Stanley DL07 Operation manual

DL07
HYDRAULIC
DRILL
SAFETY, OPERATION AND MAINTENANCE
SERVICE MANUAL
Copyright©The Stanley Works 2006
Printed in U.S.A.
60789 12/2006 ver 4D
Stanley Hydraulic Tools
3810 SE Naef Road
Milwaukie OR 97267-5698
503-659-5660
FAX [phone]
www.stanley-hydraulic-tools.com
WARNING
Read the Manual Wear Eye
Protection
Wear Ear
Protection WearDust Mask
To avoid serious injury or death
WARNING

3
TABLE OF CONTENTS
SERVICING THE STANLEY HYDRAULIC IMPACT WRENCH: This manual contains safety, operation, and
routine maintenance instructions. Servicing of hydraulic tools, other than routine maintenance, must be
performed by an authorized and certified dealer. Please read the following warning.
SERIOUS INJURY OR DEATH COULD RESULT FROM THE IM-
PROPER REPAIR OR SERVICE OF THIS TOOL.
REPAIRS AND / OR SERVICE TO THIS TOOL MUST ONLY BE
DONE BY AN AUTHORIZED AND CERTIFIED DEALER.
WARNING
SAFETY SYMBOLS......................................................................................................................5
SAFETY PRECAUTIONS .............................................................................................................6
TOOL STICKERS & TAGS............................................................................................................7
TOOL HOSE INFORMATION .......................................................................................................8
OPERATION ...............................................................................................................................11
COLD WEATHER OPERATION..................................................................................................12
EQUIPMENT PROTECTION & CARE........................................................................................13
TROUBLESHOOTING................................................................................................................14
SPECIFICATIONS.......................................................................................................................15
TORQUE AND DRILL SPEEDS..................................................................................................15
ACCESSORIES ..........................................................................................................................16
SERVICE.....................................................................................................................................17
DL07 PARTS ILLUSTRATION.....................................................................................................20
DL07 PARTS LIST.......................................................................................................................21
WARRANTY................................................................................................................................22

4
CERTIFICATE OF CONFORMITY
ÜBEREINSTIMMUNGS-ZERTIFIKAT
CERTIFICAT DE CONFORMITE CEE
CERTIFICADO DE CONFORMIDAD
CERTIFICATO DI CONFORMITA
Hydraulic Tools
______________________________________________________________________
I, the undersigned:
Ich, der Unterzeichnende:
Je soussigné:
El abajo firmante:
lo sottoscritto:
Burrows, James
Surname and First names/Familiennname und Vornamen/Nom et prénom/Nombre y apellido/Cognome e nome
hereby certify that the construction plant or equipment specified hereunder:
bestätigehiermit, daß das im folgenden genannten Werk oder Gerät:
certifies par ceci que l’ usine ou l’ équipement de construction indiqué cidessous:
por el presente certifico que la fabrica o el equipo especificado a continuacion:
certifico che l’impianto o l’attrezzatura sotto specificata:
1. Category: Drill
Kategorie:
Catégorie:
Categoria:
Categoria:
2. Make/Ausführung/Marque/Marca/Marca Stanley
3. Type/Typ/Type/Tipo/Tipo: DL0755001
4. Serial number of equipment:
Seriennummer des Geräts:
Numéro de série de l’équipement:
Numero de serie del equipo:
Matricola dell´attrezzatura: All
5. Year of manufacture/Baujahr/année de fabrication/Año de fabricacion/Anno di fabbricazione 2004
Has been manufactured in conformity with - EEC Type examination as shown.
Wurde hergestellt in Übereinstimmung mit - EEC Typ-Prüfung nach.
Est fabriqué conformément - au(x) type(s) examiné(s) comme indiqué dans le tableau ci-après.
Ha sido fabricado de acuerdo con - tipo examen EEC como dice.
E’ stata costruita in conformitá con - le norme CEE come illustrato.
Examen CEE de type
Directive
Richtlinie
Directives particulières
Directriz
Direttiva
No.
Nr
Numéro
No
n.
Date
Datum
Date
Fecha
Data
Approved body
Prüfung durch
Organisme agréé
Aprobado
Collaudato
Date of expiry
Ablaufdatum
Date d´expiration
Fecha de caducidad
Data di scadenza
Machinery Directive
EN
EN ISO
EN
98/37/EC
792-3
3744
28662-1
1998
1994
1995
1988
Self
Self
Self
Self
NA
NA
NA
NA
6. Special Provisions: None
Spezielle Bestimmungen:
Dispositions particulières:
Provisiones especiales:
Disposizioni speciali:
Done at/Ort/Fait à/Dado en/Fatto a Stanley Hydraulic Tools, Milwaukie, Oregon USA Date/Datum/le/Fecha/Data
Signature/Unterschrift/Signature/Firma/Firma
Position/Position/Fonction/Puesto/Posizione Engineering Manager
Rev 1 3/05

5
Safety symbols and signal words, as shown below, are used to emphasize all operator, maintenance and repair
actions which, if not strictly followed, could result in a life-threatening situation, bodily injury or damage to equip-
ment.
This safety alert and signal word indicate an imminently hazardous situa-
tion which, if not avoided, will result in death or serious injury.
Always observe safety symbols. They are included for your safety and for the protection of the tool.
LOCAL SAFETY REGULATIONS
Enter any local safety regulations here. Keep these instructions in an area accessible to the operator and mainte-
nance personnel.
CAUTION
WARNING
DANGER
NOTICE
CAUTION
This is the safety alert symbol. It is used to alert you to potential personal
injury hazards. Obey all safety messages that follow this symbol to avoid
possible injury or death.
This safety alert and signal word indicate a potentially hazardous situation
which, if not avoided, could result in death or serious injury.
This safety alert and signal word indicate a potentially hazardous situation
which, if not avoided, may result in minor or moderate injury.
This signal word indicates a potentially hazardous situation which, if not
avoided, may result in property damage.
This signal word indicates a situation which, if not avoided, will result in
damage to the equipment.
This signal word indicates a situation which, if not avoided, may result in
damage to the equipment.
SAFETY SYMBOLS
IMPORTANT

