oticon Corda miniFit Configuration guide

The following pictures illustrate how to
clean a hearing aid with a thin tube.
Cleaning the Corda miniFit (thin tube)
1. Detach the corda tube by pulling the tube away from the hearing
instrument.
2. Insert the cleaning tool into the top part of the tube and feed it all
the way through to the dome.
3. Carefully push the cleaning tool through the dome past the vent, without removing the dome.
Corda miniFit
PLEASE NOTE:
1. If the dome is
removed, always
replace with a NEW
dome.
2. Never re-attach a
used dome back onto
the tube.
3. If the dome is missing
DO NOT USE. Please
call audiology.
4. Always change the
dome & tube as one
unit - do not change
the dome on its own.
5. If the dome is pushed
too far and it comes
through the wax
guard please replace
the dome.

4. To clean the dome, wipe
the dome gently with a wet-
wipe or damp cloth to remove
any excess cerumen (wax).
5. Re-attach the corda tube by pushing it back on to the hearing
instrument with a simple click t action.
*Always clean the dome
from tip to base*
Corda miniFit
Rev. 2 Feb 2017
Place your nger on the bend
of the tube and gently push to
place the dome in the correct
position. Do not try to push the
dome itself.
If the dome is pushed too far it can come through the wax guard
(left image).
If this happens replace dome and tube and to not use until this is
done.
Correct image of dome (right image).
6. Correctly attached tube, dome and hearing instrument.
