Squier Affinity Mini Strat User manual

Squier Mini Strat
Rosewood- m/n 0310101xxx
Loc # Description Part Number
1 Standard Tuners (set of 6) 005-5404-000
2 Bone Nut (blank) (2) 099-4920-000
3 String Guide 099-4910-000
4 Strap Buttons (2) 099-4915-000
5 Pickguard Assembly (w/ controls) 007-7506-000
5a Volume/Tone Knobs (ea) (white) 005-5424-000
6 Output Jack 007-2892-000
6a Jack Plate (chrome) 007-2893-000
10 Bridge Assembly 006-2370-000
Last Revision Date: 9/19/2008
Page 1 of 2

Wiring Diagram
Last Revision Date: 9/19/2008
Page 2 of 2
