Sound Freaq Sound Step SFQ-02RB User manual

SFQ-02RB
Sound Step

The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
Safety Information
WARNINGS:
.1.
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
DO NOT REMOVE COVER or OPEN THE CABINET.
Dangerous high voltages are present inside the enclosure.
No user serviceable parts inside. Leave all servicing to
qualified service personnel.
10. Protect the power cord from being walked
on or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
11. Only use attachments/accessories specified
by the manufacturer.
12. Use only with the cart, stand, tripod, bracket
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning
storms or when unused for long periods of
time.
14. Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is damaged,
liquid has been spilled or objects have
fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not
operate normally, or has been dropped.
15. Apparatus shall not be exposed to dripping
orsplashing and no objectsfilledwith
liquids, such as vase,shall not be placed on
the apparatus.
16. The mains plug is used as disconnect device
and it shall remain readily operable during
intended use. In order to disconnect the
mains plug from the mains completely, the
mains plug should be disconnected from
the mains socket outlet completely.
17. The batteries (battery pack & batteries installed)
shall not be exposed to excessive heat such
as sunshine, fire or the like.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install
in accordance with the manufacturer's
instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9. Do not defeat the safety purpose of the
polarized or grounding - type plug. A polarized
plug has two blades with one wider than
the other. A grounding type plug has two
blades and a third grounding prong. The
wide blade or the third prong is provided for
your safety. If the provided plug does not fit
into your outlet, consult an electrician for
replacement of the obsolete outlet.
PORTABLE CART WARNING
(Symbol provided by RETAC)

.2.
For compatibility between the SFQ-02RB
system and another device with Bluetooth
technology, consult the device's documentation
and dealer. In some countries, there may be
restrictions on using Bluetooth devices.Check
with your local authorities.
Bluetooth is a registered trademark of Bluetooth
SIG, Inc
Please read rating label at the bottom of system
for power input and other safety information.
FCC and IC Information:
This device complies with Part 15 of the FCC
Rules and RSS-210 of the IC Rules. Operation is
subject to the following two conditions: (1) This
device may not cause harmful interference, and
(2) this device must accept any interference
received, including interference that may cause
undesired operation.
Warning: Changes or modifications to this unit
not expressly approved by the party responsible
for compliance could void the user's authority to
operate the equipment.
Note: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful interference
in a residential installation. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio TV
technician for help.
Warnings: The device meets the exemption
from the routine evaluation limits in section 2.5
of RSS 102 and users can obtain Canadian
information on RF exposure and compliance
from the Canadian Representative Burnport
Holdings Ltd. 72MT Belcher Pls, East, Calgary,
Alberta, T2Z 2G1, CANADA. Tel: [phone]
FCC&IC Radiation Exposure Statement
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment and meets the exemption from
the routine evaluation limits in section 2.5 of
RSS 102.
1. This Transmitter must not be co-located or
operating in conjunction with any other
antenna or transmitter.
2. This equipment complies with FCC RF
radiation exposure limits set forth for an
uncontrolled environment. This equipment
should be installed and operated with a
minimum distance of 20 centimeters from
user and bystanders.
18. Do not place any naked flame sources, such
as lighted candles, on the apparatus.
19. The battery used in this product must be
properly recycled or disposed of.Please
contact your local recycling center for proper
battery handling and disposal instructions.

