Sonic Technology LCS110 User manual

16
Manufactured and Distributed by:
Sonic Technology Products, Inc.
P.O. Box 539
Grass Valley, CA 95945 USA
1-800-247-5548
www.sonictechnology.com
Model LCS110/LCT100/LCR100
Wireless Auditory
Assistance System
Operating Manual
16
Manufactured and Distributed by:
Sonic Technology Products, Inc.
P.O.Box 539
Grass Valley, CA 95945 USA
1-800-247-5548
www.sonictechnology.com
SuperEar
LoudandClear
Model LCS110/LCT100/LCR100
Wireless Auditory
Assistance System
Operating Manual
®
®
TM
TM
SuperEar
LoudandClear

ThankyouforpurchasingtheSuperEar®Loudand
ClearFMTransmitter/ReceiverWirelessAuditoryAssis-
tanceSystem. The SuperEar®LoudandClear is designed
andmanufacturedtoprovideclear,crispstereosound from
eitherof two sources:(1)Transmissionof normalvoice
usingthesuppliedmicrophoneor(2)Transmissionof
television,MP3programming oranyother soundsource
usingthesupplied3.5mm auxiliary cable.TheTransmitter
then sends thesignal, using one of three pre-selected FM
Radiofrequencies,totheReceiver.
The Receiver unit receives the audio signal from up
to 150 feet away and converts it to sound waves that can
be heard through the supplied earbuds and adjusted to the
desiredvolume.
THELOUDandCLEARISNOTANFMRADIO!
FOR BEST RESULTS, USE IN LINE-OF-SIGHT
COMMUNICATIONS. SOUND QUALITY WILL
DEGRADE AS WALLS AND OTHER OBSTACLES
MAY INTERFERE WITH SOUND TRANSMISSION.
TheLoudandClearisidealfor
•Classroom or Lecture environments
•Worship Services
•Tour Groups
•Hospitals and Long Term Care Facilities
•Television Viewing 2 15
2 15
ThankyouforpurchasingtheSuperEar®Loudand
ClearFMTransmitter/ReceiverWirelessAuditoryAssis-
tanceSystem. The SuperEar®LoudandClear is designed
andmanufacturedtoprovideclear,crispstereosound from
eitherof two sources:(1)Transmissionof normalvoice
usingthesuppliedmicrophoneor(2)Transmissionof
television,MP3programming oranyother soundsource
usingthesupplied3.5mm auxiliary cable.TheTransmitter
then sends thesignal, using one of three pre-selected FM
Radiofrequencies,totheReceiver.
The Receiver unit receives the audio signal from up
to 150 feet away and converts it to sound waves that can
be heard through the supplied earbuds and adjusted to the
desiredvolume.
THELOUDandCLEARISNOTANFMRADIO!
FOR BEST RESULTS, USE IN LINE-OF-SIGHT
COMMUNICATIONS. SOUND QUALITY WILL
DEGRADE AS WALLS AND OTHER OBSTACLES
MAY INTERFERE WITH SOUND TRANSMISSION.
TheLoudandClearisidealfor
•Classroom or Lecture environments
•Worship Services
•Tour Groups
•Hospitals and Long Term Care Facilities
•Television Viewing

CONTENTS (LCS110 Only)
1–FMTransmitter(LCT100)
1–FMReceiver(LCR100)
1–RechargingWallPlug
2 – USB(USBtoMini USB) Recharging Cable
4 – AA Rechargeable Batteries
2 – Belt Clips
1 – Microphone Assembly
1 – Auxilliary (3.5mm jack to 3.5mm jack) Cable
1 – EarBud Assembly
1 – Instruction Manual
This Manual is intended for use with both the
LoudandClearTransmitter(LCT100)andReceiver(LCR100).
USE OF MULTIPLE TRANSMITTERS
AND RECEIVERS
If twotransmitters are operating on the same channel
within 200 feet ofone another, static and
interference will result. Changing Channels on the
Transmitter and Receiver will resolve this problem.
Important:TheSuperEar®LoudandClearisdesigned
so that theTransmitter can be used with several Receivers
set tothesameChannel. Should you desireadditional
Receivers for multiplelisteners, please contact your
SuperEar®retailerorcall,writeore-mailSonicTechnology
Products, Inc.
