Spectare Sp 02091 User manual

Mass Storage: Computer USB Connection Mass Storage: Computer USB Connection

To connect to your Windows PC or

Mac Computer

Turn on the camera

Press the

MODE

button then select the

and Choose the PC icon with the

WT

buttons

select Mass Storage with the





buttons

Connect the small end of the USB cable

to the USB port on the side panel of the

device.

Connect the larger end of the USB cable

to a free USB port on the computer.

On the First Screen choose the

connection type as COMPUTER

CONNECTION with the arrow keys on

the back panel:

:makes the selection

SET :Confirms the Selection

Upon first connection the hardware

device will be detected under Windows

XP , Vista and Mac OS-X. The

hardware drivers will automatically

install. Click OK on the hardware wizard

installation screens

Apartition entitled "removable disc" will

automatically be mounted under the "My

Computer" Window. This partition will

give access to the Memory card that is

placed in the camera.

Double click the removable disk icons

to access, copy and manage the files

in on your camera.

To Disconnect from the Computer.

On Windows click this icon on the bottom

task bar labeled "Safely Remove

Hardware."

Adialog box will appear "Safely Remove

Hardware."

Select USB Mass Storage Device and click

"STOP."

On the next dialog box click OK to remove

the storage device.

On the final dialog box select "CLOSE" and

disconnect the device from the computer.

Afinal message should appear under

Windows that says “Safe to Remove

Hardware" afterwhich you can remove the

USB cable from the device.

Once the player / recorder has been

disconnected from the computer it will

return to normal operation

System Requirements

operating system Microsoft windows

98SE/Me/2000/XP/Vista

CPU Intel Pentium 166MHZ

or higher

Memory More than 128MB

CD-ROM at least 4X speed

Disk More than 100MB free

space

Connection USB1.1 or USB2.0

To Connect to Television

Using the suppliedAV connector insert the

small end of the cable into the side panel of

the device.

Connect the Yellow (video) and White

(Audio) connections on the other end of the

cable to the Video andAudio input

connection on the back of your television or

VCR unit.

Turn on the power to the camera by

pressing the

POWER button or opening

the LCD Panel.

On the First Screen choose the connection

type as TV OUTPUT with the arrow keys

on the back panel:

 :Makes the selection

SET :Confirms the Selection

Turn on your TV and switch the input mode

until you get an image. Refer to your

television owners manual for guidance on

setting the input to your

NOTE: If you do not have RCAconnections

on your TV you will need to purchase an

adapter at your local electronics store.

Once connected to your TV use the

controls on your device to access features

normally. Go to the PLAYBACK mode on

your camera to view the photos and

movies.

To connect to your Windows PC as a

Web Camera

Turn on the camera

Press the

MODE

button then select the

and Choose the PC MODE icon with

the

WT

buttons

press

SET

to confirm

select PC CAMERA with the





buttons

Connect the small end of the USB cable

to the USB port on the side panel of the

device.

Connect the larger end of the USB cable

to a free USB port on the computer.

On the First Screen choose the

connection type as COMPUTER

CONNECTION with the arrow keys on

the back panel:

:makes the selection

SET :Confirms the Selection

The Camera will be automatically

connected under Windows XP and

Vista. go to the MYCOMPUTER

Window to access the web cam under

the icons entitles “Coach Video camera”

and “Coach Digital Camera”.

Choose the connection type:

AC POWER

COMPUTER CONNECTION

TV OUTPUT

HEADPHONES

use the  buttons to select

press SET to confirm

Choose the connection type:

AC POWER

COMPUTER CONNECTION

TV OUTPUT

HEADPHONES

use the  buttons to select

press 

SET

to confirm

This device complies with part 15 of the FCC rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference and (2) this device must accept

any interference received, including interference that may cause undesired operation.

Technical Specifications

Troubleshooting

The SD card is loaded，but the camera does not capture or record

Check if the SD card is locked

Check if the SD card has enough space for storage

The camera turns off automatically

Check the battery level and charge the battery if necessary.

