Sony UP-D897 User manual

2-345-260-15 (1)
Digital Graphic
Printer
© 2005 Sony Corporation
UP-D897
Instructions for Use

2
Owner's Record
The model and serial numbers are located at the rear.
Record these numbers in the space provided below.
Refer to these numbers whenever you call upon your
Sony dealer regarding this product.
Model No. ____________________
Serial No. ____________________
To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture.
To avoid electrical shock, do not open the
cabinet. Refer servicing to qualified personnel
only.
No modification of this equipment is allowed.
THIS APPARATUS MUST BE EARTHED.
To disconnect the main power, unplug the
power plug.
When installing the unit, incorporate a readily
accessible disconnect device in the fixed
wiring, or connect the power plug to an easily
accessible socket-outlet near the unit.
Do not position the ME equipment where it is
difficult to unplug the power plug.
If a fault should occur during operation of the
unit, operate the disconnect device to
switch the power supply off, or unplug the
power plug.
For the customers in the U.S.A.
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference when the equipment is operated in a
commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications. Operation of this equipment in a
residential area is likely to cause harmful interference in
which case the user will be required to correct the
interference at his own expense.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your
authority to operate this equipment.
All interface cables used to connect peripherals must be
shielded in order to comply with the limits for a digital
device pursuant to Subpart B of Part 15 of FCC Rules.
For the customers in Canada
This unit has been certified according to Standard CAN/
CSA-C22.2 No.60601-1.
For the customers in the U.S.A and
Canada
When you use this product connected to 240 V single
phase, be sure to connect this product to a center tapped
circuit.
Important safeguards/notices for use in
the medical environments
1. All the equipments connected to this unit shall be
certified according to Standard IEC60601-1,
IEC60950-1, IEC60065 or other IEC/ISO Standards
applicable to the equipments.
2. Furthermore all configurations shall comply with the
system standard IEC60601-1-1. Everybody who
connects additional equipment to the signal input
part or signal output part configures a medical
system, and is therefore, responsible that the system
complies with the requirements of the system
standard IEC60601-1-1. If in doubt, consult the
qualified service personnel.
3. The leakage current could increase when connected
to other equipment.
4. For this particular equipment, all accessory
equipment connected as noted above, must be
connected to mains via an additional isolation
transformer conforming with the construction
WARNING
Symbols on the products
This symbol indicates the equipotential
terminal which brings the various parts of a
system to the same potential.
This symbol is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
This symbol indicates the manufacturer, and
appears next to the manufacturer’s name and
address.
Refer to the operating instructions
Follow the directions in the operating
instructions for parts of the unit on which
this mark appears.

3
requirements of IEC60601-1 and providing at least
Basic Insulation.
5. This equipment generates, uses, and can radiate radio
frequency energy. If it is not installed and used in
accordance with the instruction manual, it may cause
interference to other equipment. If this unit causes
interference (which can be determined by
unplugging the power cord from the unit), try these
measures: Relocate the unit with respect to the
susceptible equipment. Plug this unit and the
susceptible equipment into different branch circuit.
Consult your dealer. (According to standard IEC60601-
1-2 and CISPR11, Class B, Group 1)
Important EMC notices for use in the medical environments
• The UP-D897 needs special precautions regarding EMC
and needs to be installed and put into service according
to the EMC information provided in this instructions for
use.
• The portable and mobile RF communications equipment
such as cellular phones can affect the UP-D897.
Warning
The use of accessories and cables other than those
specified, with the exception of replacement parts sold by
Sony Corporation, may result in increased emissions or
decreased immunity of the UP-D897.
Warning
If the UP-D897 should be used adjacent to or stacked with
other equipment, it should be observed to verify normal
operation in the configuration in which it will be used.
Guidance and manufacturer’s declaration-electromagnetic emissions
The UP-D897 is intended for use in the electromagnetic environment specified below.
The customer or the user of the UP-D897 should assure that it is used in such an environment.
Emission test Compliance Electromagnetic environment-guidance
RF emissions
CISPR 11
Group 1
The UP-D897 uses RF energy only for its internal function.
Therefore, its RF emissions are very low and are not likely
to cause any interference in nearby electronic equipment.
RF emissions
CISPR 11
Class B
The UP-D897 is suitable for use in all establishments,
including domestic establishments and those directly
connected to the public low-voltage power supply network
that supplies buildings used for domestic purposes.
Harmonic emissions
IEC 61000-3-2
Class A
Voltage fluctuations/
flicker emissions
IEC 61000-3-3
Complies

