SperryMarine 5016-CA User manual

Northrop Grumman Sperry Marine B.V. (Representative Office)
Woltmanstr. 19 • D-20097 • Hamburg, Germany
Tel.: [phone] • Fax: [phone] • E-mail: [e-mail]
Operation, Installation and Service Manual
Original Documentation / Keep for Future Reference
Analogue Compass Repeaters
Types 5016-CA, 5016-CB, 5016-CC, 5016-CD
with RS-422 Serial Interface
056376/A; 05016-0128-02, 03 Feb 2015

056376/A Analogue Compass Repeaters
© 2015 Northrop Grumman Sperry Marine B.V.
This document and the information herein is the intellectual property of Northrop Grumman
Sperry Marine B.V. [NGSM BV] and it’s associate companies and may not be copied, reproduced
or translated without the express permission of NGSM BV.
Specifications were correct at time of press but may be varied in accordance with NGSM BV’s
policy of continuous product development.
Any technical content should be verified with NGSM BV.
Sperry Marine, with major engineering and support offices in New Malden, England, and
Hamburg, Germany, is part of the Northrop Grumman Navigation & Maritime Systems Division
N&MSD.
Rev. Date Remarks
A 03 Feb 2015 Initial release; this manual applies for the analogue compass repeaters
types 5015-CA, -CB, -CC and -CD.
Manual 056359 remains valid for the now discontinued types
5016, 5016-AA, -AB and -AC.

Analogue Compass Repeaters 056376/A
iii
Contents
Safet Instructions
Safet Notice Conventions ....................................................................... vii
General Safet Information for the Operator ........................................ viii
General Safet Information for Service Personnel ................................... x
Chapter 1: Introduction
1.1 S stem Description................................................................................... 1-1
Intended Use ............................................................................................. 1-1
Not Intended Use ...................................................................................... 1-1
1.2 Design and Main Features........................................................................ 1-2
1.3 Functional Description.............................................................................. 1-3
1.4 Compass Repeater T pe Variants ............................................................ 1-4
Bearing Repeater....................................................................................... 1-4
Steering Repeater...................................................................................... 1-4
Magnetic Heading Repeater ..................................................................... 1-4
Bulkhead Repeater .................................................................................... 1-5
1.5 Accessories ................................................................................................ 1-5
Bearing Repeater Stand and Brackets ..................................................... 1-5
Bulkhead Repeater Bracket....................................................................... 1-5
Connection Box ......................................................................................... 1-6
Azimuth Device PV 23 ............................................................................... 1-6
Telescopic Alidade..................................................................................... 1-6
1.6 Technical Data............................................................................................ 1-7
1.7 Declaration of Conformit ...................................................................... 1-15
Chapter 2: Operation
2.1 Readout Elements, Indicators and Controls ........................................... 2-1
2.2 Powering up the Repeaters ...................................................................... 2-2
2.3 Data Protocol and Source Detection ....................................................... 2-2
2.4 Reading off Heading and Source Indication ........................................... 2-3
2.5 Adjusting the Illumination Brightness .................................................... 2-4
2.6 S nchronizing the Compass Cards.......................................................... 2-5
2.7 Initiating the Self Test............................................................................... 2-5
2.8 Bearing Repeater Capacitive Ke s ........................................................... 2-5
2.9 Taking Bearings with the Azimuth Device PV 23 ................................... 2-6
Chapter 3: Error Indication
3.1 Error Blink Codes....................................................................................... 3-1
Heading Timeout with flashing Source Indicator................................... 3-2