6
Tool operators and maintenance personnel must always comply with the safety pre-
cautions given in this manual and on the stickers and tags attached to the tool and
hose.
These safety precautions are given for your safety. Review them carefully before
operating the tool and before performing general maintenance or repairs.
Supervising personnel should develop additional precautions relating to the specific
work area and local safety regulations. If so, place the added precautions in the
space provided on page 5.
The model DL07 Hydraulic Impact Wrench will provide safe and dependable service
if operated in accordance with the instructions given in this manual. Read and un-
derstand this manual and any stickers and tags attached to the tool and hose before
operation. Failure to do so could result in personal injury or equipment
damage.
• The operator must start in a work area without bystanders. Flying debris can cause serious injury.
• Do not operate the tool unless thoroughly trained or under the supervision of an instructor. Establish a training program
for all operators to ensure safe operation.
• Always wear safety equipment such as goggles, ear and head protection, and safety shoes at all times when operating
the tool. Use gloves and aprons when necessary.
• The operator must be familiar with all prohibited work areas such as excessive slopes and dangerous terrain conditions.
• Maintain proper footing and balance at all times.
• Do not inspect or clean the tool while the hydraulic power source is connected. Accidental engagement of the tool can
cause serious injury.
• Always connect hoses to the tool hose couplers before energizing the hydraulic power source. Be sure all hose
connections are tight and are in good condition.
• Do not operate the tool at oil temperatures above 140°F/60°C. Operation at higher temperatures can cause higher than
normal temperatures at the tool which can result in operator discomfort.
• Do not operate a damaged, improperly adjusted, or incompletely assembled drill.
• Never wear loose clothing that can get entangled in the working parts of the tool.
• Keep all parts of your body away from the rotating parts. Long hair or loose clothing can become drawn into rotating
components.
• Always use accessories that conform to the specifications given in the OPERATION section of this manual.
• Do not reverse impact wrench rotation direction by changing fluid flow direction.
• Release the trigger if the power supply has been interrupted.
• When working near electrical conductors, always assume that all conductors are energized and that insulation, clothing
and hoses can conduct electricity. Use hose labeled and certified as non-conductive.
• To avoid personal injury or equipment damage, all tool repair, maintenance and service must only be performed by au-
thorized and properly trained personnel.
• Do not carry the tool by hoses.
SAFETY PRECAUTIONS