.3.
CAUTION - Proper Ventilation
To avoid risk of electric shock and fire, and to
prevent damage, locate the apparatus as
follows:
Front:No obstructions and open spacing.
Sides / Top / Back: No obstructions should be
placed in the areas shown by the dimensions
below.
Bottom: Place on the level surface. Maintain an
adequate air path for ventilation by placing on a
stand with a height of 10 cm (3-15/16") or more.
15 cm
(5- 15/16")
15 cm
(5- 15/16")
10 cm
(3- 15/16")
15 cm
(5-15/
16")
15 cm
(5-15/
16")
15 cm
(5-15/
16")
Front View:
Side View:
Front side Back side
QDID: B017662
CAUTION - Proper Installation
Install the system in a place which is level, dry
and neither too hot nor too cold.The appropriate
temperature is between 5 oC and 35 oC.
Install the system in a location with adequate
ventilation to prevent internal heat from
building up inside the unit.
Leave sufficient distance between the system
and TV.
Keep the system away from TV to avoid
interference with TV.
Information for Users on Disposal of Old
Equipment
[European Union]
This symbol indicates that the
electrical and electronic equipment
should not be disposed as
general household waste at its
end-of-life. Instead, the product
should be handed over to the
applicable collection point for
the recycling in accordance
with your national legislation.
By disposing of this product correctly, you will
help to conserve natural resources and will help
prevent potential negative effects on the
environment and human health that could
otherwise be caused by inappropriate waste
handling of this product. For more information
about collection point and recycling of this
product, please contact your local municipal
office, your household waste disposal service or
the shop where you purchased the product.
Penalties may be applicable for incorrect
disposal of this waste, in accordance with
national legislation.
[Other Countries outside the European
Union]
If you wish to dispose of this product, please do
so in accordance with applicable national
legislation or other rules in your country for the
treatment of old electrical and electronic
equipment.
Attention:
This symbol is
only valid in the
European Union.

.4.
Getting Started
Package Contents
Installing/Replacing the Batteries
Connecting the AC Adapter
Charging the Built-in Battery
Using the Remote Control
System Overview
Front View
Back View
Bottom View
Remote Control
Selecting the Sound Source
Playing back from iPad/iPhone/iPod
Setting an iPod on the Unit
Listening to an iPod
Viewing a Video/Picture from an iPod
Charging an iPod
Playing back via Bluetooth
Downloading the SoundFreaq App
Using Multiple Bluetooth Devices
Playing back from Macbook or Macbook Pro
Playing back from PC/Notebook
Listening to Tuner
Listening to a Station
Presetting a Station
Playing back from External Source
Listening to the External Audio Device, Digital Music Player or
Any Other Audio Source
Activating "U-Cubed" Sound Effect
Troubleshooting
Technical Specifications
5
5
5
6
7
7
8
8
8
8
9
9
10
10
10
10
11
12
12
13
13
13
14
14
14
15
15
15
16
17
Contents

.5.
Package Contents
Examine whether the following package contents are all included:
Main Unit Remote Control
FM Antenna
AC Adapter
Getting Started
+
C 2025
3V
R
It is loaded on the remote
control at the factory.
Lithium Coin Battery
CR2025
Installing/Replacing the Batteries
CAUTION: Danger of explosion if battery is
incorrectly replaced. Replace only with the
same or equivalent type.
1. Squeeze and pull to release the battery cover
latch. You can remove the battery door with
your fingernails by using the spaces set back
in wall.
2. Match the polarity on the Lithium Cell with a
plus sign (+) on the battery tray.
3. Slide the tray with new battery into the
battery compartment until you hear a click
sound.
1
2
Squeeze
Pull
+
C 2025
3V
R
Handling the Remote Control
To avoid possible failure, read the following
instructions and handle the remote control
properly.
Do not drop or cause impact to the remote
control.
Do not spill water or any liquid on the remote
control.
Do not place the remote control on a wet
object.
Do not place the remote control under the
direct sunlight or near sources of excessive
heat.
Note: If you are not going to use the remote
control for a long time, remove the battery to
avoid any damage that may be caused by
leakage and corrosion.

.6.
Warning - When Using the Battery
Store the battery in a place where children
cannot reach. If a child accidentally swallows
the battery, consult a doctor immediately.
Do not recharge, short circuit, disassemble,
heat the battery, or dispose the battery in
fire. Doing any of these things may cause the
battery to give off heat, crack, or start a fire.
Do not leave the battery with other metallic
materials. Doing this may cause the battery
to give off heat, crack, or start a fire.
When throwing away or saving the battery,
wrap it in tape and insulate; otherwise, the
battery may start to give off heat, crack, or
start a fire.
Do not poke the battery with tweezers or
similar tools. Doing this may cause the
battery to give off heat, crack, or start a fire.
Dispose of battery in the proper manner,
according to federal, state, and local
regulations.
The batteries (battery pack or batteries
installed) shall not be exposed to excessive
heat source such as sunshine, fire or the like.
This product contains a CR Coin Cell Lithium
Battery that contains Perchlorate Material, so
that special handling may apply.
Connecting the AC Adapter
WARNING! For optimal performance, use only
the supplied AC adapter.
Ensure that power supply outlet matches with
the unit AC's input 100-240V~, 50/60Hz
before connection.
Plug the AC
adapter only
after all other
connections are
completed.