4
Guidance and manufacturer’s declaration - electromagnetic immunity
The UP-D897 is intended for use in the electromagnetic environment specified below. The customer or the user of the UP-
D897 should assure that it is used in such as environment.
Immunity test IEC 60601 test
level Compliance level Electromagnetic environment-guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±6 kV contact
±8 kV air
±6 kV contact
±8 kV air
Floors should be wood, concrete or ceramic tile. If floors are
covered with synthetic material, the relative humidity should
be at least 30%.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for power
supply lines
±1 kV for input/
output lines
±2 kV for power
supply lines
±1 kV for input/
output lines
Mains power quality should be that of a typical commercial or
hospital environment.
Surge
IEC 61000-4-5
±1 kV differential
mode
±2 kV common
mode
±1 kV differential
mode
±2 kV common
mode
Mains power quality should be that of a typical commercial or
hospital environment.
Voltage dips, short
interruptions and
voltage variations
on power supply
input lines
IEC 61000-4-11
< 5% UT
(> 95% dip in UT)
for 0.5 cycle
40% UT
(60% dip in UT)
for 5 cycles
70% UT
(30% dip in UT)
for 25 cycles
< 5% UT
(> 95% dip in UT)
for 5 sec
< 5% UT
(> 95% dip in UT)
for 0.5 cycle
40% UT
(60% dip in UT)
for 5 cycles
70% UT
(30% dip in UT)
for 25 cycles
< 5% UT
(> 95% dip in UT)
for 5 sec
Mains power quality should be that of a typical commercial or
hospital environment. If the user of the UP-D897 requires
continued operation during power mains interruptions, it is
recommended that the UP-D897 be powered from an
uninterruptible power supply or a battery.
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
3 A/m 3 A/m Power frequency magnetic fields should be at least
characteristic of a typical location in a typical commercial or
hospital environment.
NOTE: UTis the a.c. mains voltage prior to application of the test level.

5
Guidance and manufacturer’s declaration - electromagnetic immunity
The UP-D897 is intended for use in the electromagnetic environment specified below. The customer or the user of the UP-
D897 should assure that it is used in such as environment.
Immunity test IEC 60601 test
level Compliance level Electromagnetic environment-guidance
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 61000-4-3
3 Vrms
150 kHz to 80 MHz
3 V/m
80 MHz to 2.5 GHz
3 Vrms
3 V/m
Portable and mobile RF communications equipment should
be used no closer to any part of the UP-D897, including
cables, than the recommended separation distance
calculated from the equation appliance to the frequency of
the transmitter.
Recommended separation distance
d= 1.2 √P
d= 1.2 √P80 MHz to 800 MHz
d= 2.3 √P800 MHz to 2.5 GHz
Where Pis the maximum output power rating of the
transmitter in watts (W) according to the transmitter
manufacturer and dis the recommended separation distance
in meters (m).
Field strengths from fixed RF transmitters, as determined by
an electromagnetic site survey, ashould be less than the
compliance level in each frequency range. b
Interference may occur in the vicinity of equipment marked
with following symbol:
NOTE 1: At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and
reflection from structures, objects and people.
a Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile
radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To
assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be
considered. If the measured field strength in the location in which the UP-D897 is used exceeds the applicable RF
compliance level above, the UP-D897 should be observed to verify normal operation. If abnormal performance is
observed, additional measures may be necessary, such as reorienting or relocating the UP-D897.
b Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.

