SOUNDMASTER VC100 User manual

User’s Manual
English

ENGLISH
1
1.PARTS OF THE VIDEO CAMERA 4
2.PREPARING FOR USE 5
INSTALLING THE BATTERY 5
INSERTING THE MEMORY CARD 6
SETTINGTHE LANGUAGE 8
SETTINGTHE DATEAND TIME 9
MONITOR SCREEN DISPLAY 10
3.USING THIS VIDEO CAMERA 13
TURNINGTHE CAMERAON AND OFF 13
CHANGE THE MODE 14
RECORDING VIDEO CLIP 15
TAKING STILL IMAGES 16
USING THE SELF-TIMER AND BURST SNAPSHOT 17
USING THE ZOOM FUNCTION 18
RECORDINGAUDIO 19

ENGLISH
2
4.USING THE MENU IN RECORD MODE 20
MENU IN CAPTURE MODE 20
MENU IN VIDEO MODE 23
SETUPMENU 24
5. PLAYBACK 26
PLAYBACK STILL IMAGE 26
PLAYING BACK MOVIE CLIPS 27
PLAYING BACK AUDIO FILES 27
OTHER FUNCTIONS IN PLAYBACK MODE 28
6. MAKING CONNECTIONS 35
CONNECTINGTHE CAMERATOATV 35
CONNECTINGTHE CAMERA TO A PC 36
7. SOFTWARE INSTALLATION 38
INSTALLING THE SOFTWARE 38
8. TROUBLESHOOTING 41

ENGLISH
3
9. TECHNICAL SPECIFICATIONS 44
Thank you for purchasing this digital video camera. Please read these
operating instructions carefully in order to use the digital video camera
correctly. Keep the instructions in a safe place after reading so that you can
refer to them later.
Precautions
Before using the video camera, please ensure that you read and
understand the safety precautions described below.
• Do not try to open the case of the video camera or attempt to modify this
video camera in any way. Maintenance and repairs should be carried out
only by authorized service providers.
• Keep the video camera away from water and other liquids. Do not use the
video camera with wet hands. Never use the video camera in the rain or
snow. Moisture creates danger of electric shock.
• Use only the recommended power accessories. Use of power sources not
expressly recommended for this equipment may lead to overheating,
distortion of the equipment, fire, electrical shock or other hazards.

ENGLISH
4
1.Parts of the video camera
1:Lens
2:Microphone
3: Compensating lamp
4: Self-Timer LED
5:Delete
6: Playback
7:Mode
8:TFTLCDScreen
9: Left /Self-Timer
10:Power
11:Down button
12:Menu
13:AVOutjack
14:USBjack
15: Right /LED on or off
16:OK
17:Shutter
18: Up /Display
19: W/Zoom out button
20: T/Zoom in button
21: Speaker
22: Tripod socket
23:Cardslot
24: Battery cover

ENGLISH
5
2.Preparing for use
Installing the Battery
1. Open the video camera battery door.
2. Insert three AAA-size batteries with the positive (+) and negative (-)
poles matching the directions indicated on the battery cover.
3. Close the battery door.

ENGLISH
6
Inserting the Memory Card
This camera has an internal memory, it can
take a few pictures and video clips; please
use a SD or MMC or SDHC card for more
picture storage. Turn off the camera before
inserting or removing the memory card. Be
sure to orient the card correctly when
inserting it. Never try to force the memory
card into the slot when you feel resistance. The memory card has a write
protect switch, which is used to protect data from accidental deletion.
Therefore,
whenever you want to record, format or delete files in the SD card, disable
the write protection beforehand.
1. Turn off the video camera.
2. Find the rubber at the bottom of the video camera , and then uncover
the rubber where you will see the SD card slot.
3. Insert the memory card as illustrated.

ENGLISH
7
• Never insert any other object which is not a SD/MMC/SDHC card
into the camera’s SD card slot.
• Never remove the SD card from the camera while the camera is
powered on.
Format the memory card
All data will be deleted including protected files. Be sure to download
important files to your computer before formatting.
1:Turn the power on, press the MENU button to display the menu, and then
press the RIGHT button to select [setup] .
2: Press the UP or DOWN button to select [Format..] then press the OK or
RIGHT button to launch the submenu.
3: Press the UP or DOWN button to select the item [YES] and then press
the OK button to erase all data.

ENGLISH
8
Setting the Language
When using the video camera for the first time after purchasing it, be sure
to choose a language before using the video camera.
1: Turn the power on, press the MENU button to display the menu, and
then press the RIGHT button to select [setup] .
2: Press the UP or DOWN button to select [Language] then press the OK
or RIGHT button to launch the submenu.
3: Press the UP or DOWN button to select the desired language and then
press the OK button to confirm the setting.
4: Press the MENU button to close the menu.

