SRS Labs DC60SS User manual

1. Enter Programming Mode (see 1)
2. Enter "40" for output 1 relay
3. Enter E.g. "5" for 5 seconds
4. Press "#" to confirm
5. Press "*" to finish programming
Example: 40 5 # *
1. Enter Programming Mode (see 1)
2. Enter "1" for output 1 relay
3. Enter "01" to set PIN's location
4. Enter 4 digit user code
5. Press "#" to confirm
6. Press "*" to finish programming
Example: 1 01 USER CODE # *
1. Enter Programming Mode (see 1)
2. Enter "82 1" to disable or.....
3. Enter "82 0" to enable
4. Press "#" to confirm
5. Press "*" to finish programming
Example:
Disable: 82 1 # *, Enable: 82 0 # *
Before you add or delete users,
you must be in Programming Mode,
to do this use default master code.
0 0 0 0 * (Solid amber LED)
1. Enter Programming Mode (see 1)
2. Enter "0" for master code location
3. Enter new 4 digit Master code
4. Press "#" to confirm
5. Press "*" to finish programming
Example: 0 MASTER CODE # *
1. Enter Programming Mode (see 1)
2. Enter "41" latch mode on output 1
3. Press "#" to confirm
4. Press "*" to finish programming
Example: 41# *
1 Entering Programming mode
4 Setting lock time for output 1
2 Changing Master Code
3 Adding user PIN for output 1
5 Setting output 1 to latch mode
6 Disable/Enable "#"with user PIN
DC60SS Quick Start Guide QG_4DC60SS

Locking Options
Note : Power supply voltage and current, should match lock specification.
Fail Locked
Egress button
Fail Un-locked
+
N.C.
COM
12 / 24V
INHIB
N.O.
O/P
EG IN
DC60SS Keypad
0V
relay normally closed
relay common
relay normally open
Relay 1
+
N.C.
COM
12 / 24V
INHIB
N.O.
O/P
EG IN
DC60SS Keypad
0V
relay normally closed
relay common
relay normally open
Relay 1
0V
12V
PSU
+
+
N.C.
COM
12 / 24V
INHIB
N.O.
O/P
EG IN
DC60SS Keypad
0V
relay normally closed
relay common
relay normally open
Relay 1
0V
12V
PSU
+
Push button
contacts