6
Caution
When you dispose of the unit or accessories, you must
obey the law in the relative area or country and the
regulation in the relative hospital.
Warning on power connection
Use a proper power cord for your local power supply.
1. Use the approved Power Cord (3-core mains lead) /
Appliance Connector / Plug with earthing-contacts
that conforms to the safety regulations of each
country if applicable.
2. Use the Power Cord (3-core mains lead) / Appliance
Connector / Plug conforming to the proper ratings
(Voltage, Ampere).
If you have questions on the use of the above Power
Cord / Appliance Connector / Plug, please consult a
qualified service personnel.
Warning on power connection for
medical use
Please use the following power supply cord.
With connectors (plug or female) and cord types other
than those indicated in this table, use the power supply
cord that is approved for use in your area.
*Note: Grounding reliability can only be achieved when the equip-
ment is connected to an equivalent receptacle marked ‘Hospital Only’
or ‘Hospital Grade’.
For the customers in Europe
This product has been manufactured by or on behalf of
Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-
0075 Japan. Inquiries related to product compliance
based on European Union legislation shall be addressed
to the authorized representative, Sony Deutschland
GmbH, Hedelfinger Strasse 61, 70327 Stuttgart,
Germany. For any service or guarantee matters, please
refer to the addresses provided in the separate service or
guarantee documents.
Recommended separation distances between portable and mobile RF communications equipment and the UP-D897
The UP-D897 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The
customer or the user of the UP-D897 can help prevent electromagnetic interference by maintaining a minimum distance
between portable and mobile RF communications equipment (Transmitters) and the UP-D897 as recommended below,
according to the maximum output power of the communications equipment.
Rated maximum output power of transmitter
W
Separation distance according to frequency of transmitter
m
150 kHz to 80 MHz
d= 1.2 √P
80 MHz to 800 MHz
d= 1.2 √P
800 MHz to 2.5 GHz
d= 2.3 √P
0.01 0.12 0.12 0.23
0.1 0.38 0.38 0.73
1 1.2 1.2 2.3
10 3.8 3.8 7.3
100 12 12 23
For transmitters rated a maximum output power not listed above, the recommended separation distance din meters (m) can
be estimated using the equation applicable to the frequency of the transmitter, where Pis the maximum output power rating
of the transmitter in watts (W) according to the transmitter manufacturer.
NOTE 1: At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and
reflection from structures, objects and people.
United States and Canada
Plug Type HOSPITAL GRADE*
Cord Type Min.Type SJT
Min.18 AWG
Minimum Rating for Plug
and Appliance Couplers
10 A/125 V
Safety Approval UL Listed and CSA

7
Table of Contents
Getting Started
Overview ................................................................. 8
Location and Function of Parts and Controls .... 8
Front Panel ......................................................... 8
Rear Panel .......................................................... 9
Connections ............................................................ 9
Connecting to the USB Connector ..................... 9
Installing the Printer Driver ................................ 9
Paper ..................................................................... 10
Paper You Can Use ........................................... 10
Loading Paper in the Unit .................................. 10
Loading Paper .................................................. 10
Operation
Adjustments and Settings Using the Menu ....... 12
Menu Flow ....................................................... 12
Menu List ......................................................... 13
Basic Menu Operations .................................... 14
Registering Menu Settings ............................... 16
Printing the Menu List ...................................... 16
Printing ................................................................. 17
Starting a Print Job ........................................... 17
Cancelling a Print Job ...................................... 17
Making Copies of the Last Printout ................. 17
Feeding Paper ................................................... 17
Adjusting the Contrast and Brightness ............. 18
Others
Precautions ........................................................... 19
On Safety .......................................................... 19
On the Printer Carriage .................................... 19
On Installation .................................................. 19
Maintenance ......................................................... 20
Cleaning the Cabinet ........................................ 20
Cleaning the Thermal Head .............................. 20
Cleaning the Platen Roller ................................ 21
Specifications ........................................................ 22
Troubleshooting ................................................... 23
Error Messages .................................................... 23
Index ..................................................................... 24

Getting Started
Overview / Location and Function of Parts and Controls
8
Getting Started
Overview
Quiet, High Quality, Fast Printing
• Employs a thin thermal head with a built-in high speed
drive IC, capable of high resolution images of 12.8
dots/mm.
• Print speeds of approximately 1 high quality image
(960 ×1280 dots) every 2 seconds when printing at
high speed.
• Standard image memory capable of handling and
printing images up to 4096 ×1280 dots (approx. 320
×100mm).
• Monochrome printing with up to 256 shades of
gradation.
• Built-in temperature correction circuits prevent
temperature changes which could cause blurred prints.
USB interface
The unit is equipped with a USB connector which
complies with the Hi-Speed USB (USB 2.0).
Easy printer settings using a menu
You can make up the settings to meet your requirements
using a menu. You can store up to three settings as a set
of user settings.
Easy Paper Loading
Free access to the door panel allows you to drop paper
into the unit for easy loading.
Location and Function
of Parts and Controls
For more details, see the referenced page numbers
enclosed in parentheses ( ).
Front Panel
A!Power ON/OFF Switch (10, 14, 17, 20)
Press to switch to ON to turn the power on. The
back light on the LCD lights in green.
BPrinter window display (LCD: liquid crystal
display) (12, 17)
The back light lights in green when the unit
operates normally. Also, in normal operation, the
paper currently selected is indicated by the pointer
on the LCD.
For detailed information on the paper, see “Paper”
on page 10 and “Paper currently selected” on page
17.
If an error occurs, a corresponding alarm message
is displayed.
During menu operations, menu items and settings
are displayed
CJog dial (14, 20)
Used to make menu operations.
DCONTR (contrast) control (18)
Adjusts the contrast of the printouts.
EBRIGHT (brightness) control (18)
Adjusts the brightness of the printouts.
FRECEIVING indicator
Lights while the unit is receiving print data from the
computer.