Check the power off settings on the camera and change to a longer time as needed (see page 13).

Image is not recorded when the shutter button is pressed

Check if the camera is set to the capture mode

Check if the flash mode is set toAuto, Force or Red-eye reduction. If the flash unit is turned on it

will take a longer amount of time to take photos since the flash needs to be charged each time

The color of the photo taken is abnormal

Reset the White Balance in the camera menu.

The image is too bright or too dark

Reset the EV value

The flash does not go off

Check if the flash mode is set to “Auto”, “Force”, “Red-eye reduction”

The date displayed is not correct

Reset the date and time in Setup mode

Can not print the photos

Check if the camera is set to Print mode. If not, reset the camera to Print mode and then connect

the camera to the printer with the USB cable

For support, updates and answers that can not be answered by this

user manual please go to: http://spectareproducts.com/support

MADE IN CHINA

LENS：f=6.4mm

SENSOR：5.1 Mega Pixels CMOS Sensor

LCD: 2.4 inch LTPS LCD Display

Aperture：F/2.8

Sensitization：Auto

White Balance：Auto，Sunny，Cloudy, Tungsten，Fluorescent

Shutter Speed：1/10Sec－1/2650Sec

Memory：32MB built in memory 　or SD card or MMC card

Maximum 4GB

Resolution：1024x768, 2048x1536, 2592x1944, 3264x2448,

4000x3000

Digital Zoom：1～8×Digital Zoom

Normal Distance：1m～∞

Self-timer：10sec Self-timer，20 sec Self-timer

Flash Mode：Off/Auto/Red-eye reduction /Force

TV-Out：NTSC/PAL

USB: USB1.1 or above

POWER：Li-Battery

Appearance Size：111x62x22.5mm

Weight：122G（without battery and SD card）

Game Mode

Remote Control

PC Web Camera

Connecting to a Printer

Connecting to a TV

e-Book Mode

Capture Mode

Installing the Software Drivers

RESTART

COMPUTER

then

Product Description:

What’s Included:

Product Description:

TOP

FRONT

SIDE

BOTTOM

BACK

Video Mode

Installing the Software Tools

Playback Mode

Audio Record Mode

Music Mode

Entering CAPTURE Mode:

Flip out the LCD panel or press the

POWER

button to enter CAPTURE

mode(Default mode)

Taking Photos:

press the

>SHUTTER

button take the image

Changing Capture Settings:

Press the

MENU

button

Then use the

WT

buttons to Choose the following Settings

White Balance,

EV,

Color Effect,

Quality

Press the

SET

button to confirm the selection.

Press the

MENU

button to return to CAPTURE mode

CAPTURE Controls:

Press the

WT

buttons to ZOOM in and out

Press the



button to change the Frame setting

(Single frame shooting, burst shooting, 10 sec self timer, 20 second self timer)

Press the



buttons to Change the Flash setting.

(On, Off,Auto, Red-eye reduction)

` Press the

SET

button on the side panel to select photo frame border.

Brightness Control:Press the

MODE

button and then use the

T

buttons to select the ;EV icon; then use the



sbuttons to make the photo darker or

lighter

Entering VIDEO Mode:

Press the

MODE

button to chooseAVI icon, then press the

SET

button

to enter VIDEO mode.

Taking Video:

press the

>SHUTTER

button start the Video recording,ARed Dot will appear

when the camera is recording.

press the

>SHUTTER

button again to stop the recording

Changing VIDEO Settings:

Press the

MENU

button

Then use the

WT

buttons to Choose the following Settings

Resolution,

Frame/Sec,

White Balance,

EV,

Color Effect

Audio

Press the

SET

button to confirm the selection.