.7.
Using the Remote Control
Using the remote control
Remove the insulation sheet before using for
the first time.
Aim the remote control at the IR Sensor on
the front lens within an approximate
distance of 7m (23 feet) away.
Charging the Built-in Battery
The Sound Step has a built in Lithium Ion
battery to give you portable power when not
using the AC adapter. When the adapter is
plugged in, the unit will charge. During
charging the charging indicator next to the DC
IN jack will be solid red when fully charged, it
will be turn green. When operating the unit in
battery mode, a ashing red indicator means
the battery is low.
You must charge this unit for 12 hours before
using for the rst time.
Notes:
The battery cannot be replaced by the user.
It takes about 3 hours to charge the battery
from empty to full.
Do not dispose of unit in re; battery may
explode or leak.
Type: Li-Ion Battery
Model No: LCR 18650
Rated Voltage: 7.4V (3.7 V * 2)
Capacity: 1500 mAh
WARNING！There is a danger of explosion if
the battery is incorrectly replaced. Replace it
only with the same or equivalent type. Do not
expose it to excessive heat such as sunshine,
re, etc.
IR Sensor
Remote Control Compartment
Storing the remote control
A remote control storage compartment is
designed at the bottom of the system. The
remote control can be stored into the
compartment easily for your quick and
convenient use.
the Bottom of the System
Charging indicator

5
.8.
10. Vol +/- button
Press to increase (+) or decrease (-) the
volume level.
11. (on/Standby) button
Switch between standby and power-on
modes.
12. USB jack
Connect to an external device for charging.
13. Charging indicator
Indicate the charging status of the built-in
battery.
14. DC IN jack
Connect the supplied AC adapter.
15. Subwoofer speaker
16. FM.ANT (Antenna) jack
17. AUX IN jack
Connect to an external device.
18. VIDEO OUT jack
Connect to a video output device.
19. Built-in Lithium battery
20. Remote control compartment
System Overview
Front View Back View
Bottom View
1. U-Cubed button and indicator
Press to activate or deactivate the U-Cubed
(High Definition Wide Stereo) sound effect.
Lights when the U-Cubed is activated.
2. DOCK button and indicator
Switch to iPod mode.
Lights when the unit is in iPod mode.
3. (Bluetooth) button and indicator
Switch to Bluetooth mode.
Lights when the unit is in Bluetooth mode.
4. AUX button and indicator
Switch to AUX mode.
Lights when the unit is in AUX mode.
5. 30-pin Apple connector
Connect with iPad/iPhone/iPod.
6. Pairing indicator
To indicate when building a Bluetooth
connection.
7. PAIR button
Build a Bluetooth connection with a
Bluetooth-enabled device.
8. (Previous) / (Next) button
Skip to the previous/next track in iPod and
Bluetooth modes.
Decrease/increase the frequency to a station
in tuner mode.
9. (Play/Pause) button
Press to play or pause a track.
Save a station in tuner mode.
1 2 3 4
911
15
8
7
6
20
19
10
16 17 18
1412 13

.9.
Remote Control
Selecting the Sound Source
On the Unit
On the Remote Control
This system enables you to access one of three basic
functions - iPod, Bluetooth and AUX.
Press the DOCK, Bluetooth and AUX buttons on the unit or
the SOURCE button on the remote control/remote App to
select one of the sound sources.
The FM radio can only be played from an iPad, iPhone or iPod
touch using the Soundfreaq App. It can be played in iPod or
Bluetooth mode.
or
NOTE: When you operate the unit with the
built-in battery instead of the AC adapter, in
order to maximize the battery life, you
cannot turn on the unit with the button on
remote control.
1. (Standby) button
Switch power-on mode to standby mode.
2. (Play/Pause) button
Play/pause a track when listening to a track.
Save a station in tuner mode.
3. (Previous) / (Next) button
Skip to the previous/next track in iPod and
Bluetooth modes.
Decrease/increase the frequency to a
station in tuner mode.
4. VOL +/- button
Press to increase (+) or decrease (-) the
volume level.
5. MUTE button
Turn off the sound. Press again to restore
the sound output.
6. SOURCE button
Select iPod, AUX or Bluetooth mode by
pressing repeatedly.
7. U-Cubed button
Activate or deactives U-Cubed (High
Definition Wide Stereo) sound effect.
2
3
6
4
5
1
7

