We congratulate you on the choice of the Remote Antenna Matrix AM-01/6 system
with which it is possible to remote up to 6 antennas with a single coaxial cable.
No other cable is needed because, in addition to the RF, also DC power and data
commands are sent by the cable.
The remote Matrix is controlled by the Control Box AMB-02 directly connected to
the amplifier, no further specific software settings are required in addition to the
one already present.
With a particular version of the Remote Antenna Matrix AM-01/6 system it is also
possible to automatically manage operations in SO2R.
The system is designed for Expert 1.3K-FA, Expert 1.5K-FA, Expert 2K-FA
amplifiers and Combiner CO1-2.
In particular, for the Expert 1.3K-FA and Expert 1.5K-FA the AM-01/6 is able to
bring the antennas managed from 4 to 6.
IMPORTANT
Before installing and using the system, we recommend that you carefully read the
instructions contained in this manual.
Failure to comply with these instructions results in voiding the warranty.
Keep the manual, it contains important information regarding the safety and
correct use of your AM-01/6
The manual may be subject to changes, we recommend that you periodically
consult our website www.linear-amplifier.com .
The English version is to be considered the official one.
The Remote Antenna Matrix AM-01/6 is essentially passive and therefore does not
require FCC certification (where required) for amateur radio use.
CAUTIONS
WARNING!
DO NOT disconnect, swap, replace coaxial cables during transmission, there is a
danger of electric shock or burns.
WARNING!
Before powering on AM-01/6 and AMB-02 check the correctness of the power
supply value.

USER MANUAL
AM-01/6
INDICE Pag. 4 di 14
Unpacking
Remove the packaging and carefully check the contents.
If you find any damage, or if there are any parts missing, contact your distributor/dealer
immediately.
Accessories included in the carton
•AM-01/6-SO2R or AM-01/6-PW as ordered.
•AMB-02 Control Box.
•N° 1 PORT connection cable between AMB-02 and Expert amplifiers or
Combiner.
•N° 1 power cable for AMB-02.

USER MANUAL
AM-01/6
INDICE Pag. 5 di 14
Equipment description and use
The system consists of two types of remote Matrixes with different characteristics, each
of which must be used in conjunction with the AMB-02 Control Box.
Each matrix is built in stainless steel sheet capable of resisting snow and any type of
driving rain.
It is equipped with a bracket which enables a solid anchorage to a wall or pole.
AM-01/6-SO2R
Able to manage up to 6 antennas even in the case of Expert 1.3K-FA / Expert 1.5K-FA.
Maximum power up to 2KW.
In the case of SO2R operations. a two color LED is associated with each antenna
connector:
•Red means that the selected antenna is RTX for the band in use.
•Green means that the selected antenna is currently only RX in the other band.
For a more in-depth knowledge of SO2R, refer to the amplifier manual.
This Matrix can also be used not in SO2R operations by eliminating or ignoring
the SO2R / SO2R coaxial cable (see the following system diagram).
In this case, only the red color of the LED will be active automatically.

USER MANUAL
AM-01/6
INDICE Pag. 6 di 14
Typical connection:
In case of SO2R use, press [SET], then set “SO2R MATRIX” in the Config menu.

USER MANUAL
AM-01/6
INDICE Pag. 7 di 14
In case of no SO2R operation, even without removing the SO2R / SO2R coaxial cable,
press [SET] then set “REMOTE ANT SWITCH” in the Config menu.
In both cases the antenna settings remain those previously established in the Antenna
menu, as an example:
The examples refer to the BANK A, each setting is of course also possible with the
BANK B.
Attention: The Matrix was designed for 6 antennas because 6 are contest HF bands.
This guarantees the passage between band and band with maximum speed.
If multi-band antennas are used, WARC and 6m bands can also be set.
For the 6 m band, where a preamplifier and a probable sequencer are often used, since
a rapid passage with the HF bands is not required, it is advisable, but not mandatory, to
have a separate cable and not to pass through the Matrix.
In this case when it is necessary to operate in 50 MHz, returning to the
conventional setting, the same ANT output is maintained.

USER MANUAL
AM-01/6
INDICE Pag. 8 di 14
AM-01/6- PW
Maximum power up to 4KW.
Able to manage up to 6 antennas even in the case of Expert 1.3K-FA / Expert 1.5K-FA.
A red LED is associated with each antenna connector which, when lit, indicates the
selected antenna.
This Matrix, given the high power it can handle, has been specifically designed for use
in conjunction with our Combiner CO1-2.
It can also be used as a simple antenna switch by setting “Remote Ant Switch” in the
Config menu.
It can also be used with non-SPE systems by manually setting the antenna as
described later in this manual.

USER MANUAL
AM-01/6
INDICE Pag. 9 di 14
Typical connection:
The figure refers to use as a simple switch, in conjunction with the Combiner CO1-2 it is
sufficient to replace the amplifier in the figure with the Combiner (see its manual on
page 17).
Press [SET], then set “COMBINER” in the Config menu.

USER MANUAL
AM-01/6
INDICE Pag. 10 di 14
AMB-02
As highlighted in the previous system diagrams, the AMB-02 control box is usually
placed close to the amplifier to which it is connected with a coaxial cable always to
antenna 1 or to the single output connector of the Combiner.
The coaxial cable that reaches the Matrix and therefore the antennas must be
connected to the opposite connector.
There are six LEDs on the panel, each representing the condition of the corresponding
antenna.
In the case of AM-01-SO2R:
•Red LED means that the selected antenna is RTX for the band in use.
•Green LED means that the selected antenna is RX only.
•LED off means that the antenna is not selected.
In the case of AM-01-PW:
•Red LED means that the selected antenna is RTX for the band in use.
•LED off means that the antenna is not selected.

USER MANUAL
AM-01/6
INDICE Pag. 11 di 14
The AMB-02 Control box is powered by an external source of 13.8 VDC nominal (15.5
VDC max), you can use the supplied cable connected to the transceiver Power Supply.
At the top of the panel there is the "Ready" LED with the following meanings:
•Green LED means correct presence of 13.8 VDC.
•Red LED means anomalous absorption of 13.8 VDC.
The PORT connector must be connected via the supplied cable to the corresponding
PORT of the Expert amplifier or to the PORT OUT of the Combiner.
If a longer cable is required, build a new one according to the following diagram.
Note: with this cable, in the case of the Expert amplifier off, the Matrix automatically
activates the ANT1 in accordance with the Expert manual.
PORT Connector
Note: IC 1 and IC2 must be connected only as described in the supplied cable or in the
cable in case of manual control.

USER MANUAL
AM-01/6
INDICE Pag. 12 di 14
Case of manual control
The AM-01/6-PW system can also be controlled either manually or through a non-SPE
interface to be connected to the PORT connector.
Typical connection:
Use open collector transistors or relay contacts
where:
Bit = 0 Transistor ON or closed relay contacts
Bit = 1 Transistor OFF or open relay contacts
The antenna selection is made with the following code:
Antenna Bit C Bit B Bit A
n.1 0 0 1
n.2 0 1 0
n.3 0 1 1
n.4 1 0 0
n.5 1 0 1
n.6 1 1 0
The code is transmitted for as long as the setting remains.