14 3
Warranty
Sonic Technology Products warrants this product to
be free from defects in workmanship and material under
normaluseandconditions for aperiod ofthreeyears from
date of original purchase. Batteries and cablesare not
covered by this warranty. Warranty is void if damage is
dueto misuse, abuse, negligence, damagecausedby heat
orwater, orunauthorizedmodificationsorrepairs. Sonic
Technology is not liable for consequentialdamages arising
outof any failure of the equipment to perform as intended.
SonicTechnologyshallbearno responsibility orobligation
with respect to the manner or use of equipment sold by it.
Sonic Technology specifically disclaims andnegates any
warranty of merchantability or fitness for a particular
purposeof suchequipment including,withoutlimitation,
anywarranty that the use of such equipment forany
purpose will comply with applicable laws and regulations.
Equipment may be repaired or replaced at the
discretion of Sonic Technology. Should it be necessary to
send inyourSuperEar®LoudandClear,returnitinawell-
packaged carton and ship postage prepaid to to P.O.Box
539, GrassValley, CA 95945. Returns madeunder this
warranty mustbe accompanied by US$5.00to handle the
handlingandreturn postage cost.
CONTENTS (LCS110 Only)
1–FMTransmitter(LCT100)
1–FMReceiver(LCR100)
1–RechargingWallPlug
2 – USB(USBtoMini USB) Recharging Cable
4 – AA Rechargeable Batteries
2 – Belt Clips
1 – Microphone Assembly
1 – Auxilliary (3.5mm jack to 3.5mm jack) Cable
1 – EarBud Assembly
1 – Instruction Manual
This Manual is intended for use with both the
LoudandClearTransmitter(LCT100)andReceiver(LCR100).
USE OF MULTIPLE TRANSMITTERS
AND RECEIVERS
If twotransmitters are operating on the same channel
within 200 feet ofone another, static and
interference will result. Changing Channels on the
Transmitter and Receiver will resolve this problem.
Important:TheSuperEar®LoudandClearisdesigned
so that theTransmitter can be used with several Receivers
set tothesameChannel. Should you desireadditional
Receivers for multiplelisteners, please contact your
SuperEar®retailerorcall,writeore-mailSonicTechnology
Products, Inc.
14 3
Warranty
Sonic Technology Products warrants this product to
be free from defects in workmanship and material under
normaluseandconditions for aperiod ofthreeyears from
date of original purchase. Batteries and cablesare not
covered by this warranty. Warranty is void if damage is
dueto misuse, abuse, negligence, damagecausedby heat
orwater, orunauthorizedmodificationsorrepairs. Sonic
Technology is not liable for consequentialdamages arising
outof any failure of the equipment to perform as intended.
SonicTechnologyshallbearno responsibility orobligation
with respect to the manner or use of equipment sold by it.
Sonic Technology specifically disclaims andnegates any
warranty of merchantability or fitness for a particular
purposeof suchequipment including,withoutlimitation,
anywarranty that the use of such equipment forany
purpose will comply with applicable laws and regulations.
Equipment may be repaired or replaced at the
discretion of Sonic Technology. Should it be necessary to
send inyourSuperEar®LoudandClear,returnitinawell-
packaged carton andship postage prepaid to P.O.Box
539, GrassValley, CA 95945. Returns madeunder this
warranty mustbe accompanied by US$5.00to handle the
handlingandreturn postage cost.

FCC Statement
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This
device must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for
help. Caution: Any changes or modifications not expressly approved
by the party responsible for compliance could void the user's authority
to operate the equipment.
4 13
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This
device must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for
help. Caution: Any changes or modifications not expressly approved
by the party responsible for compliance could void the user's authority
to operate the equipment.
4 13
On/Off /Mute
Switch
On/Off/Mute
LED
Microphone
Jack
USB Recharging
Port
Recharging
Indicator LED
TRANSMITTER
On/Mute/Off
On/Off /Mute
Switch
On/Off/Mute
LED
Microphone
Jack
USB Recharging
Port
Recharging
Indicator LED
TRANSMITTER
On/Mute/Off

12 5
On/Off Volume
Control Wheel
On/Off LED
Headphone/
Ear Bud Jack
USB Recharging
Port
Recharging
Indicator LED
RECEIVER
CARE AND MAINTENANCE
Avoid excessive heat. Do not leave the
Transmitter or Receiver in hot sun or near
other sources of high temperature.
Avoid dropping. The Receiver and
Transmitter may be damaged if dropped.
Keep battery terminals and contacts
clean. Inspect to ensure they are not corroded.
Polish with a pencil eraser to clean.