056376/A Analogue Compass Repeaters
iv
Chapter 4: Preventive Maintenance
4.1 Maintenance b Shipboard Personnel .................................................... 4-1
Maintenance of externally installed Bearing Repeater .......................... 4-2
Chapter 5: Installation
5.1 Bearing Repeater ....................................................................................... 5-1
Installing Bearing Repeater with Bearing Stand..................................... 5-1
Installing Bearing Repeater with Bearing Bracket .................................. 5-4
Installing Bearing Repeater with Adjustable Bearing Bracket ............... 5-6
5.2 Steering Repeater / Magnetic Heading Repeater .................................. 5-8
5.3 Bulkhead Repeater .................................................................................. 5-10
Chapter 6: Configuration
6.1 Using the Default Configuration .............................................................. 6-1
6.2 Configuring the Analogue Repeater with SUSI...................................... 6-1
6.3 Configuration Parameters ........................................................................ 6-6
RCS Type .................................................................................................... 6-7
Protocol Type ............................................................................................. 6-8
Baudrate ..................................................................................................... 6-8
Gyro Selection ........................................................................................... 6-9
Magnetic Selection.................................................................................... 6-9
Status Selection....................................................................................... 6-10
Dimming Selection.................................................................................. 6-10
Dimming Group ID .................................................................................. 6-10
Dimming Offset ....................................................................................... 6-11
6.4 Dimming Values ...................................................................................... 6-12
Adjusting Dimming Values ..................................................................... 6-12
Serial Dimming Command Evaluation .................................................. 6-13
Chapter 7: Troubleshooting
7.1 Basic Service Checks ................................................................................ 7-1
All repeater types 5016-CA, -CB, -CC, -CD ............................................... 7-1
All repeaters, except bearing repeater, type 5016-CA ............................ 7-2
7.2 Viewing Error Information in SUSI .......................................................... 7-3
Analogue Repeater Error Page ................................................................. 7-3
Error IDs and Descriptions........................................................................ 7-4
7.3 Location of Parts on the Analogue Repeater PCB.................................. 7-6
Terminal Boards and Connectors............................................................. 7-7
Diagnostic LEDs......................................................................................... 7-7
Chapter 8: Corrective Maintenance
8.1 Updating the Repeater’s Firmware.......................................................... 8-1
Update Procedure...................................................................................... 8-2

Analogue Compass Repeaters 056376/A
v
Abbreviations
Appendix
A Setup and Configuration Tables
B Drawings

056376/A Analogue Compass Repeaters
vi

Analogue Compass Repeaters 056376/A
vii
Safet Instructions
Safet Notice Conventions
The following safety notice conventions are followed throughout this
manual:
DANGER
A Danger notice contains an operating or main-
tenance procedure, practice, condition, state-
ment, etc., which, if not strictly observed, will
result in injur or death of personnel.
WARNING
A Warning notice contains an operating or
maintenance procedure, practice, condition,
statement, etc., which, if not strictly observed,
could result in injur or death of personnel.
CAUTION
A Caution notice contains an operating or main-
tenance procedure, practice, condition, state-
ment, etc., which, if not strictly observed, could
result in damage to, or destruction of equip-
ment.
Note
A Note contains an essential operating or main-
tenance procedure, condition or statement,
which is considered important enough to be
highlighted.
Special safety symbols may be used in this
manual to indicate:
DANGER
Danger: Risk of electrical shock.
CAUTION
Caution: Components are sensitive to electro-
static discharge.

