters, indoor temp
stuck, wrong indoor temp reading, etc.):
• Check for low battery voltage. Make sure at least 3.00 Volts per pair
• If a model VT1007 make sure jumper between RH & RC.
• Check that wiring is connected to the correct terminals per wiring
diagram.
• Processor possibly spiked by a static discharge. Do an FFr Reset.
Heat/Off/Cool Switch or Fan Switch stuck or hard to move
99% of time common from transformer has been applied to circuit
board. Most switch damage can be repaired. Call for a Warranty
Return Authorization Form.
Time Saving Tips
• All time delays can be by-passed for 10 minutes by pressing both the
NO and Light Keys for 10 seconds.
• VT2007 and VT2207 Only: To reduce the 8 min delay between 1st
and 2nd Stage, move the HEAT/COOL switch to OFF and then press
and hold YES & RUN together for 10 seconds. Note: To reset the
1-minute delay back to 8 minutes, do an FFr.
• To review time and temperature program settings or make just one
or two changes, press the NO key when “minutes” are flashing.
Program will advance to next time period (WAKE, DAY, EVE or
SLEEP).
Tech Support - 8 A.M. to 5 P.M. CST
Phone Toll Free 866-743-5663
Talking Thermostat
Troubleshooting & Time Saving Tips
17