.10.
Playing back from iPad/iPhone/iPodPlaying back from iPad/iPhone/iPod
Setting an iPod on the Unit
 Compatible iPod Players: Most Apple iPod
models with 30-pin dock connectors as
follows: iPad, iPod nano 6th generation, iPod
nano 5th generation (video camera), iPod
nano 4th generation (video), iPod nano 3rd
generation (video), iPod nano 2nd generation
(aluminum), iPod nano 1st generation, iPod
4th generation (color display), iPhone, iPhone
3G/3GS, iPhone 4, iPod classic, iPod 5th
generation (video), iPod 4th generation, iPod
touch 4th generation, iPod touch 3rd
generation, iPod touch 2nd generation, iPod
touch 1st generation, iPod mini.
1. Remove the rubber cover from the iPod
connector.
2. Connect your iPod. Make sure the connector
plug of unit is firmly inserted into the
connector port of iPod.
Note： In this user manual, “iPod” is used as a
general reference to functions on an iPod, iPhone
or iPad, unless otherwise specied by the text or
illustrations.
Listening to an iPod
1. Press the " " button to power on the system.
2. Set an iPod on the unit and press the DOCK
button to switch to the iPod mode if the unit
is not in the iPod mode.
Note: Before listening to a track from an iPod
touch, iPhone or iPad, you need to tap the
corresponding icons on the display to select
a track.
3. Press the “ ”button to play the track.
Viewing a Video/Picture from an
iPod
When viewing a video/picture from your iPod
on your TV, use a composite video cord (not
supplied) to connect the VIDEO OUT jack on
the unit and the composite video input on your
TV.
DOCK Button
Rubber Cover
Rubber Pad
Back of Unit
Top
Bottom
Stick
Notes:
If you are docking your device with a case,
you can remove the rubber pad to secure a
better t and connection. Both the rubber
cover and pad can be conveniently stuck
anywhere along the ribs on the back of the
Sound Step.
Always set volume to the minimum when
connecting or disconnecting the other
equipment.
When you connect your iPod to unit, make
sure you insert it all the way.

.11.
Notes for Caring Your iPod:
Charging an iPod
The battery of the iPod is always charged
through the unit when it is connecting to a wall
outlet except when the unit is operated in
battery mode.
 Charging begins when the iPod is set on the
dock.
The charging status appears in the display on
iPod.
Make sure the AC adapter is connected to
the unit.
The iPod is charged regardless of the sound
source selected on the unit.
See the iPod instruction manual about the
details of iPod charging.
1. Press the " " button to power on the system.
2. Set an iPod on the unit and press the DOCK
button to switch to the iPod mode if the unit
is not in the iPod mode.
Note: Before viewing a video/picture from
your iPod on your TV, tap the corresponding
application icon on the iPod to select a
picture/video.
3. Press the “ ” button to play the desired
track.
The connector plug is protected with a cover
when it is first purchased. Please remove the
cover before operating the unit.
Do not carry the unit with iPod connected.
You might drop it down or it might cause
damages to the connector part.
Do not touch or hit the iPod terminal pins or
the connector pins directly. It might cause
damages to the connector part.
If the iPod does not play correctly, please
update your iPod software to the latest
version. - For details about updating your
iPod, check on the Apple web site
<http://www.apple.com>.
iPod is a trademark of Apple Inc., registered in
the U.S. and other countries.
iPhone is a trademark of Apple Inc.
iPad is a trademark of Apple Inc.
We are not responsible for any loss of or
damage to iPod that might result from the
use of this product.
Sound distortion may occur when playing back
audio sources with high recording levels.
When distortion occurs, it is recommended
to turn off the equalizer of the iPod. For
information on operating the iPod, see the
iPod instruction manual.
If you do not turn on the power of this unit
and only connect the iPod to this unit, power
may be supplied to the iPod.
"Made for iPod" and "Made for iPhone" and
"Made for iPad" mean that an electronic
accessory has been designed to connect
specifically to iPod/iPhone/iPad and has
been certified by the developer to meet
Apple performance standards.
Apple is not responsible for the operation of
this device or its compliance with safety and
regulatory standards.
Video cord (not supplied)
Back Panel
TV