Press the

MENU

button to return to VIDEO mode

VIDEO Controls:

Press the

WT

buttons to ZOOM in and out

Brightness Control: Press the

MODE

button and then use the

T

buttons to select the ;EV icon; then use the



sbuttons to make the photo

darker or lighter

Press the l LIGHT button to turn on or OFF the Fill light. This will enhance

Video under low light conditions

Entering SETUP Mode:

Press the

MODE

button to choose SETUP icon, then press the

SET

button to enter SETUP mode.

Changing the Settings:

Then use the

WT

buttons to Choose the following Settings

Animation,

Beep,

Frequency,

Default, Language,

Auto power off,

Date/Time,

Press the

SET

button to confirm the selection.

Press the

MENU

button to return

Entering MUSIC Mode:

Press the

MODE

button to choose MUSIC icon, then press the

SET

button to enter MUSIC mode.

NOTE: Standard .MP3 files should be copied to the memory card that is

inserted into the camera in order to be played by the camera. The camera

can not play .WMAor protected MP3 files-- See the following page details.

MUSIC Controls

Back Panel controls

Press the





buttons to select the song from the list

Press the

WT

buttons to adjust the volume during playback

Press the

SET

button to select a file for playback

Press the

MENU

button repeatedly to select the Repeat mode as:

RepeatALL > Repeat Once > Do not Repeat

Side Panel controls

Press the

/ II

button to Play or Pause the Music

Press the

>>>I

button to select to the next song; Press

SET

to confirm

Press the

I<< <

button to select to the previous song

Headphone connection

Open the USB connection cover on the Front panel of

the camera

Turn on the camera by opening the LCD panel

On the First Screen choose the

connection type as

HEADPHONES with the arrow

keys on the back panel:

 :Makes the selection

SET :Confirms the Selection

Music Mode

Copying and Playing MP3 Files:

To play music on your 9 in 1 Player you can simply copy the files directly onto a

memory card that is inserted into the player.

* Connect the camera to the computer using the USB cable as described on

page 20. The camera's memory or a memory card on the camera will mount

as a drive on your computer.

* Once it is connected you can copy files onto the player by simply dragging

and dropping them onto the window for the player. You may also use the

BlazeVideo Magic Software to covert and copy files for playback on your 9

in 1 Player

*After the files have been copied disconnect the camera from the computer.

* Turn on the camera and go to the Music Player from the main menu to

playback the files.

The 9 in 1 Player will play all "standard MP3 files" (non-rights protected music).

There are other music file formats that are available on other sites that will

not play such as .WMAand other formats. If you have music in a format

other than .MP3 you will need to convert it with the BlazeVideo Magic

Software. Please refer to the User Manual provided on the CD ROM for

instructions on converting file types

If you purchase Music from theApple iTunes

store it will not be recognized

sinceApple

will only allow their files to be played on iPods

. There are

also other sites that when you download it will set privacy restrictions that

will not allow it to play on some players or only on the computer you

download it on. There many sites that you can purchase and download

standard MP3 files that can be played directly on the 9 in 1 player. Make

certain you are downloading a “STANDARD.MP3” file that is not limited for

playback on your computer only or certain MP3 Players.

NOTE: Download and use 3rd party software and enter web sites at your

own risk. Spectare products is not responsible for any damage caused by

the use of software provided by other companies.

Entering MUSIC Mode:

Press the

MODE

button to choose E-BOOK icon, then press the

SET

button to enter E-BOOK mode.

Choosing the Text File

Then use the





buttons to choose the file you want to read that has

been copied to the memory card on your camera.

NOTE: .txt files should be copied to the memory card that is inserted into

the camera in order to be read by the camera-- See “Connection to

Computer for the procedures on copying files.

Press the

/ II

button to Read the file

Press the





to Page UP or Page DOWN on theText File

Press the

MENU

button to return back and choose another file

Entering MUSIC Mode:

Press the

MODE

button to choose GAME icon, then press the

SET

button to enter GAME mode.