Removerechargeable batterieswhenReceivers
andTransmitters are being stored.Inspect
batteriesperiodicallyforleakage.
Use care when removing Ear Buds and
Microphones. Do not pull on wire leads, as
this may loosen connections and cause failure.
12 5
On/Off Volume
Control Wheel
On/Off LED
Headphone/
Ear Bud Jack
USB Recharging
Port
Recharging
Indicator LED
RECEIVER
CARE AND MAINTENANCE
Avoid excessive heat. Do not leave the
Transmitter or Receiver in hot sun or near
other sources of high temperature.
Avoid dropping. The Receiver and
Transmitter may be damaged if dropped.
Keep battery terminals and contacts
clean. Inspect to ensure they are not corroded.
Polish with a pencil eraser to clean.
Removerechargeable batterieswhenReceivers
andTransmitters are being stored.Inspect
batteriesperiodicallyforleakage.
Use care when removing Ear Buds and
Microphones. Do not pull on wire leads, as
this may loosen connections and cause failure.

611
GETTING STARTED
Battery Placement
Open the battery compartment by sliding the battery
door on the back of the Receiver down and insert the 2
Rechargeable batteries as indicated (+ and – symbols are
molded into the bottom of the battery compartment to
ensure proper placement). Repeat the process for the
Transmitter.
Channel Selection
TheSuperEarLoudandClearprovidesachoiceof
three channels,with theFrequency Selector Switch located
insidethe battery compartment, above thebatteries:
Channel 1 – Far Left Position – 72.2 MHz
Channel2 - Center Position– 72.8MHz
Channel3 –Far RightPosition– 75.8 MHz
The Channel Frequency can be easily changed for
the best possible reception. THE SAME CHANNEL
FREQUENCY MUST BE SELECTED FOR BOTH THE
RECEIVER AND THE TRANSMITTER. IF CHANNEL
FREQUENCIES ARE NOT SYNCHRONIZED,
TRANSMISSION AND RECEPTION WILL FAIL.
Channel frequencies are printed on the inside of the
battery compartment door for quick reference.
Belt Clip Installation/Removal
1) Place belt clip over the Battery Compartment
Door, with the top hinge centered between the two anti-
scuff pads and the clips over the retaining slots.
2) Slip the small joint into the slot located above the
Battery Compartment Door.
3) Apply pressure on both sides of the clip until the
clip retainers snap into the slots on the sides of the unit.
4) To remove, flex out one side of the clip retainer,
unsnap from the retaining slot and remove the clip.
Troubleshooting
If noise, distortion or static is present, check that:
•batteries are high quality and fully charged.
•Transmitter and Receiver are set to the same
Channel.
•there areno otherTransmitters intheimmediate
vicinity transmitting on the same frequency.
•all cables are fully connected.
•theMicrophonehasnotbeendamagedwith
excessive heat or moisture.
•Ear Buds havenot been damaged bypulling on the
wires.
If the above steps do not correct the problem,
contact Sonic Technology Products, Inc. for repair or
replacement.
611
GETTING STARTED
Battery Placement
Open the battery compartment by sliding the battery
door on the back of the Receiver down and insert the 2
Rechargeable batteries as indicated (+ and – symbols are
molded into the bottom of the battery compartment to
ensure proper placement). Repeat the process for the
Transmitter.
Channel Selection
TheSuperEarLoudandClearprovidesachoiceof
three channels,with theFrequency Selector Switch located
insidethe battery compartment, above thebatteries:
Channel 1 – Far Left Position – 72.2 MHz
Channel2 - Center Position– 72.8MHz
Channel3– FarRightPosition–75.8MHz
TheChannelFrequency canbeeasilychangedforthe
best possiblereception. THE SAME CHANNEL FRE-
QUENCY MUST BE SELECTED FOR BOTH THE RE-
CEIVERANDTHETRANSMITTER. IFCHANNEL
FREQUENCIESARENOTSYNCHRONIZED,
TRANSMISSIONANDRECEPTIONWILLFAIL.
Channelfrequenciesareprintedontheinsideofthebattery
compartmentdoorforquickreference.
Belt Clip Installation/Removal
1) Place belt clip over the Battery Compartment
Door, with the top hinge centered between the two anti-
scuff pads and the clips over the retaining slots.
2) Slip the small joint into the slot located above the
Battery Compartment Door.
3) Apply pressure on both sides of the clip until the
clip retainers snap into the slots on the sides of the unit.
4) To remove, flex out one side of the clip retainer,
unsnap from the retaining slot and remove the clip.
