KDF -70XBR950
70" XBR®Rear Projection Grand WEGA ™ Television
Shown with optional SU-GW3 A/V stand
Key Features
Wega Engine ™system maintains picture in the
digital domain
Optical Engine delivers high-resolution, corner to
corner
3.28 million dots resolution delivers stunning detail
and clarity
Fixed pixel display and constant light eliminate
flicker
Expand the life of your TV with easily replaceable
lamp
Slim, lightweight design enhances any d é cor
Images, audio come alive with Memory Stick ®
Media Enhanced Playback
High Contrast Screen with A/R (Anti-Reflective)
Coating
Image Quality Enhancer LSI
Integrated ATSC Tuner
Enjoy outstanding picture quality on HDTV
monitor
Key Technologies
WEGA Engine ™ System Because of the special demands HDTV places on signal quality a new generation of
Sony’s exclusive WEGA Engine™advanced picture quality system has evolved into WEGA Engine™ HD. Two
innovative digital imaging processes have been added to improve overall picture quality. A High Contrast Image
processor dynamically detects the histogram of each frame and instantly applies the ideal contrast level for
crisper images. And the Natural High Density Picture image processor reduces noise elements by intelligently
separating the noise from the video signal for a purer more detailed picture. Enjoy a stunning display of realistic
images, amazing detail and sharpness, reduced noise and enhanced clarity with improved depth and contrast.
Step - up

SonyElectronicsInc. • 16530Via Esprillo Drive • SanDiego, CA 92127 • 1-800-222-7669 • www.sony.com
Last Updated: 04/27/2006
KDF -70XBR950
70" XBR®Rear Projection Grand WEGA ™ Television
Optional SU-GW3 A/V stand
Pleasevisit the Dealer Network forcurrent
information at www.sony.com/dn
Features
General
Auto SAP: Yes
Channel Fix: Yes
Closed Caption (CC): Yes
ID1 Detection: Yes
Video Label: Yes
Video
Screen or Display Technology: Grand WEGA™
Rear Projection
Tuner: ATSC, HD, NTSC
Video Processing: WEGA Engine ™Technology
Auto White Balance: Yes
Color Temperature: Cool, Neutral, Warm
Color Correction: On/Off
Noise Reduction: High, Medium, Low, Off
Black Corrector: High, Medium, Low, Off
Cinema Black Pro: Yes
Clear White: On/Off
Gamma Compensation: High, Medium, Low,
Off
CineMotion® Reverse 3:2 Pulldown
Technology: Yes
Contrast Enhancer: Yes
Direct Digital II Circuitry: Yes
16:9 Enhanced Mode: Yes
Wide Mode (16:9): Normal, Full, Zoom, Wide
Zoom
Wide Mode (4:3): Wide Zoom, Normal, Full,
Zoom
Slide Show Mode: Yes
MID®-X Technology: Yes
Mild Mode: Yes
Comb Filter: 3D Digital Comb Filter
DRC® MultiFunction Circuitry: Yes
DRC® Mode: Mode 1, Mode 2, CineMotion®
Technology
DRC® Palette Presets: Custom 1, Custom 2,
Custom 3
Direct Mode: High Density, Progressive,
CineMotion® Technology
Game Picture: Yes
Image Shift: Auto, Level 1, 2, 3, 4
Phase (PC Only): Yes
Pitch (PC Only): Yes
Advanced Video Menu: Yes
Picture Modes: Vivid, Standard, Pro
Detail Enhancer: Off, Low, Medium, High
Color System: ATSC, NTSC
BN Smoother: Yes
Audio
Tone Control(s): Treble and Bass
MTS Stereo Decoder: Yes
Audio Mute: Yes
Speaker On/Off: Yes
Simulated Surround: Yes
SRS ® TruSurround® Audio Effect: Yes
Dolby® Virtual Surround: Yes
Convenience
Channel Label: Yes
Channel Skip/Add: Yes
Channel Jump: Yes
Favorite Channel: Yes
Speed Surf ™ Channel Selection: Yes
Program Guide Access: Yes
Auto Channel Programming: Yes
Multiple Language Display: English, Español,
Français
Parental Control (V-Chip): Yes
Programmable Timer: Yes
Sleep Timer: Yes
Timer Events: Timer 1, Timer 2
Caption Vision: Yes
Clock: Yes (2 Event)
Picture And Picture: Yes
Built -in AC Adaptor: Yes
Picture Freeze: Yes
Specifications
General
Aspect Ratio: 16:9
Screen Size: 70"
Video
Native Resolution: 720p
Display Resolution: 1386 x 788
Viewing Angle: Right/Left: 130 ° , Up/Down: 60 °
Vertical Size: +7 to -7 (Wide Zoom and Zoom)
Vertical Center: +25 to -25 (Zoom) / +10 to -10
(Wide Zoom)
Audio
Audio Power Output: 30W Total (5W x 2 + 20W
Woofer)
Inputs and Outputs
Analog Audio Input(s): 6 (1 Front/5 Rear)
Audio Out (Variable/Fixed): 1 (Rear) -
Fixed/Variable
Component Video (Y/Pb/Pr ) Input(s): 2 (Rear)
Composite Video Input(s): 4 (1 Front/3 Rear):
1080i, 720p, 480p, 480i
Control-S Input(s): 1 (Rear)
Control- S Output(s): 1 (Rear)
Digital Audio Output(s): 1 (Rear: PCM/ Dolby®
Digital (Optical))
i.LINK® Connection: 3 (1 Front/2 Rear)
Memory Stick ® Media Slot: 1 (Front)
RF Connection Input(s): 2 (Rear)
S -Video Input(s): 4 (1 Front / 3 Rear)
DVI Connection Input(s): 1 (Rear)
Power
Internal Power Supply: Yes
Power Consumption (in Operation): 250W
Power Consumption (in Standby): Less than
1W
Power Requirements: AC 120V, 60Hz
Power Consumption (CableCARD ™ Function in
Standby): Less than 20W
Regulation and Standard Compliance
Energy Star ® Compliant: Yes
Service and Warranty Information
Limited Warranty: 1 Year Parts / 1 Year Labor
Dimensions
Weight: 204 lbs (92.5 kg)
Measurements: 71 3/4" x 45" x 25 1/2" (1821 x
1143 x 647 mm)
Supplied Accessories
Instruction Manual
Remote Control
AAA Battery (2)
Optional Accessories
Replacement Lamp: XL-2100U
TV Stand: SU-GW3
UPC Code: 027242633179
Confidential Sony Information. For Internal Use Only.
©2005 Sony Electronics Inc.
Sony are trademarks of Sony.
Features and specifications are subject to change without notice. Non -
metric weights and measures are approximate.
