SoundLogic XT ANC-BS949 User manual

1
ANC-BS949, MFSB-2/1755
SUPER-BASS
Multi Function Portable BT Speaker
INSTRUCTION MANUAL
PLEASE READ ALL INSTRUCTIONS CAREFULLY
AND RETAIN FOR FUTURE USE

2
Getting Started
Remove the product from the box.
Remove any packaging from the product.
Please retain all packaging after you have checked and counted all the parts and the contents
against the list.
Package Contents
Bluetooth Speaker
AUX/USB rechargeable cable
Wired Microphone
Instruction Manual
Key Features
Portable Multi-function Bluetooth Speaker with LED lights
Connect & stream wireless music anytime, anywhere
Delivers rich sound with bass
Built-in 2 x 4 inch speaker drivers delivers superior sound with bass
Wireless range up to 33 feet
Multi-function: Bluetooth, USB slot, Micro-SD card slot & AUX jack
Long-lasting rechargeable battery
Built-in microphone input
AUX/USB cable included
Safety Instructions
Keep the unit away from heat sources, direct sunlight, humidity, water and any other liquids.
Do not use the unit if it has been dropped or damaged in any way.
Repairs to electrical equipment should only be performed by a qualified electrician. Improper
repairs may place the user at serious risk.
Do not use the unit with wet hands.
Do not put objects into any of the openings.
Keep the unit free from dust, lint etc.
Do not use this unit for anything other than its intended use.
Keep the unit out of reach of children.
This unit is not a toy.

3
Description of Parts
LED Display
Number
Item
Function
1
MIC IN
Microphone input
2
ON/OFF SWITCH
Turn the speaker On or Off
3
PREVIOUS
TRACK/STATION
Bluetooth/USB/SD card mode: Skip to previous track
FM radio mode: Skip to the previous already saved radio station
4
PLAY/PAUSE/SCAN
PLAY/PAUSE, scan FM radio stations (only in FM radio mode)
5
Micro SD (TF) slot
Micro SD (TF) card input
6
NEXT TRACK/STATION
Skip to the next track in Bluetooth/USD/SD card mode/Skip to the next radio station in
FM radio
7
MODE/LIGHT button
Short press to change the mode between Bluetooth / FM radio / AUX / USB / SD
Long press to turn on/off the colour changing LED lights
8
DC 5V IN/AUX IN
Charging port/External audio input
9
USB slot
USB input (Flash Drive)
10
VOLUME KNOB
Increases/Decrease the speaker volume

4
INSTRUCTIONS FOR USE
Charging the Boombox Bluetooth Speaker
For best results, fully charge the unit before use.
1. Plug the Micro USB end of the included AUX/USB charging cable into the charging port of the
speaker. Plug the other end into a USB port on your computer or USB power source with 1A
output.
2. Red charging indicator on the display is on while charging, and turns off when fully charged
Note: Before using the unit for the first time, please charge it for around 4-5 hours or until the red
charging indicator turns off.
Turn On/Off the Speaker
Slide the ON/OFF SWITCH to ON position to turn on the unit with colour changing LED lights, or OFF
position to turn off the unit.
Pairing your device with the Speaker –
Your Bluetooth Speaker can stream wireless audio from any Bluetooth enabled device within the range
of up to 10 meters. Simply follow the below steps.
1. Rotate the volume knob to your favorite sound level.
2. Turn ON the speaker.
3. LED display will show ‘HIFI’ and then ‘bt, and indication tone would be heard. The speaker is now
in pairing mode.
4. Turn on the Bluetooth on your Mobile Phone or Tablet or Computer.
5. It will search for available Bluetooth devices.
6. Bluetooth Speaker would appear as “SL SUPER-BASS”, in the list of searched devices. Select it
from the available list of devices.
7. If required, enter the password ‘0000’ to confirm pairing.
8. Once paired successfully, another indication tone would be heard.
9. If you fail to pair it within a few seconds or you want to pair it with a new device, please repeat
above steps.
Play your favorite song on the Bluetooth source device and music would now stream through the
speaker.
Listening to Wireless Music
Please ensure that your device (iPhone, Tablet or Other Smart Phone) is paired with the speaker to
stream wireless music. Once it is paired, play music from your device.

5
Function
Operation
Button
Increase /
Decrease Volume
Playing music
Turn VOLUME KNOB to adjust the volume to your desired level,
or
Adjust volume from the source device (in Bluetooth mode only).
Pause
Playing music
Short press PLAY/PAUSE/SCAN button once to pause music
Play
Pause
Short press PLAY/PAUSE/SCAN button once to resume music
Previous track
Playing music
Short press the PREVIOUS TRACK/STATION button to the
previous track
Next track
Playing music
Short press the NEXT TRACK/STATION button to the next track
Listening to Music using USB / Micro SD (TF) Card Slot
1. Rotate the volume knob to your favorite sound level.
2. Turn on the speaker.
3. Insert USB flash drive into the USB slot or Micro SD (TF) card into the Micro SD (TF) card slot
accordingly. LED display will show ‘USb or tF’ first, and music would play automatically with LED
display showing track number & then music time.
4. Short press the NEXT TRACK/STATION button or PREVIOUS TRACK/STATION button to move
forward or backward on your playlist.
5. Short press PLAY/PAUSE/SCAN button to Play or Pause a track.
Listening to Music using AUX-In
1. Rotate the volume knob to your favorite sound level.
2. Turn on the speaker.
3. Insert the Micro USB end of the included AUX/USB rechargeable cable into the Aux in. Plug the
Aux pin to the audio device (such as phone / MP3 Player / computer / tablet / …..etc.).
4. Short press the MODE button each time until it reaches Aux-in mode, LED display will show ‘LINE’,
and an indication tone would be heard.
5. Select your favorite song at the source device to play.
(Note: While using AUX-In function, all functions such as playing next/previous track can be controlled
only through your source device).
Listening FM radio
1. Rotate the volume knob to your favorite sound level.
2. Turn on the speaker.
3. Short press the MODE button each time until it reaches FM radio mode, LED display will show a
FM radio frequency with sound.