Troubleshooting
If noise, distortion or static is present, check that:
•batteries are high quality and fully charged.
•Transmitter and Receiver are set to the same
Channel.
•there areno otherTransmitters intheimmediate
vicinity transmitting on the same frequency.
•all cables are fully connected.
•theMicrophonehasnotbeendamagedwith
excessive heat or moisture.
•Ear Buds havenot been damaged bypulling on the
wires.
If the above steps do not correct the problem,
contact Sonic Technology Products, Inc. for repair or
replacement.

710
Battery Charging
To charge the batteries in the Receiver or Transmit-
ter, placetherechargeablebatteriesin thebattery compart-
ment as explained above. Plug the recharging MiniUSB
endoftheRechargingcableintotherecharging port.The
other end of the cable with the USB connector may be
eitherpluggedintoaUSBport onyourcomputerorplugged
intotheRechargingWallPlug, whichis inturn plugged into
a110VAC outlet.Oncechargingbegins,thegreenRe-
charging Indicator LED will flash until the LED turns to
solid green. This indicates charging is complete.
•Allow Ni-MH Batteries (provided) to charge 12-16
hours for up to 11 hours of useage forTransmitter (102 mA/
hour)andupto15hoursuseageforReceiver (55mA/hour).
•Excessive charging may reduce the life expect-
ancy and capacity
•The LED light will flash red when the unit is in a
low battery state.
• Charging may be accomplished with the “Power”
either ON or OFF.
•Normal operation may continue while recharging,
if the “Power” mode is ON.
TRANSMITTER OPERATION FOR
TELEVISION/MP3/AUXILLIARY SOUND
TRANSMISSION
Transmitter
1) InstallRechargeableBatteriesandchargeas
indicated
2) SelectChannelOption
3) Plug in the 3.5mm Auxillary Cable Jack into the
Microphone Plug
4) Plug in the other end of the Auxillary Cable into
the Speaker/Aux. Output plug of the television, radio,
computer or MP3 Player.
5) Position the “On/Off/Mute” Switch to the “On”
position. The Green LED will light to indicate the unit is
operating.
Receiver
1) InstallRechargeableBatteriesandchargeas
indicated
2) SelectChannelOptiontomatchTransmitter
Channel
3) Plug in the 3.5mm Headphone or Earbud jack
into the Headphone plug
4) Turn the “On/Off/Volume” Control wheel until it
clicks and the Green LED light goes on. Adjust volume to
preferred level.
710
Battery Charging
To charge the batteries in the Receiver or Transmit-
ter, placetherechargeablebatteriesin thebattery compart-
ment as explained above. Plug the recharging MiniUSB
endoftheRechargingcableintotherecharging port.The
other end of the cable with the USB connector may be
eitherpluggedintoaUSBport onyourcomputerorplugged
intotheRechargingWallPlug, whichis inturn plugged into
a110VAC outlet.Oncechargingbegins,thegreenRe-
charging Indicator LED will flash until the LED turns to
solid green. This indicates charging is complete.
•AllowNi-MHBatteries(provided)tocharge12-16
hours for up to 11 hours of useage forTransmitter (102 mA/
hour)andupto15hoursuseageforReceiver (55mA/hour).
•Excessive charging may reduce the life expect-
ancy and capacity
•The LED light will flash red when the unit is in a
low battery state.
• Charging may be accomplished with the “Power”
either ON or OFF.
•Normal operation may continue while recharging,
if the “Power” mode is ON.
TRANSMITTER OPERATION FOR
TELEVISION/MP3/AUXILLIARY SOUND
TRANSMISSION
Transmitter
1) InstallRechargeableBatteriesandchargeas
indicated
2) SelectChannelOption
3) Plug in the 3.5mm Auxillary Cable Jack into the
Microphone Plug
4) Plug in the other end of the Auxillary Cable into
the Speaker/Aux. Output plug of the television, radio,
computer or MP3 Player.
5) Position the “On/Off/Mute” Switch to the “On”
position. The Green LED will light to indicate the unit is
operating.
Receiver
1) InstallRechargeableBatteriesandchargeas
indicated
2) SelectChannelOptiontomatchTransmitter
Channel
3) Plug in the 3.5mm Headphone or Earbud jack
into the Headphone plug
4) Turn the “On/Off/Volume” Control wheel until it
clicks and the Green LED light goes on. Adjust volume to
preferred level.