Playing the games

Press the

SET

button to Start

Press the



button to Trasmute

Press the



button to speed up

Press the

WT

button to move

Press the

/ II

button to Pause / Start

Press the

MODE

button to return back to the Menu

EnteringAUDIO RECORD Mode:

Press the

MODE

button to choose WAV icon, then press the

SET

button to enterAUDIO RECORD mode.

Making aAudio Recording:

press the

>SHUTTER

button start the recording,ARed Dot will appear when

the camera is recording.

press the

>SHUTTER

button again to stop the recording

To Playback andAudio Recording:

Press the

START

button on the side panel to enter the Playback mode.

Use the

WT

buttons on the back panel or the

I<< <

>>>I

buttons on

the Side Panel to choose the File to play.

Use the

SET

button on the back panel or the

/ II

to play and pause

the audio recording.

On Screen Display: On Screen Display:

On Screen Display:

IMPORTANT: INSTALLTHE DRIVER

SOFTWARE BEFORE CONNECTING THE

CAMERAFOR THE FIRST TIME.

Insert the software CD into the

CD-ROM, and the CD will run

automatically. (If the CD does not run

automatically, double click

Bdvdarun.Exe in the CD root folder)

On the Main Menu screen of the CD click:

“Install Device Driver”

Follow the on Screen instructions to

install the drivers onto your computer

system

NOTE: You must agree to the License

Agreement and accept the terms to

continue the installation

Click “Finish” to complete installation

Restart your computer

After Restart connect the 9 in 1

Camera using the USB Cable provided

upon the first connection the Hardware

Wizard will automatically launch.

Follow the on Screen instructions to

install the drivers onto your system.

From the CD ROM main menu interface:

Click on “Install Photo Editing Tools” and

follow the on screen instructions. This

will install the BlazePhoto software that

will allow you to edit and organize your

photos.

Click on “Install Video PlayerTools” and

follow the on screen instructions. This

will install the BlazeVideo Media Player

software that will allow you playback

movies and other media on your

computer.

Click on “Install Media Converter” and follow

the on screen instructions. This will

install the BlazeVideo Magic software

that will allow you convert movies and

other media into specific formats.

These programs will be automatically

installed into your programs menu. To

use these programs click on the START

button and choose the desired

application

Please refer to the user manual that is

included on the CD ROM for instructions

on the use of these software applica-

tions or go to:

http://www.blazevideo.com/support.htm

for technical support on the software

① Power Capacity

② White Balance

③ Flash mode

④ Capture mode

⑤ Resolution

⑥ Image Quality

⑦ Counter(Recorded/Allowance)

Entering PLAYBACK Mode:

Press the

START

button on the side panel to enter Playback mode

Press the

I<< <

>>>I

WT

buttons to browse images you want. If the

file is movie or voice, press the

/ II

button to start the movie or

playback file, then press it again to stop

Changing PLAYBACK Settings:

press the

MENU

button

Then use the

WT

buttons to Choose the following Settings

Delete files,

Slideshow,

Crop,

Lock,

Start Screen,

Rotate,

PLAYBACK Controls:

Press the



button to enter Zoom mode,

When in ZOOM Mode Press the

WT

buttons to enlarge or minimize

the image and press





to Pan the Image

Press the



button for the thumbnail view

choose a file you want to play with the

WT

buttons

then press the

SET

button to select the Thumbnail to view

Press the

DISP

button To adjust volume or playback speed

then use the





buttons to adjust speed and volume

The camera can print photos directly by connecting it to a printer by

following these steps.

NOTE: The printer must have a standard USB connection in order

to be used for direct printing from a camera. Please refer to your

printer’s user manual for specific instructions on connecting a

camera to your printer.

Turn the camera on and enter Playback mode by pressing

the

START

button on the side panel,

Select a photo to be printed using the

WT

buttons

Press the

MENU

button and select the PRINT function from the

menu .