056376/A Analogue Compass Repeaters
viii
General Safet Information for the Operator
WARNING
Risk of Deviation
Never rel on the heading indication of an analogue compass repeater
alone to navigate a vessel or to perform other safet -critical operations.
The analogue repeater is an indicator onl and will indicate ship’s head-
ing as long as it receives formall valid data. It does not appl an filter-
ing or plausibilit checks of the incoming data.
Loss of data suppl will result in a visual error indication but will not
raise an audible alarm.
Alwa s confirm the plausibilit of the heading indication at the repeater
against the respective source which generates the heading data.
In safet -critical operations, regularl check the data source and the
repeater’s indication against all available aids to navigation.
WARNING
Risk of using magnetic heading data for steering
The magnetic heading repeater is equipped with a removable cover, hid-
ing the compass card when navigating the vessel under normal use, as
the magnetic heading repeater is onl classified for steering purposes in
case of emergenc with other heading sources not available.
Never remove the cover from the magnetic heading repeater when nav-
igating the vessel under normal use, to avoid steering the vessel mistak-
enl b magnetic compass heading.
WARNING
Risk of using invalid heading data
The heading indication at the repeater is onl valid if the error indicator
is off and exactl one of the source indicators is permanentl lit.
In case the error indicator in on and one or all of the source indicators
are flashing the heading indication of the repeater must be considered
as invalid and the heading data must not be used for steering the vessel.
WARNING
Risk of injur
Permanent e e damage ma result, when looking directl at the sun or
at its reflection in the black azimuth mirror when using the azimuth
device PV 23.
The PV 23 is not suited for taking the azimuth of the sun itself, as the
anti-glare filters do not sufficientl block out direct sunlight.
Never look directl at the sun or at its reflection in the black azimuth mir-
ror when using the azimuth device PV 23.
WARNING
Risk of freeze
The bearing repeater 5016-CA is equipped with capacitive ke s, sensi-
tivel reacting to the fingers skin resistance which will not function
when touched with gloves.
In case of minus temperatures alwa s be extremel careful not to touch
the metal housing of the bearing repeater to avoid freeze of hands and
fingers.
Note
The capacitive keys of the bearing repeater 5016-CA are sensitive against
surface water, e.g. remaining rain drops, which may result in random
changing of the illumination brightness.
This effect does not have any impact on the functionality or handling of
the capacitive keys.

Analogue Compass Repeaters 056376/A
ix
CAUTION
Risk of damage though solar radiation
The bearing repeater 5016-CA is equipped with a cover plate for protec-
tion against solar radiation.
It is recommended to always protect the bearing repeater with the cover
plate when not in use.
CAUTION
Risk of damage
The cover plate, protecting the bearing repeater 5016-CA against solar
radiation, must never be touched with tools to avoid any damage.
Always install and remove the cover plate with bare hands only.
CAUTION
Risk of damage through wrong cleaning agent
The front plates of the compass repeaters are sensitive against aggres-
sive cleaning agents as organic solvents or acetone.
Do not clean the front plate with organic solvents, acetone or any other
aggressive cleaning agent.
Use only water and soap or a mild detergent to clean the front plate.
CAUTION
Risk of unnecessary wear
The bearing repeater 5016-CA can optionally be equipped with a water-
tight plastic cover for protection against environmental conditions.
It is recommended to always protect the bearing repeater with the plastic
cover when not in use.
CAUTION
Risk of damage
The prismatic azimuth device PV23 and the telecopic alidade are not
designed to stay permanently mounted on the bearing repeater.
Leaving the PV23 or the alidade on the bearing repeater after usage, will
cause wear and damage to the equipment.
Always remove the PV23 or the alidade from the bearing repeater and
store it carefully away in its storage box.
Note
The repeater compasses do not possess an audible alarm indicator.
Note
Sperry Marine Service:
In case of service refer to www.sperrymarine.com/offices for a list of
all Sperry Marine Offices and Service Agents worldwide.

