Song Max HMP-138 User manual
LED BULBS
SPEAKER
ON / OFF SWITCH
DEMO / PLAY SELECTOR (at rear)
BATTERY COMPARTMENT (at rear)
8 INSTRUMENTS
INSTRUMENT SWITCH
STOP BUTTON
EDIT SOUND
ONE KEY ONE NOTE
CHORD ON / OFF
RED LED BULB
RECORD / REPLAY KEY
8 RHYTHMS
BLACK & WHITE 37 KEYS
TEMPO CONTROL
DEMO SELECT BUTTON
BEAT MODE
4 DRUMS
ALL DEMO SELECT BUTTON
VOLUME CONTROL
BOOK STAND
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
KEYBOARD
INSTALLING BATTERIES
IMPORTANT
Switch to "PLAY"
before use.
The "DEMO" mode is for
shelf sales demonstration
purpose only.
HMP-138
INSTRUCTIONS For ages 3 and up
INSTALL BATTERIES AS SHOWN
USES 4 "AA" BATTERIES (INCLUDED)
*For the keyboard's best performance and longest life, we recommend same type of New Alkaline Batteries *
Notes : WATCH CAREFULLY THE + AND - ENDS OF BATTERIES.
IF YOU DON'T INSTALL BATTERIES CORRECTLY THE KEYBOARD WILL NOT WORK.
REMOVE BATTERIES IF UNIT IS NOT TO BE USED FOR A LONG PERIOD OF TIME (ABOUT 30 DAYS OR MORE)
TO PREVENT BATTERY LEAKAGE AND POSSIBLE DAMAGE TO THE UNIT.
Follow these steps to install batteries.
1. Set "PLAY' mode at rear and ON/OFF (on the front of the keyboard) to the "OFF" position.
2. Use a screwdriver to loosen the screw on the battery compartment cover.
3. Install the batteries in the compartment as indicated by the polarity symbols ( + and - ) as marked inside.
4. Close the cover, then tighten the screw.
5. When the volume weakens or the keyboard stops operating properly, replace the batteries.
CAUTIONS :
∗If you do not plan to use the 37-keys keyboard for 4 or more weeks, remove the batteries.
∗Dispose of old batteries promptly and properly. Do not burn or bury them.
PRECAUTION :
Do not mix old and new batteries.
Do not mix alkaline, standard (Carbon-zinc), or rechargeable (Nickel-cadmium)batteries.
Do not use rechargeable batteries.
(The packaging has to be kept since it contains imprtant information)
- 1 -
WARNING:
CONTAINS THE GLASS LIGHT
BULB WHICH COULD CAUSE AN
INJURY IF THE TOY IS BROKEN!
Made in China
16
15
14 13 12 11 10
17
18
19
21
20
1
9 8 7 6 5
4
3
2
1
2
HMP-138
INSTRUCTIONS For ages 3 and up
1. LED Bulbs : Sounds are lighting system with changeable running flash-lights.
2. Speaker : Left and right speakers.
3. On / Off : At rear of keyboard switch "PLAY" set, the ON/OFF switch to normal. (Keyboard shut-off automatically. If you do not press
any key for about 60 minute and hear a short melody and LED light up) When powerswitch ON, the keyboard is default
setting and hear a short melody and LED light up. Base on the power is "ON" + "PLAY" mode or "DEMO" + "ON/OFF"
mode you may press any key to restart.
4. Demo / Play : At rear of keyboard switch "PLAY" before use.
The "DEMO" mode is for shelf sales demonstration purpose only. Switch "DEMO" mean "Try-Me" available. Press
function keys (Demo next, Demo all, Beat mode, OKON, Record, Replay:After record still light up, and 8 Rhythms) play 10
minute will stop.
Batteries Compartment : See install batteries as shown as above.
5. 8 Instruments : Press once to choose from the 8 percussion instrument sounds key available. You can create your own melodies on the
keyboards. Just the black and white keys. The keyboard automatically selects the piano sound each time you turn it on.