7
The safety tag (p/n
15875) at right is attached
to the tool when shipped
from the factory. Read
and understand the safety
instructions listed on this
tag before removal. We
suggest you retain this tag
and attach it to the tool
when not in use.
TOOL STICKERS & TAGS
DANGER
IMPORTANT
READ OPERATION MANUAL AND
SAFETY INSTRUCTIONS FOR THIS
TOOL BEFORE USING IT.
USE ONLY PARTS AND REPAIR
PROCEDURES APPROVED BY
STANLEY AND DESCRIBED IN THE OPERA-
TION MANUAL.
TAG TO BE REMOVED ONLY BY
TOOL OPERATOR.
SEE OTHER SIDE
1. FAILURETO USEHYDRAULIC HOSE LABELEDANDCERTIFIED
AS NON-CONDUCTIVE WHEN USING HYDRAULIC TOOLS
ON OR NEAR ELECTRICAL LINES MAY RESULT IN DEATH
OR SERIOUS INJURY.
BEFORE USING HOSE LABELED AND CERTIFIED AS NON-
CONDUCTIVE ON OR NEAR ELECTRIC LINES BE SURE THE
HOSE IS MAINTAINED AS NON-CONDUCTIVE. THE HOSE
SHOULD BE REGULARLY TESTED FOR ELECTRIC CURRENT
LEAKAGE IN ACCORDANCE WITH YOUR SAFETY DEPART-
MENT INSTRUCTIONS.
2. A HYDRAULIC LEAK OR BURSTMAY CAUSE OILINJECTION
INTO THE BODY OR CAUSE OTHER SEVERE PERSONAL
INJURY.
A DO NOT EXCEED SPECIFIED FLOW AND PRESSURE FOR
THIS TOOL. EXCESS FLOW OR PRESSURE MAY CAUSEA
LEAK OR BURST.
B DO NOT EXCEED RATED WORKING PRESSURE OF HYDRAU
LIC HOSE USED WITH THIS TOOL. EXCESS PRESSURE
MAYCAUSE A LEAK OR BURST.
C CHECK TOOLHOSE COUPLERS AND CONNECTORS DAILY
FOR LEAKS. DO NOT FEEL FOR LEAKS WITH YOUR
HANDS.CONTACT WITH A LEAK MAY RESULT IN SEVERE
IMPORTANT
READ OPERATION MANUAL AND
SAFETY INSTRUCTIONS FOR THIS
TOOL BEFORE USING IT.
USE ONLY PARTS AND REPAIR
PROCEDURES APPROVED BY
STANLEY AND DESCRIBED IN THE OPERA-
TION MANUAL.
TAG TO BE REMOVED ONLY BY
TOOL OPERATOR.
SEE OTHER SIDE
D DO NOT LIFT OR CARRY TOOL BY THE HOSES. DO
NOT ABUSE HOSE. DO NOT USE KINKED, TORN OR
DAMAGED HOSE.
3. MAKESURE HYDRAULICHOSESARE PROPERLYCONNECTED
TO THE TOOL BEFORE PRESSURING SYSTEM. SYSTEM
PRESSURE HOSE MUSTALWAYS BE CONNECTED TO TOOL
“IN” PORT. SYSTEM RETURN HOSE MUST ALWAYS BE
CONNECTED TO TOOL “OUT” PORT. REVERSING CONNEC-
TIONSMAYCAUSE REVERSETOOLOPERATIONWHICH CAN
RESULT IN SEVERE PERSONAL INJURY.
4. DO NOT CONNECT OPEN-CENTER TOOLS TO CLOSED-CEN-
TER HYDRAULIC SYSTEMS. THIS MAY RESULT IN LOSS OF
OTHER HYDRAULIC FUNCTIONS POWERED BY THE SAME
SYSTEM AND/OR SEVERE PERSONALINJURY.
5. BYSTANDERS MAY BE INJURED IN YOUR WORK AREA. KEEP
BYSTANDERS CLEAR OF YOUR WORK AREA.
6. WEAR HEARING, EYE, FOOT, HAND AND HEAD PROTEC-
TION.
7. TO AVOID PERSONAL INJURYOR EQUIPMENT DAMAGE, ALL
TOOL REPAIR MAINTENANCE AND SERVICE MUST ONLY BE
PERFORMED BY AUTHORIZED AND PROPERLY TRAINED
PERSONNEL.
(shown smaller then actual size)
SAFETY TAG P/N 15875
DANGER
NOTE
THE INFORMATION LISTED ON
THE STICKERS SHOWN, MUST BE
LEGIBLE AT ALL TIMES.
REPLACE DECALS IF THEY
BECOME WORN OR DAMAGED.
REPLACEMENTS ARE AVAILABLE
FROM YOUR LOCAL STANLEY
DISTRIBUTOR.
28322
CE STICKER (CE)
11207
CIRCUIT TYPE D STICKER (CE)
D
30 LPM @ 138 B AR
EHTMA CATEGORY
58862
PRESSURE WARNING STICKER
28788
MANUAL STICKER (CE)
60807
DL07 MODEL STICKER
Stanley Hydraulic Tools
3810 SE Naef Road
Milwaukie, Oregon USA
26-45 LPM / 7-12 GPM
140 BAR / 2000 PSI
Model No.
IW16
DL07 4-12 GPM/15-45 LPM
2000 PSI / 140 BAR
OC/CC
FOR USE ON OPEN CENTER AND
CLOSED CENTER HYDRAULIC
SYSTEMS. “SET FOR PROPER SYSTEM
BEFORE USE”
11354
OC/CC STICKER
Please refer to the parts illustration for location of stickers.
RATED NO-LOAD SPEED
1000 RPM AT
8 GPM/30 LPM
29148
RPM STICKER
WARNING
58864
ELECTRICAL WARNING STICKER