.12..12.
Notes:
If your mobile phone supports A2DP protocol,
its music will play through the unit.
You can build a Bluetooth connection with a
mobile phone, an iPhone/iPad or any other
Bluetooth-enabled devices.
1. Press the " " button to power on the unit.
The pair indicator is solid on when the unit is
powered on.
2. Press the PAIR button on the unit to put the
unit into the pair mode.
The Pair indicator starts blinking at a fast rate.
If you hold the PAIR button for more than 2
seconds during the process of pairing, the
operation will be cancelled.
3. During this period, you can operate the mobile
phone,iPad or Bluetooth-enabled device to
pair with the unit within a 33 feet (10m) range.
Please check the user manual of the iPad or
Bluetooth-enabled device with which you
are initiating pair to learn about Bluetooth
connection with any other devices.
4. Once the unit is detected and its name
"Sound Step" appears on the display of your
Bluetooth-enabled device, key in the default
password "1234" if a prompt requests it.
You may change the device name on your
Bluetooth-enabled device after the pair is
successfully set up.
Playing back via Bluetooth
Downloading the SoundFreaq App
We have developed an App to give you
full control from your iPhone/iPad while
playing audio over the Bluetooth wireless
connection, please download the
"SoundFreaq Remote" App for FREE.
After you build a Bluetooth connection
between your iPhone/iPad and the Sound
Step, a prompt will be displayed on your
iPhone/iPad asking you if you would like
to install our App, click "Yes" to install the
APP. After a while, "For his Accessory"
page will appear on your iPhone/iPad.
Enter the "User Name" and "Password" in
the iTune. After pressing the "FREE"
button, press the "INSTALL APP" button
that will appear to install the APP for your
unit. When the installation is finished, you
can control the playback from your
iPhone/iPad.
You will need the App to operate the
FM radio function.
You can click "No" to choose not to
download the App and still play music via
the Bluetooth connection but you will
have limited control, we suggest you
download the App.
PAIR Button
Bluetooth Button
Main Unit
Warning: Do not unplug the AC adapter from
the unit when playing back a track via the
Bluetooth connection.

.13.
The pair indicator starts blinking quickly to
indicate that the unit and your device have
put into the connection mode.
When a Bluetooth connection is established
successfully, the indicator will be solid on.
5. Select Bluetooth mode by repeatedly pressing
the SOURCE button on the remote control
or pressing the Bluetooth button on the unit.
6. Select the desired music and press "Play"
button on your device.The unit automatically
starts playing the audio.
Try again above steps 2 to 5 if the pair
indicator turns solid after blinking for 3
minutes, the pair was unsuccessful.
Using Multiple Bluetooth Devices
Only one device can be used at a time, but you
can switch between different Bluetooth devices.
Make sure each device you want to use has
already been paired, to switch devices:
1. On the Sound Step, press the pair button.
2. On the Bluetooth device,select connect to the
Sound Step.
This device is now the connected device to the
Sound Step, (the previous connected device is
now disconnected). Repeat those steps to
switch the connected device again.
Note:If the unit has no sound output,please
check if the volume level of your Bluetooth
device connected to the system is set to the
minimum, or the Bluetooth device is muted.
PlayingbackfromMacbookorMacbook
Pro
1. In the desktop screen, Select the “Open
Bluetooth Preference”.
2. If there is any old “Sound Step” records,
remove it. And then select “Setup New
Device” again.
3. Select “Sound Pla” and the type should be
“Audio” in the latest SFQ-02RB unit.
Click the “Continue” to proceed pairing
process.
4. Once completed, the pairing success screen
will come out.
Note: Don’t quit the page immediately. You
may notice that the previous dialog screen
stillshowsthe devicenot connected. Just
ignore it. It’s confusing to the user. In fact,
it’s connected already.
5. Open iTune, play a song. Then use mouse to
click the Bluetooth icon and the top right
hand corner of the desktop screen, select
the “Sound Step” option and then select the
“Use as Audio Device (Stereo)”. After a while (a
few seconds), the music will come out
from the SFQ-02RB. If not, retry to select the
“Use as Audio Device (Stereo)” once again.
The Sound Quality should be good.
Playing back from PC/Notebook
1. Press the “Start” button to open the “Device
and Printers” dialog box.
2. Turn on the SFQ-02RB system and press the
PAIR button on the unit to put the unit into
the pair mode.
3. Select the “Add a device” in the “Device and
Printer” dialog box. The “Sound Step” icon
will appear on the display.
4. Double click the“Sound Step” icon and wait
until the device has been added successfully.
5. Click the “Close” button to close the “Device
and Printer” dialog box. A ”Sound Step” icon
appears in the dialog box.
6. Double click the “Sound Step” icon and the
device connection screen will be shown.
7. Click the “Connect” button in the “Music and
Audio” option.
8. Once connected, the pair indicator on the
unit will be solid on and the connection
success screen will be shown.