Getting Started
Connections 9
GFEED button (11, 17)
Hold down to feed paper. While a print job is in
progress, press to cancel the print job.
HCOPY button (17)
Prints another copy of the previous printout.
You can make only one copy each time you press
this button regardless of the print quantity set using
the menu.
IOPEN button (11, 17)
Press to open the paper door. While a print job is in
progress, press to cancel the print job.
JPaper cutter
Cuts the paper as each image is printed.
Rear Panel
AUSB connector (9)
Connects to a computer equipped with the USB
interface (which conforms to USB 2.0), using the
supplied USB cable.
BEquipotential ground terminal connector
Used to connect to the equipotential plug to bring
the various parts of a system to the same potential.
Refer to “Important safeguards/notices for use in
the medical environments” on page 2.
C-AC IN connector
Use a proper power cord for your local power
supply (not supplied).
Refer to “Warning on power connection” on page 6
and “Warning on power connection for medical
use” on page 6.
Connections
After connecting the USB connecting cable (supplied)
to the unit and the computer, connect the power cord.
For details about the unit connection, refer to the
manuals for the computer or other peripheral devices.
Notes
• Before connecting the unit to the computer, turn off
the unit, computer, monitor, and all peripheral devices
connected to the computer.
• Before connecting the unit to the computer, disconnect
the power cord from the unit. Connect the power cord
to the unit only after connecting the unit and the
computer.
• Follow the connection procedures described in the
computer manual.
• Make sure that the cables are connected securely at
both ends.
• The unit drive software provided with the unit is not
suitable for using the unit connected to a network.
• Printer operation is not guaranteed when connecting
to the computer using the USB cable via a hub.
Connecting to the USB Connector
Installing the Printer Driver
Install the printer driver provided with the printer. For
detailed instructions about how to install the unit driver,
refer to the Readme.txt file included on the supplied CD-
ROM disc.
to (USB) connector
USB connecting
cable (supplied)
UP-D897

Getting Started
Paper / Loading Paper in the Unit
10
Paper
Use only Sony UPP-110S/110HD/110HG paper
designed for use with this unit. High print quality cannot
be guaranteed if any other paper is used with this unit,
and such paper could damage the unit.
You cannot use the UPP-110HA as specified for the
UP-D890/890 series printer.
Paper You Can Use
Print paper characteristics are as follows.
Notes on storing and handling paper
Do not re-use
Doing so may result in malfunction and
negatively affect printing results.
Storing unused paper
• Store unused paper at a temperature below 30°C
(86°F) in a dry location that is not exposed to direct
sunlight.
• Do not store unused paper near volatile liquids or
allow the paper to contact any organic volatile liquid,
cellophane tape, or any compound of vinyl chloride.
Loading paper
• Handle the paper carefully when loading to avoid
touching the printing surface with your fingers.
Perspiration or oil from you hands could cause
pictures to blur.
• After removing the label from the leading edge of the
paper, pull the paper out 15~20 cm (about 6~8 in.)
before printing. Label adhesive remaining on the
paper could spoil a picture.
Storing printouts
• To prevent printouts from fading or changing color,
store them in a cool, dry location where the
temperature is not higher than 30°C (86°F).
• Store printouts in a polypropylene pouch or between
sheets of paper that contain no plastic.
• Do not store printouts where they will be exposed to
direct sunlight or high humidity.
• Do not store printouts near volatile liquids or allow the
prints to contact any organic volatile liquid,
cellophane tape, or any compound of vinyl chloride.
• To prevent fading, do not stack printouts on or under a
diazo copy sheet.
• To mount printouts on another sheet of paper, use
double-sides tape or a water base adhesive.
• Do not incinerate waste printer paper.
Loading Paper in the
Unit
Notes
• Before loading paper in the unit, see “Notes on storing
and handling paper” (page 10).
• Always handle paper carefully when loading to avoid
adversely affecting the quality of the printouts. Never
bend or crease the paper and never touch the printing
surface with your fingers. Fingerprints perspiration
can blur printing.
• Do not use any paper other than UPP-110S/110HD/
110HG paper. (page 10)
• Be sure to set the “MEDIA” of the menu to the paper
to be used. (page 13) You can confirm the media
currently selected on the LCD.
For detailed information on how to confirm, see
“Paper currently selected” on page 17.
Loading Paper
A paper cutter is mounted with the unit. When loading
paper, be careful not to touch the paper cutter. Touching
the paper cutter may cause injury.
1 Press the power ON/OFF switch to turn the unit on.
When paper is not loaded yet, the back light on the
LCD lights in umber and the message “EMPTY” is
displayed.
Print Characteristics Paper Type
TYPE I (Normal) UPP-110S
TYPE II (High Density) UPP-110HD
TYPE V (High Glossy) UPP-110HG
Caution