8
HOSE TYPES
The rated working pressure of the hydraulic hose must be equal to or higher than the relief valve setting on the hydraulic
system.There are three types of hydraulic hose that meet this requirement and are authorized for use with Stanley Hydraulic
Tools. They are:
Certified non-conductive - constructed of thermoplastic or synthetic rubber inner tube, synthetic fiber braid rein-
forcement, and weather resistant thermoplastic or synthetic rubber cover. Hose labeled certified non-conductive
is the only hose authorized for use near electrical conductors.
Wire-braided (conductive)-constructedof synthetic rubber innertube,singleordoublewire braid reinforcement, and
weather resistant synthetic rubber cover. This hose is conductive and must never be used near electrical
conductors.
Fabric-braided (notcertified or labelednon-conductive)-constucted of thermoplasticorsyntheticrubber inner tube,
synthetic fiber braid reinforcement, and weather resistant thermoplastic or synthetic rubber cover. This hose is not
certified non-conductive and must never be used near electrical conductors.
HOSE SAFETY TAGS
To help ensure your safety, the following DANGER tags are attached to all hose purchased from Stanley Hydraulic Tools.
DO NOT REMOVE THESE TAGS.
If the information on a tag is illegible because of wear or damage, replace the tag immediately. A new tag may be obtained
from your Stanley Distributor.
THE TAG SHOWN BELOW IS ATTACHED TO “CERTIFIED NON-CONDUCTIVE” HOSE
THE TAG SHOWN BELOW IS ATTACHED TO “CONDUCTIVE” HOSE.
TOOL HOSE INFORMATION
SIDE 1 SIDE 2
D A N G E R
DO NOT REMOVE THIS TAG
D A N G E R
1 FAILURE TO USE HYDRAULIC HOSE LABELEDAND CERTIFIED AS NON-CONDUCTIVE
WHEN USING HYDRAULIC TOOLS ON OR NEAR ELECTRIC LINES MAYRESULT IN DEATH
OR SERIOUS INJURY.
FOR PROPERAND SAFE OPERATION MAKE SURE THAT YOU HAVE BEEN PROPERLY
TRAINED IN CORRECT PROCEDURES REQUIRED FOR WORK ON ORAROUND
ELECTRIC LINES.
2. BEFORE USING HYDRAULIC HOSE LABELED AND CERTIFIEDAS NON-CONDUCTIVE ON
OR NEAR ELECTRIC LINES. WIPE THE ENTIRE LENGTH OF THE HOSEAND FITTING
WITH ACLEAN DRYABSORBENT CLOTH TO REMOVE DIRTAND MOSISTURE AND TEST
HOSE FOR MAXIMUM ALLOWABLE CURRENT LEAKAGE IN ACCORDANCE WITH SAFETY
DEPARTMENT INSTRUCTIONS.
SEE OTHER SIDE
DO NOT REMOVE THIS TAG
3. DO NOT EXCEED HOSE WORKING PRESSURE OR ABUSE HOSE. IMPROPER USE OR
HANDLING OF HOSE COULD RESULT IN BURST OR OTHER HOSE FAILURE. KEEP
HOSE AS FAR AWAY AS POSSIBLE FROM BODY AND DO NOT PERMIT DIRECT CONTACT
DURING USE. CONTACTATTHE BURST CAN CAUSE BODILY INJECTIONAND SEVERE
PERSONAL INJURY.
4. HANDLE AND ROUTE HOSE CAREFULLY TOAVOID KINKING,ABRASION, CUTTING, OR
CONTACT WITH HIGH TEMPERATURE SURFACES. DO NOT USE IF KINKED. DO NOT USE
HOSE TO PULLOR LIFT TOOLS, POWER UNITS, ETC.
5. CHECK ENTIRE HOSE FOR CUTS CRACKS LEAKS ABRASIONS, BULGES, OR DAMAGE TO
COUPLINGS IF ANYOF THESE CONDITIONS EXIST, REPLACE THE HOSE IMMEDIATELY.
NEVER USE TAPE ORANY DEVICE TO ATTEMPT TO MEND THE HOSE.
6. AFTER EACH USE STORE INA CLEAN DRYAREA.
SEE OTHER SIDE
(shown smaller than actual size)
(shown smaller than actual size)
D A N G E R
DO NOT REMOVE THIS TAG
D A N G E R
1 DO NOT USE THIS HYDRAULIC HOSE ON OR NEAR ELECTRIC LINES. THIS HOSE IS
NOT LABELED OR CERTIFIEDAS NON-CONDUCTIVE. USING THIS HOSE ON OR NEAR
ELECTRICAL LINES MAY RESULT IN DEATH OR SERIOUS INJURY.
2. FOR PROPER AND SAFE OPERATION MAKE SURE THATYOU HAVE BEEN PROPERLY
TRAINED IN CORRECT PROCEDURES REQUIRED FOR WORK ON ORAROUND
ELECTRIC LINES.
3. DO NOT EXCEED HOSE WORKING PRESSURE OR ABUSE HOSE. IMPROPER USE OR
HANDLING OF HOSE COULD RESULT IN BURST OR OTHER HOSE FAILURE. KEEP
HOSE AS FAR AWAY AS POSSIBLE FROM BODY AND DO NOT PERMIT DIRECT CONTACT
DURING USE. CONTACTATTHE BURST CAN CAUSE BODILY INJECTIONAND SEVERE
PERSONAL INJURY.
4. HANDLE AND ROUTE HOSE CAREFULLY TOAVOID KINKING, CUTTING, OR CONTACT
WITH HIGH TEMPERATURE SURFACES. DO NOT USE IF KINKED. DO NOT USE HOSE TO
PULL OR LIFTTOOLS, POWER UNITS, ETC.
SEE OTHER SIDE
DO NOT REMOVE THIS TAG
5. CHECK ENTIRE HOSE FOR CUTS CRACKS LEAKS ABRASIONS, BULGES, OR DAMAGE TO
COUPLINGS IF ANYOF THESE CONDITIONS EXIST, REPLACE THE HOSE IMMEDIATELY.
NEVER USE TAPE OR ANY DEVICETO ATTEMPT TO MEND THE HOSE.
6. AFTER EACH USE STORE INA CLEAN DRYAREA.
SEE OTHER SIDE
SIDE 1 SIDE 2

9
Oil Flow Hose Lengths Inside Diameter USE
(Press/Return)
Min. Working Pressure
GPM LPM FEET METERS INCH MM PSI BAR
Certified Non-Conductive Hose - Fiber Braid - for Utility Bucket Trucks
4-9 15-34 up to 10 up to 3 3/8 10 Both 2250 155
Conductive Hose - Wire Braid or Fiber Braid -DO NOT USE NEAR ELECTRICAL CONDUCTORS
4-6 15-23 up to 25 up to 7.5 3/8 10 Both 2500 175 4-6 15-23 26-100 7.5-30 1/2 13 Both 2500 175
5-10.5 19-40 up to 50 up to 15 1/2 13 Both 2500 175 5-10.5 19-40 51-100 15-30 5/8 16 Both 2500 175 5-10.5 19-40 100-300 30-90 5/8 16 Pressure 2500 175
3/4 19 Return 2500 175
10-13 38-49 up to 50 up to 15 5/8 16 Both 2500 175 10-13 38-49 51-100 15-30 5/8 16 Pressure 2500 175
3/4 19 Return 2500 175
10-13 38-49 100-200 30-60 3/4 19 Pressure 2500 175
1 25.4 Return 2500 175
13-16 49-60 up to 25 up to 8 5/8 16 Pressure 2500 175
3/4 19 Return 2500 175
13-16 49-60 26-100 8-30 3/4 19 Pressure 2500 175
1 25.4 Return 2500 175
Typical Hose Connections
Tool to Hydraulic Circuit Hose Recom- mendations The chart to the right shows recommended mini- mum hose diameters for various hose lengths based on gallons per minute (gpm)/liters per min- ute (lpm). These recommendations are intended to keep return line pressure (back pressure) to a minimum acceptable level to ensure maximum tool performance. This chart is intended to be used for hydraulic tool applications only based on Stanley Hydraulic Tools tool operating requirements and should not be used for any other applications. All hydraulic hose must have at least a rated minimum working pressure equal to the maximum hydraulic system relief valve setting. All hydraulic hose must meet or exceed specifi- cations as set forth by SAE J517.
PRESSURE
RETURN
<<< FLOW
FLOW >>>

