Starling Technologies S-RMST-1 User manual

www.starling-tech.com
Instruction Manual
Warning : Protect Board from electrostatic discharge. Ground yourself before
handling.
Thank you for purchasing the Titanic Horn sound board from Starling
Technologies™. Board features Steam Horn sound for this Historic Ship.
The use of the board is uite obvious, but here are some basic instructions
below.
Note: Kit shown with optional
Remote control.
The sound board arrives as seen at left.
A hole can be drilled through a custom
plastic housing, and the on/off switch can
be glued from behind protruding through
the hole.
You may use board and speaker as is,
or remove them from the sticky pad. Be
careful with the wires as they are very
thin and fragile.
Push-button activates horn.
1

Some ideas for mounting.
Because the board is battery powered, you will need to install it where you will
have access to the batteries.
1) You may create a custom box from polystyrene sheet to house the unit and
allow the speaker to mount to. Drill small holes where the speaker will mount to
let the sound out.
2) If you left a portion of your model loose, so as to have access to it one day,
you may install it inside the model.
Spea er:
Because of the deep bass of the horn, the speaker may not be as loud as you
would like it. You will need to use a cup to encase the speaker directing the
sound forward. Some builders use empty yogart cups or Dixi cups. I also use
polystyrene(Plastruct) sheet to make custom size cups.
Optional Remote control:
If you purchased the remote, you may use the push-button or remote to
activate the horn.
To change batteries of the key fob, carefully use a thin blade to separate the
case. Ease the blade in as shown and pry the case apart.
2

Specificatons
Board supported voltage: 4.5 volts supplied by 3 x AAA batteries.
Key Fob batteries : 2x CR2016 3v
Troubleshooting: If board stops playing or doesn't play after changing the
batteries, remove batteries, and bend inward the small tabs, that sit on top of
the batteries, that hold the batteries in place. This will place more tension on the
batteries for better contact.
All photos contained in this document are property of Starling technologies. This document may not be
copied, sold or transfered without permission.
E/FX™ is a trade mark of Starling Technologies™
Copyright © 2020 Starling Technologies™ www.starling-tech.com