89
OPERATION WITHOUT USING
RECHARGEABLE BATTERIES
TheSuperEar®LoudandClearwasdesignedtooperate
usingbatteriesor110VAChouseholdcurrent. Topowerthe
TransmitterorReceiverusinghouseholdcurrent,pluginthe
RechargingcabletotheunitandtheRechargingWallPlug
just as you would for recharging. Batteries must be in the
unit to operate while plugged into 110v wallplug. If batteries
are not in the unit, it will not operate.
Any rechargeable Ni-MH AA batteries or premium
Alkaline batteries may be used in the SuperEar®
LoudandClear.CAUTION:DONOTATTEMPTTORE-
CHARGENON-RECHARGEABLEBATTERIES.THIS
MAYDAMAGETHEUNIT.
LED Indicators
Power LED
Green indicates “Power” is ON
Red indicates “Mute” is ON
No light indicates “Power” is OFF
Charging LED
Red Flashing (when “Power” is ON) indicates Low
Battery Status
Green Flashing indicates Batteries are Charging
Solid Green indicates Batteries Fully Charged
No light indicates Batteries are NOT Charging
OPERATION FORVOICETRANSMISSION
Transmitter
1) InstallRechargeableBatteriesandchargeas
indicated
2) SelectChannelOption
3) Plug in the 3.5 mm microphone jack into the
microphone plug on the transmitter
4) Clip the microphone to a lapel or collar near the
mouth. HOLDING THE MICROPHONE, AND NOT
CLIPPING IT TO CLOTHING, WILL RESULT IN
SCRATCHY AND DEGRADED SOUND QUALITY.
5) Position the “On/Off/Mute” Switch to the “On”
position. The Green LED will light to indicate the unit is
operating.
6) To disable the transmission momentarily, turn the
Switch to “Mute”. This will cause the transmitter audio
output to cease, without transmitting any static or back-
ground noise. In the “Mute” position, the LED light will
indicateRed.
Receiver
1) Install Batteries and charge as indicated above
2) Select Channel Option to match Transmitter Channel
3) Plug in the 3.5mm Earbud jack into the plug
4) Turn the “On/Off/Volume” Control wheel until it
clicks and the Green LED light goes on. Adjust volume to
preferred level
89
OPERATION WITHOUT USING
RECHARGEABLE BATTERIES
TheSuperEar®LoudandClearwasdesignedtooperate
usingbatteriesor110VAChouseholdcurrent. Topowerthe
TransmitterorReceiverusinghouseholdcurrent,pluginthe
RechargingcabletotheunitandtheRechargingWallPlug
just as you would for recharging. Batteries must be in the
unit to operate while plugged into 110v wallplug. If batteries
are not in the unit, it will not operate.
Any rechargeable Ni-MH AA batteries or premium
Alkaline batteries may be used in the SuperEar®
LoudandClear.CAUTION:DONOTATTEMPTTORE-
CHARGENON-RECHARGEABLEBATTERIES.THIS
MAYDAMAGETHEUNIT.
LED Indicators
Power LED
Green indicates “Power” is ON
Red indicates “Mute” is ON
No light indicates “Power” is OFF
Charging LED
Red Flashing (when “Power” is ON) indicates Low
Battery Status
Green Flashing indicates Batteries are Charging
Solid Green indicates Batteries Fully Charged
No light indicates Batteries are NOT Charging
OPERATION FORVOICETRANSMISSION
Transmitter
1) InstallRechargeableBatteriesandchargeas
indicated
2) SelectChannelOption
3) Plug in the 3.5 mm microphone jack into the
microphone plug on the transmitter
4) Clip the microphone to a lapel or collar near the
mouth. HOLDING THE MICROPHONE, AND NOT
CLIPPING IT TO CLOTHING, WILL RESULT IN
SCRATCHY AND DEGRADED SOUND QUALITY.
5) Position the “On/Off/Mute” Switch to the “On”
position. The Green LED will light to indicate the unit is
operating.
6) To disable the transmission momentarily, turn the
Switch to “Mute”. This will cause the transmitter audio
output to cease, without transmitting any static or back-
ground noise. In the “Mute” position, the LED light will
indicate Red.
Receiver
1) InstallRechargeableBatteriesandchargeas
indicated
2) SelectChannelOptiontomatchTransmitterChannel
3) Plug in the 3.5mm Earbud jack into the plug
4) Turn the “On/Off/Volume” Control wheel until it
clicks and the Green LED light goes on. Adjust volume to
preferred level
