Squier Jagmaster User manual

Squier Jagmaster
Rosewood- m/n 0320700xxx
Loc # Description Part Number
1 Standard Tuners (set of 6) 007-7448-000
2 Bone Nut (blank) (2) 099-4920-000
3 Vintage String Guide 099-4910-000
4 Strap Buttons (2) 099-4915-000
5 Pickguard (parchment) 007-7450-000
5 Pickguard (tortoise shell) 007-7451-000
5a Pickguard Screws 099-4923-000
6 Neck Pickup 007-7452-000
7 Bridge Pickup 007-7453-000
8-9 500K Solid Shaft Pot (Set of 2) 005-5440-000
8-9a Volume/Tone Knobs (set) (black) 099-1365-000
10 Output Jack 007-7443-000
11 Bridge Assembly 007-7454-000
12 Tremolo Arm 007-7455-000
Last Revision Date: 7/15/2008
Page 1 of 2

Wiring Diagram
Last Revision Date: 7/15/2008
Page 2 of 2