Connect the camera to the printer with a USB cable

Select YES on PRINTmenu of the camera and the file will be printed

directly on the printer

5M 0000/0021

AWB

①Power Capacity

②White Balance

③Video mode

④Resolution

⑤Recording time

① Power Capacity

② Allowance of record-

ing time

③ Audio mode icon

Start:Shutter

00:15:48

Setup Mode

5 6 7

Quick Start Guide Quick Start Guide

To begin using your Spectare 9 in 1

Media Player / Recorder follow these

simple instructions:

Turn the camera over to the

bottom and slide the battery

compartment open.

Insert the battery included in the

package into the slot on the

bottom.

NOTE: Please ensure the battery

contact are in this position before

inserting into the camera.

Insert the included SD Card into

the memory Slot.

NOTE: The camera will accept

any SD or MMC memory cards

up to 4GB

Open the USB Connection

cover on the Front Panel and

plug in the SMALLend of the

USB/AV cable into the

connection on the camera.

Plug in theACAdapter to a Wall

Outlet and then plug in the

LARGE end of the USB/AV

cable into bottom of theAC

Adapter

Open the Side Panel/Monitor

and the power should

automatically turn on or press

the

POWER button on the top.

On the First Screen choose the

connection type with the arrow

keys on the back panel:

 :Makes the selection

SET :Confirms the Selection

NOTE: For Charging the battery

and using the camera

underAC power select

and confirm theAC

POWER Choice.

Let the camera battery charge

for 24 hours before the

first use

For questions and support on this product that can not be solved

by your retailer please contact:

Spectare Products

6081 MeridianAve Suite 70-308

San Jose, CA95120

http://spectareproducts.com

[email protected]

The Spectare Logo and the Spectare brand are trademarked by SuMaWah LLC, San Jose, CA.

POWER

: Press and hold to turn on

Led Indicator

: Press and hold to turn on



: Upward Selection

Frame Setting in the Capture Mode

PAN in Viewing Mode

W

: Upward Selection

WIDE angle in Capture Mode

LAST photo in Viewing Mode

SET

: SET

Frame selector in Capture mode

RESET Image selector in Viewing mode

T

: Right Selection

Telephoto ZOOM in Capture mode

NEXT photo in Viewing mode



: Down Selection

Flash Setting in Capture mode

PAN in Viewing Mode

>SHUTTER

: Take the photo in Capture mode

MENU

: Choose the settings

MODE

: Change from Capture, Video, Music....

DISP

: Change the on screen display

Light for Video

: Fill Light for Video

Flash

: Flask for Still image Capture

USB / Power cover

:Access to USB / power connector

: UP Selection

selects the next upward selection

>>>I

: LEFT Selection

selects the file or media to the right or fast forward

I<< <

: RIGHT Selection

selects the file or media to the left or fast backward

: DOWN Selection

selects the next downward selection

SELECT

: Changes Modes

START

: Begins the Photo and Video Viewing mode

/ II

:Starts or pauses the playback of a Photo Slide show, movie or Music file

LIGHT

: Turns on/off the Video light in Video Mode

Battery Compartment:

:Slide open to reveal the battery and SD Card slot

Choose the connection type:

AC POWER

COMPUTER CONNECTION

TV OUTPUT

HEADPHONES

use the  buttons to select

press SET to confirm

Choose the connection type:

AC POWER

COMPUTER CONNECTION

TV OUTPUT

HEADPHONES

use the  buttons to select

press 

SET

to confirm

Choose the connection type:

AC POWER

COMPUTER CONNECTION

TV OUTPUT

HEADPHONES

use the  buttons to select

press 

SET

to confirm

CAPTURE

: Changes to the Capture mode

VIDEO

: Changes to the Video Mode

POWER

: Press and hold to turn on

PLAY

: Changes to Playback Mode

>REC /SHUTTER

: Take the photo in Capture mode /

Start and Stop the recording in Video Mode



: Upward Selection

Frame Setting in the Capture Mode | PAN in Viewing Mode

T

: Right Selection

Telephoto ZOOM in Capture mode| NEXT photo in Viewing mode

SET

: SET

Frame selector in Capture mode | RESET Image selector in Viewing mode



: Down Selection

Flash Setting in Capture mode | Thumbnail in Viewing Mode

W

: Upward Selection

WIDE angle in Capture Mode | LAST photo in Viewing Mode

Contact

Installing the Software Drivers ......