056376/A Analogue Compass Repeaters
x
General Safet Information for Service Personnel
CAUTION
Risk of wrong installation
Wrong positioning of the bearing stand will obstruct to take bearings.
Always make sure that the bearing stand is so positioned that the ves-
sel’s superstructure does not unduly obstruct the view of the horizon.
In case one bearing stand does not allow to take bearings in a full circle
of 360°, a second bearing stand must be installed for compensation.
CAUTION
Risk of damage
The compass repeaters are heavy instruments. The compass repeater
cables are not designed for holding the repeater just with the cable.
Never hold or transport the repeater on the cable alone when installing
or wearing a compass repeater.
CAUTION
Risk of damage
The bearing repeater is a heavy instrument.
To avoid any damage during installation of the bearing repeater into the
gimbal ring, the installation should be carried out by two service persons.
CAUTION
Risk of malfunction
Do not lengthen the cable between the bulkhead repeater and the con-
nection box as the USB service port will not work reliably.
If the connection box cannot be installed at an accessible location close
to the repeater, it will be required to unmount and disassemble the
repeater to gain access to the internal USB receptacle when configuring
or servicing the device.
If the repeater cable is connected directly to shipside terminals, the exter-
nal USB port may not be used and its four wires must be connected to
blind terminals.
CAUTION
Risk of damage through unauthorized service
The housing of the bearing repeater 5016-CA is designed for increased
watertightness and shall therefore not be opened in the field.
Opening the housing in the field will diminish the watertightness and
may lead to condensation forming on the inside surfaces, especially the
top glass, at a later point in time.
Never open the bearing repeater housing in the field.
Always return a defective bearing repeater to Sperry Marine.
CAUTION
Risk of damage through unauthorized service
The analogue compass repeaters are complex electronic devices, which
are not serviceable in the field down to the level of individual circuit com-
ponents.
Defective units must be sent back to Sperry Marine for repair.
CAUTION
Risk of damage of electrostatic-discharge-sensitive components
The analogue compass repeaters contain electrostatic sensitive compo-
nents. Electrostatic discharge may permanently damage components.
When servicing an analogue compass repeater, take precautions to pre-
vent electrostatic discharge. Avoid touching any of the electronic cir-
cuitry.

Analogue Compass Repeaters 056376/A
xi
CAUTION
Risk of parameter settings loss
It cannot be guaranteed that the repeater’s configuration parameter set-
tings are left intact during a firmware update.
Before updating firmware, record all parameter settings to be able to re-
enter them manually, if required.
Note
The analogue compass repeaters are serviced and configured using the
Sperry Universal Setup Instrument (SUSI).
This tool is provided to authorized service personnel only and is gener-
ally not available to end-customers.
Note
Exact voltage levels must be checked with a voltmeter true RMS.
The data content on serial I/O lines must be checked with the aid of suit-
able analysing tools, such as PC-based protocol interpreters or terminal
programs.

056376/A Analogue Compass Repeaters
xii

Analogue Compass Repeaters 056376/A
System Description 1-1
Chapter 1: Introduction
1.1 S stem Description
Intended Use
The analogue compass repeaters are remote heading indicators which
display ship’s heading (secondary heading data), provided by a con-
nected gyrocompass as active heading source (primary heading data),
and must only be operated from appropriately trained and educated
personnel familiar with all mandatory safety and operating procedures.
The prismatic azimuth device PV23 is a classified compass bearing
device designed for usage together with the bearing repeater 5016-CA.
Not Intended Use
The analogue compass repeaters are not allowed to be used for the nav-
igation of inland water vessels and river boats. Any exception to this
restriction must be regulated by specific certification of an entitled
organisation or administration, for further details see certification infor-
mation under ‘Design and Main Features” on page 1-2 and ‘Declaration
of Conformity” on page 1-15.
The magnetic heading repeater, type 5016-CC, is only classified for steer-
ing purposes in case of emergency when the gyrocompass(es) as pri-
mary heading source(s) are not available and must not be used for
navigating the vessel under normal conditions.
The telescopic alidade, stock no 60280, is not type approved as compass
bearing device, therefore it cannot be used to fulfil the carriage require-
ments.