10
HTMA REQUIREMENTS
FLOW RATE
TOOL OPERATING PRESSURE
(at the power supply outlet)
SYSTEM RELIEF VALVE SETTING
(at the power supply outlet)
MAXIMUM BACK PRESSURE
(at tool end of the return hose)
Measured at a max. fluid viscosity of:
(at min. operating temperature)
TEMPERATURE
Sufficient heat rejection capacity
to limit max. fluid temperature to:
(at max. expected ambient temperature)
Min. cooling capacity
at a temperature difference of
between ambient and fluid temps
NOTE:
Do not operate the tool at oil temperatures above 140° F (60° C). Operation at higher temperatures can cause operator
discomfort at the tool.
FILTER
Min. full-flow filtration
Sized for flow of at least:
(For cold temp. startup and max. dirt-holding capacity)
HYDRAULIC FLUID
Petroleum based
(premium grade, anti-wear, non-conductive)
VISCOSITY
(at min. and max. operating temps)
NOTE:
When choosing hydraulic fluid, the expected oil temperature extremes that will be experienced in service determine the
most suitable temperature viscosity characteristics. Hydraulic fluids with a viscosity index over 140 will meet the require-
ments over a wide range of operating temperatures.
*SSU = Saybolt Seconds Universal
4-6 gpm 7-9 gpm 11-13 gpm 9-10.5 gpm
(15-23 lpm) (26-34 lpm) (42-49 lpm) (34-40 lpm)
2000 psi 2000 psi 2000 psi 2000 psi
(138 bar) (138 bar) (138 bar) (138 bar)
2100-2250 psi 2100-2250 psi 2100-2250 psi 2200-2300 psi
(145-155 bar) (145-155 bar) (145-155 bar) (152-159 bar)
250 psi 250 psi 250 psi 250 psi
(17 bar) (17 bar) (17 bar) (17 bar)
400 ssu* 400 ssu* 400 ssu* 400 ssu*
(82 centistokes)(82 centistokes)(82 centistokes)(82 centistokes)
140° F 140° F 140° F 140° F
(60° C) (60° C) (60° C) (60° C)
3 hp 5 hp 7 hp 6 hp
(2.24 kW) (3.73 kW) (4.47 kW) (5.22 kW)
40° F 40° F 40° F 40° F
(22° C) (22° C) (22° C) (22° C)
25 microns 25 microns 25 microns 25 microns
30 gpm 30 gpm 30 gpm 30 gpm
(114 lpm) (114 lpm) (114 lpm) (114 lpm)
100-400 ssu* 100-400 ssu* 100-400 ssu* 100-400 ssu*
(20-82 centistokes)
TOOL CATEGORY
HYDRAULIC SYSTEM
REQUIREMENTS TYPE 1 TYPEII TYPEIII TYPE RR
NOTE:
These are general hydraulic system requirements. See tool Specification page for tool specific requirements.

11
OPERATION
PREOPERATION PROCEDURES
CHECK POWER SOURCE
1. Using a calibrated flow meter and pressure gauge, check
that the hydraulic power source develops a flow of 4-12
gpm/15-45 lpm at 1000-2000 psi/70-140 bar.
2. Make certain that the hydraulic power source is equipped
with a relief valve set to open at 2100 psi/145 bar minimum.
CONNECT HOSES
1. Wipe all hose couplers with a clean lint-free cloth before
making connections.
2. Connet hoses from the hydraulic power suupply to the
tool quick disconnects. It is good practice to connect the
return hose first and disconnect it last to minimize or avoid
trapped pressure within the drill.
3. Observe the arrow on hose couplers to ensure that the
flow is in the proper direction. The male coupler on the
circtuit hose end is the supply (pressure) coupler.
4. Make sure the circuit PRESSURE (male quick disconect)
hose is conneced to the port at the back of the drill handle.
The circuit RETURN hose (female quick disconnect) is con-
nected to the port closest to the trigger.
5. Move the hyraulic circuit control valve to the ON position
to direct hydraulic flow to the drill.
Note:
If uncoupled hoses are left in the sun, pressure in-
crease inside the hose may result in making them dif-
ficult to connect. Whenever possible, connect the free
ends of the hoses together.
OPEN-CENTER (OC) OR CLOSED-CENTER
(CC) OPERATION
The DL07 can be configured to run on OC or CC circuits.
1. Determine the system type.
2. Remove the hex plug (81) from the spring cap.
FOR OPEN-CENTER OPERATION:
Using a 3/16 in. hex, reach through the hole in the spring
cap and turn the selector screw counter-clockwise until
meeting resistance (from the retaining ring). Turn the selec-
tor clockwise and then counter-clockwise to be sure the
selector is being stopped by the retaining ring. Do not force
the selector screw. Open-center operation is now selected.
FOR CLOSED-CENTER OPERATION:
Using a 3/16 in. hex, reach through the hole in the spring
cap and turn the selector screw fully clockwise. When the
selector screw bottoms. Closed-center operation is now
selected.
To prevent damage to the retaining ring, do not attempt
to force the selector screw counter-clockwise beyond
the point of initial resistance.
Reinstall the hex plug. Failure to install the plug may intro-
duce contaminants to the spool bore resulting in replace-
ment of the valve spool and main housing.
DRILL OPERATION
1. Observe all safety precautions.
2. Place the selected drill bit fully into the chuck. Center the
bit and tighten the chuck using the key provided. Remove
the key and store away from the drill.
3. Momentarily press the trigger to ensure that the drill bit
rotates clockwise and runs true.
4. Select a work position that gives secure footing and bal-
ance while operating the drill.
5. Press the drill against the work and squeeze the trigger.
The drilling method used is determined by the material be-
ing drilled and the size and depth requirements of the hole.
Brittle material such as rock, brick or concrete can be
drilled efficiently when the bit is caused to strike (hammer)
the hole bottom to break up the material. Without hammer-
ing, the rotating bit will only grind down and become dull.
The Stanley HD08 should be used for this application.
CAUTION