Game Mode ............................................................17Game Mode ............................................................17Game Mode ............................................................17Game Mode ............................................................17Game Mode ............................................................17Game Mode ............................................................17Game Mode ............................................................17

Contents

Important Notes ............................................................... 2

What’s Included ............................................................. 3

Product Description .......................................................... 4

Quick Start Guide ............................................................ 6

Installing the Software Drivers ......................................... 8

Installing the Software Tools ........................................... 9

Capture Mode ................................................................ 10

Video Mode .................................................................... 11

Audio Record Mode ....................................................... 12

Setup Mode ................................................................... 13

Music Mode ................................................................... 14

PlayBack Mode ............................................................. 16

e-Book Mode ................................................................. 17

Game Mode ................................................................... 17

Connecting to a TV ....................................................... 18

Remote Control ............................................................. 19

Connecting to a Printer ................................................... 19

Mass Storage: USB Connection ..................................... 20

PC Web Cam ................................................................. 22

Troubleshooting .............................................................. 23

Technical Specifications ................................................. 24

www.spectareproducts.com

Warranty

Please contact the original retail location where this product was

purchased to obtain warranty information and service.

User Guide

Model: SP 02091

9 in 1 Media

Player / Recorder

The following items should be included:

Please contact your retailer if you have not received any of these items

Discarded electric appliances are recyclable and should not be discarded n

domestic waste. Please actively support us in conserving resources and

protecting the environment by returning this appliance to the collection

centers (if available).

Battery Disposal: Do not incinerate, disassemble or short circuit the battery.

Do not expose the battery to temperatures above

113oFahrenheit.

Please observe the local regulations regarding the

disposal of exhausted batteries and old equipment.

Thank you for purchasing the Spectare 9 in 1 Media Player / Recorder. Please

take some time to read through and follow these important safety and

operation instructions.

WARNING:TO REDUCE THE RISK OF FIRE OR SHOCK HAZARD, DO NOT

EXPOSE THIS PRODUCTTO RAIN OR MOISTURE.

CAUTION: RISK OF ELECTRIC SHOCK. DO NOT DISASSEMBLE THIS UNIT.

TO PREVENTTHE RISK OF ELECTRIC SHOCK, DO NOTREMOVE

COVER. NO USER- SERVICEABLE PARTS INSIDE. REFER

SERVICING TO QUALIFIED PERSONNEL.

VENTILATION - The device should be situated so that its location or position does

not interfere with its proper ventilation. For example, the unit should

not be situated on a bed, sofa, rug or similar surface that may block

the ventilation openings.

HEAT - The device should be situated away from sources of high heat such as

radiators or stoves.

POWER SOURCE - The device should be connected to a power supply only of

the type described in the technical specification of this user guide.

CLEANING - The device should be cleaned gently using a soft cloth dampened

with water. Do not clean the inside of the unit.

NON USE PERIOD - The power cord for the device should be unplugged from the

outlet when the unit is left unused for a long period of time.

AVOIDING SURGES- For added protection during a lightning storm, unplug the

device from wall outlets to prevent damage to the product due to

power line surges.

OVERLOADING - Do not overload wall outlets or extension cords, as this may

result in fire or electrical shock

SERVICING - The user should not attempt to service the device beyond those

means described in the operating instructions. All other servicing

should be referred to qualified service personnel.