.14.
2. Press the " " button to power on the
system.
3. Select tuner mode with the SOURCE button
on the remote App.
4. Select a desired radio station for listening.
5. Move the antenna around to get the best
reception.
6. If necessary, adjust the volume level.
Listening to Tuner
Listening to a Station
Note: Position the antenna as far away as
possible from the AC adapter, a TV, or other
radiation source.
1. Plug the supplied FM antenna into the
FM.ANT jack located on the back of unit.
Press the Button
Functions
Remote App
 Switch between the frequency
display and channel number
display.
 Hold this button to enter saving
mode.Press to save a channel.
(see "Presetting a station”)
Select a channel (from 01 to
20).
Change frequency (from
87.5 MHz to 108.0 MHz).
Hold for more than one second
to activate the Auto Scan
function, and then release
the button. The frequency
will be scanned automatically
until a radio station is found.
Or press again to quit search
while searching.
Presetting a Station
Note: Presetting station function can be
completed through the Soundfreaq App, in
either iPod or Bluetooth mode.
1. Select tuner mode with the SOURCE button
on the remote App.
2. Switch to the frequency display if the display
is channel number.
3. Tune a desired frequency. You can use either
of the below methods to tune the frequency.
A. Manual Tuning - Briefly press " "/ " "
button repeatedly to move frequency to
frequency (from 87.5 MHz to 108.0 MHz)
until you find the desired station.
The FM radio function can be accessed by:
1) the remote App, when Bluetooth connection
has been built;
2) the remote App, when the iPad/iPhone is set
on the unit.
The operation interface of remote App software
is similar to the remote control. You can easily
operate the tuner function on the display of
iPad/iPhone.
FM Antenna

.15.
B. Auto Scanning - Hold " "/ " " button
until the frequency display starts flashing.
The frequency will be scanned automatically
until a station is found.
4. Hold " " button to start storing a station.
The channel number and “Select” word start
blinking together on the display of the
iPad/iPhone.
5. Use " "/ " " to select the channel number
(from 01 to 20) to be set.
6. Press " " button again to store the frequency.
The selected frequency will then be stored
with the preset channel number.
1. Turn the unit power on.
2. Set the volume to the minimum position.
3. Select AUX mode with the AUX button on
the unit or the SOURCE button on the
remote control.
4. Start playback on the external device.
5. Adjust the volume level to the level that you
want to listen to.
Note: Each time you press the volume buttons
to adjust the level, the power indicator will
blinks.
Playing back from External Source
Listening to an External Audio
Device, Digital Music Player or Any
Other Audio Source
Connect an external device to the AUX IN jack
on the back panel of the unit using a stereo
mini plug cord (not supplied).
Activating "U-Cubed" Sound Effect
"U-Cubed" is an proprietary technology designed to create an ultra wide stereo sound
field in digital music systems. With exceptional natural sound reproduction of high definition and
fidelity, we create a listening experience where you feel like your speakers are separated much more
than they are.
To activate UQ3 on:
The unit, press the " " button to activate, press again to deactivate.
On the remote control or remote App,press the " " button to activate and deactivate.
Note: In tuner mode, the U-Cubed sound effect can not be activated.
To audio
output such
as CD/MD/
digital music
player, etc.