6
4. Press and hold the PLAY/PAUSE/SCAN button 2 seconds for searching and recording all radio
stations within frequency range 87.5-108MHz.
5. Short press the NEXT TRACK/STATION button or PREVIOUS TRACK/STATION button for listening
next or previous already saved radio station.
Tips!!
1. Short press the MODE button to switch different functions of the speaker. The functions are –
Bluetooth / FM radio / AUX / USB-Micro SD (TF).
2. When the speaker is not in use, turn OFF the device to save the battery power.
3. Do not overcharge the speaker.
Colour Changing LED lights in front of speaker
1. Turn on the speaker.
2. Long press the LIGHT button can turn on/off the colour changing LED lights.
Using the Microphone
1. Turn on the speaker
2. Insert the plug of the Microphone (not included) into the MIC INPUT of the speaker.
3. Turn on the Microphone, and speak for microphone operation or sing for Karaoke operation.
4. Turn VOLUME KNOB to adjust the desired level.
Do’s and Don’ts
Do not play music at excessive levels as damage to hearing and/or equipment may result.
Do not use outdoors in wet or in damp surroundings.
Care and maintenance
Clean the unit with a soft, dry cloth. Never use chemicals or hard abrasives.
Keep this unit away from wet or damp surroundings.
Product Specifications:
Bluetooth version: 5.0
Speaker output: 2x5W
Unit size: Dia. 6.30” x 15.16” H
Unit weight: ~2.62 lb
Power input: DC 5V
Charging time: 4-5 hours
Play time: 1.5 to 2.5 hours (maximum volume)

7
Bluetooth range: 33 feet
FM frequency range: 87.5-108MHz
Built-In Rechargeable Lithium Battery: 3.7V 1200mAh
(Note: Battery life & charging time may vary based on usage, types of devices connected & wireless
distance.)
TROUBLESHOOTING
Problem
Possible Cause
Solution
Low sound level
Source (Tablet, Mobile Phone, Laptop,
etc.) volume too low.
Battery dead
Adjust source volume.
Charge battery.
No sound
Volume in minimum position.
The connected device is not in play
mode.
Input source incorrect.
Turn VOLUME knob to increase the
volume.
Play the music in the connected device
and make sure the volume level is in
high level.
Press the MODE button to set the input
source to the desired function.
Sound distortion
Volume level too high
Turn VOLUME knob to decrease the
volume.
FCC Instructions
Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the product.
NOTE: This product has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This product generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If the product does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures :
-Reorient or relocate the receiving antenna.
-Increase the separation between the product and receiver.
-Connect the product into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.

8
The device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Limited Warranty
This manufacturer's product warranty extends to the original consumer purchaser ofthe product.Neitherthe
retailer norany othercompany involvedinthesale or promotion of this product is a co-warrantor of this
manufacturerwarranty.
WARRANTY DURATION: All materials and workmanship are warranted to the original consumer purchaser
for a period of ninety (90) days from the originalpurchase date.
WARRANTY COVERAGE: Thisproduct iswarrantedagainstdefectivematerials or workmanship. This warranty
is void if the product has been damaged by accident, in shipment, unreasonable use, misuse, neglect,
improper service, commercial use, repairs by unauthorized personnel or other causes not arising out of
defects in materials or workmanship. This warranty doesn’t cover the following which may be supplied
with this product, including but not limited to; LCD Screens, glass parts, lenses, bulbs etc. This warranty is
effective only if the product is purchased and operated in USA and Canada, and does not extend to any
units which have been used in violation of written instructions furnished by manufacturer or to units which have
been altered or modified or, to damaged products or parts thereof which have had the serial number removed,
altered, defaced or rendered illegible.
WARRANTY DISCLAIMERS: Thiswarrantyisinlieuofallwarrantiesexpressedorimplied and no representative or
person is authorizedto assumefor manufacturer any otherliability in connection with the sale of our products.
There shall be no claimsfordefects or failure under any theory of tort,contractorcommerciallaw including but
not limited to, negligence, gross negligence, strict liability, breach of warranty and breach of contract. Under no
circumstances will Manufacturer’s / Distributor’s maximum liability exceed the retail value of the product.
WARRANTY PERFORMANCE: Duringtheabove90daywarrantyperiod,aproduct with a defect will be either
repaired or replaced with a reconditioned comparable model (at manufacturer's option). The repaired or
replacement product will be in warranty for the balance of the 90 day warranty period andan additional
one-month period. No charge will be applicable for such repairor replacement.
SERVICE AND REPAIR: If service is required forthis product,youshouldfirst contactMidwest Trading Group
Customer Service at [e-mail] or by calling1 [phone], Monday to Friday10am to 6pm
EST.
NOTE: Manufacturer cannot assume responsibility for loss or damage during incoming shipment. As a
precautionary measure, carefully package the product for shipment, and insure it with the carrier. Be sure to
enclose the following details with the product: your full name, return address and daytime phone number, a
note describing the problem you experienced, a copy of your sales receipt or other proof of purchase to
determine warranty status. C.O.D. shipments cannot be accepted.
