Foot-Candle Meter
PRODUCT MANUAL
Item # 3413F

2
Thank you for purchasing a Field ScoutTM 3413F Foot-Candle
Meter. This manual describes the features and operation of
the meter.
Using the Meter
1. Turn the dial clockwise to the “ON” position.
2. Hold the meter vertical for accurate readings.
3. Turn the meter off after use to conserve battery power.
Changing the Battery
The Field Scout Light Meters use a standard 9V battery. To
change the battery:
1. Remove the two screws on the back of the meter.
2. Lift the back from the bottom of the meter.
3. Remove the old battery from the connector, and snap the
new battery in its place. Set the battery into the front half
of the case.
4. Connect the front and back of the case at the top (by the
sensor).
5. Close the case and tighten the two screws.
Accuracy
The Field Scout Light Meters are accurate to ±5%. Cosine
correction is accurate to ±3% at 45°, and ±7% at 80°.
For customer support, or to place an order,
call Spectrum Technologies, Inc. at
[phone] or [phone]
between 7:30 am and 5:00 p.m. CST
FAX [phone]
e-mail: [email protected].
www.specmeters.com
Spectrum Technologies, Inc
12360 S. Industrial Dr. East
Plainfield, IL 60585

3
Foot-Candle meters measure light intensity as perceived by
the human eye. The eye perceives light of approximately 560
nm most strongly, with perception half that at 500 and 600
nm.
The meters display values in the range 0-1999. This must be
multiplied by 10 to obtain Foot-Candles, so the meter range is
0-19990 Foot-Candles. Since 1 Foot-Candle is equivalent to
approximately 10.8 lux, multiplying the meter reading by 108
will compute lux.

Warr anty
This product is warranted to be free from defects in material or
workmanship for one year from the date of purchase. During the
warranty period Spectrum will, at its option, either repair or replace
products that prove to be defective. This warranty does not cover
damage due to improper installation or use, lightning, negligence,
accident, or unauthorized modifications, or to incidental or conse-
quential damages beyond the Spectrum product. Before returning
a failed unit, you must obtain a Returned Materials Authorization
(RMA) from Spectrum. Spectrum is not responsible for any pack-
age that is returned without a valid RMA number or for the loss of
the package by any shipping company.
12360 S. Industrial Dr. E
Plainfield IL 60585
[phone] or [phone]
Fax [phone]
E-Mail: [email protected]
www.specmeters.com
This equipment has been manufactured for
Spectrum Technologies, Inc.
12360 S. Industrial Dr. East
Plainfield, IL 60585 USA
The Manufacturer’s DECLARATION OF CONFORMITY is on file at the above
address, and certifies conformity to the following:
Model Number: 3413F
Description: Foot Candle Meter
Type: Electrical Equipment for Measurement, Control, and Laboratory Use
Directive: 2004/108/EC
Standards: EN 61326-1 (2006)
CISPR11
EN 61000-4-2 (1995/A1:1998/A2:2001)
EN 61000-4-3 (2006)