12
Ductile material such as metal or wood is drilled efficiently
when a steady down force is applied to the drill center to
cause the bit to slice chips of material from the hole bottom.
When drilling in metal, use a cutting lubricant to prolong bit
life and reduce the amount of force required to drill effec-
tively.
Large drill holes are more productively created from small
drill holes. Drill bits are incrementally selected to enlarge
the hole until the desired hole size is obtained. Each bit
selected must always be too large to thread and jam into
an existing hole; otherwise the bit may break and endanger
the operator.
COLD WEATHER OPERATION
If the wrench is to be used during cold weather, preheat the
hydraulic fluid at low engine speed. When using the nor-
mally recommended fluids, fluid temperature should be at
or above 50
o F/10oC (400 ssu/82 centistokes) before use.
Damage to the hydraulic system or wrench can result from
use with fluid that is too viscous or too thick.
OPERATION

13
• Make sure all couplers are wiped clean before connection.
• The hydraulic circuit control valve must be in the “OFF” position when coupling or uncoupling
hydraulic tools. Failure to do so may result in damage to the quick couplers and cause overheating
of the hydraulic system.
• Always store the tool in a clean dry space, safe from damage or pilferage.
• Make sure the circuit PRESSURE hose (with male quick disconnect) is connected to the “IN” port.
The circuit RETURN hose (with female quick disconnect) is connected to the opposite port. Do not
reverse circuit flow. This can cause damage to internal seals.
• Always replace hoses, couplings and other parts with replacement parts recommended by Stanley
Hydraulic Tools. Supply hoses must have a minimum working pressure rating of 2500 psi/172 bar.
• Do not exceed the rated flow (see Specifications) in this manual for correct flow rate and
model number. Rapid failure of the internal seals may result.
• Always keep critical tool markings, such as warning stickers and tags legible.
• Tool repair should be performed by experienced personnel only.
• Make certain that the recommended relief valves are installed in the pressure side of the system.
• Do not use the tool for applications for which it was not intended.
In addition to the Safety
Precautions in this manual,
observe the following for
equipment protection and
care.
NOTICE
EQUIPMENT PROTECTION & CARE

14
TROUBLESHOOTING
If symptoms of poor performance develop, the following chart can be used as a guide to correct the problem. When diag-
nosing faults in operation of the wrench, always check that the hydraulic power source is supplying the correct hydraulic
flow and pressure to the tool as listed in the following table. Use a flow meter known to be accurate. Check the flow with
the hydraulic fluid temperature at least 80oF/27oC.
PROBLEM CAUSE SOLUTION
Tool will not start.
Power not being supplied. Check to make certain that both hoses
are connected.
Turn hydraulic circuit control valve ON.
Defective quick disconnects. Check each quick disconnect.
Low drilling torque.
Relief valve set too low. Set relief valve at 2100 psi/145 bar.
Fluid restriction in hose or valve.
Excess flow and pressure loss.
Locate and remove restriction.
Use correct fluid.
Fluid not warmed up. Prehead system.
Hoses too long for hose ID. Use
shorter hose.
Hose ID too small for hose length. Use
larger ID hose.
Low tool speed. Fluid flow rate is too low. Check circuit flow rate.
High tool speed. Fluid flow rate is excessive. Check circuit flow rate. Add proper flow control valve or reduce the pump
RPM.
Oil leaks around gear housing. Hydraulic pressure and return hoses
reversed. Correct hose connections. Pressure should be to the handle port away
from the trigger, return is near the
trigger, then replace the main shaft oil
seal.
Oil gets hot, power unit working hard.
Open-center tool on a closed-center
circuit or vice-versa. Use tools to match circuit.
Circuit relief set too low. Adjust relief valve to 2100 psi/145 bar.
Too much oil going through tool. Adjust flow for 12 gpm/45 lpm maxi-
mum or less.
Oil leaks at reversing spool. Damaged O-Rings. Replace as required.
Wrong hydraulic fluid. Circuit too hot. Refer to Operation Instructions for cor-
rect fluid/circuit specifications.
Oil leak at motor cap face. Fasteners loose. Refer to Service Instructions Face O-Ring worn or missing. Replace as required.
Motor cap/main housing damaged. Replace as required.