Remote control

Camera/ Player

Soft Case

Ear Phones 1 GB SD memory Card

USBAudio / Headphone adapter

CD ROM Installer

for driver and

software applications

USB/ ACAdapter Strap

TV Connection

user's guide22 Spectare 9 in 1 Media Player / Recorder

user's guide20 Spectare 9 in 1 Media Player / Recorder

user's guide18 Spectare 9 in 1 Media Player / Recorder

user's guide16 Spectare 9 in 1 Media Player / Recorder

user's guide

14 Spectare 9 in 1 Media Player / Recorder

user's guide

12 Spectare 9 in 1 Media Player / Recorder

user's guide6Spectare 9 in 1 Media Player / Recorder

user's guide8Spectare 9 in 1 Media Player / Recorder

user's guide10 Spectare 9 in 1 Media Player / Recorder

user's guide4Spectare 9 in 1 Media Player / Recorder

user's guide2Spectare 9 in 1 Media Player / Recorder

user's guideSpectare 9 in 1 Media Player / Recorder

user's guide24 Spectare 9 in 1 Media Player / Recorder

Mass Storage: Computer USB Connection Mass Storage: Computer USB Connection

To connect to your Windows PC or

Mac Computer

Turn on the camera

Press the

MODE

button then select the

and Choose the PC icon with the

WT

buttons

select Mass Storage with the





buttons

Connect the small end of the USB cable

to the USB port on the side panel of the

device.

Connect the larger end of the USB cable

to a free USB port on the computer.

On the First Screen choose the

connection type as COMPUTER

CONNECTION with the arrow keys on

the back panel:

:makes the selection

SET :Confirms the Selection

Upon first connection the hardware

device will be detected under Windows

XP , Vista and Mac OS-X. The

hardware drivers will automatically

install. Click OK on the hardware wizard

installation screens

Apartition entitled "removable disc" will

automatically be mounted under the "My

Computer" Window. This partition will

give access to the Memory card that is

placed in the camera.

Double click the removable disk icons

to access, copy and manage the files

in on your camera.

To Disconnect from the Computer.

On Windows click this icon on the bottom

task bar labeled "Safely Remove

Hardware."

Adialog box will appear "Safely Remove

Hardware."

Select USB Mass Storage Device and click

"STOP."

On the next dialog box click OK to remove

the storage device.

On the final dialog box select "CLOSE" and

disconnect the device from the computer.

Afinal message should appear under

Windows that says “Safe to Remove

Hardware" afterwhich you can remove the

USB cable from the device.

Once the player / recorder has been

disconnected from the computer it will

return to normal operation

System Requirements

operating system Microsoft windows

98SE/Me/2000/XP/Vista

CPU Intel Pentium 166MHZ

or higher

Memory More than 128MB

CD-ROM at least 4X speed

Disk More than 100MB free

space

Connection USB1.1 or USB2.0

To Connect to Television

Using the suppliedAV connector insert the

small end of the cable into the side panel of

the device.

Connect the Yellow (video) and White

(Audio) connections on the other end of the

cable to the Video andAudio input

connection on the back of your television or

VCR unit.

Turn on the power to the camera by

pressing the

POWER button or opening

the LCD Panel.

On the First Screen choose the connection

type as TV OUTPUT with the arrow keys

on the back panel:

 :Makes the selection

SET :Confirms the Selection

Turn on your TV and switch the input mode

until you get an image. Refer to your

television owners manual for guidance on

setting the input to your

NOTE: If you do not have RCAconnections

on your TV you will need to purchase an

adapter at your local electronics store.

Once connected to your TV use the

controls on your device to access features

normally. Go to the PLAYBACK mode on

your camera to view the photos and

movies.

To connect to your Windows PC as a

Web Camera

Turn on the camera

Press the

MODE

button then select the

and Choose the PC MODE icon with

the

WT

buttons

press

SET

to confirm

select PC CAMERA with the





buttons

Connect the small end of the USB cable

to the USB port on the side panel of the

device.

Connect the larger end of the USB cable

to a free USB port on the computer.

On the First Screen choose the

connection type as COMPUTER

CONNECTION with the arrow keys on

the back panel:

:makes the selection

SET :Confirms the Selection

The Camera will be automatically

connected under Windows XP and

Vista. go to the MY COMPUTER