Getting Started
Loading Paper in the Unit 11
2 Press the OPEN button to open the paper door.
3 Remove the label from the leading edge of the
paper, pull out about 15~20 cm (about 6~8 in.) of
the paper, and then set the paper roll in the paper
tray.
Note
To avoid exposing the paper to dust, dirt, etc.
always handle it carefully when removing from its
package and loading it in the unit. Paper exposed to
dirt or dust cannot be used for printing.
4 Close the paper door and press on it to shut it.
Notes
• Make sure that the paper is loaded straight. If it is
skewed, this could cause the paper to jam.
• If you did not pull out enough paper in step 3, press the
FEED button on the operation panel to feed some
more paper out of the unit without pulling out the
paper.
Remove label and pull
out 15 to 20 cm (about 6
to 8 inches).
Load the paper with the printing side (heat
sensitive side) up. Printing is not possible if the
paper is reversed.
Make sure that the paper is set
straight.

Operation
Adjustments and Settings Using the Menu
12
Operation
Adjustments and
Settings Using the Menu
You can carry out adjustments and settings to meet your
requirements. Those settings and adjustments are
retained even if the unit is turned off.
You can set up the unit according to its intended
purpose, connected equipments or your individual
preferences.
You can store up to three settings as a set of user settings.
Menu Flow
The contents displayed on the LCD changes in sequence
as you turn the jog dial as shown in the following menu
flow chart, and you can make the settings for each menu
item.

Operation
Adjustments and Settings Using the Menu 13
Menu List
This section describes the menus displayed as you turn
the jog dial. The setting surrounded by
indicates the factory setting.
Item Function Settings
BEEP To select whether
the operation and
error tones sound
BE: OFF: The operation
tone does not sound.
[BE: ON]: The operation
and error tones sound.
BACK: Cancels the setting
change and returns to the
item selection column.
CLEAN To start head
cleaning
[CL: OK]: Starts the head
cleaning. Be sure to use the
supplied cleaning sheet.
BACK: Cancels the head
cleaning and returns to the
item selection column.
COMD To select the
printer driver to
be used
CO:895: UP-D895 driver
conversion mode. Uses the
printer driver for the UP-
D895.
[CO:897]: Uses the printer
driver for the UP-D897.
BACK: Cancels the setting
change and returns to the
item selection column.
DIR a) To select whether
the top or bottom
of the screen is to
be printed first
DI: REV: Starts to print in
the reverse direction (from
the top of the screen).
[DI: NOR]: Starts to print in
the normal direction (from
the bottom of the screen).
BACK: Cancels the setting
change and returns to the
item selection column.
FEED To select the
paper feed
method to be used
after printing
FE: OFF: Feeds less paper
between prints to conserve
paper, or when printing
multiple pictures on the
same sheet. More pictures
can be printed on one sheet,
but because there is so little
space between printed
picture, feed the desired
length of the paper to leave
a margin using the FEED
button, before cutting the
paper.
[FE: ON]: Feeds extra blank
paper between prints.
BACK: Cancels the setting
change and returns to the
item selection column.
GAMMA b)
(When
“ME:S” is
selected in
“MEDIA,”
GAMMA is
fixed to
TONE 1.)
To select the tone
(density
gradation)
GA:4: TONE 4 Softest
gradation
GA:3: TONE 3 Hard
gradation
[GA:2]: TONE 2 Standard
GA:1: TONE 1 Soft
gradation
BACK: Cancels the setting
change and returns to the
item selection column.
IMAGE To set the printout
to either positive
printout or
negative printout
IM:NEG: Makes negative
printouts.
[IM:POS]: Makes normal
printouts.
BACK: Cancels the setting
change and returns to the
item selection column.
INFO To select whether
or not the print
conditions (such
as contrast,
bright, gammas
and sharpness
information) are
printed under the
IF:ON: Prints the
information.
[IF:OFF]: Does not print the
information.
BACK: Cancels the setting
change and returns to the
item selection column.
LOAD To load the
registered settings
LO:3: Loads the “SA:3”
settings registered using the
“SAVE” menu item.
LO:2: Loads the “SA:2”
settings registered using the
“SAVE" menu item.
[LO:1]: Loads the “SA:1”
settings registered using the
“SAVE” menu item
BACK: Cancels the setting
change and returns to the
item selection column.
MEDIA To select the type
of paper
ME:S: Uses the UPP-110S.
ME:HD: Uses the UPP-
110HD.
[ME: HG]: Uses the UPP-
110HG
BACK: Cancels the setting
change and returns to the
item selection column.
MENU To print the menu
settings currently
selected
[ME:OK]: Prints the menu
list currently set.
BACK: Cancels printing
and goes back to its item
column.
QTY b) To set the print
quantity between
1 and 255
You can make one to 255
copies of the same printout.
[QT: 1]: Makes one sheet of
the printout.
BACK: Cancels the setting
change and returns to the
item selection column.
Item Function Settings