15
SPECIFICATIONS
Drive Size..........................................................................................................................1/2 inch / 1.3 cm 3-Jaw Adjustable
5/8 -16 THD Chuck
Drill Torque ...................................................................................................................20 ft lbs / 27 Nm at 2000 psi / 140 bar
Drill Speed....................................................................................................................................1000 rpm at 8 gpm / 30 lpm
RPM Range.............................................................................................................................................................. 350-1500
Weight .................................................................................................................................................................8 lbs / 3.6 kg
Overall Length................................................................................................................................................9 inch / 22.9 cm
Width ................................................................................................................................................................3.5 inch / 9 cm
Motor ............................................................................................................................................................................Integral
Pressure Range............................................................................................................................1000-2000 psi / 70-140 bar
Flow Range .................................................................................................................................................4-12 gpm / 30 lpm
Optimum Flow .............................................................................................................................................8 gpm / 15-34 lpm
System Type...............................................................................................Open and Closed Center, HTMAType I, II and III
Porting..............................................................................................................................................................-8 SAE O-Ring
Output Torque............................................................................................................................................ 500 ft lbs / 675 Nm
Connect Size and Type .................................................................................................................3/8 inch NPT MaleAdapter
Sound Power Level .................................................................................................................................................87.69 dBA
Vibration Level................................................................................................................................................................9 m/s2
TORQUE HYDRAULIC FLOW DRILL SPEED
4 ft lbs @ 500 psi / .5 Nm @ 35 bar 3 gpm / 11.3 lpm 350 rpm
9 ft lbs @ 1000 psi / 1.2 Nm @ 70 bar 4 gpm / 15 lpm 475 rpm
14 ft lbs @ 1500 psi / 1.9 Nm @ 105 bar 6 gpm / 23 lpm 750 rpm
19 ft lbs @ 2000 psi / 2.6 Nm @ 140 bar 8 gpm / 30 lpm
10 gpm / 38 lpm 1000 rpm 1250 rpm
TORQUE AND DRILL SPEEDS

16
ACCESSORIES
DESCRIPTION PART NUMBER
WOOD AUGER BITS, 5/8 INCH HEX
9/16 inch dia x 18 inch Carbide Tipped Auger Bit (22 inch OAL) .................................................................................27845
13/16 inch dia x 18 inch Carbide Tipped Auger Bit (22 inch OAL) ...............................................................................27847
WOOD AUGER BITS, 7/16 INCH HEX
9/16 inch dia x 8 inch Carbide Tipped Auger Bit (12 inch OAL) ...................................................................................27850
11/16 inch dia x 8 inch Carbide Tipped Auger Bit (12 inch OAL)..................................................................................27851
13/16 inch dia x 8 inch Carbide Tipped Auger Bit (12 inch OAL) .................................................................................27852
15/16 inch dia x 8 inch Carbide Tipped Auger Bit (12 inch OAL) .................................................................................27853
1-1/16 inch dia x 8 inch Carbide Tipped Auger Bit (12 inch OAL)................................................................................27854
9/16 inch dia x 12 inch Carbide Tipped Auger Bit (16 inch OAL) .................................................................................27855
11/16 inch dia x 12 inch Carbide Tipped Auger Bit (16 inch OAL)................................................................................27856
13/16 inch dia x 12 inch Carbide Tipped Auger Bit (16 inch OAL) ...............................................................................27857
15/16 inch dia x 12 inch Carbide Tipped Auger Bit (16 inch OAL) ...............................................................................17858
1-1/16 inch dia x 12 inch Carbide Tipped Auger Bit (16 inch OAL)..............................................................................27859
9/16 inch dia x 18 inch Carbide Tipped Auger Bit (22 inch OAL) .................................................................................27860
11/16 inch dia x 18 inch Carbide Tipped Auger Bit (22 inch OAL)................................................................................27861
13/16 inch dia x 18 inch Carbide Tipped Auger Bit (22 inch OAL) ...............................................................................27862
15/16 inch dia x 18 inch Carbide Tipped Auger Bit (22 inch OAL) ...............................................................................27863
1-1/16 inch dia x 18 inch Carbide Tipped Auger Bit (22 inch OAL)..............................................................................27864
13/16 inch dia x 36 inch Carbide Tipped Auger Bit (48 inch OAL) ...............................................................................27869
11/16 inch dia x 15 inch Carbide Tipped Auger Bit (18 inch OAL)................................................................................32399
13/16 inch dia x 15 inch Carbide Tipped Auger Bit (18 inch OAL) ...............................................................................32400

17
SERVICE
PRIOR TO DISASSEMBLY
Note:
For orientation of parts in the following procedures,
refer to the parts drawing later in this manual
1. Clean the exterior of the tool and place on a clean work
surface.
2. Obtain the seal kit listed on the PARTS LIST so all seals
exposed during disassembly can be replaced.
PRIOR TO REASSEMBLY
1. Clean all parts with a degreasing solution.
2. Blow dry all parts or use lint-free cloths.
3. Ensure that all seals exposed during disassembly are
replaced with new parts.
4. Apply clean grease or o-ring lubricant to all parts during
assembly.
TOOL DISASSEMBLY
GEAR HOUSING
1. Remove the chuck (33) from the output shaft (36) by
holding the seal nut (35) with an open end wrench and turn-
ing the chuck counter-clockwise.
2. Remove the capscrews (31) and lockwashers (32) se-
curing the gear housing (69) to the main housing assembly
(76). If the tool has a trigger guard (80), remove capscrew
(34), nut (20) and trigger guard before removing the gear
housing.
3. Remove the ring gear (27), roll pin (5) and gasket (71).
4. Remove the retaining ring (29) near the planet shafts
(23) before removing the planet shafts. Remove the seal
nut (35) by using the planet shaft holes to keep the output
shaft from turning. Pull the output shaft with attached parts
from the gear housing.
5. Remove the planet gears (26) from the output shaft.
Inspect shafts, gears and gear bore bushings (see CLEAN-
ING AND INSPECTION procedure).
6. Spin the ball bearing (28) on the output shaft. The bear-
ing should turn smoothly. To replace the bearing, support
the outer race and press down on the output shaft from the
chuck end. Do not reuse the ball bearing once it has been
removed from the output shaft.
7. Remove the output shaft seal (30) by pressing it from
the gear housing bore.
8. Check the end faces of the seal nut and output shaft for
nicks and war (see CLEANING AND INSPECTION proce-
dure).
MOTOR CAP
9. Remove the six capscrews (41) and lockwashers (3)
securing the motor cap assembly (46) to the main housing
assembly and lift off the motor cap assembly. Do not in any
way excessively force the motor cap off the main housing
assembly.
10. Remove the o-ring (9) from the motor cap.
MAIN SHAFT AND IDLER SHAFT
11. Tap on the small gear end of the main shaft (5) and
push the shaft from the main body.
12. Remove the idler gear (45) and idler shaft (47).
13. Remove the retaining ring (16) and then pick out the
seal washer (44), back-up ring (39) and o-ring (4) from the
main housing.
VALVE SPOOL
14. Unscrew the spring cap (66), pick out the spring (79)
and push the valve spool (59) out the spring cap end of the
main housing.
TRIGGER
15. Remove the trigger by first removing the capscrews (8)
and lockwashers (32) and removing the trigger and trigger
mount (78) as an assembly. Drive out the roll pin (21).
REVERSING SPOOL
16. Remove the retaining rings (67) and end caps (65).
17. Unscrew the seal caps (64) and slide the reversing
spool (68) out of the main housing. Make sure the idler
shaft has been removed prior to completing this step.