.16.
Troubleshooting
In These Cases Check the following points
Check this list for a possible troubleshooting solution before calling for service.
• Is the selected dock adapter compatible to your iPad/iPhone/iPod?
• Is the dock adapter properly mounted on the unit? Make sure to mount the
dock adapter properly.
• AC adapter is not inserted securely. Plug in securely.
• The built-in lithium battery is no power. Charge the battery.
• Is the connector plug of the unit firmly inserted into the connector port of
the iPad/iPhone/iPod?
• Is the iPad/iPhone/iPod properly functioning? Test the iPad/iPhone/iPod
functions in stand-alone condition.
• Is the connector plug of the unit firmly inserted into the connector port
of the iPad/iPhone/iPod?
• Is the AC adapter plug firmly inserted into DC IN jack of the unit?
• The path between the remote control and the sensor on the unit is blocked.
• The battery of remote control is exhausted.
• Remove and reconnect the AC power plug and turn on the system again.
Hard to listen to broadcasts
because of noise.
No sound output.
• The antenna is not properly extended or positioned.
• Tune to the correct radio channel/frequency.
• Making sure the antenna is further away from any equipment that may be
causing the noise or interference.
Cannot set the
iPad/iPhone/iPod.
Power does not come on.
Cannot operate
iPad/iPhone/iPod.
iPad/iPhone/iPod cannot be
charged.
The system does not react
when the buttons are
pressed.
Unable to operate the
System from the remote
control.
• Check if the volume level is set to the minimum.
• Check if the volume level of your Bluetooth device connected to the system is
set to the minimum.
• Check if the volume level is muted. Press MUTE button on the remote control
again to restore the sound output.
• Check to make sure your Bluetooth device is not muted.
a. Right click the“Sound Step” icon in the “Device and Printer” dialog box.
b. Open the“Sound Step Properties” dialog box and select the “Services” tab.
c. Put the ticks on the “Audio Sink” and “Remote Control” boxes.
d. Press the “Apply” button and the exclamation mark of the “Sound Step” driver
icon will be cleared.
Bluetooth connection can not
be established between the
system and your Lenovo PC
with Win 7 OS.
• The system enters the saving energy mode. The unit may be no sound output
for more than 28 minutes. Turn on the system again and play back an audio
source.
The system is suddenly
powered off.
• The system enters the protection mode. The unit may have a short circuit.
Unplug the AC adapter immediately. You need to consult your seller and
leave all servicing to the qualified personnel.
All the indicators on the
system start blinking quickly
at the same time when iPod/
iPhone is charging.
Bluetooth connection can not
be built.
• When building a Bluetooth connection between the unit and your device for
the first time, if the connection is fail, you need to power off your device and
power on again to clear the device name, and build the connection again.
No sound output is via Bluetooth
or Bluetooth connection can
not be restored automatically.
• The unit may be powered off and powered on when playing back a track via
Bluetooth connection. You need to build the connection again.

.17.
External DC IN (for AC adapter), AUX IN
DC 12 V 2.5 A (External DC IN)
Input: AC 100-240V, 50/60Hz
Output: DC 12 V 2.5 A
330mm (W) * 92mm (H) * 112.5mm (D)
1.32Kg (including remote control)
Model
Type
Support Bluetooth
Support Profile
Bluetooth 1.2, 2.0 and 2.1 compliant
Sound Step
A2DP
Input Sensitivity/Impedance AUX Input 1200 mV
Tuner
Band
Tuning Range
Frequency Step
Preset Stations
Input Terminal
Power Source
AC Adapter
Dimensions (Approx.)
Weight
Technical Specifications
SFQ-02RB
FM
87.5 ~ 108.0 MHz
100 KHz
20

Save this manual