Operation
Adjustments and Settings Using the Menu
14
a) The printing direction is as follows.
b) These items can also be set on the printer driver side.
When you place a check mark in a checkbox on the
“Settings” tab of the printer driver, the settings made
on the printer side are enabled. When “CO:895” is
selected in “COMD,” these items are not displayed
and can not be set. When “CO:897” is selected, these
items are disabled since the computer sends the print
command to the printer until the printer completes
printing.
c) The print direction of the images printed is as follows.
Basic Menu Operations
This section describes the basic menu operation which
are common to each menu, taking “How to set the
printing direction” as an example.
1 Press the power ON/OFF switch to ON to turn the
unit on.
RSIZE b) To select whether
or not the image
is enlarged
[RS:OFF]: Prints the image
at the original size.
RS:ON: Prints the image at
a larger size, according to
the paper size set by the
printer driver.
BACK: Cancels the setting
change and returns to the
item selection column.
SAVE To register up to
three kinds of
settings
SA:3: Registers the menu
settings as No.3.
SA:2: Registers the menu
settings as No.2.
[SA:1]: Registers the menu
settings as No.1.
BACK: Cancels the setting
change and returns to the
item selection column.
SHARP b) To adjust the
sharpness of the
printout
You can set the sharpness to
any of 15 steps, from 0 to
14.
At a setting of 0, the outline
of the printout is not
emphasized.
A setting of step 2 is the
factory setting.
BACK: Cancels the setting
change and returns to the
item selection column.
SIDE c) To select the
direction in which
the image is to be
printed
S:SIDE: Prints the image
rotated by 90 degrees
counterclockwise.
[S:STD]: Prints the image in
the same direction as that
displayed on the monitor.
BACK: Cancels the setting
change and returns to the
item selection column.
SPEED
(When
“ME:HD” is
selected in
“MEDIA,”
the printing
speed is fixed
to “SP:NOR”
and this item
is not
displayed.)
To select the
printing speed
SP:NOR: Prints at the
normal speed.
[SP:HI]: Prints at high
speed.
BACK: Cancels the setting
change and returns to the
item selection column.
Note
When “SP:HI” is selected,
the power consumption is a
little higher, compared with
printing at the normal
speed.
BACK To exit menu
mode
Display this item and then
press the jog dial. The unit
exits the menu mode and
“READY” is displayed on
the LCD.
Item Function Settings
When DI:NOR is selected When DI: REV is selected
I
mage
di
sp
l
aye
d
on
th
e mon
it
or
Printouts
When S:STD is selected. When S:SIDE is selected

Operation
Adjustments and Settings Using the Menu 15
The back light on the LCD lights in green.
2 Confirm that “READY” is displayed on the LCD,
and press the jog dial.
The unit enters the menu mode.
When you perform a menu operation for the first
time after you purchase the unit, the top item of the
“BEEP” menu is displayed.
If you have performed a menu operation already,
the item that you set last is displayed.
3 Display “DIR” by turning the jog dial up or down.
4 Press the jog dial.
The unit enters the mode in which you can select
the printing direction.
“DI:NOR,” which is the factory setting, is
displayed on the LCD. “DI:NOR” is the currently
selected setting.
In this menu operation, you will change the setting
to “DI:REV.”
5 Display “DI:REV” in the LCD by turning the jog
dial up or down, and then press the jog dial.
“DI:REV” is registered as the printing direction.
Note
If about 20 seconds elapse without making any
menu operation after you have displayed the menu
item or setting, the display returns to “READY” on
the LCD and the unit exits the menu mode. In such
a case, the setting of “DIR” is not changed.
LCD