ENGLISH
9
Setting the date and time
1: Turn the power on, press the MENU button to
display the menu, and then press the RIGHT button
to select [setup] .
2: Press the UP or DOWN button to select
[Date&Time] then press the OK or RIGHT
button to launch the submenu.
3: Press the UP or DOWN button to change the highlighted value. Press
the LEFT or RIGHT button to move the cursor between settings.
4: Press the OK button to confirm the setting.
5: Press the MENU button to close the menu.

ENGLISH
10
Monitor screen display
A. When shooting movies

ENGLISH
11
B. When shooting still images

ENGLISH
12
C: When recording audio file
D. When playing back

ENGLISH
13
3.Using this video camera
Turning the Camera On and Off
1. Open the LCD panel.
2. To turn on the camera, press hold the POWER button, the LCD
screen turns on.
3. Press the POWER button again will turn the camera off.
To save battery power, the video camera automatically turns off after a
period of idle time. Press the POWER button to power the camera back on.
You can change the power-off time by setting the function [Power Save] in
the Setup menu.

ENGLISH
14
Change the mode
There are three record modes in this video camera.
1: Press the POWER button to turn on the camera, and the camera get into
the default video mode.
2: Press the MODE button to change the record mode. Each time the
MODE button is pressed the mode icon is changed.
• If you want to preview the record files you can press the PLAYBACK
button to set the video camera to playback mode .
• When the video camera is in playback mode you must press the
PLAYBACK button to change it to record mode first before you can
use the MODE button to change mode.
Display Title Description
Capture mode For taking still photos.
Video mode For recording movie clips.
Audio mode For recording audio files.

ENGLISH
15
Recording video clip
1: Turn the video camera on and its default mode is video record mode.
2: Press the SHUTTER button to start recording. Press the UP button to
pause and press it again to continue.
3: Press the SHUTTER button again to end the recording. If the memory is
full the video camera will stop recording automatically.
• The LCD monitor displays the recorded time.
•When light is insufficient press the RIGHT/ LED ON or OFF button
to turn on the compensating lamp and when light is enough press
the LED ON/OFF button to turn off the compensating lamp .

ENGLISH
16
Taking still images
1. Turn on the video camera.
2. Press the MODE button to set the video camera to capture mode, the
icon appears on the LCD screen.
3. Use the LCD screen to frame your subject.
4. Hold the video camera steady and then press the SHUTTER button
completely down to take a picture.
• The number displayed on the screen is automatically decreased by
one. For example, if the screen displays 018 when the camera is
power on , after one photo has been captured, 017 will appear. If
the memory is full, “Memory Full” will appear on screen.
• When light is insufficient press the RIGHT/ LED ON or OFF button
to turn on the compensating lamp and when light is enough press
the RIGHT/ LED ON or OFF button to turn off the compensating
lamp .
• Make sure your fingers do not cover the lens.
• Do not take the memory card or battery out when the video camera
is saving the image, otherwise the image will not be saved
completely.

ENGLISH
17
Using the Self-timer and Burst snapshot
Use the self-timer to set a delay from the time the shutter button is pressed
to the time the image is shot. Use the burst snapshot to take pictures
continuously.
1: Turn the power on, and set the video camera to the Capture mode.
2: Press the LEFT button to change the self-timer mode: each time the
LEFT button is pressed the icon on the top left corner is changed.
Off: Take photos without delay.
2 seconds: The shutter release will delay for 2 seconds.
10 Seconds: The shutter release will delay for 10 seconds.
Burst snapshot: Press the SHUTTER button once to take three
pictures continuously
3: Press the SHUTTER button to take picture.
•You can also set the self-timer and burst snapshot by the capture
menu. See the details on page 20.

ENGLISH
18
Using the Zoom Function
This video camera has a digital zoom function that allows you to zoom in or
zoom out on subjects. The digital zoom enlarges or shrinks the image using
a software process.
1: Turn the video camera on and set it to capture mode or video record
mode.
2: Press the Wor T button to compose the image.
W: zoom out for a wide-angle shot.
T : zoom in for a telephoto shot.
• When the zoom button is pressed, the value of magnification
appears on the LCD monitor.

ENGLISH
19
Recording audio
1: Turn the video camera on and set it to audio record mode.
2: Press the SHUTTER button to start recording. Press the UP button to
pause and press it again to continue.
3: Press the SHUTTER again to end the recording. If the memory is full the
video camera will stop recording automatically.
• On the center of the LCD monitor displays the recorded time.
• There is no menu in audio record mode.