18
SERVICE
CLEANING AND INSPECTION
CLEANING
Clean all parts with a de-greasing solution. Blow dry with
compressed air or use lint-free cloths.
GEAR CHAMBER (MOTOR CAP)
The chamber bores and bottoms around the shaft bushings
should be polished and not rough or grooved. If the bushing
bores are yellow-bronze, replace them and investigate the
cause of wear.
The flat surfaces around the chamber and bolt holes should
be flat and free of nicks or burrs that could cause misalign-
ment or leaks.
BUSHINGS
The inside of the bushings should be gray with some
bronze showing through. If significant yellow-bronze shows,
replace the bushings. Inspect the motor shaft and idler
shaft for corresponding wear and replace as required.
GEARS
The drive and idler gears should have straight tips without
nicks, square tooth ends and have a smooth even polish
on the teeth and end faces. Replace the gear if cracks are
present.
MAIN HOUSING ASSEMBLY
The surface near the gears should show two interconnect-
ing polished circles without a step.
SHAFTS
The shaft diameter at the bearing and seal locations must
be smooth. Grooves, roughness or a reduced diameter
indicate fluid contamination or damaged bushings. Grit
particles may have been imbedded in the bushings, grind-
ing into the hardened shaft. If abnormal shaft wear as noted
above occurs (more than normal polishing), replace both
the shaft and associated bushings.
Also check the hydraulic system for excess contamination
in the fluid and for filter condition. Operating conditions may
require changing from a 25-micron filter to an oversized
10-micron filter.
TOOL REASSEMBLY
1. Lubricate and install a new o-ring (4) and back-up ring
(39) into the main housing. Install the seal back-up washer
(44) and retaining ring (16).
2. Slide the reversing spool (68) into the main housing as-
sembly. Insert the spool with the slot toward the idler shaft
hole and the narrow side of the depression in the spool
facing up toward the top of the main housing.
3. Insert the idler shaft (47) to prevent the reversing spool
from turning.
4. Lubricate and install a new wiper seal (63), o-ring (10),
back-up ring (17) and o-ring (2) into each seal cap (64).
Install each seal cap onto the main housing assembly.
5. Install each end cap (65) and secure with snap ring (67).
6. Lubricate seal area of main shaft (50) and install it into
the main housing. Install the idler gear (45) onto the idler
shaft.
7. Lubricate and install a new o-ring (9) onto the motor cap
(46). Lubricate capscrew threads (41) with an anti-seize
compound and install the motor cap with the capscrews
and lockwashers (3). Tighten bolts to 15-17 ft lbs / 20-23
Nm in a cross pattern.
Do not force parts together.
8. Lubricate and install a new o-ring (19) in the main hous-
ing and a new seal wiper (61) in the trigger mount (78).
Secure the trigger (77) to trigger mount with roll pin (21).
Install trigger assembly to main housing with capscrews (8)
and lockwashers (32).
9. Lubricate and install a new o-ring (18) on the valve
spool (59) before installing valve spool into the main hous-
ing from the spring cap end. Do not install the vavle spool
from the trigger side of the main housing as this will result
in spool seal damage. Ensure that the tab on the valve
spool nose is aligned with the slot in the trigger. Install
spring (79) behind valve spool. Using Loctite™ 242, install
the spring cap (66) to the main housing.
CAUTION

19
SERVICE
10. Lubricate and install the shaft seal (30) into the gear
housing. Install shaft keeper (24) and bearing keeper (25)
beofre installing bearing (28) on output shaft (36). Install
planet gears (26) into output shaft and install the output
shaft with aqttached parts into the gear housing (69). Install
the ring gear (27) into the gear housing and secure with the
roll pin (5). Install the seal gasket (71) around the ring gear.
11. Lubricate and install the o-ring (4) on the output shaft.
Install the seal nut (35), using the planet shaft bores to
prevent the output shaft from turning. Install the planet
shafts (23) and secure them with retaining ring (29). Install
the gear chamber and attached parts to the main housing
using capscrews (31) and lockswashers (32). If the tool has
a trigger guard (80), install guard with capscrew (34) and
nut (20) at this time.
12. Lubricate the output shaft threads and install the chuck
(33). While holding the seal nut secure with an open end
wrench, torque the chuck to 50 ft lbs / 69 Nm.

20
DL07 PARTS ILLUSTRATION