Operation
Adjustments and Settings Using the Menu
16
To cancel the setting
1Display “BACK” by turning the jog dial in step
5.
2Press the jog dial.
The display on the LCD returns to “DIR.”
To continue menu operations
Make settings by repeating steps 3 to 5.
To end the menu operation
1 Display “BACK” by turning the jog dial after
performing the operation of step 5.
2 Press the jog dial.
The display returns to “READY.”
The unit exits the menu mode.
Menu lock function
If the message “LOCK” is displayed and you hear the
alarm sound when you press the jog dial, the jog dial is
disabled because the menu operation function is locked.
If you want to perform a menu operation, contact the
nearest authorized dealer.
Registering Menu Settings
You can store up to three sets of settings made using the
menu, and you can load the desired setting when needed.
The unit retains these settings even if you turn off the
power.
Note
When you use the unit for the first time after you
purchase it, factory settings are registered in all three of
the stored selections.
Registering new settings
1 Make all of the required settings.
2 Display “SAVE” by turning the jog dial, and then
press the jog dial.
3 Display the desired number by turning the jog dial,
and then press the jog dial, again.
The settings made in step 1 are registered in the
number selected in step 3.
Loading the desired settings
You can load the desired settings and make printouts
with the loaded settings.
1 Confirm that “READY” is displayed on the LCD,
and press the jog dial.
2 Display “LOAD” by turning the jog dial, and then
press the jog dial again.
3 Display the number corresponding to the desired
settings, and then press the jog dial.
Settings corresponding to the number selected in
step 3 are loaded.
When you change the loaded settings
The unit operates according to the changed settings. In
this case, the unit operates according to these settings
until you load another set of settings, even if you turn off
the unit. When you load another group of settings, the
settings loaded previously are cleared.
To retain previously loaded settings
Example: Settings registered as “SA:1” are loaded and
settings are to be changed. To retain the original settings
of “SA:1” and to register the new settings as “SA:2,”
proceed as follows.
1 Load the settings of “LO:1” following the
procedure for loading the desired settings.
2 Change the loaded settings as required.
3 Select “SA:2” following procedure for registering
the settings.
4 Press the jog dial.
The settings, changed in step 2, are registered as
“SA:2” (No.2).
Printing the Menu List
You can make a printout of the current menu settings.
1 Press the jog dial.
The menu item you changed last is displayed.
2 Display “MENU” by turning the jog dial, and then
press the jog dial.
3 Display “ME:OK” by turning the jog dial and then
press the jog dial.
The unit starts printing the current menu settings.
“MENU” is displayed on the LCD.
4 Display “BACK” by turning the jog dial, and then
press the jog dial.
The message “READY” is displayed on the LCD,
and the unit returns to the normal printing mode.

Operation
Printing 17
Printing
Before Starting a Print Job
Always check the following points:
• unit connected correctly? (page 9)
• Printer driver installed? (page 9)
• Paper loaded correctly? (page 10)
• Menu settings and menu adjustments done correctly?
(page 12)
Starting a Print Job
1 Press the power ON/OFF switch to turn the unit on.
The back light on the LCD lights in green, and
“READY” is displayed on the LCD.
2 Execute the print job with the software application.
When the message is displayed on the LCD
If a problem occurs, the back light on the LCD lights in
umber and the error message stating the problem is
displayed on the LCD.
When the unit stops printing during printing
When printing almost black images continuously, the
thermal head protection circuit may shut down the unit
to prevent the thermal head from overheating. In such a
case, the message “COOL” is displayed on the LCD.
Leave the unit until the head cools down and this
message disappears.
Paper currently selected
You can confirm the paper currently selected on the
LCD. The pointer points to the paper currently selected.
In the following figure, the currently selected paper is
the UPP-110S paper.
Cancelling a Print Job
To cancel a print job in progress, press the OPEN button
or the FEED button.
Making Copies of the Last Printout
Press the COPY button. The unit makes a copy of the
last printout. The image of the last printout is retained in
the unit’s memory until you make a printout of another
image or turn the power off. You can make only one
copy regardless of the print quantity set using the menu.
Note
If you press the COPY button immediately after turning
the power on, the alarm buzzer will sound as nothing is
stored in memory.
To make multiple copies of the same printout
Press the COPY button as many times as necessary
(maximum 20 copies including the first printout) while
copying the first printout. Each time you press the
COPY button, a short buzzer sounds.
To interrupt copying
Press the OPEN or FEED button while copying.
Feeding Paper
To feed paper, press the FEED button. The unit will
continue to feed paper as long as you hold down the
FEED button. Do not attempt to pull paper out of the
unit with your hand.
Message Cause and remedy
EMPTY Paper is not loaded. Load paper.
DOOR The door is open. Close the door.
LCD
Indicates the UPP-110S
Indicates the UPP-110HD
Indicates the UPP-110HG

