Sony Wega Trinitron KV-27FV17 User guide

KV-27FV17
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
REAR TERMINAL
SIDE VIEW
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX [phone] • b2b.sel.sony.com
23 7/8"
20 1/2"
16 7/8"
AUX
IN
VHF/UHF
IN
TO
CONVERTER
Optional Stand
SU-27FD4 (W xH x D)
27 3/4" x 19" x 21"
Video
S-
Video
VIDEO IN
13 4
Audio
L
MONO
R
Y
Pb
Pr
Audio
L
MONO
R
AUDIO OUT