056376/A Analogue Compass Repeaters
1-2 Design and Main Features
1.2 Design and Main Features
The analogue compass repeaters are remote heading indicators which
display ship’s heading (secondary heading data), provided by a con-
nected gyrocompass as active heading source (primary heading data),
using a rotating compass card assembly.
The repeaters are available in four type variants:
• Bearing Repeater, Type 5016-CA
• Steering Repeater, Type 5016-CB
• Magnetic Heading Repeater, Type 5016-CC
• Bulkhead Repeater, Type 5016-CD
The analogue compass repeaters have been type-approved by German-
ischer Lloyd (GL), in accordance with the Maritime Equipment Directive
(MED) 96/98/EC as amended, as
gyrocompass accessory equipment
in the type approval certificates of the
Sperry Marine gyrocompass systems
NAVIGAT X MK 1 (certificate no. 94418-10HH, 94428-10HH),
NAVIGAT X MK 2 (certificate no. 94420-10HH),
NAVIGAT 2100 (certificate no. 94416-10HH, 94426-10HH)and
NAVIGAT 3000 (certificate no. 37757-12HH, 37957-12HH).
The analogue compass repeaters comply with the following specified
standard as gyrocompass accessory equipment:
IMO resolution MSC.116(73).
For further details see “Declaration of Conformity” on page 1-15.
Heading data is received at an RS-422 serial data input, using the
NMEA 0183/IEC 61162 or the Plath binary protocol. The repeaters are
able to auto-detect the input data protocol and baudrate at power-up
and will self-synchronize with the input heading received.
Depending on the currently active heading source, the repeaters will
indicate true heading from a gyrocompass (GYRO), or a transmitting
heading device (THD1), or magnetic compass heading (raw or corrected
for deviation and/or variation) from a magnetic compass (MAG). The
active source is constantly highlighted at the repeater by a backlit indi-
cator (“GYRO, “THD” or “MAG”).
Graduations and numbering of the cards’ scales appear white on a
matte black background. The cards are backlit by dimmable white LEDs.
A set of dimmer push buttons is integrated into the repeater front plate
of the steering repeater, type 5016-CB, magnetic heading repeater, type
5016-CC and the Bulkhead Repeater, type 5016-CD whereas the bearing
repeater, type 5015-CA, is designed with a new glass front and capaci-
tive dimmer keys instead.
All repeater variants feature a 360° and a 10° compass card, except for
the magnetic heading repeater, where the 10° card is not assembled.
1. In the context of this manual, “THD” refers to a transmitting heading device
according to IMO MSC.116(73) or IEC 22090 parts 1-3 respectively.

Analogue Compass Repeaters 056376/A
Functional Description 1-3
The magnetic heading repeater, type 5016-CC, is preconfigured to indi-
cate magnetic compass heading only, regardless of which source is cur-
rently active.
The magnetic heading repeater is equipped with a removable cover, hid-
ing the compass card when navigating the vessel under normal use, as
the magnetic heading repeater is only classified for the indication of
magnetic heading data in case of emergency when the gyrocompass(es)
as primary heading source(s) are not available and the vessel is actually
steered by magnetic compass heading.
1.3 Functional Description
The compass card assembly is driven through a gear train by a stepper
motor. To ensure smooth and silent operation, the microprocessorized
motor control uses micro stepping. Photo interrupters detect when the
compass cards pass their zero positions at 360° and every 10°, respec-
tively, allowing minor step losses to be automatically corrected during
operation.
Once valid heading data is received, the heading to be indicated is trans-
lated into a counter value representing the required compass cards’ off-
set from the North (zero) position. A second counter is maintained for
the cards’ current offset.
The motor control constantly executes a routine to minimize the differ-
ence between these two offsets, thus making the compass cards follow-
up to the heading to be indicated.
The position of the cards is held in non-volatile memory, so that it is not
normally required to zero (re-synchronize) the cards upon power-up.