Operation
Printing
18
Adjusting the Contrast and
Brightness
You can adjust the contrast and brightness of the unit
using the CONTR control and BRIGHT control on the
front panel.
To adjust the contrast
You can adjust the contrast of printouts using the
CONTR control.
To make the contrast stronger: Turn the CONTR
control clockwise.
To make the contrast weaker: Turn the CONTR
control counterclockwise.
Note
The contrast adjusting function is equivalent to “Light”
of the density control provided with the printer driver.
The value adjusted by using this CONTR control is
added to the value already set as “Light.”
To adjust the brightness
You can adjust the brightness of printouts using the
BRIGHT control.
To make the image brighter: Turn the BRIGHT
control clockwise.
To make the image darker: Turn the BRIGHT control
counterclockwise.
Note
When the menu operation function is locked, CONTR
and BRIGHT controls are also disabled in addition to
the jog dial. If you want to use the CONTR and
BRIGHT controls, contact the nearest authorized dealer.

Others
Precautions 19
Others
Precautions
On Safety
• Check the operating voltage before operation.
Operate the unit only with a power source specified in
“Specifications”.
• Stop operation immediately if any liquid or solid
object falls into the cabinet. Unplug the unit and have
it checked by qualified personnel.
• Unplug the unit from the wall outlet if you will not be
using it for a long time. Disconnect the power cord by
grasping the plug. Never pull the cord itself.
• Do not disassemble the cabinet. Refer servicing to
qualified personnel only.
• Connect the power plug of the unit to a wall outlet
with a protective earth terminal. The safety earth
should be properly established.
Caution on the paper cutter
A paper cutter is mounted with the unit. When loading a
paper or cleaning the unit, be careful not to touch the
paper cutter. Touching the paper cutter may cause injury.
On the Printer Carriage
Do not carry or move the unit when the paper roll is
placed in the unit. Doing so may cause a malfunction.
On Installation
• Place the unit on a level and stable surface.
If you use the unit with placed on an uneven surface,
malfunction of the unit is likely to occur.
• Do not install the unit near heat sources. Avoid
locations near radiators or air ducts, or places subject
to direct sunlight or excessive dust, humidity,
mechanical shock or vibration.
• Provide adequate air circulation to prevent heat build-
up. Do not place the unit on surfaces such as rugs,
blankets, etc., or near materials such as curtains and
draperies.
• To prevent internal heat built-up, leave enough room
around the printer for air to circulate through the
ventilation holes (intake) on the left hand side and the
ventilation holes (exhaust) on the rear of the cabinet.
• If the unit is subjected to wide and sudden changes in
temperature, such as when it is moved from a cold
room to a warm room or when it is left in a room with
a heater that tends to produce large amounts of
moisture, condensation may form inside the unit. In
such cases the unit will probably not work properly,
and may even develop a fault if you persist in using it.
If moisture or condensation forms, turn off the power
and allow the unit to stand for at least one hour.
Ventilation holes (exhaust)
Ventilation holes (intake)

Others
Maintenance
20
Maintenance
Cleaning the Cabinet
Use a wrung out damp cloth, or a damp cloth soaked in
water and a mild detergent, to clean the cabinet surface.
To avoid damaging the cabinet of the unit, never use
alcohol, thinner, or any other type of organic solvent, or
any type of abrasive cleaner, to clean the cabinet.
Cleaning the Thermal Head
If the printout is dirty or white stripes appear on the
printouts, clean the thermal head using the cleaning
sheet supplied.
Carry out the head cleaning operation using the menu.
Note
A paper cutter is mounted with the unit. When cleaning
the thermal head, be careful not to touch the paper cutter.
Touching the paper cutter may cause injury.
1 Press the power ON/OFF switch to ON to turn the
unit on.
2 Press the OPEN button to open the door.
If the paper is loaded in the paper tray, remove it.
3 Insert the cleaning sheet, with the black surface
facing down, into the groove of the paper tray.
4 Close the door by pushing it.
5 Press the jog dial.
The menu item changed last is displayed.
6 Display “CLEAN” by turning the jog dial, and then
press the jog dial.
7 Confirm that “CL:OK” is displayed, and then press
the jog dial.
The unit starts cleaning the thermal head.
“CLEAN” is displayed on the LCD.
When the cleaning sheet stops and the alarm
sounds, the cleaning is completed.
8 Press the OPEN button to open the door and remove
the cleaning sheet.
9 Close the door by pushing it.
Note
Clean the thermal head only when necessary. If you
clean the thermal head too frequently, it may cause a
malfunction.
Insert the
cleaning
sheet into the
groove of the
paper tray.
Cleaning sheet
supplied