To select a different instrument sound, press the desired sound's button. (Piano, Music Box, Bass, Trumpet, Flute,
E.Piano, Oboe and Jazz Guitar)
*8 Instruments + 4 Drums : Press once to choose from the 8 percussion instrument sounds key available. You can create your
own melodies on the keyboard. Just play the black and white keys and add any 4 drums sound in
your melodies.
6. Instruments Switch : Press the instrument switch key to switch between the 8 instruments choose from echo, you can create your own
melodies on the keyboard. Just play the black & white keys.
7. Stop : Exit the any mode by pressing the STOP key.
8. Edit Sound : Press to Edit 8 Instruments to produce special effects. Press one to vibration, press twice to produce echo effect and press
again to resume / press STOP to exit produce special effects and before selected instrument.
9. OKON : Press OKON once to choose first demo song, press again to choose the next song. Meanwhile, the background music start
demo sound continuously play the black & white keys until the end of playing and with right size LED light up. Press STOP key to
turn off this function.
10. Chord : Press CHORD are non-stop sound to switch on the any 8 rhythms. Press once to switch off are single beat & press again to
resume. When switch the lighting system changeable running flash-lights. You can create your own melodies on the keyboard.
Just play the black & white keys. Press STOP key to turn off this function.
*OKON + Chord : Press OKON + CHORD have demo song and background music, press again OKON to choose the next song. Just
play the black & white keys unit the end of playing and with lighting system changeable running flash-light. Press
STOP key to turn off this function.
11. Red LED Blue : RECORD and REPLAY the LED light up signal is ON.
12. Record / Replay : -Press Record when Red LED Blue light up and produce background music with lighting system changeable running
flash-light. Just play the black & white keys to create your own tune.
-Press Replay to hear it your record music at about 6 minute, press Replay again will play once each time. The
Replay button is pressed unit the Red LED Blue light up. Press STOP key to turn off this function.
13. 8 Rhythms : Press once to choose from non-stop the 8 rhythm keys background music available, press again to choose different
styles of best (New Wave, Swing, Waltz, Rock, Disco, Twist, Blues & 16 Beat Pop) and lighting system changeable running
flash-lights. You can create your own melodies on the keyboard. Just play the black & white keys. Press STOP key to turn
off this function.
*8 Rhythms + 4 Drums : Press once to choose from non-stop the 8 rhythm keys background music available. You can create your own
melodies on the keyboard. Just play the black and white keys and add any 4 drums sound in your melodies. Press STOP key to turn off
this function.
14. Black & White Keys : You can create your own melodies on the keyboard. Just play the 37 keys of black and white.
15. Tempo Control : You can adjust the tempo of the background rhythm with the two Tempo Buttons. Press UP button to speed up the
tempo and press DOWN button to slow the tempo down.
16. Demo Next : Press once to choose first demo song, press again to choose the next song. When start the demo song continuously until
the end of music and the lighting system changeable running flash-lights. Press STOP key to turn off this function.
17. Beat Mode : Press this key the sound is non-stop and lighting system changeable running flash-lights. Press STOP key to turn off this
function.
18. 4 Drums : There are 4 different styles buttom (Cowbell, Ride CYM, B.Drum and S.Drum) of drums. Press any drum button to hear its
sound.
*Beat Mode + 4 Drums : Press BEAT MODE is non-stop music + any 4 DRUMS are a few minute sound and lighting system changeable
running flash-lights. Press STOP key to turn off this function. You can select any 8 instruments sound to create
your own melodies on the keyboard. Just play the black & white keys. Press STOP key to turn off this function.
19. Demo All : Pressing the DEMO ALL key will play the demo songs with lighting system changeable running flash-light. There are a total
demo songs that can be selected in button. During the demo all mode, the 37 keys will be disabled player can change the
demo instrument by pressing the instrument keys. Press STOP key to turn off this function.
20. Volume Control : The volume control has several levels. The keyboard automatically selects the regular levels for each time you turn it
on. To adjust the volume repeated press the UP to increase the volume and DOWN to decrease
21. Book Stand : Put down the book stand on the holder and put out to release.
(The packaging has to be kept since it contains imprtant information)
- 2 -
OPERATION