056376/A Analogue Compass Repeaters
1-4 Compass Repeater Type Variants
1.4 Compass Repeater T pe Variants
Bearing Repeater
The bearing repeater, type 5016-CA, is gimbal-mounted for usage in a
bearing stand or in a repeater bracket attached to a bulwark. The bowl-
shaped watertight housing with new glass front permits installation at
exposed locations. The new capacitive keys of the bearing repeater front
increase additionally the watertightness of the housing.
The bearing repeater is equipped with a cover plate against solar radia-
tion. For optimum protection and long term usage without unnecessary
wear, a watertight cover protecting against environmental conditions is
available as an optional accessory for the bearing stand.
In addition to the regular heading scales, the bearing repeater features
an azimuth scale on the 360° card and a graduated verge ring for taking
absolute and relative bearings with the azimuth device PV 23 (optional
accessory).
Steering Repeater
The steering repeater, type 5016-CB, is the type variant most commonly
used as steering compass repeater on the bridge.
It is suitable for direct console mounting or mounting in a console frame
and may be installed horizontally, vertically or inclined.
The steering repeater is normally installed at a protected location. It may
be installed at an exposed location if directly mounted to the console
using a watertight seal.
The repeater is equipped with a removable sun shade.
Magnetic Heading Repeater
The magnetic heading repeater, type 5016-CC, designed for console
mount, is preconfigured to permanently indicate magnetic compass
heading only.
It possesses no 10° card. Instead, the 360° card is graduated every 1°.
The magnetic repeater is to be used only as an emergency steering
repeater in case of failure of the gyrocompass(es).
To prevent its indication from being mistaken for the reference to steer
by, the magnetic repeater is equipped with a removable cover, which
should be removed only in case of failure of the gyrocompass(es), when
the vessel is actually steered by magnetic compass heading.
Note
The capacitive keys of the bearing repeater 5016-CA are sensitive against
surface water, e.g. remaining rain drops, which may result in random
changing of the illumination brightness.
This effect does not have any impact on the functionality or handling of
the capacitive keys.

Analogue Compass Repeaters 056376/A
Accessories 1-5
Bulkhead Repeater
The bulkhead repeater, type 5016-CD, is equipped with the same com-
pass card assembly as the steering repeater. It is suitable for mounting
onto a bulkhead or other flat surface, vertically, horizontally or inclined.
An optional mounting bracket is available to install the repeater at an
inclined angle relative to the mounting surface.
The watertight housing permits installation at exposed locations without
an additional hood or cover.
1.5 Accessories
Bearing Repeater Stand and Brackets
The bearing repeater stands, type 4622-AC and -AD, comprise a base,
column and flared top rim in one integral part. It is made of a welded
aluminium alloy and is powder-coated. The repeater gimbal ring is held
in two bearing supports attached to the top rim.
• When the repeater is installed in bearing repeater stand 4622-AC, its
working height is 1.45 m.
• When the repeater is installed in bearing repeater stand 4622-AD, its
working height is 1.30 m.
The connection box, 4894-AD, is attached to the stand’s column.
An optional watertight cover is available to protect the bearing repeater
from the elements.
The bearing repeater bracket type 4890 is made of a welded aluminium
alloy and is powder-coated. It is to be fitted to a bulwark or other vertical
surface. The installation height of the bracket determines the repeaters
working height.
The connection box, 4894-AD, is attached to the side of the bracket.
The adjustable bearing repeater bracket type 4905 is made of aluminium
alloy and is powder-coated. It is to be fitted to a bulwark or other vertical
surface. The height-adjustable bracket arms permit to vary the repea-
ter’s working height in three steps within a range of 250 mm.
The connection box, 4894-AD, is attached to the bracket’s mounting
plate.
Bulkhead Repeater Bracket
The swivelling bulkhead repeater bracket is made of powder-coated
sheet metal. It permits to install the repeater at an inclined angle relative
to the mounting surface, e.g. when it is mounted high up a bulkhead or
on a ceiling. The angle is adjustable within a range of 45°.

