SSC-LUXon TOBI-S User manual

Assembly/operating instructions for SSC-LUXon ceiling/wall light TOBI-S & TOBI-L
1. Intended use
This product is for lighting purposes only and:
-may only be installed indoors / only be operated in dry rooms, i.e. not in damp rooms or rooms where there is a risk of dirt and in the area of
high humidity
-must not be exposed to strong mechanical loads or heavy soiling
-may not be operated after damp or dirty storage until after a condition check
-may not be changed or modied, otherwise the operating permit and conformity will expire with immediate eect!
It is not allowed to remove the type plate.
 If the aforementioned points are not observed, a short circuit or electric shock may occur! There is danger to life!
2. General safety instructions
The complete installation may only be carried out by an authorized electrician who is familiar with the applicable guidelines. Hereinafter
referred to as „qualied electrician“.
For safe handling of the product, the user must have read and understood the installation/operating instructions completely before using
the device for the rst time.
 The product may only be used if it is alright. If the device or parts of it are defective, it must be repaired by a qualied electrician.
Only use lamps/light source approved by the manufacturer. The max. lamp wattage in watts is not allowed be exceeded.
This product is not a toy and is not allowed be stored or used within the reach of children.
Safe operation of the product is only guaranteed if these instructions are followed. Therefore, keep these assembly/operating instructions.
SSC-LUXon GmbH accepts no liability if the instructions given here are not followed or the lamp is subjected to improper use.
3. Assembly & conguration
Caution: The connecting cable must be disconnected from the power supply before starting work (switch o the main switch/fuse)! Only use
parts which are supplied with the product or which are clearly marked as equipment! Otherwise the product may not be suciently safe!
When drilling, pay attention to cables and gas and water lines.
3.1 Assembly location
The product is suitable for mounting on ceilings and walls. The product may only be mounted on a stable, tilt-resistant and level surface. Do
not cover the product under any circumstances, especially not with insulating material! Fire hazard!
 Components of the luminaire and especially the lamps/light source become hot during operation. Especially in the case of halogen lamps/
light source. Keep a sucient distance (0.5 m) from easily ammable objects (e.g. curtains, drapes, etc.) and ammable materials (ignition
temperature<250°C)!
4. Operation, bulb replacement, faults & disorders
 Caution: Disconnect the connecting cable from the power supply before replacing lamps/light sources! Do not cover! Covering with (e.g.
towel) is a re hazard! Luminaires with protective cover may only be operated with complete protective cover!
 Never look directly into the light source!
What to do in case of error?
In case of an error, the device must be switched o immediately. The product may only be operated if it works correctly. The device may only
be put back into operation after it has been checked by a qualied electrician! This is the case if:
1. there is visible damage, 2. the product is not working corrctly, 3. there is smoke, steam, or audible crackling noises, 4. overheating can be
detected
Caution: There is a danger to life - repairs to the product or work on parts carrying mains voltage may only be carried out by qualied
electricians.
Avoidance of disturbances and re hazards:
It is not allowed to cover the product under any circumstances. Air circulation must be ensured. Nothing may be attached or hung on the
product, especially no decoration.
5. Cleaning & care instructions
The product may only be wiped dry or carefully with a slightly damp and lint-free cloth. The product is not allowed to be removed for this
purpose. Do not use abrasive or sharp objects or aggressive cleaning agents. Do not use solvents.
Technical data & assembly instruction model TOBI-S & TOBI-L
TOBI-S
TOBI-L
1. Disconnect the connecting cable from the power
supply!
2. Remove the base plate (towards the ceiling/wall) from
the enclosure by turning the base plate anti-clockwise.
3. Mark the drill holes with the help of the base plate.
Drill the holes in the ceiling and insert the dowels. Pay
particular attention to the position of the thread on
the TOBI-L model so that the lights all face in the same
direction later.
4. Guide the connection cable through the large
opening in the base plate and x the base plate with the
screws in the intended position.
5. Connect L & N of the connecting cable to the
connecting terminal / luster terminal.
6. Turn the front ring (light direction) o by turning the
ring counterclockwise.
7. Screw the luminaire body onto the base plate
mounted on the ceiling.
8. Screw the GU10 light source into the socket. Insert
the light source into the luminaire. Then screw the front
ring back onto the lamp.
9. Switch on the voltage again. The product is now ready
for operation.
Models: TOBI-S 990070782, 990070784
TOBI-L 990070781, 990070783
Type: Ceiling/wall light
Voltage: 230 VAC
Material: Aluminium
Operating temperature: -5°C - +40°C
Swivelling: 90° (only model TOBI-L)
Max. power: 15 W
Protection class: II
Measurements: TOBI-S: Ø 60 mm / height 85 mm
TOBI-L: Ø 56 mm / height 160 mm
Can only be
used indoors
Colour: White or black
Notes / Explanations & Legend
The following applies to all models
Distance to illuminated objects
min. 0.5m
Protection class II
Installation only by qualied
electrician
Disconnect the device from the
mains power before starting
any work
Disposal instructions
Make sure to dispose
packaging in accordance
with the applicable
guidelines of your local
authority. Devices marked
with the crossed-out was-
te garbage do not belong
in the household waste!
You are obliged to hand
in these devices at one of the free collection
points in your municipality. You can obtain
more information from your local authority,
the relevant town hall or a local or regional
waste disposal company.
 Keep packaging material and small parts
away from children and animals. Danger of
suocation!
Notes on use indoors & outdoors
 Protection type IP20 & IP23: Use only
indoors and dry, i.e. do not use in damp or
dirty rooms and in areas of high humidity.
 Protection type IP44 & IP65: Can be used
indoors and outdoors.
Onlineshop:
www.led-lichtraum.de
Satised with your product?
Then we look forward to your
product review in our online store,
on Amazon or eBay!
SSC-LUXon GmbH – Am Krozinger Weg 4, 79189 Bad Krozingen, Germany
E-Mail: [email protected]; Phone: +49 7633 - 988 3000
Vers. 06/2020
Protection type: IP20
Socket: GU10

SSC-LUXon GmbH – Am Krozinger Weg 4, 79189 Bad Krozingen, Germany
E-Mail: [email protected]; Phone: +49 7633 - 988 3000
TOBI-S 990070782, 990070784 TOBI-L 990070781, 990070783