056376/A Analogue Compass Repeaters
1-6 Accessories
Connection Box
The connection box, type 4894-AD, a stainless steel box with cable
glands, is for connecting the bearing repeater and bulkhead repeater to
the gyrocompass system. It is either attached to the repeater stand’s col-
umn, or to the side of the bracket/bracket’s mounting plate.
The connection box holds as well the standard USB type B receptacle
for service purposes.
Azimuth Device PV 23
The prismatic azimuth device PV 23 (type no. 2535) is a vane-type azi-
muth device, classified as compass bearing device to be used in combi-
nation with the bearing repeater, type 5016-CA.
It is suitable for taking absolute and relative bearings of terrestrial
objects and of celestial bodies (stars and planets).
The near sight vane is equipped with a prism mirror to read absolute
bearings off the compass card and two coloured anti-glare filters.
An index mark at the near side of the PV 23 is used to read relative bear-
ings off the repeater’s verge ring scale.
The far sight vane is equipped with a wire sight and with a pivoting
black azimuth mirror to pick up the reflections of objects at high eleva-
tion, i.e. terrestrial bodies.
For more details see “Taking Bearings with the Azimuth Device PV 23”
on page 2-6.
Telescopic Alidade
The telescopic alidade, stock no 60280, not classified as compass bear-
ing device in combination with the bearing repeater, type 5016-CA, for
classified vessels, may also become used with the bearing repeater for
taking bearings on non classified ships only.
It is suitable for taking absolute and relative bearings of magnified ter-
restrial objects and celestial bodies (stars and planets).
For more details see the separate operation manual of the
telescopic alidade 056339.

Analogue Compass Repeaters 056376/A
Technical Data 1-7
1.6 Technical Data
Common Features, all Repeater T pes
,
Environmental Requirements
ambient temperature, operation -25 °C – +55 °C
ambient temperature, storage -25 °C – +70 °C
Power Suppl
supply voltage 24 VDC
max. ripple content ±4 Vpp; extreme values may not
exceed 36 V or fall below 18 V
power consumption 6 W max.
Readout Elements
compass cards colour: white on black
illumination: LED backlight, white
card system follow-up speed ≥ 30°/s
max. error of indication ±0.1° at rest, ±0.5° at turn ≤ 20°/s
lubber line illuminated pointer, yellow
Data Input
protocol NMEA 0183 / IEC 61162 at 4800,
9600, 19200, or 38400 Bd., 8N1, or
Plath binary, 9600 Bd., 8N1
evaluated IEC 61162 sentences
gyrocompass heading
magnetic compass heading
heading from THD
nav. status (active source)
central dimming command
$--THS, $--HDT
(talker ID not HC or GP)
$HCHDT, $HCHDM, $HCHDG
$GPTHS, $GPHDT
$PPLAN, $PPNSD (proprietary)
$--DDC or $PPLAI (proprietary)
Service I/O Port
USB service port Standard USB type B receptacle
for connection to a Windows host
PC using a vendor-specific USB
communications device class
driver, directly accessible at the
back side of types 5016-CB and -
CC. For types 5016-CA and -CD the
USB receptacle is accessible in-
side the connection box housing.
The analogue compass repeater is
accessed via the “SUSI” applica-
tion, using a proprietary data pro-
tocol.

056376/A Analogue Compass Repeaters
1-8 Technical Data
Bearing Repeater, T pe 5016-CA
Environmental Requirements
protection grade IP 56 to DIN EN 60529
environmental conditions / EMC
according to IEC 60945, equipment
category “exposed to the weather”
Magnetic Clearance
to standard magnetic compass 0.80 m
to steering magnetic compass 0.50 m
reduced, to standard magnetic compass 0.50 m
reduced, to steering magnetic compass 0.30 m
Readout Elements
360° card diameter
scale graduations
heading scale, numbering
azimuth scale, numbering
10° card diameter
graduation
numbering
172 mm
outer: every 1°; inner: every 5°
every 10°
every 5°
130 mm
every 0.5°
every 1°
verge ring diameter
colour
graduation
numbering
225 mm
white on black
every 1°
every 10°
Controls
Capacitive keys
Dimensions and Weight
diameter at top
(verge ring outer dia.)
225 mm
height 165 mm
depth 173 mm
weight 5.5 kg
free cable length 2 m
